Ubiquiti EdgeRouter ER-8 User manual

8-Port Router
Model: ER-8
https://arttel.ru/
https://arttel.ru/shop/marshrutizatory/ubiquiti-edgerouter

Introduction
Thank you for purchasing the Ubiquiti Networks® 8-Port
EdgeRouter™. This Quick Start Guide is designed to guide you
through installation and also includes warranty terms.
Package Contents
EdgeRouter ER-8
Mounting Screws
(#10-32 x 5/8", Qty. 4)
Cage Nuts
(#10-32 x 5/8", Qty. 4)
8-PortRouter
Model:ER-8
Power Cord Quick Start Guide
TERMS OF USE: All Ethernet cabling runs must use CAT5 (or above). It is the customer’s
responsibility to follow local country regulations, including operation within legal frequency
channels, output power, indoor cabling requirements, and Dynamic Frequency Selection
(DFS) requirements.
https://arttel.ru/
https://arttel.ru/shop/marshrutizatory/ubiquiti-edgerouter

Installation Requirements
• Phillips screwdriver (for rack- or wall-mounting)
• Standard-sized, 19" wide rack with a minimum of 1U height
available (for rack-mounting)
• For indoor applications, use Category 5 (or above) UTP
cabling approved for indoor use.
• For outdoor applications, shielded Category 5 (or above)
cabling should be used for all wired Ethernet connections
and should be grounded through the AC ground of the
power supply.
We recommend that you protect your networks from
harmful outdoor environments and destructive ESD events
with industrial-grade, shielded Ethernet cable from Ubiquiti
Networks. For more details, visit:
www.ubnt.com/toughcable
WARNING: To reduce the risk of fire or electric shock, do
not expose the EdgeRouter to rain or moisture.
Note: Although the cabling can be located outdoors,
the EdgeRouter itself should be housed inside a
protective enclosure.
https://arttel.ru/
https://arttel.ru/shop/marshrutizatory/ubiquiti-edgerouter

Hardware Overview
Front Panel Ports
Console RJ45 (eth0-eth7)
USB
Interface Description
Console
RJ45 serial console port for Command
Line Interface (CLI) management. Use an
RJ45-to-DB9, serial console cable, also
known as a rollover cable, to connect the
Console port to your computer. (If your
computer does not have a DB9 port, then
you will also need a DB9 adapter.) Then
configure the following settings as needed:
• Baud rate 115200
• Data bits 8
• Parity NONE
• Stop bits 1
• Flow control NONE
USB Reserved for future use.
RJ45
(eth0-eth7)
RJ45 ports support 10/100/1000 Ethernet
connections.
https://arttel.ru/
https://arttel.ru/shop/marshrutizatory/ubiquiti-edgerouter

Front Panel Button
Reset
Button Description
Reset
There are two methods to reset the
EdgeRouter to factory defaults:
• Runtime reset (recommended) The
EdgeRouter should be running after
bootup is complete. Press and hold
the Reset button for about 10seconds
until the right LED on RJ45 port eth7
starts flashing and then becomes
solidly lit. After a few seconds, the LED
will turn off, and the EdgeRouter will
automaticallyreboot.
• Power-on reset Disconnect the Power
Cord from the EdgeRouter. Press and
hold the Reset button while connecting
the Power Cord to the EdgeRouter. Keep
holding the button until the right LED on
RJ45 port eth7 starts flashing and then
stops flashing after a few seconds.
https://arttel.ru/
https://arttel.ru/shop/marshrutizatory/ubiquiti-edgerouter

Front Panel LEDs
The LEDs on the left side of the RJ45 ports are not used at this
time. Below is a description of the other LEDs:
PowerSpeed/Link/Act
LED State Status
RJ45 (eth0-7)
Speed/
Link/Act
Off No Link
Amber Link Established at
10/100Mbps
Amber Flashing Link Activity at
10/100Mbps
Green Link Established at
1000Mbps
Green Flashing Link Activity at
1000Mbps
Power
White 8-Port EdgeRouter is
poweredon.
Back Panel
Mounting Holes
Power
Ventilation Holes
Mounting Holes
Fans
Note: There are additional ventilation holes on the sides
of the EdgeRouter.
https://arttel.ru/
https://arttel.ru/shop/marshrutizatory/ubiquiti-edgerouter

Hardware Installation
WARNING: FAILURE TO PROVIDE PROPER VENTILATION
MAY CAUSE FIRE HAZARD. KEEP AT LEAST 20 MM OF
CLEARANCE NEXT TO THE VENTILATION HOLES FOR
ADEQUATE AIRFLOW.
1. Attach the EdgeRouter to the rack using the four Mounting
Screws. (If the rack has square slots, then use the Cage Nuts
with the Mounting Screws.)
2. Connect the Power Cord to the Power port.
https://arttel.ru/
https://arttel.ru/shop/marshrutizatory/ubiquiti-edgerouter

3. Connect the other end of the Power Cord to a power outlet.
Accessing the Configuration Interface
1. Connect an Ethernet cable from the Ethernet port of
your computer to the port labeled eth0 on the 8-Port
EdgeRouter.
2. Configure the Ethernet adapter on your host system with a
static IP address on the 192.168.1.x subnet.
3. Launch your web browser. Type https://192.168.1.1 in the
address field. Press enter (PC) or return (Mac).
https://arttel.ru/
https://arttel.ru/shop/marshrutizatory/ubiquiti-edgerouter

4. The login screen will appear. Enter ubnt in the Username
and Password fields. Read the Ubiquiti License Agreement,
and check the box next to I agree to the terms of this License
Agreement to accept it. Click Login.
The EdgeOS™Configuration Interface will appear, allowing
you to customize your settings as needed. You can click the
Wizards tab to access the Setup Wizard.
For more information, refer to the EdgeOS User Guide, which is
available at documentation.ubnt.com/edgemax
https://arttel.ru/
https://arttel.ru/shop/marshrutizatory/ubiquiti-edgerouter

Specifications
8-Port EdgeRouter
Dimensions 484 x 164 x 44 mm (19.06 x 6.46 x 1.73")
Weight 2.3 kg (5.07 lb)
Max. Power Consumption 35 W
Power Method 110 - 240VAC
Power Supply Internal AC/DC Power Adapter,
60 W (24V, 2.5A)
Button Reset
LED Power
Processor Dual-Core 800 MHz, MIPS64
with Hardware Acceleration
for Packet Processing
System Memory 2 GB DDR3 RAM
Code Storage 4 GB
LEDs
Serial Console Port
Data Ports
N/A
Speed/Link/Activity
Networking Interfaces
Serial Console Port
Data Ports
(1) RJ45 Serial Port
(8) 10/100/1000 RJ45 Ethernet Ports
Certications CE, FCC, IC
Rack-Mount Yes
ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature -10 to 45° C (14 to 113° F)
Operating Humidity 10 - 90% Noncondensing
*640-00095-05*
640-00095-05
