Toyota Tacoma guide User manual

2008
Quick Reference Guide
MN 00505-QRG08-TAC
Printed in the USA 7/07
Customer Experience Center
1-800-331-4331

2008
Tacoma
Spare tire & tools
Tool location
Removing the spare tire
21
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
(1) Assemble the jack handle.
(2) Insert the jack handle end into the lowering
screw.
(3) Turn the jack handle counterclockwise.
Refer to the Owner’s Manual for tire changing and
jack positioning procedures.
Regular cab models
-behind the seatback Double cab models -under the rear seat
Access cab models
-under the rear seat
Tool bag
Jack
Tool bag
Jack
Tool bag
Jack
Front
Front
!Aword about safe vehicle operations
This Quick Reference Guide is a summary of
basic vehicle operations. It contains brief
descriptions of fundamental operations so
you can locate and use the vehicle’s main
equipment quickly and easily.
The Quick Reference Guide is not intended
as a substitute for the Owner’s Manual
located in your vehicle’s glove box. We
strongly encourage you to review the
Owner’s Manual and supplementary manuals
so you will have a better understanding of
your vehicle’s capabilities and limitations.
Your dealership and the entire staff of Toyota
Motor Sales, U.S.A., Inc. wish you many years
of satisfied driving in your new Tacoma.
This Quick Reference Guide is not a full
description of Tacoma operations. Every
Tacoma owner should review the Owner’s
Manual that accompanies this vehicle.
Pay special attention to the boxed
“ ” information highlighted
throughout the Owner’s Manual.Each box
contains safe operating instructions to
help you avoid injury or equipment
malfunction.
All information in this Quick Reference
Guide is current at the time of printing.
Toyota reserves the right to make changes
at any time without notice.
Moving the lever to “LOCK” will allow the door to
be opened only from the outside.
Doors-Child safety locks (double cab only)
Rear door
(1)
(3)
(2)

1
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
INDEX
Item Page no.
OVERVIEW
Engine maintenance 7
Fuel tank door release and cap 6
Hood release 6
Indicator symbols 4-5
Instrument cluster 4
Instrument panel 2-3
Keyless entry 6
FEATURES/OPERATIONS
Accessory meter 16
Air Conditioning/Heating 16
Audio 14-15
Auto LSD (Auto Limited Slip Differential) 19
Automatic Transmission 8
Bottle holders 18
Clock 10
Cruise control 17
Cup holders 18
Door locks-Power 19
Four-wheel drive 9
Lights & turn signals 11
Light control-Instrument panel 19
Manual Transmission 8
Parking brake 13
Power outlets 13
Rear differential lock 17
Seat adjustments-Front 10
Seats-Head restraints 10
Tilt and telescopic steering wheel 9
Windows-Power 12
Windshield wipers & washers 12
SAFETY AND EMERGENCY FEATURES
Doors-Child safety locks 21
Seat belts 20
Seat belts-Shoulder belt anchor 20
Spare tire & tools 21
Tire Pressure Warning System reset 20

3
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
2
OVERVIEW
Volume control buttons (for audio)
“ ” buttons (for audio)
“MODE” button (for audio)
Front fog light switch1
Rear differential lock switch1
115V AC Power outlet ON/OFF switch1
Instrument panel light control
Headlight and turn signal controls
Wiper and washer controls
Two-wheel/Four-wheel drive selector1
Audio system
Clock
Theft deterrent system/Engine immobilizer
indicator1
Front passenger seat belt reminder
Front passenger occupant classification indicator1
or front passenger airbag ON/OFF indicator1
Front passenger airbag manual ON/OFF switch1
Air Conditioning controls
12V DC Power outlet
Emergency flasher switch
12V DC Power outlet/Cigarette lighter
Parking brake lever (stick type)2
Cruise control1
Engine switch
Roll sensing curtain shield airbags OFF switch
“DAC” (Downhill Assist Control) button1or clutch
start cancel switch1
“VSC OFF” switch1
Power rearview mirror control switches1
1If equipped
2Manual Transmission only.
(Automatic Transmissions are equipped with a
parking brake pedal.)
Instrument panel
>
>
Steering wheel
controls (if equipped)

5
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
4
OVERVIEW
1For details, refer to “Service reminder indicators and warning
buzzers,” Section 1-6, 2008 Owner’s Manual.
2If this light flashes, refer to “Four-wheel drive system,” Section
1-7, 2008 Owner’sManual.
3If this light flashes, refer to “Rear differential lock system,”
Section 1-7, 2008 Owner’sManual.
4If this light flashes, refer to “Cruise control,” Section 1-7, 2008
Owner’sManual.
5If this light flashes, refer to “Roll sensing of curtain shield
airbags off switch,” Section 1-3, 2008 Owner’s Manual.
Tachometer
Speedometer
Odometer and two trip meters
Service indicator and reminder
Engine coolant temperature
Fuel gauge
Trip meter reset knob
Gear shift position indicator*
* If equipped
Instrument cluster
Automatic Transmission indicator
(5-speed)/(4-speed)
Driver/Front passenger seat belt
reminder1
Charging system warning1
Low engine oil pressure warning1
Brake system warning1
Malfunction/Check Engine indicator1
Engine oil replacement reminder1
Anti-lock Brake System warning1
Front passenger occupant classification
indicator
Indicator symbols
Headlight low beam indicator
Headlight high beam indicator
Turn signal indicator
Four-wheel drive indicator2
Low speed four-wheel drive indicator2
Rear differential lock indicator3
Slip indicator
Vehicle Stability Control “OFF” indicator
warning1
Downhill assist control indicator
“AUTO LSD” indicator
Cruise control indicator4
Automatic Transmission fluid temperature
warning1
Low Tire Pressure Warning1
Theft deterrent/Engine immobilizer system
indicator
Open door warning1
Airbag SRS warning1
Roll Sensing Curtain shield Airbags off
indicator5

7
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
6
OVERVIEW
Windshield washer fluid tank
Engine coolant reservoir
Engine oil filler cap
Power steering fluid reservoir
Engine oil level dipstick
Note: Regularly scheduled maintenance, including
oil changes, will help extend the life of
your vehicle and maintain performance.
Please refer to the “Owner’s Warranty
Information Booklet,” “Scheduled
Maintenance Guide” or “Owner’s Manual
Supplement.”
Fuel tank door release and cap
Engine maintenance
Hood release
NOTE: Tighten until one click is heard. If the cap is
not tightened enough, Check Engine “ ” indicator
may illuminate.
4cylinder (2TR-FE) engine
6 cylinder (1GR-FE) engine
Pull
Pull up latch and
raise hood
Turn
Panic button
Keyless entry
Locking operation Unlocking operation
NOTE: After unlocking, if a door is not opened within
30 seconds, all doors will relock for safety.
Push
Push and hold
Push ONCE: Driver door
TWICE: All doors
Pull

9
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
8
FEATURES/OPERATIONS
Automatic Transmission
1The engine switch must be ON, and the brake
pedal depressed to shift from “Park.”
Downshifting increases power going uphill, or
provides engine braking downhill. For best fuel
economy during normal driving conditions, always
drive with the shift lever in the “D” position.
5-speed models
4-speed models
Four-wheel drive (if equipped)
High speed (2WD)
High speed (4WD)
Shift when speed is below 62 mph.
Low speed (4WD)
Shift into neutral while stopped, or depress
clutch pedal at speeds below 2 mph.
For best fuel economy and performance under
normal driving conditions, keep in “H2” position.
Tilt and telescopic steering wheel
Hold wheel, push lever down, set angle and length,
and return lever.
Note: Do not attempt to adjust while the vehicle
is in motion.
Park1
Reverse
Neutral
Drive
Third gear
Second gear
First gear
Fourth gear
Park1
Reverse
Neutral
Drive
Third gear
Second gear
First gear
Fourth gear
Park1
Reverse
Neutral
Drive
Third gear
Second gear
First gear
Tacoma is available with optional 5-speed or
6-speed Manual Transmission. For safety, the engine
will not start unless the clutch pedal is FULLY
depressed.
Refer to the Owner’s Manual for more details.
Manual Transmission
Turn
Push and
turn
Length
Angle
Lock release
lever
Turn

11
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
10
FEATURES/OPERATIONS
Seat adjustments-Front
Separate seat Bench seat
Position
Lumbar support*
Seatback angle
* If equipped
Seats-Head restraints
Bench seat-Front
Separate seats-Front
Lock release button Lock release button
Lights & turn signals
Turn signals
Headlights
High beam flasher
Low beam
Front fog lights (if equipped)
Headlights
-Daytime Running Light system (DRL)
Automatically turns on the turn signal lights at a
reduced intensity.
-Automatic light cut off system Automatically turns
lights off when driver’s door is opened with the
engine switch in the “ACC” or “LOCK” position.
Front fog lights come on only when the headlights
are on low beam.
Parking lights
Right turn
Push
Lane change
Lane change
Left turn
High beam
Clock
H- Hour set
M- Minute set
(1)
(2)

13
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Parking brake
12
FEATURES/OPERATIONS
Windshield wipers & washers
Interval wipe
Single wipe
Slow
Manual Transmission
Set Release
(1)
Push
button
(2)
Turn and
push in
lever
Fast
Pull to wash and wipe
Adjust interval
With intermittent wiper
Without intermittent wiper
Pull to wash and wipe
Single wipe
Slow
Fast
Automatic Transmission
Set: Depress
Release: Depress again
Windows-Power (if equipped)
Access cab models
Up
Down
Driver side Window lock switch
Up
Down
Double cab models
Up
Down
Driver side Window
lock
switch
Up
Down
Automatic down operation (driver side only)
Push the switch completely down and release to
fully open. To stop window midway, lightly pull up
on the switch.
Window lock switch Deactivates all passenger
windows. Driver’s window remains operable.
Power outlets
12V DC
115V AC (if equipped)
ON/OFF switch
Green
indicator
Yellow
indicator
Right side
of bed Push
Key must be in the “ACC” or “ON” position to
be used.
The engine must be running for use.
Yellow Light Only Max Capacity 115V AC/100W
Green & Yellow Lights Max Capacity 115V AC/400W
Refer to the Owner’s Manual for more details.

15
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
14
FEATURES/OPERATIONS
Type 2 additional functions
Type 3 additional functions
Audio
Eject CD
Push to turn
ON/OFF
View CD
information
Push to
adjust
tone &
balance
Seek
station/
CD track
select Station/CD
track scan
Mode
View radio
and CD
information
Preset buttons - functions in other
modes indicated below number
View genre
with RDS
system
Traffic information
Load CD(s)
“-+”
Volume control
“ ”
-In radio mode
Push to select a preset station; push and hold to
seek the next strong station.
-In CD mode
Push to skip up or down to the next/previous
track.
“MODE”
Push to turn audio ON and select an audio mode.
Push and hold to turn the audio system “OFF
.”
>
>
Steering wheel switches (if equipped)
RADIO
To preset stations Tune in the desired station and
hold down a preset button (1-6) until you hear a
beep. Push desired preset button (1-6) to select.
To scan stations Push and hold “SCAN” to scan
preset stations. Push again to hold selection.
RDS (Radio Data System - FM, Type 3 only)
-Push “TYPE” to select station genre.
-Push steering wheel switches “ ” or “ ,” or
preset button (1-6) to select stations within genre.
-Push “TEXT” to receive information transmitted
from radio stations.
>
>
CD PLAYER
To scan tracks on a disc Push and hold “SCAN.”
Push again to hold selection.
CD changer (Types 2 and 3 only)
-To load one disc Push “LOAD” and insert one disc.
-To load multiple discs Push and hold “LOAD” until
you hear a beep. Insert one disc. Shutter will close
and then re-open for next disc.
Type 1

17
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
16
FEATURES/OPERATIONS
Air Conditioning (if equipped)/Heating
Fan speed
Temperature
Airflow vent
In “ ” or “ ” mode, use fresh air (“ ”
indicator “OFF”) to reduce window fogging.
Fresh or recirculated cabin air
Air Conditioning ON/OFF (if equipped)
Use fresh air to quickly cool interior, then
change to recirculate for cooler air.
Use ONLY when wheel spinning occurs in a ditch, or
on slippery or unpaved surfaces. DO NOT USE THE
REAR DIFFERENTIAL LOCK IN CONDITIONS OTHER
THAN SPECIFIED IN THE OWNER’S MANUAL.
UNLOCK THE DIFFERENTIAL ONCE THE VEHICLE
MOVES OUT OF THE TROUBLE SPOT.
Refer to your Owner’s Manual for complete details
on this system before attempting to use it.
Rear differential lock (if equipped)
Rear differential
Lock/Unlock
Cruise control (if equipped)
1The set speed may also be cancelled by depressing
the brake pedal.
2The set speed may be resumed once vehicle speed
exceeds 25 mph.
Turning system ON/OFF
Functions
System ON/OFF
Resume2/Increase speed
Set/Decrease speed
Cancel1
Accessory meter (if equipped)
E/M (English/Metric) button To select Fahrenheit
or Celsius.
Compass
Outside temperature display

19
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
18
FEATURES/OPERATIONS
Door locks-Power (if equipped)
Light control-Instrument panel
VSC OFF
Lock
Unlock
Brightness
control
-
Briefly push the “VSC OFF” switch to activate Auto
LSD. To deactivate, briefly push the switch again.
Note: ONLY works in 2-wheel drive at speeds
under 62 mph. Should ONLY be used when
wheel spinning occurs on slippery or
unpaved surfaces.
Refer to the Owner‘s Manual for more details on
this system before attempting to use it.
+
Bottle holders
Front door
Rear door
(double cab only)
Center console-Rear
Cup holders
Bench seat
Separate seats
(Manual Transmission)
Separate seats
(Automatic Transmission)
Front console
Center console
Auto LSD (Auto Limited Slip
Differential)(if equipped)
Separate seats
(Automatic Transmission)

20
SAFETY AND
EMERGENCY FEATURES
If belt is fully extended, then retracted even
slightly, it cannot be re-extended beyond that point,
unless fully retracted again. This feature is used to
help hold child restraint systems securely.
To find more information about seat belts, and how
to install a child restraint system, refer to the
Owner's Manual.
Keep as low on
hips as possible
Take up
slack
Too high
Seat belts
Seat belts-Shoulder belt anchor
Push up, or
squeeze lock
release to lower
Tire Pressure Warning System reset
If tire pressure becomes critically low on any of the
tires (including spare), indicator comes on. Pushing
“ SET” button should not turn off the light.
Correctly adjusting tire inflation will turn off the
light after a few minutes. After replacing/rotating
tire or wheels, the system must be initialized.
Refer to the Owner’s Manual for details on system
reset initialization.

2008
Tacoma
Spare tire & tools
Tool location
Removing the spare tire
21
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
(1) Assemble the jack handle.
(2) Insert the jack handle end into the lowering
screw.
(3) Turn the jack handle counterclockwise.
Refer to the Owner’s Manual for tire changing and
jack positioning procedures.
Regular cab models
-behind the seatback Double cab models -under the rear seat
Access cab models
-under the rear seat
Tool bag
Jack
Tool bag
Jack
Tool bag
Jack
Front
Front
!Aword about safe vehicle operations
This Quick Reference Guide is a summary of
basic vehicle operations. It contains brief
descriptions of fundamental operations so
you can locate and use the vehicle’s main
equipment quickly and easily.
The Quick Reference Guide is not intended
as a substitute for the Owner’s Manual
located in your vehicle’s glove box. We
strongly encourage you to review the
Owner’s Manual and supplementary manuals
so you will have a better understanding of
your vehicle’s capabilities and limitations.
Your dealership and the entire staff of Toyota
Motor Sales, U.S.A., Inc. wish you many years
of satisfied driving in your new Tacoma.
This Quick Reference Guide is not a full
description of Tacoma operations. Every
Tacoma owner should review the Owner’s
Manual that accompanies this vehicle.
Pay special attention to the boxed
“ ” information highlighted
throughout the Owner’s Manual.Each box
contains safe operating instructions to
help you avoid injury or equipment
malfunction.
All information in this Quick Reference
Guide is current at the time of printing.
Toyota reserves the right to make changes
at any time without notice.
Moving the lever to “LOCK” will allow the door to
be opened only from the outside.
Doors-Child safety locks (double cab only)
Rear door
(1)
(3)
(2)
