TOYOTA JZX90/JZX100
NEW OWNERS HANDBOOK
Prepared with the help of the JZX World community
http://www.jzx100.com

JZX90 / JZX100 NEW OWNERS HANDBOOK
Version 1.01
2
www.jzx100.com
CONTENTS
General Maintenance Items ...........................................................................................................................................3
Oil System..................................................................................................................................................................3
Cooling System...........................................................................................................................................................3
Various Fluids and Their Capacities ............................................................................................................................3
Misc Items..................................................................................................................................................................4
Spark Plugs.................................................................................................................................................................4
Spark Plug Gap.......................................................................................................................................................4
Spark Plug Heatrange.............................................................................................................................................5
Brakes........................................................................................................................................................................5
Light Bulb Sizes...........................................................................................................................................................5
Chaser JZX100........................................................................................................................................................5
Mark II and Cresta JZX100......................................................................................................................................6
Chaser JZX90..........................................................................................................................................................6
JZX90 Mark II .........................................................................................................................................................6
JZX100 Interior and Other Lights............................................................................................................................6
Wheel Alignment .......................................................................................................................................................6
JZX90 Alignment Specs...........................................................................................................................................6
JZX100 Alignment Specs.........................................................................................................................................7
100K Service Requirements............................................................................................................................................8
Toyota Diagnostic Codes ................................................................................................................................................8
Toyota Error Codes.....................................................................................................................................................9

JZX90 / JZX100 NEW OWNERS HANDBOOK
Version 1.01
3
www.jzx100.com
GENERAL MAINTENANCE ITEMS
OIL SYSTEM
•Engine Oil: 5.1 Litres (oil change only)
•Engine Oil: 5.4 Litres (oil and filter change)
•Engine Oil Filter: Ryco part # Z418 (90mm tall)
•Engine Oil Filter: Ryco part # Z68 (120mm tall)
•OEM Engine Oil: Toyota Genuine (SAE 10W-30)
•Aftermarket Engine Oil: Any brand you are happy using providing it is either the factoy specified 10W-30 or
close to that viscosity range. For example, a 0W-40 oil should be just fine, as should a 5W-30 etc.
COOLING SYSTEM
If you are planning to use an aftermarket coolant, make sure it is compatible with Toyota Red as other coolant types
may eat away at the alloy cylinder heads.
•Coolant (Automatic trans):8.4 Litres - Toyota Genuine Long Life Coolant
•Coolant (Manual trans):7.7 Litres - Toyota Genuine Long Life Coolant
VARIOUS FLUIDS AND THEIR CAPACITIES
•Windscreen Washer Tank: 3.5 Litres
•Power Steering Fluid: 0.3 Litres – Toyota Genuine Power Steering Fluid or ATF DextronIII
•Clutch Fluid: Toyota Genuine brake fluid 2500H
•Brake Fluid: Toyota Genuine brake fluid 2500H
•Fuel Tank: 70 Litres – Unleaded Premium
•Automatic Transmission Fluid: 7.65 Litres – Toyota Genuine Auto Fluid Type T-III
•Manual Transmission Oil: 3.0 Litres – Toyota Genuine MG Gear Oil Special II (API GL-4 or GL-5 SAE 75W-90)
•Differential Oil (with & without Torsen LSD):1.3 Litres Toyota Genuine Hypoid Gear Oil SX (API.GL-5, SAE
85W-90)

JZX90 / JZX100 NEW OWNERS HANDBOOK
Version 1.01
4
www.jzx100.com
MISC ITEMS
•Fuel Filter: Ryco Part# Z373
•Gasket Turbine Outlet: 17279-88410 (gasket that goes between dump and back out theturbo)
•Front Wheel Studs: NS312 (from Repco)
•Panel Air Filter: OEM 17801-46060 – K&N 33-2504
•O2 sensor: 89465- 80015
•Timing Belt (OEM): 13568-49065
•Oil Pump Assembly: 15100-46030
•Crank Position Sensor: 90919-05023
•Air Box Assembly: 17700-46290
•Air Box - Cold Air Assembly/scoop: 17751-46080 + 17751-46081
•Ignition Coil Assembly: 90919-02216
•Alternator Assembly: 27060-46160 + 27060-46301
•Starter Motor (0.8kw): 28100-46130
•Starter Motor (1.4kw): 28100-46140
•Heater tap (Valve Assy, Water):87240-22370
SPARK PLUGS
Twin electrode plugs are recommended due to the Wasted Spark ignition system used on the 1JZ-GTE engine.
Platinum (or other precious metal) spark plugs do not necessarily perform any better nor last any longer than
standard copper plugs.
•Recommended: NGK BKR6EK (twin electrode copper plugs~$8ea)
•Platinum: NGK BKR6EKPB-11 (twin electrode ‘Premium Platinum, Special Design’spark plugs ~$20ea)
•Alternatives: NGK BKR6E, NGK BKR6E-11, NGK BKR7E, or NGK BKR7E-11
Notes: The -11 designation of the above NGK brand spark plugs denotes that the plugs are
factory pre-gapped to 1.1mm. The non -11 designated plugs are exactly the same except that they are
not factory pre-gapped to 1.1mm, however, I’m jet to find a set of non factory pre-gapped plugs to be
anything otherthan 1.1mm!
SPARK PLUG GAP
The recommended spark plug gap for a stock 1JZ-GTE engine is 1.1mm.
As you increase boost in a BPU application, you should consider progressively reducing the gap on your spark plugs,
starting with the largest gap,until such a point that any ignition issues are negated (i.e. misfire, rough idle etc)
Also, before reducing the plug gap too much, consider changing to a colder heat range plug first while starting with
the recommended stock 1.1mm plug gap. Only reduce the spark plug gap if problems persist.

JZX90 / JZX100 NEW OWNERS HANDBOOK
Version 1.01
5
www.jzx100.com
SPARK PLUG HEATRANGE
When increasing boost pressure it is generally recommended to change to a colder range spark plug. In the case of
NGK spark plugs, if you were using a heat range 6 plug, you would go to a heat range 7 (colder) plug.
In addition, consider spark plug gap when increasing the performance of your engine as well.
Please note that other spark plug manufacturers may not follow the same heat range numbering system whereby
going to a heat range 7 spark plug of another brand could actually increase the heat range.
Notes: Both Champion and Bosch spark plugs use a decreasing value range to indicate colder
plugs as opposed to NGK who use an increasing heat range. i.e. When using NGK, a 2 heat range is
hotter than a 12heat range.
BRAKES
The front brakes on the JZX100 are 100% IDENTICAL to that of the IS300, this means that Calipers,Rotors, and Pads
which fit the IS300 will also fit theJZX100.
•Front Brake Pads: 04465-22312
•Rear Brake Pads: 04466-30030
•Front Rotors (OEM):43512-50100
•Front Rotors (DBA): DBA 748L/R (Left/Right)
•Front Rotors (DBA Slotted):DBA 478SL/R (Left/Right)
LIGHT BULB SIZES
CHASER JZX100
•Tourer V cars - hid d2r for high and low
•Tourer V cars after compliance - it should be h4 for high and low (however dont quote me on that)
•Series 1 fogs - h3c
•Series 2 fogs - hb4
•Non Tourer V cars series 1 ie gx100/105, lx100 etc - hb4 low and fog, hb3 high
•Non Tourer V cars series 2 same

JZX90 / JZX100 NEW OWNERS HANDBOOK
Version 1.01
6
www.jzx100.com
MARK II AND CRESTA JZX100
•Tourer V cars - hid d2r low, hb3 hi, h3c fog
•Tourer V cars - dont know here, only low beam will change
•Mark II series 1 fogs - h3c
•Mark II series 2 fogs - same
•Non Tourer V cars series 1 ie gx100/105, lx100 etc - h4 hiand low,hb4 fog
•Non Tourer V cars series 1 – same
•Roulant G and Exceed cars - hid d2r low, hb3 hi, h3c fog
•Super Lucent and non Roulant G cars - h4 hiandlow,hb4 fog
•Roulant series 1 fog - h3c
•Roulant series 2 fog - hb4
CHASER JZX90
•Should be h4 high and low, h3c for fogs
JZX90 MARK II
•Same for hi and low, with 9006 for fogs
JZX100 INTERIOR AND OTHER LIGHTS
•T10 for indicators
•G14 is the room light
•T20 for rear tail lights
•T10 are dash lights
Should be same for JZX90 cars though unconfirmed
WHEEL ALIGNMENT
JZX90 ALIGNMENT SPECS
Anyone have JZX90 alignment specs?

JZX90 / JZX100 NEW OWNERS HANDBOOK
Version 1.01
7
www.jzx100.com
JZX100 ALIGNMENT SPECS
FRONT
•Caster - left = 6degree 25' right = 5degree 57'
•Camber- left = -2degree 10' right = -2degree 11'
•Toe - left = 0.9 right = 0.1
REAR
•Camber- left = -1degree 31' right = -1degree 27'
•Toe - total = 4.0 left = 2.0 right = 1.9

JZX90 / JZX100 NEW OWNERS HANDBOOK
Version 1.01
8
www.jzx100.com
100K SERVICE REQUIREMENTS
•Engine Oil 10w-30sj VVTi: 08880-81704
•Diff Oil 85W-90: 08885-80924
•Brake Fluid: 08823-80080
•Oil filter: 90915-YZZD2
•V-belt: 90916-A2007
•Spark Plugs: PK20TR11
•Transmission Fluid: 08886-81120
•Idler Sub Assembly: 13505-46070
•Idler Tensioner: 13540-46030
•Water Pump: 16100-49855
•Coolant: 08889-80086
•Seal - Type T Oil: 90311-38056
•Oil Seal: 90311-40020
•Oil Seal: 90311-46001
TOYOTA DIAGNOSTIC CODES
Reading the diagnostic trouble codes is very easy. You will need a paper clip to short the check connectors of the
diagnostic connector. The diagnostic connector comes in two types. The early system is located on the inner-left
fender well and is a round, green connector, usually located near the air cleaner. Simply jump the two terminals in this
connector with the ignition switch in the "ON" position and the engine off. Later models, '87 and newer use a multiple
terminal "DIAGNOSTIC" connector which is a small, rectangular-shaped grey "box", usually located near the right
fender in the enigne compartment. To get codes out of this type of connector, jump the "TE1" and "E1" terminals.
Finding these terminals is easy as the inside cover of the diagnostic connector contains a schematic of the connector
pinouts. If the under hood emission decal (VECI) is still intact on your vehicle, the proper pins for this are outlined
there as well.
The trouble codes will appear as flashes of the check engine lamp. Be sure the ignition key is on, the engine off, and
your foot off of the accelerator when reading the codes. Two different codes may appear: One-digit and two digit.
One digit codes have an approximate 4.5 second delay between flashes with the check engine light illuminating for
about a half of a second. Multiple codes have a 2.5 second delay between them. For example a code two flashes the
check engine lamp two times in a little over one second: I I. If two codes are stored, such as a code two and a code
four, the lamp may flash as such: ....I I....I I I I. Crude examples but you get the idea. Two digit codes are similar but will
flash the lamp with the first number first and the second number last. An example of a code twleve is I ....II and a code
twenty fouris I I..IIII.
YouTube video of how to read codes: http://www.youtube.com/watch?v=O_EDiu23AMs

JZX90 / JZX100 NEW OWNERS HANDBOOK
Version 1.01
9
www.jzx100.com
TOYOTA ERROR CODES
1 or NONE
•SYSTEM NORMAL
11
•LOSS OF POWER SUPPLY TO ECU
•IGNITIONSWITCH/CIRCUIT
•MAINRELAY/CIRCUIT
•ECU
6 or 12
•RPM SIGNAL-NO SIGNAL TO ECU FROM DISTRIBUTOR ("Ne" OR "G") AFTER ENGINE HAS BEEN CRANKED
•DISTRIBUTOR/CIRCUIT
•STARTERSIGNAL CIRCUIT
•IGNITER/IGNITERCIRCUIT
•ECU
13
•SAME AS ABOVE BUT AFTER ENGINE HAS RUN AT 1,000-1,500 RPM
•DISTRIBUTOR/DISTRIBUTORCIRCUIT
•ECU
3 or 14
•IGNITIONSIGNAL
•NO "IGF" SIGNAL TO ECU
•IGNITER/IGNITERCIRCUIT
•IGNITER AND IGNITIONCOIL/CIRCUIT
•ECU
5 or 21
•OXYGEN SENSOR SIGNAL/OXYGEN SENSOR HEATER SIGNAL
•OPEN OR SHORT IN OXYGEN SENSOR OR OXYGEN SENSOR SIGNAL
4 or 22
•WATER TEMPERATURE SENSOR SIGNAL
•OPEN OR SHORT IN WATER TEMP. SENSOR SIGNAL
•WATER TEMPERATURE SENSOR CIRCUIT
•WATER TEMPERATURE SENSOR
•ECU

JZX90 / JZX100 NEW OWNERS HANDBOOK
Version 1.01
10
www.jzx100.com
8 or 24
•INTAKE AIR TEMPERATURE SENSOR SIGNAL
•OPEN OR SHORT IN INTAKE AIR TEMP. SIGNAL
•INTAKE AIR TEMPERATURE CIRCUIT
•INTAKE AIR TEMPERATURE SENSOR
•ECU
25
•AIR/FUEL RATIO LEAN INDICATOR
•LEAN SIGNAL SENT TO ECU FROM O2 SENSOR
•INJECTOR FAULT(S)
•FUEL PRESSURE
•OXYGEN SENSOR
•AIRFLOW METER OR MAP SENSOR
•IGNITION
•ECU
26
•AIR/FUEL RATIO RICHINDICATOR
•SAME AS ABOVE
•COLD START INJECTOR
27
•SUB-OXYGEN SENSOR CIRCUIT OR SUB-OXYGEN SENSOR HEATER CIRCUIT
•SUB OXYGEN SENSOR/HEATER/CIRCUIT
•ECU
28
•No.2 OXYGEN SENSOR/OXYGEN SENSOR HEATER
•SAME AS CODE 21
2 or 31
•MANIFOLD AND/ORAIRFLOW METER SENSOR SIGNALCIRCUIT
•AIRFLOW METER/CIRCUIT
•MANIFOLD PRESSURE SENSOR/CIRCUIT
•ECU
32
•AIRFLOW METER SIGNAL (VANE-TYPE)
•AIRFLOWMETER./CIRCUIT
•ECU

JZX90 / JZX100 NEW OWNERS HANDBOOK
Version 1.01
11
www.jzx100.com
14 or 34
•TURBOCHARGER PRESSURE
•ABNORMAL TURBOCHARGER PRESSURE
•TURBO CHARGER
•AIRFLOW METER/MANIFOLD/TURBOCHARGER PRESSURE SENSOR
•INTERCOOLER SYSTEM
•ECU
35
•TURBOCHARGER PRESSURESENSOR SIGNAL
•TURBOCHARGER PRESSURE SENSOR
•ECU
7 or 41
•THROTTLE POSITION SENSOR SIGNAL
•OPEN OR SHORT IN TPS SIGNAL
•TPS SENSOR
•TPS SIGNAL/CIRCUIT
•ECU
9 or 42
•VEHICLE SPEED SENSOR SIGNAL CIRCUIT
•NO SPD. SIGNAL FOR SEVERLA SECONDS
•WHILE VEHICLE IS OPERATED UNDER HEAVY LOAD (TPS/MAP/AIR FLOW INPUTS)
•SPEED SENSOR/CIRCUIT
•ECU
10 or 43
•STARTER SIGNAL
•NO "STA" SIGNAL TO ECU UNTIL ENGINE SPEED EXCEEDS 800RPM
•IGNITIONSWITCH/CIRCUIT
•ECU
11 or 51
•SWITCH SIGNALS
•IDL (tps) CONTACTS OFF, NEUTRAL START SWITCH OFF, A/C SWITCH "ON" SIGNAL TO ECU
•WITH DIAGNOSTIC CHECK CONNECTOR SHORTED
•A/C SWITCH/CIRCUIT
•A/C AMPLIFIER
•TPS/CIRCUIT
•NEUTRAL START SWITCH/CIRCUIT
•ECU

JZX90 / JZX100 NEW OWNERS HANDBOOK
Version 1.01
12
www.jzx100.com
12 or 52
•KNOCK SENSOR SIGNAL--OPEN OR SHORT IN KNOCK SENSOR SIGNAL
•KNOCK SENSOR/CIRCUIT
•ECU
13 or 53
•KNOCK CONTROL SIGNAL IN ECU
•ECU
71
•EGR VALVE MALFUNCTION--EXHAUST GAS TEMPEATURE BELOW SPEC. FOR EGR CONTROL
•EGR SYSTEM
•EGR GAS TEMPERATURE SENSOR/CIRCUIT
72
•AIR CONDITIONER COMPRESSOR RELAY/RELAY SIGNAL
•A/C COMPRESSOR RELAY/CIRCUIT
•ECU
