Toslon TFL40 User manual

Key function
MENU Open Menu settings( Basic, Sonar Setting and GPS Setting).
PUSH-GO Used to quickly enter into waypoint or go home by one-button pusing.
KEYPAD Selects items on menus; increase & decrease a value of option.
POWER Turns unit on/o. Also be use to quit a menu setting.
PAGE
ENTER
ZOUT /ZIN Used to zoom out GPS route on the screen.
Used to switch between main menus or some sub menus.
Finalizes menu selections; conrm a setting.
ENTER key is also used to quickly enter into GPS Operation menu.
1
MENU
ZOUT/ZIN KEYPAD
PAGE
POWER PUSH-GO ENTER

What’s on the display
2
Depth
readout
Water temp
Voltage of
bait boat
SD Card in
Strength of
Radio signal
Distance
to Home
Time
Speed
of boat
Voltage of
display
Depth range
at bottom
Fish symbol
Structure
Indicator of
Boat heading
direction
Number of satellite
Distance to Target
Autopilot mode
Remote mode
Surface
clutter
Route of boat
Note: on the route, dierent color means
the depth changing of the water while the
boat is running.

Quickly Operation
3
Quickly enter into 【Waypoint】Quickly enter into 【GPS operation】
Note: pushing the key for
3s will start autopilot:
back to home.

How to set the Overlap Data?
1) Press Key to enter into 【QUICK OPERATION】, then choose【Overlap Data】
2) Use keypad to choose an option which you hope to change, then press key to enter into the option menu.
3) Choose an option and press Key to conrm.
Overlap Data
4
On the bottom half area of the display, you can use Overlap Data to determin which option will be displayed:
Time of day, Heading, Speed, tc.

Start Using
5
Note: Aer the device is powered on, it will set
the current locaon as default HOME Posion.
Set HOME posion
1) Press key to enter into 【QUICK OPERATION】
2) Use keypad to choose 【Set Home Pos.】
Press to conrm.
Save a waypoint
When the boat arrive at a positon on water, you
can choose to save it as a waypoint：
1) Press key to enter into 【QUICK OPERATION】
2) Use keypad to choose 【Quick Marker】then
Press to enter into the waypoint detail info.
3) Set the options and choose 【OK】.
Now, the waypoint was successfully created and
saved in waypoint list.

Go to target waypoint
1) Press key to enter into 【QUICK OPERATION】
2) Use keypad to choose 【Waypoint】then press to enter into waypoint list.
3) Choose one target waypoint then press to select 【Go to target】
6

7
Import KML
You can import KML file( from Google map) to TF740. And run the boat with autopilot to
a posion on the map simply by moving the cursor.
1) Press key to enter
into【QUICK OPERATION】
then use keypad to choose
【Import kml】
2) Import a kml file from
the micro SD card.
3) Move the cursor to a
locaon on the map.

4) Press key to confirm
the locaon. Then choose
to save or go.
5) When you choose 【Go】
the autopilot will start.
Note: when you choose a
locaon, please guarantee
there is no land obstacle
betweem it and the boat.
land
obstacle
8

9
Go back
Go-Back can guide the boat running to the first target, and aer delaying some me, then
automacally run to the second target.
1) Press key to enter
into【QUICK OPERATION】
then use keypad to choose
【GO-Back】
2) Select the Target 1 and Target 2
from Waypoint list and Home
Posion, and set delay me.
3) The boat arrived the first
target. And aer delaying
the set me, then run to
the second target automat-
ically.

10
Xboat mode ESC of Right Motor ESC of Left Motor
2 Engines ESC of Right Motor ESC of Left Motor
1 Engine ESC Servo
channel-3 channel-1
channel of right Motor channel of left Motor
channel of ESC channel of servo
Port A
Transmitter connection & function
Port B
Port B is connected to
Reciver of the remote
Port A is connected to Speed
Contorller(ESC) or Servo
Socket to
Sonar Box-740w
The following figures instruct how to connect the Autopilot CCU740 with your bait boat.
The system could control most 2 engineers or 1 engine (with rudder) boat with proper settings.
Connection of AutopIlot CCU740

Connection of Parts
