Trace Engineering LEGEND I User manual

SSeerriieessII
Designed Specifically for Recreational Vehicles
“The best quality of life improvement we ever made to our rig”
Trace Engineering offers the answer for cost effective Inverter/Chargers for any size RV.
Now anyone can enjoy the benefits of AC power on demand. Get all the famous Trace Legend
Series advantages and rugged reliability in one great package. Take household AC appliances
and conveniences on the road without being tied to the shore power cord or dependent on a
noisy generator. Use the microwave, TV, or tools anytime, day or night; then use shore power
or your generator to automatically charge the battery with up to 50 amps of 3 stage,
temperature compensated charging.
“We used to have to start the generator to run the microwave, now we have AC Power
all the time”
Standard Features
• Choose from 3 models 600, 1100, or 1400 watts of high performance AC output.
• Very high surge allows great motor and microwave starting performance.
• Super “long term over-load” allows double the rated output for 5 minutes or more.
• Rugged design allows tough use and years of service.
• Compact size and easy wiring access allow hardwired connections and out-of-the-way Installations.
• High efficiency means hours of operation from your batteries.
• Adjustable low voltage DC disconnect protects batteries from over-discharge.
• Built-in protection against: over-current, short circuit,
overvoltage, undervoltage, over-temperature.
• Low idle power and adjustable search mode protect
batteries from discharge when the unit is not in use.
Standby Option (SB)
• Automatic 30 amp transfer switch allows transparent
switch-over from battery to shore power or generator
and back.
• Built-in 3 stage battery charger with temperature
compensation charges fast and delivers optimum
battery care.
• Selections for flooded or sealed/Gel Cell battery type.
• Selection for deep or shallow discharge protection.
• Automatic shore power black-out and brown-out
protection.
• Automatic neutral/ground switching.
Optional RC8 remote on/off switch
• Remote On/Off switch with status LED, shows Inverter/charger status and fault conditions.
BTS
• Battery Temperature (BTS) allows the charger to compensate the charge rate based on
temperature conditions.
ENGINEERING
THE POWER COMPANY
INVERTER/CHARGER
UL
®
UL
®
LISTED
39FL
C
POWER CONVERTERS/INVERTERS
AND POWER CONVERTERS/INVERTER
SYSTEMS FOR LAND VEHCLES
STANDARD UL 458
COMMERCIAL AND INDUSTRIAL
POWER SUPPLIES—CERTIFIED TO
CAN/CSA-C22.2 NO. 107.1-M91
5 YEAR WARRANTY!
From
Trace Engineering,
maker of the world’s
most reliable
inverters
5 YEAR WARRANTY!
From
Trace Engineering,
maker of the world’s
most reliable
inverters

SPECIFICATIONS AND FEATURES (rev. 1.0)
MODEL L612 L1112 L1412
Nominal DC Input Voltage 12 VDC 12 VDC 12 VDC
AC Output Voltage (RMS) 120 VAC 120 VAC 120 VAC
Nominal Frequency 60 HZ 60 HZ 60 HZ
Continuous Power @ 25
°Ÿ°Ÿ
C600 VA 1100 VA 1400 VA
Continuous Current @ 25
°Ÿ
C5 amps AC 9 amps AC 12 amps AC
Maximum Current (100 mSec surge) 18 amps AC 22 amps AC 30 amps AC
Maximum Power (Light Bulb Rating) 2500 W 3000 W 3400 W
Efficiency (peak) 92% max 90% max 92% max
DC INPUT REQUIREMENTS
Search Mode 0.022 A (0.4W) 0.045 A (0.5W) 0.060 A (0.7W)
On Mode (no load - idle) 0.400 A (5.0W) 0.450 A (5.5W) 0.600 A (7.0 W)
At Full Rated Power 63 amps 120 amps 153 amps
Input Voltage Range 10.8 to 15.5 VDC 10.8 to 15.5 VDC 10.8 to 15.5 VDC
Low Battery Cutout (w/out SB Option) 9.5 VDC 9.5 VDC 9.5 VDC
High Voltage Cutout 15.7 VDC 15.7 VDC 15.7 VDC
AC OUTPUT CHARACTERISTICS
AC Output Waveform Modified sinewave
Voltage Regulation +/- 5% Maximum, +/- 2.5% Typical
Power Factor Allowed -1 to 1
Frequency Regulation +/- 0.01% (crystal regulated)
ENVIRONMENTAL LIMITATIONS
Enclosure Type Indoor, ventilated, steel chassis with powdercoat finish
Specified Temperature Range 32
°Ÿ
F to 104
°Ÿ
F (0
°Ÿ
C to +40
°Ÿ
C) (output will meet specified tolerances)
Allowed Operating Temperature Range -40
°Ÿ
F to 140
°Ÿ
F (-40
°Ÿ
C to +60
°Ÿ
C) (output may not meet specified tolerances)
Dimensions - Inverter Only 10.5” high, 15.5” wide, 6” deep (when wall mounted)
Dimensions - Shipping 20.5” x 27” x 15.5”
Mounting Wall or Shelf Mount
Weight - Inverter only 25 lbs (11.4 kg) 25 lbs (11.4 kg) 35 lbs (15.9 kg)
Weight - Shipping 30 lbs (13.6 kg) 30 lbs (13.6 kg) 40 lbs (18.2 kg)
STAND-BY (SB) OPTION
Automatic AC Transfer Relay 30 amps AC 30 amps AC 30 amps AC
Maximum Battery Charging Rate 25 amps DC 50 amps DC 50 amps DC
3-stage Charger Regulation Method
Bulk (constant current), Absorption (constant voltage) and Float (maintenance voltage & current)
Selectable Low Battery Cutout 9.5 VDC (allows deep discharge) or 11.8 VDC ( for use with starting or shallow cycle batteries)
ADDITIONAL OPTIONS
Battery Temperature Sensor BTS/15: 15 foot plug-in battery temperature sensor with phone jack (can be extended)
Remote Control Panel RC8/10: 10 foot On/Off remote with LED status indicator
RC8/25: 25 foot On/Off remote with LED status indicator
Note: All specifications are subject to change without notice
Legend Series I
Typical Efficiency Power vs. Time Battery Charger Method
40
50
60
70
80
90
100
0 500 1000 1500
Output in Watts
Efficiency %
0
1,000
2,000
3,000
4,000
1 4
16 64
TIMEINMINUTES
POWER IN WATT
S
1412
1112
612
5916 195th St. N.E. ARLINGTON, WA. USA 98223 Phone [phone] Fax [phone] Web: www.traceengineering.com
ENGINEERING
THE POWER COMPANY
Available From:
Rev# 4/98
