Toucan TVD200WU User manual

AA AA
Regulations & Compliance
Fcc Statement
Warning: Changes or modications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipemnt has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installaction. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including intereference that may cause undesired operation.
ISED Regulatory Compliance
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic
Development Canada’s lincence-exempt RSS(s). Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired operation of the
device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation,
Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes :
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
RF Exposure Compliance
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
Cet équipement est conforme aux limites d’exposition aux radiations FCC/IC établies pour un environnement non
contrôlé. Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et votre
corps.
VuPoint Solutions, Inc. (USA):
710 Nogales Street, City of Industry, CA 91748
VuPoint Company Limited (Europe):
Innovation Center, Longbridge Technology Park,
Longbridge, Birmingham B31 2TS
For additional info, visit our website at toucansmarthome.com
©2020 VUPOINT SOLUTIONS, INC. All Rights Reserved.
The Toucan logo and Toucan are trademarks or registered trademarks of VuPoint Solutions Inc. in the United States and other
countries. App Store is a registered trademark of Apple Inc. iOS is a registered trademark of Cisco Technology, Inc. in the
U.S. and other countries and is under license. Android and Google Play are registered trademarks of Google LLC. Product
names, logos, brands and other trademarks referred to herein are the property of their respective trademark holders. All
trademarks remain the property of their respective holders, and are used only to describe the products or services being
provided. These trademark holders are not aliated with VuPoint Solutions, Inc. They do not sponsor or endorse VuPoint
Solutions, Inc’s products or services.
Wireless
Video Doorbell
Use the video doorbell to see and talk to
whoever is at your door from anywhere.
Feel more secure when away from home.
TVD200WU
facebook.com/toucansmarthome Charging Cable
instagram.com/toucansmarthome
Items Included
AA Battery Adhesive Tape
Chime
TDC100WU
Doorbell
TVD200WU
Thank You Card
Warranty Card
Screwdriver Screws Wall Anchors Wall Bracket Quick Start Guide
Follow us for the latest updates:
2020 New WVD_QSG_TVD200WU.indd 12020 New WVD_QSG_TVD200WU.indd 1 7/30/20 9:39 AM7/30/20 9:39 AM

Chime LED
Description
5
6
1
2
3
4
7
8
10
9
Get to know your video doorbell and chime
www.toucansmarthome.com/
pages/smarthomeapp
Doorbell
1. Camera lens
2. Microphone
3. Light sensor
4. Doorbell
5. Motion sensor
6. Speaker
7. SET button
Get to know your video doorbell and chime
Open the back cover,
plug in micro usb cable to
charge the video doorbell.
Recommend to fully charge the
device before 1st use.
Solid Red
Solid Blue
Charging Battery
Battery Fully Charged
Download Toucan app
Scan QR code or visit
Open the app to
add camera.
The chime included in the package is already paired with your doorbell
Available at Apple© App Store© and Google Play™
Flashing BLUE
Flashing PURPLE
Flashing RED
Setup Mode
Connecting to cloud server
Connection Failed
If using the adhesive to mount the doorbell, please adhere to the surface and wait
24-48 hours to enable maximum bond strength before adding the doorbell.
Apply 3M adhesive to dry surfaces only.
You can mount the doorbell using just the
adhesive on UPVC, wooden or smooth surface
door frames (not suitable for brick or stone)
Chime supports >50m of SUB-1G connection
distance with video doorbell
*
**
***
For detailed setup procedure,
please refer to Toucan website or
scan the QR code above
Chime LED
Description
LED
Description
Chime
8. LED indicator
9. SET button
10. Speaker
Charge your video doorbell
Press and hold the SET
button until LED light blinks
to enter the setup mode.
Follow the camera
voice navigation to
complete setup.
LED
Description
Pairing your chime with your video doorbell
Press and HOLD the Set button
until LED light blinks
Press and HOLD doorbell button
to pair with chime
Flashing BLUE
BLUE Flashes Once
Pairing Mode
Select Next Chime Sound
Install your video doorbell and chime
1. Drill holes for wall anchor placements
2. Insert wall anchors
3. Mount wall bracket with screws
4. Place the doorbell
on bracket
5. Tighten the lock
screw with cross
screw drive
6. Place the adhesive tape to the
back of the chime and stick
to the wall in a suitable location
inside your home*
Setup your video doorbell
2020 New WVD_QSG_TVD200WU.indd 22020 New WVD_QSG_TVD200WU.indd 2 7/30/20 9:39 AM7/30/20 9:39 AM
