Toyota 2005 PRIUS User manual

1
FEATURES ON NEW TOYOTA VEHICLE
Overview of instruments and controls
Instrument panel overvieww2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument cluster and multi−information display overview 5. . . . . . . .
Indicator symbols on the instrument panel and multi−information
display 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1– 1

2
Instrument panel overview
1. Side vents 187. . . . . . . . . . . . . . . . . . . . . . .
2. Side defroster outlets
3. Instrument cluster 5. . . . . . . . . . . . . . . . . .
4. Center vents 187. . . . . . . . . . . . . . . . . . . . .
5. Glove boxes 193. . . . . . . . . . . . . . . . . . . . .
6. Power door lock switches 39. . . . . . . . .
7. Power window switches 42. . . . . . . . . . .
8. Auxiliary boxes 197. . . . . . . . . . . . . . . . . . .
9. Cup holders 198. . . . . . . . . . . . . . . . . . . . .
10. Tilt steering lock release lever 96. . . . .
11. Hood lock release lever 44. . . . . . . . . . .
12. Parking brake pedal 142. . . . . . . . . . . . . .
13. Power rear view mirror
control switch 97. . . . . . . . . . . . . . . . . . . . .
14. Window lock switch 43. . . . . . . . . . . . . . .
11p003d

3
1. Headlight and turn signal
switches 102. . . . . . . . . . . . . . . . . . . . . . . . .
2. Wiper and washer switches 109. . . . . . .
3. “POWER” switch 131. . . . . . . . . . . . . . . . .
4. Clock 192. . . . . . . . . . . . . . . . . . . . . . . . . . . .
5. Multi−information display or
navigation system including
multi−information display
(For the navigation system,
see the separate “Navigation
System Owner’s Manual”.) 146. . . . . . . .
6. Emergency flasher switch 106. . . . . . . . .
7. Trip meter reset button 115. . . . . . . . . . .
8. Km/h or MPH button 116. . . . . . . . . . . . .
9. Audio system 156. . . . . . . . . . . . . . . . . . . .
10. Power outlet 192. . . . . . . . . . . . . . . . . . . . .
11. “P” position switch 136. . . . . . . . . . . . . . .
12. Electronic shift lever
(R, N, D, B) 136. . . . . . . . . . . . . . . . . . . . .
13. Key slot 130. . . . . . . . . . . . . . . . . . . . . . . . .
14. Cruise control switch 142. . . . . . . . . . . . .
15. Smart entry and start system
cancel switch 33. . . . . . . . . . . . . . . . . . . . .
16. Climate remote control
switches 186. . . . . . . . . . . . . . . . . . . . . . . . .
11p001h

4
17. Instrument panel light control
dial 107. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18. Audio remote control switches 173. . . .

5
1. Service reminder indicators
and indicator lights 117, 124. . . . . . . . . .
2. Fuel gauge 114. . . . . . . . . . . . . . . . . . . . . .
3. Speedometer
4. Odometer and trip meter 115. . . . . . . . .
Instrument cluster and multi−information display overview
11p002i

6
Indicator symbols on the instrument cluster and Multi−information display
or
and
Brake system warning lights∗1
Driver’s seat belt reminder light∗1
Front passenger’s seat belt reminder light∗1
Malfunction indicator lamp∗1
Low fuel level indicator light∗1
Open door warning light∗1
Master warning light∗1
Anti−lock brake system warning light∗1
SRS warning light∗1
Engine oil replacement reminder light∗1
(for vehicles sold in U.S.A.)
Vehicle stability control system warning light∗1
Discharge warning light∗2
High coolant temperature warning light∗2
Low engine oil pressure warning light∗2
Hybrid vehicle battery warning light∗2
Electric power steering system warning light∗2
or
(U.S.A)
(Canada)

7
Hybrid vehicle immobilizer / Theft deterrent sys-
tem indicator light
Tail light indicator light
Shift position indicator light∗4
Driving ready light
Automatic air conditioner indicator light
Recirculate mode indicator light
Smart entry and start system warning light∗5
Windshield air flow indicator light
Slip indicator light
Rear window and outside rear view mirror defog-
gers indicator light
Low temperature indicator light
Headlight high beam indicator light
Headlight indicator light
Turn signal indicator lights
∗1: For details, see “Service reminder indicators and warning
buzzers— —Instrument cluster” on page 117.
∗2: For details, see “Service reminder indicators and warning
buzzers— —Multi−information display” on page 124.
∗3: If this light flashes, see “Cruise control” on page 142.
∗4: For details, see “Hybrid transaxle” on page 136.
∗5: For details, see “Smart entry and start system” on page 24.
Cruise control indicator light∗3
Hybrid system warning light∗2
Automatic head light leveling system
warning light∗2

8

9
FEATURES ON NEW TOYOTA VEHICLE
Toyota hybrid system
Toyota hybrid systemm10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Toyota hybrid system operating condition 10. . . . . . . . . . . . . . . . . . . . . .
Starting your vehicle 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For efficient use of your vehicle 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Precautions for use 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1– 2

10
Toyota hybrid system combines a gaso-
line engine and electric motor power to
improve the fuel economy and minimize
the emissions as well as to provide
better power performance than the ordi-
nary gasoline−powered vehicles.
Depending on the driving condition, the
vehicle runs on the best combination of;
DGasoline engine power
DElectric motor power generated by
the gasoline engine
DElectric motor power of the hybrid
vehicle battery
Furthermore, the energy is efficiently used
in the following ways:
DWhen stopping the vehicle, the gaso-
line engine is automatically stopped.
DWhen applying the brakes or decelerat-
ing, electricity is converted from the
turning force of the wheels and stored
in the hybrid vehicle battery. (This is
called regenerative brake.)
Since the battery is charged by the
gasoline engine as needed, it does not
require charging from an outside
source like an electric vehicle.
If you do not use the vehicle for a
long time (2 weeks or more), the hy-
brid vehicle battery and auxiliary battery
will discharge and their condition is li-
able to decline. Therefore, in order to
make up for discharging, charge them
once in every 2 weeks for about 30
minutes by starting the hybrid system
with all electrical components turned off.
Basic operations are described below. Be-
sides, Toyota hybrid system performs vari-
ous controls depending on the operating
condition: The “Energy Monitor” screen
tells you which power is used currently.
Toyota hybrid system
Toyota hybrid system
operating condition
