IFM O1D100 series User manual

Mode/
Enter Set
PWR mm m inch OUT1 OUT2
Output LED’s
Setting of the parameters
Mode: Selecting the mode
Enter: Acknowledging the setting
4 digit numeric display
Programming Mode
Press until desired menu item is
displayed. (See distance
sensor menu items)
Press to display the current setting.
To change the setting, press and hold the set button
for 5 seconds until the flashing value is continuously
incremented. After this time, the value may be increased
continuously (by holding down the set button) or incre-
mented (by pressing and releasing the button repeatedly)
until the desired value is reached.
Press once to enter desired value.
The desired value is set. If no button is pressed for 15
seconds, the sensor returns to the operating mode.
Repeat these steps to set other values as required.
1
2
3
4
5
6
Display
O1D100 Series
Distance Sensor
Display Unit LED’s

Setpoint 1
Output 1
Hysteresis mode: normally open
Hysteresis mode: normally closed
Output 2
Hysteresis mode: normally open
Hysteresis mode: normally closed
4 - 20 mA analog output
Analog start point
Analog end point
Setpoint 2
Sampling rate
Repeatability
Program (Display units) first to avoid
programming errors.
Distance Sensor Menu Items
(continued)

Enhanced functions - Press Set, then Mode/ Enter
button to scroll through the Enhanced Function
options.
On delay for switching output
Off delay for switching output
Display options
Display updated every 50 mS
Display updated every 200 mS
Display updated every 600 mS
Same as above with
display rotated 180º
Display deactivated
Indication of signal strength in %
Select display units (m, mm, inch)
Millimeter
Meter
Inch
Return to factory default
Software revision

TEL: [phone] • FAX: [phone]
www.ifmefector.com
10/05
Lit. No. B41005
Measuring
range
[mm]
Repeatability* [mm] Accuracy* [mm]
white (90%
remission)
grey (18%
remission)
white (90%
remission)
grey (18%
remission)
200...1000 10 (±5) 15 (±7.5) ±15 ±18
1000...2000 11 (±5.5) 20 (±10) ±15 ±20
2000...4000 35 (±17.5) 45 (±22.5) ±25 ±32
4000...6000 55 (±27.5) 80 (±40) ±35 ±50
6000...10,000 120 (±60) –±70–
* The values specified for repeatability and accuracy refer to a sampling
frequency of 50 Hz. At a lower sampling frequency, which is adjustable
on the unit, these values will be lower. View the calculation tool at
www.ifmefector.com/ifmus/web/pmd_5.htm
Distance to target
(shown on sensor display)
[mm]
200...1000
1,000...2000
2,000...4000
4,000...6000
6,000...10,000
Minimum distance from
target to background
[mm]
38
50
113
200
300
For background suppression applications
The following chart shows the minimum distance required
between target and background
