Touch TCH-313012 Series User manual

170
HEAVY DUTY FREE STOP LID STAY
CABINET DOORS LID STAY
●Basic spec
●Arms material : Zinc alloy
●In󰀬allation : Wood screws
●Cabinet internal depth : Min. 150 mm
●Brackets material : Cold - rolled 󰀬eel
●Supplied with : Lid 󰀬ay, Wood screws,
Allen key and In󰀬ruction manual
●Edge di󰀬ance : 37 mm
●Cabinet internal height : Min. 255 mm
●Finishing : Nickel plated
●Opening angle : 75°, 90° or 110°
●Mounting : Could be in󰀬alled for
one side ( left or right )
TCH-313012 SERIES
● In󰀬allation
12
Fix always the brake leaving the adju󰀬ing
screw always inside the cabinet.
Adju󰀬 with allen key friction force according
to ap door according to ap door dimension
and weight using the adju󰀬ing screw.
Adju󰀬ing screw

171
● Specication
32
40
C
18
B
A
40
32
18
123
132
90°
●Uses
Brake in opening Brake in closing
Left Right
Maximun opening angle C
Size (A) Size (B)
75° 164mm 126mm
90° 132mm 119mm
105° 132mm 87mm
