TP-Link TL-PA4020P User manual

Quick Installation Guide
More: To add additional Powerline
adapters and extenders with the default
settings, simply plug them into the wall
sockets on the same electrical circuit.
Applicable to TL-PA4020P and its multiple-pack kits
AV600 2-port Passthrough Powerline Adapter
7106506195 REV3.0.0
Plug and Play
* TL-PA4020P KIT(European version) is used for demonstration in this QIG.
Powerline
Adapter
Router
WAN LAN
1
2
3
4Enjoy!
Attention
Wait until the powerline
LED turns on.
Power Strip
600Mbps
600Mbps
600Mbps
Adapter
Wall Outlet

Set Up a Secure Powerline Network by Pairing (Recommended)
LED and Item Legend
You can use the Pair button on two devices at a time to create or join a secure powerline network.
Tips: We recommend that you plug in the powerline devices near each other when pairing.
To create a secure powerline network: To join an existing secure powerline network:
FAQ (Frequently Asked Questions)
Existing Powerline Network
1 Press the Pair button
for 1 second.
1 Press the Pair button for 1 second on any powerline
device in the existing powerline network.
2 Within 2 minutes, press the
Pair button for 1 second.
3 Done. 2 Within 2 minutes, press the
Pair button for 1 second.
3 Done.
More advanced configurations, such as firmware upgrade and QoS configuration, can be accessed through the tpPLC Utility (for Windows
only). You can download and install the tpPLC Utility from the TP-LINK official website.
DESCRIPTIONITEM
Press and hold for 1 second to set up or join a secure powerline network.
Press and hold for 8 seconds to leave an existing powerline network.
Pair Button
Uses as an electrical outlet expansion for power strips or household appliances.
It can remove some electrical noise that might affect powerline performance.
Integrated
Electrical Socket
Q1. How to troubleshoot if there is no Internet connection in my powerline network?
A1. Make sure all powerline devices are on the same electrical circuit.
A2. Make sure the Powerline LEDs light up on all of your powerline devices. If they do not, reset or pair all your powerline devices.
A3. Make sure all hardware connections are correctly and securely connected.
A4. Check if you have an Internet connection by connecting the computer directly to the modem or router.
A5. Make sure your computer’s IP address is in the same segment as your router’s.
Q2. What can I do if a successfully-paired powerline device does not reconnect after it has been
moved to a new location?
A1. Try another socket and make sure it is on the same electrical circuit.
A2. Try to pair it again, and make sure the Powerline LED is on.
A3. Check for possible interference, such as a washer, air conditioner or other household appliance that may be too close to one of the
powerline devices.
©2016 TP-LINK
Power
DESCRIPTIONLED STATUS
Powerline
Ethernet
On/Off
Blinking
On
Off
On/Off
The powerline adapter is on or off.
Once every second: Pairing is in process.
Once every 15 seconds: Power-Saving Mode is on.*
The powerline adapter is connected to a powerline network.
The powerline adapter is not connected to any powerline network or
is in Power-Saving Mode.
The Ethernet port is connected or not connected.
* Five minutes after the device connected to the powerline adapter is turned off or inactive, the powerline
adapter will automatically switch to Power-Saving Mode.
For more information, please visit our website:
http://www.tp-link.com
