Toyota Tundra 2015 User manual

Pictorial index Search by illustration
1For safety
and security Make sure to read through them
2Instrument
cluster How to read the gauges and meters, the variety of
warning lights and indicators, etc.
3Operation of
each
component
Opening and closing the doors and windows,
adjustment before driving, etc.
4Driving Operations and advices which are necessary for
driving
5Multimedia Operating the multimedia system
6Interior features Usage of the interior features, etc.
7Maintenance
and care Caring for your vehicle and maintenance
procedures
8When trouble
arises What to do in case of malfunction or emergency
9Vehicle
specifications Vehicle specifications, customizable features, etc.
10 For owners Reporting safety defects for U.S. owners, and seat
belt and SRS airbag instructions for Canadian
owners
Index Search by symptom
Search alphabetically

TABLE OF CONTENTS
2
For your information....................... 8
Reading this manual....................12
How to search.............................. 13
Pictorial index .............................. 14
1-1. For safe use
Before driving...................... 28
For safety drive ...................30
Seat belts............................ 32
SRS airbags........................ 38
Front passenger occupant
classification system ......... 50
Safety information
for children ........................ 55
Child restraint systems........ 56
Installing child restraints...... 60
Exhaust gas precautions..... 77
1-2. Theft deterrent system
Engine immobilizer
system............................... 78
Alarm................................... 80
2. Instrument cluster
Warning lights and
indicators........................... 84
Gauges and meters............. 88
Multi-information display ..... 90
3-1. Key information
Keys.....................................98
3-2. Opening, closing and
locking the doors
Side doors .........................100
Tailgate..............................106
3-3. Adjusting the seats
Front seats.........................111
Rear seats (Double
Cab and CrewMax
models)............................114
Driving position memory
(driver’s seat)...................116
Head restraints..................120
3-4. Adjusting the steering
wheel and mirrors
Steering wheel...................124
Inside rear view mirror.......127
Outside rear view
mirrors.............................130
3-5. Opening, closing the
windows and moon roof
Power windows..................134
Back window......................137
Power back window...........138
Moon roof ..........................141
1For safety and security
2Instrument cluster
3Operation of
each component

3
1
9
8
7
5
4
3
2
10
6
4-1. Before driving
Driving the vehicle............. 146
Cargo and luggage............ 153
Vehicle load limits .............156
Trailer towing..................... 158
Dinghy towing.................... 178
4-2. Driving procedures
Engine (ignition) switch..... 179
Automatic transmission..... 181
Turn signal lever................ 186
Parking brake.................... 187
4-3. Operating the lights and
wipers
Headlight switch................ 188
Fog light switch .................191
Windshield wipers and
washer ............................ 192
4-4. Refueling
Opening the fuel tank
cap .................................. 195
4-5. Using the driving support
systems
Cruise control.................... 199
Intuitive parking assist....... 202
Rear view monitor
system............................. 208
BSM
(Blind Spot Monitor)........ 217
Four-wheel drive system... 225
AUTO LSD system............ 228
Driving assist systems....... 230
Trailer brake controller...... 237
4-6. Driving tips
Winter driving tips.............. 240
Off-road precautions ......... 244
5-1. Basic Operations
Multimedia system types...250
Entune Audio.....................252
USB Port/AUX Port............255
5-2. Setup
Setup menu.......................256
General settings ................257
Audio settings....................259
Display settings .................260
Voice settings....................261
5-3. Using the audio system
Basic audio operations......262
Selecting the audio
source..............................263
List screen operation.........264
Sound settings...................266
5-4. Using the radio
Radio operation.................267
5-5. Playing an audio CD and
MP3/WMA/AAC discs
CD player operation...........269
5-6. Using an external device
Listening to an iPod...........274
Listening to a USB
memory device................278
Using the AUX port............282
4Driving 5Multimedia

TABLE OF CONTENTS
4
5-7. Connecting Bluetooth®
Preparations to use
wireless
communication................ 283
Registering a Bluetooth®
audio player
for the first time............... 287
Registering a Bluetooth®
phone for the first time ... 288
Registering a Bluetooth®
device.............................. 289
Connecting a Bluetooth®
device.............................. 291
Displaying a Bluetooth®
device details .................. 293
Detailed Bluetooth®
system settings ............... 294
5-8. Bluetooth®audio
Listening to Bluetooth®
audio ............................... 295
5-9. Bluetooth®phone
Using a Bluetooth®
phone.............................. 296
Making a call..................... 298
Receiving a call................. 301
Speaking on the phone.....302
Bluetooth®phone
message function............ 305
Using the steering
wheel switches................ 309
Bluetooth®phone
settings............................ 310
Contact/Call History
Settings........................... 312
What to do if...
(Troubleshooting)............ 321
5-10.Using the voice
command system
Voice command system.... 325
5-11.Bluetooth®
Bluetooth®.........................327
5-12.Antenna
Antenna.............................332
6-1. Using the air conditioning
system
Manual air conditioning
system.............................336
Automatic air conditioning
system.............................343
Seat heaters/
seat ventilators................350
6-2. Using the interior lights
Interior lights list.................353
• Personal/interior lights
main switch ...................354
• Personal/interior
lights..............................354
• Cargo lamp main
switch ............................355
6-3. Using the storage features
List of storage features......356
• Glove box......................358
• Console box (front
separated type seat) .....359
• Card holder ...................360
• Map holder (front
bench type seat)............362
• Pen holder.....................363
• Tissue pocket................364
• Overhead console.........365
• Cup holders...................366
• Bottle holders ................368
• Auxiliary boxes (front
bench type seat)............369
• Storage box...................371
Luggage compartment
features ...........................373
6Interior features

5
1
9
8
7
5
4
3
2
10
6
6-4. Other interior features
Other interior features....... 374
• Sun visors..................... 374
• Vanity mirrors................ 374
• Clock............................. 375
• Outside temperature
display........................... 376
• Power outlets................ 377
• Armrest ......................... 379
• Assist grips ................... 380
Garage door opener..........381
Compass........................... 387
7-1. Maintenance and care
Cleaning and protecting
the vehicle exterior.......... 392
Cleaning and protecting
the vehicle interior........... 394
7-2. Maintenance
Maintenance
requirements................... 397
General maintenance........399
Emission inspection
and maintenance (I/M)
programs......................... 402
7-3. Do-it-yourself maintenance
Do-it-yourself service
precautions ..................... 403
Hood.................................. 405
Engine compartment......... 406
Tires.................................. 416
Tire inflation pressure........ 424
Wheels.............................. 427
Air conditioning filter.......... 430
Wireless remote control
battery............................. 433
Checking and replacing
fuses ............................... 435
Light bulbs......................... 438
8-1. Essential information
Emergency flashers...........456
If your vehicle has to
be stopped in
an emergency..................457
8-2. Steps to take in an
emergency
If your vehicle needs to
be towed..........................458
If you think something is
wrong...............................463
Fuel pump shut off
system.............................464
If a warning light turns on
or a warning buzzer
sounds.............................465
If a warning message is
displayed.........................472
If you have a flat tire..........476
If the engine will not
start .................................491
If the shift lever cannot
be shifted from P.............492
If the vehicle battery is
discharged.......................494
If your vehicle overheats....497
If the vehicle becomes
stuck................................499
7Maintenance and care
8When trouble arises

TABLE OF CONTENTS
6
9-1. Specifications
Maintenance data
(fuel, oil level, etc.).......... 502
Fuel information ................ 520
Tire information ................. 524
9-2. Customization
Customizable features ...... 534
9-3. Items to initialize
Items to initialize................ 539
Reporting safety defects
for U.S. owners........................ 542
Seat belt instructions
for Canadian owners
(in French) ............................... 543
SRS airbag instructions
for Canadian owners
(in French) .............................. 545
Camper information ................... 554
What to do if...
(Troubleshooting) .................... 562
Alphabetical index...................... 565
9Vehicle specifications
10 For owners
Index
For vehicles with Entune Audio Plus or Entune Premium Audio, refer
to the “NAVIGATION SYSTEM OWNER’S MANUAL” for information
regarding the multimedia system.
Multimedia system types: P. 250

7
1
9
8
7
5
4
3
2
10
6

8
For your information
Please note that this manual applies to all models and all equipment, includ-
ing options. Therefore, you may find some explanations for equipment not
installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of equipment.
Approximately five hours after the engine is turned off, you may hear sound
coming from under the vehicle for several minutes. This is the sound of a fuel
evaporation leakage check and, it does not indicate a malfunction.
A wide variety of non-genuine spare parts and accessories for Toyota vehi-
cles are currently available in the market. You should know that Toyota does
not warrant these products and is not responsible for their performance,
repair, or replacement, or for any damage they may cause to, or adverse
effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products. Modi-
fication with non-genuine Toyota products could affect its performance, safety
or durability, and may even violate governmental regulations. In addition,
damage or performance problems resulting from the modification may not be
covered under warranty.
Main Owner’s Manual
Noise from under vehicle after turning off the engine
Accessories, spare parts and modification of your Toyota

9
The installation of a mobile two-way radio system in your vehicle could affect
electronic systems such as:
●Multiport fuel injection system/sequential multiport fuel injection system
●Cruise control system (if equipped)
●Anti-lock brake system
●SRS airbag system
●Seat belt pretensioner system
Be sure to check with your Toyota dealer for precautionary measures or spe-
cial instructions regarding installation of a mobile two-way radio system.
Your Toyota is equipped with several sophisticated computers that will record
certain data, such as:
• Engine speed
• Accelerator status
• Brake status
• Vehicle speed
• Shift position
The recorded data varies according to the vehicle grade level and options
with which it is equipped. Furthermore, these computers do not record con-
versations, sounds or pictures.
●Data usage
Toyota may use the data recorded in these computers to diagnose malfunc-
tions, conduct research and development, and improve quality.
Toyota will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if
the vehicle is leased
• In response to an official request by the police, a court of law or a govern-
ment agency
• For use by Toyota in a lawsuit
• For research purposes where the data is not tied to a specific vehicle or
vehicle owner
Installation of a mobile two-way radio system
Vehicle data recordings

10
This vehicle is equipped with an event data recorder (EDR). The main pur-
pose of an EDR is to record, in certain crash or near crash-like situations,
such as an air bag deployment or hitting a road obstacle, data that will assist
in understanding how a vehicle’s systems performed. The EDR is designed to
record data related to vehicle dynamics and safety systems for a short period
of time, typically 30 seconds or less.
The EDR in this vehicle is designed to record such data as:
• How various systems in your vehicle were operating;
• Whether or not the driver and passenger safety belts were buckled/fas-
tened;
• How far (if at all) the driver was depressing the accelerator and/or brake
pedal; and,
• How fast the vehicle was traveling.
These data can help provide a better understanding of the circumstances in
which crashes and injuries occur.
NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situ-
ation occurs; no data are recorded by the EDR under normal driving condi-
tions and no personal data (e.g., name, gender, age, and crash location) are
recorded. However, other parties, such as law enforcement, could combine
the EDR data with the type of personally identifying data routinely acquired
during a crash investigation.
To read data recorded by an EDR, special equipment is required, and access
to the vehicle or the EDR is needed. In addition to the vehicle manufacturer,
other parties, such as law enforcement, that have the special equipment, can
read the information if they have access to the vehicle or the EDR.
●Disclosure of the EDR data
Toyota will not disclose the data recorded in an EDR to a third party except
when:
• An agreement from the vehicle’s owner (or the lessee for a leased vehi-
cle) is obtained
• In response to an official request by the police, a court of law or a govern-
ment agency
• For use by Toyota in a lawsuit
However, if necessary, Toyota may:
• Use the data for research on vehicle safety performance
• Disclose the data to a third party for research purposes without disclosing
information about the specific vehicle or vehicle owner
Event data recorder

11
The SRS airbag and seat belt pretensioner devices in your Toyota contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt pretensioner
removed and disposed of by a qualified service shop or by your Toyota dealer
before you scrap your vehicle.
Special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These compo-
nents may include airbag, seat belt pretensioners, and wireless remote con-
trol batteries.
Scrapping of your Toyota
Perchlorate Material
CAUTION
■General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ-
ence of alcohol or drugs that have impaired your ability to operate your vehi-
cle. Alcohol and certain drugs delay reaction time, impair judgment and
reduce coordination, which could lead to an accident that could result in
death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other
drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that
distracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.
■General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the windows, the moon roof, or other features of the vehicle. In addition,
heat build-up or extremely cold temperatures inside the vehicle can be fatal
to children.

12
Reading this manual
CAUTION:
Explains something that, if not obeyed, could cause death or
serious injury to people.
NOTICE:
Explains something that, if not obeyed, could cause damage to
or a malfunction in the vehicle or its equipment.
Indicates operating or working procedures. Follow the steps
in numerical order.
Indicates the action (push-
ing, turning, etc.) used to
operate switches and other
devices.
Indicates the outcome of an
operation (e.g. a lid opens).
Indicates the component or
position being explained.
Means “Do not”, “Do not do
this”, or “Do not let this hap-
pen”.
123

13
How to search
■Searching by name
• Alphabetical index.......P. 565
■Searching by installation
position
• Pictorial index................P. 14
■Searching by symptom or
sound
• What to do if...
(Troubleshooting)........P. 562
■Searching by title
• Table of contents.............P. 2

14 Pictorial index
Pictorial index
■Exterior
The illustration represents the CrewMax models and may differ from the body
shape of other models.
Side doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 100
Locking/unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 100
Opening/closing the door glasses . . . . . . . . . . . . . . . . . . . . . . P. 134
Warning lights/warning messages. . . . . . . . . . . . . . . . . . P. 466, 473
Tailgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 106
Locking/unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 106
Opening/closing the tailgate. . . . . . . . . . . . . . . . . . . . . . . . . . . P. 106
Removing the tailgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 107
Outside rear view mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 130
Adjusting the mirror angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 130
Folding the mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 131
Driving position memory*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 116
Defogging the mirrors*2. . . . . . . . . . . . . . . . . . . . . . . . . . P. 338, 345
Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 192
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 240
To prevent freezing (windshield wiper de-icer)*2. . . . . . . P. 339, 346
Back window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 137, 138
1
2
3
4
5

15
Pictorial index
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 195
Refueling method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 195
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 511
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 416
Tire size/inflation pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 517
Winter tires/tire chain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 240
Checking/rotation/tire pressure warning system . . . . . . . . . . . P. 416
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 476
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 405
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 405
Engine oil. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 512
Coping with overheat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 497
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 208
Headlights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 188
Fog lights*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 191
Front turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 186
Parking lights (bulb type)*2/
daytime running lights (bulb type)*2. . . . . . . . . . . . . . . . . . P. 188
Parking lights (LED type)*2/
daytime running lights (LED type)*2. . . . . . . . . . . . . . . . . . P. 188
Rear turn signal lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 186
Tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 188
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 188
Back-up lights
Shifting the shift lever to R. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 181
Side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 188
6
7
8
9
Light bulbs of the exterior lights for driving
(Replacing method: P. 438, Watts: P. 519)
*1: If equipped on CrewMax models
*2: If equipped
10
11
12
13
14
15
16
17
18

16 Pictorial index
■Instrument panel
Front separated type seats
Engine switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 179
Starting the engine/changing the positions . . . . . . . . . . . . . . . P. 179
Emergency stop of the engine. . . . . . . . . . . . . . . . . . . . . . . . . P. 457
When the engine will not start . . . . . . . . . . . . . . . . . . . . . . . . . P. 491
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 181
Changing the shift position. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 181
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 458
When the shift lever does not move. . . . . . . . . . . . . . . . . . . . . P. 492
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 88
Reading the meters/adjusting the instrument panel light. . . . . . P. 88
Warning lights/indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . P. 84
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . P. 465
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 90
Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 90
When the warning messages are displayed . . . . . . . . . . . . . . P. 472
Parking brake pedal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 187
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 187
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 241
Warning buzzer/message . . . . . . . . . . . . . . . . . . . . . . . . P. 465, 473
1
2
3
4
5

17
Pictorial index
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 186
Headlight switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 188
Headlights/parking lights/tail lights/
daytime running lights*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 188
Fog lights*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 191
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . P. 192
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 192
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 415
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 473
Hood lock release lever. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 405
Tilt and telescopic steering lock release lever*2. . . . . . . . P. 124
Tilt and telescopic steering control switch*3. . . . . . . . . . . P. 125
Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 125
Driving position memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 116
Manual air conditioning system*1. . . . . . . . . . . . . . . . . . . . P. 336
Automatic air conditioning system*1. . . . . . . . . . . . . . . . . P. 343
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 336, 343
Back window defogger*4. . . . . . . . . . . . . . . . . . . . . . . . . P. 338, 345
Windshield wiper de-icer*1. . . . . . . . . . . . . . . . . . . . . . . P. 339, 346
Multimedia system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 250
*1: If equipped
*2: Vehicles without driving position memory
*3: Vehicles with driving position memory
*4: For CrewMax models
6
7
8
9
10
11
12

18 Pictorial index
Front bench type seat
Engine switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 179
Starting the engine/changing the positions . . . . . . . . . . . . . . . P. 179
Emergency stop of the engine. . . . . . . . . . . . . . . . . . . . . . . . . P. 457
When the engine will not start . . . . . . . . . . . . . . . . . . . . . . . . . P. 491
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 181
Changing the shift position. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 181
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 458
When the shift lever does not move. . . . . . . . . . . . . . . . . . . . . P. 492
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 88
Reading the meters/adjusting the instrument panel light. . . . . . P. 88
Warning lights/indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . P. 84
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . P. 465
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 90
Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 90
When the warning messages are displayed . . . . . . . . . . . . . . P. 472
1
2
3
4

19
Pictorial index
Parking brake pedal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 187
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 187
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 241
Warning buzzer/message . . . . . . . . . . . . . . . . . . . . . . . . P. 465, 473
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 186
Headlight switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 188
Headlights/parking lights/tail lights/
daytime running lights*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 188
Fog lights*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 191
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . P. 192
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 192
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 415
Warning lights/warning messages. . . . . . . . . . . . . . . . . . . . . . P. 473
Hood lock release lever. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 405
Tilt steering lock release lever . . . . . . . . . . . . . . . . . . . . . . . P. 124
Manual air conditioning system*1. . . . . . . . . . . . . . . . . . . . P. 336
Automatic air conditioning system*1. . . . . . . . . . . . . . . . . P. 343
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 336, 343
Back window defogger*2. . . . . . . . . . . . . . . . . . . . . . . . . P. 338, 345
Windshield wiper de-icer*1. . . . . . . . . . . . . . . . . . . . . . . P. 339, 346
Multimedia system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 250
*1: If equipped
*2: For CrewMax models
5
6
7
8
9
10
11

20 Pictorial index
■Switches
The illustration represents the instrument panel for the front separated type
seat.
Driving position memory switches*1. . . . . . . . . . . . . . . . . . P. 116
Power window switches*2. . . . . . . . . . . . . . . . . . . . . . . . . . P. 134
Door lock switch*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 103
Window lock switch*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 134
Outside rear view mirror switches*2. . . . . . . . . . . . . . . . . . P. 130
Personal/interior lights main switch . . . . . . . . . . . . . . . . . . P. 354
Cargo lamp main switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 355
Manual headlight leveling dial*2. . . . . . . . . . . . . . . . . . . . . P. 189
BSM main switch*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
Power back window switch*3. . . . . . . . . . . . . . . . . . . . . . . . P. 138
Intuitive parking assist switch*2. . . . . . . . . . . . . . . . . . . . . P. 202
VSC off switch . . . . . . . . . . . . . . . . . . . . . . . . P. 228, 231, 233, 234
TOW/HAUL switch*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 184
Trailer brake controller*2. . . . . . . . . . . . . . . . . . . . . . . . . . . P. 237
1
2
3
4
5
6
7
8
9
10
11
12
13
14
