TP-Link TL-MR6400 User manual

Report No.: BL-SZ1770154-601
2/25
Revision History
Version Issue Date Revisions Content
Rev. 01 Nov. 08, 2017 Initial Issue
Rev. 02 Dec. 06, 201 Revise the blocking signal on the page 23
and add the test data of adaptivity.
TABLE OF CONTENTS
1 ADMINISTRATIVE DATA (GENERAL INFORMATION)........................................................................................4
1.1 Identification of the Testing Laboratory..............................................................................................................4
1.2 Identification of the Responsible Testing Location...........................................................................................4
1.3 Laboratory Condition.............................................................................................................................................4
1.4 Announce................................................................................................................................................................4
2 PRODUCT INFORMATION........................................................................................................................................5
2.1 Applicant Information............................................................................................................................................5
2.2 Manufacturer Information.....................................................................................................................................5
2.3 Factory Information...............................................................................................................................................5
2.4 General Description for Equipment under Test (EUT).................................................................................... 5
2.5 Ancillary Equipment.............................................................................................................................................. 5
2.6 Technical Information........................................................................................................................................... 6
3 SUMMARY OF TEST RESULTS...............................................................................................................................8
4 GENERAL TEST CONFIGURATIONS..................................................................................................................... 9
4.1 Test Environments................................................................................................................................................ 9
4.2 Test Equipment List.............................................................................................................................................. 9
4.3 Test Software List............................................................................................................................................... 10
4.4 Measurement Uncertainty..................................................................................................................................10
4.5 Description of Test Setup...................................................................................................................................11
4.5.1 For Conducted Test.....................................................................................................................................11
4.5.2 For Receiver Blocking Test........................................................................................................................11
5 Test Type and Test Results......................................................................................................................................12
5.1 Transmitter Parameters..................................................................................................................................... 12
5.1.1 Adaptivity (adptive equipment using modulations other than FHSS)..................................................12
5.2 Receiver Parameters..........................................................................................................................................14
5.2.1 Receiver Blocking........................................................................................................................................14

Report No.: BL-SZ1770154-601
3/25
ANNEX A TEST RESULT............................................................................................................................................ 16
A.1 Adaptivity (adaptive equipment using modulations other than FHSS )......................................................16
A.2 Receiver Blocking...............................................................................................................................................23
ANNEX B TEST SETUP PHOTOS.............................................................................................................................25
ANNEX C EUT EXTERNAL PHOTOS.......................................................................................................................25
ANNEX D EUT INTERNAL PHOTOS........................................................................................................................ 25
ANNEX E INFORMATIVE............................................................................................................................................25

Report No.: BL-SZ1770154-601
4/25
1 ADMINISTRATIVE DATA (GENERAL INFORMATION)
1.1 Identification of the Testing Laboratory
Company Name Shenzhen BALUN Technology Co., Ltd.
Address Block B, 1st FL, Baisha Science and Technology Park, Shahe Xi Road,
Nanshan District, Shenzhen, Guangdong Province, P. R. China
Phone Number [phone]
1.2 Identification of the Responsible Testing Location
Test Location Shenzhen BALUN Technology Co., Ltd.
Address Block B, 1st FL, Baisha Science and Technology Park, Shahe Xi Road,
Nanshan District, Shenzhen, Guangdong Province, P. R. China
Accreditation
Certificate
The laboratory has been listed by Industry Canada to perform
electromagnetic emission measurements. The recognition numbers of
test site are 11524A-1.
The laboratory has been listed by US Federal Communications
Commission to perform electromagnetic emission measurements. The
recognition numbers of test site are 832625.
The laboratory is a testing organization accredited by China National
Accreditation Service for Conformity Assessment (CNAS) according to
ISO/IEC 17025. The accreditation certificate number is L6791.
Description
All measurement facilities used to collect the measurement data are
located at Block B, FL 1, Baisha Science and Technology Park, Shahe
Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R.
China 518055
1.3 Laboratory Condition
Ambient Temperature 20 to 25℃
Ambient Relative
Humidity 45% - 55%
Ambient Pressure 100 kPa - 102 kPa
1.4 Announce
(1) The test report reference to the report template version V1.0.
(2) The test report is invalid if not marked with the signatures of the persons responsible for preparing and
approving the test report.
(3) The test report is invalid if there is any evidence and/or falsification.
(4) The results documented in this report apply only to the tested sample, under the conditions and modes of
operation as described herein.
(5) This document may not be altered or revised in any way unless done so by BALUN and all revisions are duly
noted in the revisions section.
(6) Content of the test report, in part or in full, cannot be used for publicity and/or promotional purposes without
prior written approval from the laboratory.

Report No.: BL-SZ1770154-601
5/25
2 PRODUCT INFORMATION
2.1 Applicant Information
Applicant TP-Link Technologies Co., Ltd.
Address Building 24 (floors 1,3,4,5) and 28 (floors1-4) Central Science and
Technology Park, Shennan Rd, Nanshan, Shenzhen, China
2.2 Manufacturer Information
Manufacturer TP-Link Technologies Co., Ltd.
Address Building 24 (floors 1,3,4,5) and 28 (floors1-4) Central Science and
Technology Park, Shennan Rd, Nanshan, Shenzhen, China
2.3 Factory Information
Factory N/A
Address N/A
2.4 General Description for Equipment under Test (EUT)
EUT Name 300Mbps Wireless N 4G LTE Router
EUT Type Stand-alone equipment
Under Test Model
Name TL-MR6400
Series Model Name N/A
Description of Model
name differentiation N/A
Hardware Version V2
Software Version 1.0.15
Dimensions (Approx.) N/A
Weight (Approx.) N/A
Network and Wireless
connectivity
2G Network GPRS/EDGE 900/1800
3G Network WCDMA/HSDPA/HSUPA Band 1/8
4G Network FDD LTE Band 1/3/7/8/20
TDD LTE Band 38/40
WIFI 802.11b, 802.11g, 802.11n(HT20/40)
2.5 Ancillary Equipment
Ancillary Equipment 1
Adapter 1
Brand Name tp-link
Model No. T120100-2C1(EU Plug)Note
Serial No. N/A
Rated Input 100-240 V , 0.3 A, 50/60 Hz
Rated Output 12 V 1A
Ancillary Equipment 2
Adapter 2
Brand Name tp-link
Model No. T120100-2D1(UK Plug)Note
Serial No. N/A

Report No.: BL-SZ1770154-601
6/25
Rated Input 100-240 V , 0.3 A, 50/60 Hz
Rated Output 12 V 1A
Ancillary Equipment 3
Adapter 3
Brand Name tp-link
Model No. T120100-2E1(AU Plug)Note
Serial No. N/A
Rated Input 100-240 V , 0.3 A, 50/60 Hz
Rated Output 12 V 1A
Note: The adapter are same with electrical parameters and internal circuit structure, only differ in
model name and adapter plug, T120100-2C1 (EU Plug) as the main for tested in this report.
2.6 Technical Information
The requirement for the following technical information of the EUT was tested in this report:
Frequency Range
802.11b/g/n(20 MHz): 2.412 GHz - 2.472 GHz
fc= 2412 MHz + (N-1)*5 MHz, where
-f
c= “Operating Frequency” in MHz,
- N = “Channel Number” with the range from 1 to 13.
802.11n(40 MHz): 2.422 GHz - 2.462 GHz
fc= 2412 MHz + (N-1)*5 MHz, where
-f
c= “Operating Frequency” in MHz,
- N = “Channel Number” with the range from 3 to 11.
Modulation Type DSSS, OFDM
Equipment Type
(LBT / non- LBT) LBT based Detect and Avoid
Adaptive or non-adaptive Adaptive
LBT Based Yes (Load Based)
Geo-location Capability Declared by manufacturer
Antenna System (eg., MIMO,
Smart Antenna) 11b/g CDD; 11n CDD&MIMO
Categorization as Correlated or
Completely Uncorrelated CDD Correlated; MIMO Completely Uncorrelated
Antenna
Type
Antenna 0 (ANT 0) Internal Antenna
Antenna 1 (ANT 1)
Antenna
Gain
Antenna 0 (ANT 0) 2.70 dBi
Antenna 1 (ANT 1) 2.70 dBi
Beamforming Gain N/A
The Max RF Output power 17.10 dBm
Receiver Category 1

Report No.: BL-SZ1770154-601
7/25
Modulation technology Modulation Type Transfer Rate (Mbps)(Single RF
path)
DSSS (802.11b)
DBPSK 1
DQPSK 2
CCK 5.5/ 11
OFDM (802.11g)
BPSK 6 / 9
QPSK 12 / 18
16QAM 24 / 36
64QAM 48 / 54
OFDM
(802.11n-20 MHz)
BPSK 6.5
QPSK 13/19.5
16QAM 26/39
64QAM 52/58.5/65
OFDM
(802.11n-40 MHz)
BPSK 13.5
QPSK 27/40.5
16QAM 54/81/108
64QAM 121.5/135
Note: Preliminary tests were performed in different data rate in above table to find the worst
radiated emission. The data rate shown in the table below is the worst-case rate with respect to
the specific test item. Investigation has been done on all the possible configurations for
searching the worst cases. The following table is a list of the test modes shown in this test
report.
Test Items Mode Data Rate Channel
Receiver Blocking 11b 1 Mbps 1/13
Adaptivity (adptive equipment
using modulations other than
FHSS )
11b/11g/11n20/11n40 1/6/6.5/13.5 Mbps 1/13 3/11
Mode Channel Channel Number Frequency (MHz)
11b HIIGH/MIDDLE/LOW(H/M/L) 13/7/1 2472/2442/2412
11g HIIGH/MIDDLE/LOW(H/M/L) 13/7/1 2472/2442/2412
11n20 HIIGH/MIDDLE/LOW(H/M/L) 13/7/1 2472/2442/2412
11n40 HIIGH/MIDDLE/LOW(H/M/L) 11/7/3 2462/2442/2422

Report No.: BL-SZ1770154-601
8/25
3SUMMARYOFTESTRESULTS
The EUT has been tested according to ETSI EN 300 328 V2.1.1 (2016-11).
No. Identity Document Title
1ETSI EN 300 328
V2.1.1 (2016-11)
Wideband transmission systems; Data transmission equipment operating in
the 2,4 GHz ISM band and using wide band modulation techniques;
Harmonised Standard covering the essential requirements of article 3.2 of
Directive 2014/53/EU
Test items and the results are as follows:
Report
Section
Standard
Rule Description Channel Test Result Verdict Remark
5.1.1 4.3.2.6
Adaptivity (adptive
equipment using
modulations other than
FHSS )
Low/High ANNEX A.1 Pass Note
5.2.1 4.3.2.11 Receiver Blocking Low/ High ANNEX A.1 Pass Note
Note: This is a supplementary report of Report No.:ER571484A, which was issued by SPORTON
INTERNATIONAL INC. on Oct. 22, 2015. The differences between them are updraded standard version to
EN300328 V2.1.1, the Receiver Blocking test item need to be performed in this report.

Report No.: BL-SZ1770154-601
9/25
4 GENERAL TEST CONFIGURATIONS
4.1 Test Environments
During the measurement, the normal environmental conditions were within the listed ranges:
Relative Humidity 45% - 55%
Atmospheric Pressure 100 kPa - 102 kPa
Temperature NT (Normal Temperature) +22℃to +25℃
Working Voltage of the EUT NV (Normal Voltage) 230 V
4.2 Test Equipment List
Description Manufacturer Model Serial No. Cal. Date Cal. Due
Spectrum Analyzer ROHDE&SCHWARZ FSV-30 103118 2017.06.22 2018.06.21
Vector Signal Generator ROHDE&SCHWARZ SMBV100A 260592 2017.06.22 2018.06.21
Signal Generator ROHDE&SCHWARZ SMB100A 177746 2017.06.22 2018.06.21
Switch Unit with
OSP-B157 ROHDE&SCHWARZ OSP120 101270 2017.06.22 2018.06.21
EMI Receiver ROHDE&SCHWARZ ESRP 101036 2017.06.22 2018.06.21
LISN SCHWARZBECK NSLK 8127 8127-687 2017.06.22 2018.06.21
Bluetooth Tester ROHDE&SCHWARZ CBT 101005 2017.06.22 2018.06.21
Power Splitter KMW DCPD-LDC 1305003215 -- --
Power Sensor ROHDE&SCHWARZ NRP-Z21 103971 2017.06.22 2018.06.21
Attenuator (20 dB) KMW ZA-S1-201 110617091 -- --
Attenuator (6 dB) KMW ZA-S1-61 1305003189 -- --
DC Power Supply ROHDE&SCHWARZ HMP2020 018141664 2017.06.22 2018.06.21
Temperature Chamber ANGELANTIONI
SCIENCE NTH64-40A 1310 2017.06.22 2018.06.21
Test Antenna-
Loop(9 kHz-30 MHz) SCHWARZBECK FMZB 1519 1519-037 2017.06.22 2018.06.21
Test Antenna-
Bi-Log(30 MHz-3 GHz) SCHWARZBECK VULB 9163 9163-624 2017.06.22 2018.06.21
Test Antenna-
Horn(1-18 GHz) SCHWARZBECK BBHA 9120D 9120D-1148 2017.06.22 2018.06.21
Test Antenna-
Horn(15-26.5 GHz) SCHWARZBECK BBHA 9170 9170-305 2017.06.22 2018.06.21
Anechoic Chamber RAINFORD 9m*6m*6m N/A 2017.02.24 2019.02.23
Bluetooth Signaling Unit ROHDE&SCHWARZ CMW270. 100607 2017.06.22 2018.06.21
Frequency Signal Analyzer ROHDE&SCHWARZ FSL3 103640/003 2017.06.22 2018.06.21
Signal Generator ROHDE&SCHWARZ SMF100A 1167.0000k0
2/104260 2017.06.22 2018.06.21
Switching Unit 7Layers TCOT -- -- --
Vector Signal Generator ROHDE&SCHWARZ SMJ100A 1403.4507k0
2/101859 2017.06.22 2018.06.21
Shielded Enclosure ChangNing CN-130701 130703 -- --

Report No.: BL-SZ1770154-601
10 /25
4.3 Test Software List
Description Manufacturer Software Version Serial No.
TS8997 EMC32 ROHDE&SCHWARZ V10.00.00 N/A
4.4 Measurement Uncertainty
The following measurement uncertainty levels have been estimated for tests performed on the EUT as specified
in CISPR 16-4-2.
This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using
acoveragefactorofk=2.
Measurement Value
Occupied Channel Bandwidth ±4 %
RF output power, conducted ±1.4 dB
Power Spectral Density, conducted ±2.5 dB
Unwanted Emissions, conducted ±2.8 dB
All emissions, radiated ±5.4 dB
Temperature ±1 °C
Humidity ±4 %

Report No.: BL-SZ1770154-601
11 /25
4.5 Description of Test Setup
4.5.1 For Conducted Test
(Diagram 1)
4.5.2 For Receiver Blocking Test
(Diagram 2)

Report No.: BL-SZ1770154-601
12 /25
5 Test Type and Test Results
5.1 Transmitter Parameters
5.1.1 Adaptivity (adptive equipment using modulations other than FHSS)
5.1.1.1 Limit
Requirement
Operational Mode
Non-LBT
based
Detect and
Avoid
LBT based Detect and Avoid
Frame Based
Equipment
Load Based
Equipment
(CCA using
'energy detect')
Load Based
Equipment
(CCA not using any
of the mechanisms
referenced asNote 2)
Minimum Clear Channel
Assessment (CCA) Time NA 18 us (see Note 1)(seeNote
2)18us(seeNote 1)
Maximum Channel
Occupancy (COT) Time 40ms 1msto10ms (seeNote2)13ms
Minimum Idle Period 5% of COT 5% of COT (see Note 2)NA
Extended CCA check NA NA (see Note 2)
a random duration in
the range between
18 μs and at least
160 μs
Short Control Signalling
Transmissions
Maximum duty cycle of 10 % within an observation period of 50 ms
(see Note 3)
Note 1: The CCA time used by the equipment shall be declared by the supplier.
Note 2: Load Based Equipment may implement an LBT based spectrum sharing mechanism based
on the Clear Channel Assessment (CCA) mode using energy detect, as described in IEEE
802.11™-2012 [i.3] clause 9, clause 10, clause 16, clause 17, clause 19 and clause 20, or in IEEE
802.15.4™-2011 [i.4], clause 4, clause 5 and clause 8.
Note 3: Adaptive equipment may or may not have Short Control Signaling Transmissions.
Interference threshold level:
Maximum transmit power (PH)
EIRP dBm Threshold level (TL)
20 -70 dBm / MHz
Note 1: TL = -70 dBm/MHz + 10 × log10 (100 mW / Pout) (Pout in mW e.i.r.p.).
Note 2: transmitter the CCA threshold level (TL) shall be equal or lower than -70 dBm/MHz at
theinputtothereceiver(assuminga0dBireceiveantenna).
Unwanted Signal parameters
Wanted signal mean power
from companion device
Unwanted signal
frequency
(MHz)
Unwanted CW signal
power (dBm)
sufficient to maintain the link
(see Note 2)
2 395 or 2 488,5
(see Note 1)
-35
(see Note 3)
Note 1: The highest frequency shall be used for testing operating channels within the range
2400 MHz to 2442 MHz, while the lowest frequency shall be used for testing operating channels

Report No.: BL-SZ1770154-601
13 /25
within the range 2 442 MHz to 2 483.5 MHz. See clause 5.4.6.1.
Note 2: A typical value which can be used in most cases is -50 dBm/MHz.
Note 3: The level specified is the level in front of the UUT antenna. In case of conducted
measurements, this level has to be corrected by the actual antenna assembly gain.
5.1.1.2 Test Setup
The section 4.5.1 (Diagram 1) test setup description was used for this test. The photo of test setup please refer to
ANNEX B.
5.1.1.3 Test Procedure
Reference to ETSI EN 300 328 V2.1.1 clause 5.4.6.2.
5.1.1.4 Test Result
Please refer to ANNEX A.1.

Report No.: BL-SZ1770154-601
14 /25
5.2 Receiver Parameters
5.2.1 Receiver Blocking
Limit
While maintaining the minimum performance criteria as defined in clause 4.3.1.12.3, the blocking levels at
specified frequency offsets shall be equal to or greater than the limits defined for the applicable receiver category
provided in table 6, table 7 or table 8.
Receiver Category 1 equipment
Wanted signal mean power from
companion device (dBm)
Blocking signal
frequency(MHz)
Blocking signal
power (dBm)
(see Note 2)
Type of blocking
signal
Pmin + 6 dB 2380 -53 CW
2 503.5 -53 CW
Pmin + 6 dB
2300 -47 CW
2330 -47 CW
2360 -47 CW
Pmin + 6 dB
2 523.5 -47 CW
2 553.5 -47 CW
2 583.5 -47 CW
2 613.5 -47 CW
2 643.5 -47 CW
2 673.5 -47 CW
Note 1: Pmin is the minimum level of wanted signal (in dBm) required to meet the minimum performance
criteria as defined in clause 4.3.1.12.3 in the absence of any blocking signal.
Note 2: The levels specified are levels in front of the UUT antenna. In case of conducted measurements,
the levels have to be corrected by the actual antenna assembly gain.
Receiver Category 2 equipment
Wanted signal mean power from
companion device (dBm)
Blocking signal
frequency(MHz)
Blocking signal
power (dBm)
(see Note 2)
Type of blocking
signal
Pmin + 6 dB 2380 -57 CW
2 503.5 -57 CW
Pmin + 6 dB 2300 -47 CW
2 583.5 -47 CW
Note 1: Pmin is the minimum level of the wanted signal (in dBm) required to meet the minimum
performance criteria as defined in clause 4.3.1.12.3 in the absence of any blocking signal.
Note 2: The levels specified are levels in front of the UUT antenna. In case of conducted measurements,
the levels have to be corrected by the actual antenna assembly gain.

Report No.: BL-SZ1770154-601
15 /25
Receiver Category 3 equipment
Wanted signal mean power from
companion device (dBm)
Blocking signal
frequency(MHz)
Blocking signal
power (dBm)
(see Note 2)
Type of blocking
signal
Pmin + 12 dB 2 380 -57 CW
2503.5 -57 CW
Pmin + 12 dB 2 300 -47 CW
2583.5 -47 CW
Note 1: Pmin is the minimum level of the wanted signal (in dBm) required to meet the minimum
performance criteria as defined in clause 4.3.1.12.3 in the absence of any blocking signal.
Note 2: The levels specified are levels in front of the UUT antenna. In case of conducted
measurements, the levels have to be corrected by the actual antenna assembly gain.
Categorization
Receiver
category Definition
1Adaptive equipment with a maximum RF output power greater than 10 dBm e.i.r.p. shall
be considered as receiver category 1 equipment.
2
Non-adaptive equipment with a Medium Utilization (MU) factor greater than 1 % and less
than or equal to 10 % or adaptive equipment with a maximum RF output power of 10 dBm
e.i.r.p. shall be considered as receiver category 2 equipment.
3
Non-adaptive equipment with a maximum Medium Utilization (MU) factor of 1 % or
adaptive equipment with a maximum RF output power of 0 dBm e.i.r.p. shall be
considered as receiver category 3 equipment
5.2.1.1 Test Setup
See the section 4.5.2 (Diagram 2) for test setup description. The photo of test setup please refer to ANNEX B.
5.2.1.2 Test Procedure
Reference to ETSI EN 300 328 V2.1.1 clause 5.4.11.2.
5.2.1.3 Test Result
Please refer to ANNEX A.2.

Report No.: BL-SZ1770154-601
16 /25
ANNEX A TEST RESULT
A.1 Adaptivity (adaptive equipment using modulations other than FHSS )
Test Method&Interference threshold level
Tes t M e t hod Interference threshold level
Radiated
Conducted
The maximum EIRP power is 17.1 dBm and antenna gain is 2.7 dBi.
Threshold level= -70 dBm/MHz +10 × log10 (100 mW / Pout) = -67.10 dBm/MHz .The
interference signal level to the UUT is -67.10 dBm/MHz
Test plot
99% Bandwidth
Threshold level

Report No.: BL-SZ1770154-601
17 /25
Tes t D ata
Test step 1
Test Conditions Test Result
Temperature Voltage Tes t Mo de Tes t
Channel
Number of
Bursts
Max Burst
Power(dBm)
COT
(ms)
Limit
(ms)
CCA
Tim(μs) Limit(μs)
NT NV
802.11b 2412 19 18.0 2.452 13 45.000 18
2472 19 16.4 1.314 13 44.000 18
802.11g 2412 87 16.3 0.283 13 51.000 18
2472 37 16.2 0.549 13 45.000 18
802.11n20 2412 17 17.4 3.211 13 54.000 18
2472 17 16.8 3.232 13 57.000 18
802.11n40 2422 19 17.6 3.218 13 52.000 18
2462 14 16.4 3.243 13 61.000 18
Test Verdi ct Pass
Tes t s tep 2
Note: The least monitoring time during the adapitivity test is 60s, please refer to the test plot as shown below.
Test step 2_2nd
Temperature Voltage Tes t Mo de Test
Channel Number of Bursts Short Signaling (%) Limit (%)
NT NV
802.11b 2412 0 0.0 10
2472 0 0.0 10
802.11g 2412 0 0.0 10
2472 0 0.0 10
802.11n20 2412 0 0.0 10
2472 0 0.0 10
802.11n40 2422 0 0.0 10
2462 0 0.0 10
The step 3
Note: The least monitoring time during the blocking test is 60s, please refer to the test plot as shown below.

Report No.: BL-SZ1770154-601
18 /25
Tes t P l ots
Note: Test Step 1 (blue line) means Interferer off / Blocker off.
Test Step 2 (green line) means Interferer on / Blocker off.
Test Step 2_2nd (green line) means Interferer on / Blocker off.
Test Step 3 (red line) means Interferer on / Blocker on.
802.11b: Low Channel Test Step 1 802.11b: Low Channel Test Step 2
-30
-20
-10
0
10
20
0 5 10 15 20 25 30
Level in dBm
Time in ms
Test Step 1
802.11b: Low Channel Test Step 2_2nd 802.11b: Low Channel Test Step 3
-32.6
-32.55
-32.5
-32.45
0 10 20 30 40 50 60
Level in dBm
Time in s
Test Step 3 Limit for Evaluation

Report No.: BL-SZ1770154-601
19 /25
802.11b: High Channel Test Step 1 802.11b: High Channel Test Step 2
-30
-20
-10
0
10
20
0 5 10 15 20 25 30
Level in dBm
Time in ms
Test Step 1
-30
-25
-20
-15
-10
0 10 20 30 40 50 60
Level in dBm
Time in s
Test Step 2 Limit for Evaluation
802.11b: High Channel Test Step 2_2nd 802.11b: High Channel Test Step 3
-30
-25
-20
-15
-10
0 10 20 30 40 50 60
Level in dBm
Time in s
Test Step 3 Limit for Evaluation
802.11g: Low Channel Test Step 1 802.11g: Low Channel Test Step 2
-30
-20
-10
0
10
20
0 5 10 15 20 25 30
Level in dBm
Time in ms
Test Step 1
802.11g: Low Channel Test Step 2_2nd 802.11g: Low Channel Test Step 3
-34
-33
-32
-31
0 20 40 60 80 100 120 140 150
Level in dBm
Time in ms
Test Step 2_2 Limit for Evaluation
-31.55
-31.5
-31.45
0 10 20 30 40 50 60
Level in dBm
Time in s
Test Step 3 Limit for Evaluation

Report No.: BL-SZ1770154-601
20 /25
802.11g: High Channel Test Step 1 802.11g: High Channel Test Step 2
-30
-20
-10
0
10
20
0 5 10 15 20 25 30
Level in dBm
Time in ms
Test Step 1
-30
-25
-20
-15
-10
0 10 20 30 40 50 60
Level in dBm
Time in s
Test Step 2 Limit for Evaluation
802.11g: High Channel Test Step 2_2nd 802.11g: High Channel Test Step 3
-30
-25
-20
-15
-10
0 10 20 30 40 50 60
Level in dBm
Time in s
Test Step 3 Limit for Evaluation
802.11n-20MHz: Low Channel Test Step 1 802.11n-20MHz: Low Channel Test Step 2
-30
-20
-10
0
10
20
0 5 10 15 20 25 30
Level in dBm
Time in ms
Test Step 1
-30.15
-30.1
-30.05
0 10 20 30 40 50 60
Level in dBm
Time in s
Test Step 2 Limit for Evaluation
802.11n-20MHz: Low Channel Test Step 2_2nd 802.11n-20MHz: Low Channel Test Step 3
-35
-34
-33
-32
-31
0 20 40 60 80 100 120 140 150
Level in dBm
Time in ms
Test Step 2_2 Limit for Evaluation
-30.15
-30.1
-30.05
0 10 20 30 40 50 60
Level in dBm
Time in s
Test Step 3 Limit for Evaluation
