Kingtop V510 User manual

User guide
POS terminal V510
Manual Version: V1.0

Copyrights © 2023 Kingtop Corp. All rights reserved. The information contained in this document is
subject to change without notice and should not be construed as a commitment by Kingtop Corp.
Patents and Licenses
For a complete list of all Kingtop Corp. patents, visit https://www.kingtoptec.com/contact
Software License
Proprietary Rights Provisions:
The software drivers provided with this product are copyrighted by Kingtop Corp. and/or
Kingtop Corp.’ suppliers. Although copyrighted, the software drivers are unpublished and
embody valuable trade secrets proprietary to Kingtop Corp. and/or Kingtop Corp. suppliers.
The disassembly, decompilation, and/or Reverse Engineering of the software drivers for
any purpose is strictly prohibited by international law. The copying of the software drivers,
except for a reasonable number of back-up copies is strictly prohibited by international law.
It is forbidden by international law to provide access to the software drivers to any person
for any purpose other than processing the internal data for the intended use of the software
drivers.
Trademarks and Service Marks
Kingtop Corp. is a trademark of Kingtop Corp., and the other trademarks, logos, and
service marks (collectively the “Trademarks”) used in this user manual are the property of
Kingtop Corp. or their respective owners. Nothing contained in this user manual should be
construed as granting by implication, estoppel, or otherwise, a license or right of use of
Kingtop Corp. or any other Trademark displayed in this user manual without the written
permission of Kingtop Corp. or its respective owners.
• Kingtop Corp., and the Kingtop Corp. logo are all trademarks of Kingtop Corp.
• Microsoft and Windows are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/orother countries.
The names of actual companies and products mentioned in this user manual may be the
trademarks of their respective owners.

Contents
1. Appearance Description ...................................................................................- 1 -
Front view ......................................................................................................- 1 -
Back view ...................................................................................................... - 2 -
Side view ....................................................................................................... - 3 -
2. Printing Instructions ......................................................................................... - 4 -
Printing tips ....................................................................................................- 4 -
System pre-production software list .............................................................. - 4 -
3. Precautions ......................................................................................................- 5 -
Safety Warning .............................................................................................. - 5 -
Important safety instructions ..........................................................................- 5 -
Suggestions ...................................................................................................- 5 -
Declaration .................................................................................................... - 6 -
Disclaimer ......................................................................................................- 6 -
4. Proper Battery Use and Disposal .................................................................... - 7 -
5. Limited Warranty and liability ...........................................................................- 8 -

- 1 -
1. Appearance Description
Front view
❶NFC reader —— For Proximity card, membership card
❷Printer —— Printing documents in power-on mode
❸Power button—— Short press and Long press
Short press: light up the screen, lock the screen
Long press: In the off state, press and hold for 2~3 seconds to turn on the phone.
Press and hold for 2~3 seconds to turn off or restart.
In the dead state, press and hold for 11 seconds to restart automatically.
❹Volume keys—— Adjust the volume level (the button can be set as a quick swipe key,
which requires application support).
❺Type-C —— For charge devices and for developer debugging.
❻Soft keys —— To help user to complete various operations quickly.

- 2 -
Back view
❶Camera —— Support for taking pictures and 1D/2D quick scan.
❷Speaker —— Remind merchants of each transaction in a timely manner
❸SIM Slot
Note:When inserting or removing the SIM card, please make sure the machine is off, as
plugging and unplugging in the on state may cause the machine to malfunction.
❹PSAM Slot —— Used to insert encrypted PSAM CPU card.
❺QR code reader——Used to read product barcodes and cell phone payment codes.
❻TF Slot
❼SIM Slot

- 3 -
Side view
How to Put Thermal Paper Roll Correctly?

- 4 -
2. Printing Instructions
Printing tips
-This machine supports 58mm thermal paper, 57±0.5mm ×40mm.
-Please open the paper compartment (shown in the illustration) by opening the cover handle,
do not force the paper to prevent the print head gear from wearing out.
-Place the paper in the paper compartment correctly in the direction shown in the figure, and
pull out part of the paper to the outside of the cutter (Figure 1-1).
-Cover the paper compartment cover, the paper installation is complete figure (Figure 1-2).
Note:If the print content is blank, please check if the paper roll is placed in the opposite
direction.
System pre-production software list
1. Function key customization, BaseService, custom services (wallpaper, boot animation)
2. Developer's Guide (debugging assistant) , User's Guide, boot guide, remote assistance
3. How to check the above software details: select "Settings->Applications", select the
corresponding software name to view the information.
4. Software uninstall method: select "Settings->Applications->Manage
Applications->Uninstall" to uninstall the application, or long press the icon and drag it to
the trash to uninstall.

- 5 -
3. Precautions
Safety Warning
Please insert the AC plug into the AC outlet corresponding to the marked input on the
accessory power adapter
This is a Class A product. In living environments, this product may cause radio interference.
In this case, the user may be required to take practical measures against interference.
-Use only the battery supplied with the unit.
-Do not replace the battery when explosive gases are present.
-Do not charge in hazardous locations.
Important safety instructions
-Avoid installation or use during lightning, otherwise there is a risk of being struck by
lightning.
-When you find abnormal smell, overheating or smoke, please cut off the power immediately.
-Do not touch the tear-off knife as it is sharp!
-When you find residual glue on the label print head, you can do the following maintenance.
-The device will be turned off, use cotton swabs or non-woven dipped in 75% concentration of
alcohol wipe the print head, wait for the alcohol to dry and then turn on again.
Note:Do not use hard objects or sharp objects, otherwise it will damage the print head.
Suggestions
-Do not use in extreme cold or hot environments, such as near a fire or a lit cigarette.
-Do not drop, throw or bend the printer.

- 6 -
-Use in a clean and dust-free environment to avoid small objects falling into the terminal.
-Do not use in the vicinity of medical equipment without permission.
Declaration
Our company is not responsible for the following actions
-Damage caused by not using and maintaining the device under the conditions described in
this guide.
-For damage or problems caused by options or consumables (other than the original or
approved products provided by the Company).
(No modification or change of the product is authorized without our consent)
The operating system of this product supports official system updates. If the user brushes a
third-party ROM system or modifies the system files by cracking, it may lead to system
instability, as well as security risks and security threats.
Disclaimer
Due to the update of the product, some details of this document may not match the product,
please refer to the actual product, the interpretation of this document belongs to our company.
We reserve the right to modify this manual without prior notice.

- 7 -
4. Proper Battery Use and Disposal
IMPORTANT In event of a battery leak:
Do not allow the liquid to come in contact with the skin or the eyes. lf contact has been made, wash
the affected area with large amounts of water and seek medical advice.
Seek medical advice immediately if a battery has been swallowed.
Communicate the appropriate steps to be taken if a hazard occurs. Due to the transmission and
reception properties of wireless communications, data occasionally can be lost or delayed.
Please review the following guidelines for safe and responsible battery use.
Do not disassemble or open, crush, bend or deform, puncture, or shred.
Do not modify or re-manufacture, attempt to insert a foreign object into the battery,
immerse or expose to water or other liquids, or expose to fire, explosion, or other hazard.
Only use the battery for the system for which it was specified.
Only use the battery with a charging system that has been qualified with the system per
this standard. Use of an unqualified battery or charger may present a risk of fire,
explosion,leakage, or other hazard.
Do not short circuit a battery or allow a metallic or conductive object to contact the
battery terminals.
Replace the battery only with another battery that has been qualified with the system per
this standard. Use of an unqualified battery may present a risk of fire, explosion, leakage,
or other hazard.
Promptly dispose of used batteries in accordance with local regulations.
Battery usage by children should be supervised.
Avoid dropping the POS or battery. If the POS or the battery is dropped, especially on a
hard surface, and the user suspects damage, take it to a service center for inspection.
Improper battery use may result in a fire, explosion, or other hazard.

- 8 -
5. Limited Warranty and liability
Kingtop Corp. warrants for the 12-month period immediately following receipt of the Product
by Purchaser that the Product will be free from defects in material and workmanship under
normal use.
THESE WARRANTIES ARE EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ALL IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
The exclusive remedy for a claim under this warranty shall be limited to the repair or
replacement, at KINGTOP CORP’ option, of defective or non-conforming materials, parts or
components. The foregoing warranties do not extend to
(I) non conformities, defects or errors in the Products due to accident, abuse, misuse or
negligent use of the Products or use in other than a normal and customary manner,
environmental conditions not conforming to KINGTOP CORP’ specification, of failure to
follow prescribed installation, operating and maintenance procedures,
(II) defects, errors or nonconformities in the Product due to modifications, alterations,
additions or changes not made in accordance with KINGTOP CORP’ specifications or
authorized by KINGTOP CORP,
(III) normal wear and tear,
(IV) damage caused by force of nature or act of any third person,
(V) shipping damage,
(VI) service or repair of Product by the purchaser without prior written consent from
KINGTOP CORP,
(VII) products designated by KINGTOP CORP as beta site test samples, experimental,
developmental, reproduction, sample, incomplete or out of specification Products, or
(VIII) returned products if the original identification marks have been removed or altered.
