Tosibox Lock 150 User manual

Matching the Lock with the Key
Deploying into Broadband Networks
1. Connect an Internet-connected ethernet cable to
the Lock’s WAN port.
2. Plug the devices into the Lock’s LAN ports (LAN
1-3 or connect wirelessly via WLAN). If the devices
have static IP addresses, please see Deploying the
Lock in the TOSIBOX®user manual.
1
2a
TOSIBOX®Lock
TOSIBOX®Key
AC Adapter
1. Connect the AC adapter to the Lock and wait
for 2 minutes.
2. Insert the Key into the USB port of the Lock. When
the LED on the Key stops blinking, (after approx.
10 seconds) the matching is complete and you can
remove the Key from the USB port.
3. Go to if deploying into broadband networks
(ethernet) or if deploying into mobile
networks.
Internet /xDSL router
WAN
2a
2b
VPN tunnel through Internet
PC
TOSIBOX®
Mobile
Client
TOSIBOX®
Key
W
A
N
L
A
N
Firewall
TOSIBOX®
Lock
HMI
PLC
Camera
PC
Lock 150
Quick Start Guide
Copyright © Tosibox Oy, 2020
TOSIBOX®SoftKey

Deploying into Mobile Networks
2b
Using the Key
3
1. Connect a computer to the Lock’s service port with an
ethernet cable
2. Type http://172.17.17.17 into your browser’s address
field to access the Lock’s user interface. Log in using
“admin” account. The password can be found on the
bottom of the Lock. Select Network > USB modem and
either use the Automatic APN setting or fill in the APN
according to your mobile operator settings. Enter PIN
code if necessary. Click Save.
3. Plug a supported USB modem into the USB port of the
Lock.
4. Plug network devices into the Lock’s LAN ports
(LAN 1-3) or connect wirelessly via WLAN. See
Deploying the Lock in the user manual for static IP
configurations.
5. Verify on the status page of the Lock user interface
that Internet connection is OK.
For more information and latest supported modem models, visit www.tosibox.com/support
Insert a TOSIBOX®Key into the USB port of your computer to install the Key software.
The TOSIBOX®Key user interface illustrated above shows all Lock devices serialized to
the Key and the network devices connected to them.
For more options click or icon.
The Lock is connected to the Internet and the Key is connected to the Lock.
The Lock is not connected to the Internet.
The Lock is connected to the Internet, but the Key isn’t connected to the Lock.
TOSIBOX®Lock 150 Quick Start Guide v 1.4 www.tosibox.com [email protected]
DECLARATION OF CONFORMITY
Hereby, Tosibox Oy declares that the radio equipment type Lock 150 is in compliance with Directive 2014/53/EU. The full text of the
EU declaration of conformity is available at www.tosibox.com/documentation-and-downloads
FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT
This device complies with FCC part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user´s authority to operate this equipment. This equipment should be installed and operated with a minimum
distance of 20 cm between the antenna and the user or bystanders. FCC ID: 2AHCN-LOCK150 IC: 25009-LOCK150
This device is UL listed in USA and Canada with UL file number E507259.
INDUSTRY CANADA STATEMENT
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device. This radio transmitter IC: 25009-LOCK150 has been approved by ISED to operate with
the antenna types listed below with the maximum permissible gain indicated. Antenna types not included in this list, having a gain
greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. Lock 150: Wi-Fi monopole
antenna max peak gain 2.0 dBi. Under ISED regulations, this radio transmitter may only operate using an antenna of a type and
maximum (or lesser) gain approved for the transmitter by ISED. To reduce potential radio interference to other users, the antenna
type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary
for successful communication! This equipment should be installed and operated with a minimum distance of 20 cm between the
antenna and the user or bystanders.
Patented, incl. US8831020, US9900178.
Patents pending, incl. US14/119753,
US14/39015
Visit Support
www.tosibox.com/support/
Download user manual
www.tosibox.com/documentation-and-downloads
