Quick Installation Guide
Connect the Hardware
Register the Terminal
Connect to the Internet
1-Port XGS-PON Terminal
XGZ030
Establish your internet connection according to your ISP's instructions.
Note: If you need assistance, contact your ISP.
If the PON LED is solid on, please skip to Connect to the Internet.
BGo to Network > GPON Settings > GPON Registration.
Enter the GPON Password and/or GPON SN provided by
your ISP (Internet Service Provider) to register the Terminal
and click Save.
2 1
Power adapter Terminal
Enjoy!
http://192.168.1.1
Internet
Verify that the hardware connection
is correct by checking these LEDs.
3
Power: On
PON: On or Flashing
LOS: O
1Connect your computer to the Terminal via an Ethernet cable.
3Register the Terminal via a web browser.
Ethernet Cable
ALaunch a web browser and type in http://192.168.1.1 in the
address bar. Set and confirm your password to log in to the
Terminal.
If the Terminal’s LAN IP address is 192.168.1.1, please type
in IP address 192.168.1.x (x is from 2 to 253), subnet mask
255.255.255.0, and default gateway 192.168.1.1.
2Configure TCP/IP Properties manually on your computer.
Save
New Password
Conrm Password
Low Middle High
SN Type:
GPON SN:
Password Type:
GPON Password:
Normal Mode
GPON Registration
OLT Mode:
ASCII+HEX HEX
ASCII HEX

Q1. What should I do if I cannot access the web management page?
A1. Make sure that the computer is properly connected to the Terminal via the Ethernet cable.
A2. Make sure that an IP address is set for the computer connected to the Terminal.
A3. Make sure that http://192.168.1.1 is correctly entered, or use another web browser and try again.
A4. Disable then enable the network adapter being used.
A5. Restore the Terminal to its factory default settings and reconfigure your Terminal by following the
instructions in this Quick Installation Guide.
Q2. What should I do if I cannot access the internet?
A1. Make sure that all cables are connected properly and securely to the Terminal.
A2. Check the PON LED and make sure that it is lit and stable, indicating that the internet connection
is established. If not, make sure that the provided GPON Password and/or GPON SN are entered
correctly in the Network > GPON Settings >GPON Registration page.
A3. Unplug and reconnect the fiber cable to the Terminal. Wait for 2 minutes and try again.
A4. Make sure that you follow your ISP's specific instructions to connect to the internet.
A5. Make sure that the computer connected to the Terminal.
A6. Contact your ISP if the problem still exists.
Q3. How do I restore my Terminal to its factory default settings?
A. With the Terminal powered on, press and hold the RESET button on the rear panel of the Terminal
for at least 5 seconds, then release the button. The Terminal will restore and reboot automatically.
Need Help?
LED Indicators
On
O
On
Flashing
O
On
Flashing
O
On
Flashing
O
Power is on.
Power is o.
The Terminal is registered with the OLT.
The Terminal is trying to register with the OLT.
The Terminal is not registered with the OLT.
The power of the optical module transmitter is turned o.
The received optical power is lower than the optical receiving
sensitivity.
The received optical power is properly.
A device is connected to the LAN port.
The LAN port is transmitting or receiving data.
No device is connected to the LAN port.
LED Status Indication
(LAN)
(PON)
(LOS)
(Power)
Safety Information
• Keep the device away from water, fire, humidity or hot environments.
• Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
• Do not use damaged charger or USB cable to charge the device.
• Do not use any other chargers than those recommended.
• Adapter shall be installed near the equipment and shall be easily accessible.
EU Declaration of Conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant
provisions of directives 2014/30/EU, 2014/35/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863.
The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce/
UK Declaration of Conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant
provisions of the Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety)
Regulations 2016.
The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca
