TradeQuip 1020T User manual

04/20 Product Code: 1020T
Made in China to TQB Brands Pty Ltd specifications.
Visit us at www.tqbbrands.com.au
About the TradeQuip brand
The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop
environment by professional users. With proven and trusted “Made for the
Trade” reliability, 'TradeQuip' branded products offer the very best in performance for an
affordable price. All backed by a 1year trade guarantee across 1,000+ distributors Australia wide.
Product Code: 1020T
T
TRANSMISSION
ENGINE CRANE
LIFTER
ENGINE
SUPPORT BAR
Specifications:
Safe Working Capacity: 500kg
Minimum Extension: 1020mm
Maximum Extension: 1430mm
Nett Weight: 19kg
Carton: 1530 x 120 x 120mm
Gross Weight: 20kg

04/20 Product Code: 1020T
Made in China to TQB Brands Pty Ltd specifications Page 2
Visit us at www.tqbbrands.com.au
WARNING
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE
WARNING
The instructions and warnings contained in this manual should be read and understood before using or operating this equipment.
Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough
understanding of how this equipment works. Failure to observe any of the instructions contained in the manual could result in
severe personal injury to the user or bystanders, or cause damage to the equipment and property. Keep this manual in a
convenient and safe place for future reference.
Whilst every effort has been made to ensure accuracy of information contained in this manual, the TQB Brands Pty Ltd policy of
continuous improvement determines the right to make modifications without prior warning.
CONTENT
WARNING............................................................................................................................................................................................ 2
CONTENT............................................................................................................................................................................................. 2
STANDARD OPERATING PROCEDURE ................................................................................................................................................. 3
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE .................................................................................................................... 4
PARTS DIAGRAM ................................................................................................................................................................................. 5
PARTS LIST........................................................................................................................................................................................... 5
WARRANTY ......................................................................................................................................................................................... 6

04/20 Product Code: 1020T
Made in China to TQB Brands Pty Ltd specifications Page 3
Visit us at www.tqbbrands.com.au
PRE-OPERATIONAL SAFETY CHECKS
Save these instructions. For your safety, read, understand, and follow the information provided.
Before using the engine support bar ensure it is in sound condition, and good working order.
Replace or repair damaged parts. Use recommended parts only. Non-authorised parts may be dangerous and will invalidate
the warranty.
Keep the engine support bar clean for best and safest performance.
Locate the engine support bar in an adequate working area for its function, keep area clean and tidy and free from unrelated
materials, and ensure there is adequate lighting.
Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
Ensure all non-essential persons keep a safe distance whilst the engine support bar is in use.
Lock all knobs securely in position before fixing a load, and ensure the load is centred across the engine support bar.
Always ensure the engine support bar and the load is stable.
DO NOT operate unit if damaged.
DO NOT allow untrained persons to operate the engine support bar.
DO NOT exceed the rated capacity of 500kg.
DANGER: DO NOT work under an engine mounted on the engine support bar.
Intended Use
Safely supports an engine in place during repairs such as replacing engine mounts or removing the transmission or transaxle
without removing the engine.
STANDARD OPERATING PROCEDURE
DO NOT use this machine unless you have been trained and assessed to a competent level in its sate use and operation, and
have been given permission to use this
Safety glasses must be worn when operating this
equipment
Long loose hair must be contained when operating
this equipment
Safety footwear must be worn when operating
this equipment
Close fitting/protective clothing must be worn
when operating this equipment
Rings and jewellery must not be worn when
operating this equipment

04/20 Product Code: 1020T
Made in China to TQB Brands Pty Ltd specifications Page 4
Visit us at www.tqbbrands.com.au
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE
1. FEATURES
The 1020T 500kg Engine Support Bar accepts a wide variety of engines and transmissions. This engine support bar comes
with everything needed to perform work on your engine or transmission, including a steel beam, standing block and brackets,
adjusting screw, rubber-moulded cushion, steel chain with handles, hooks and hardware. The rubber padded support legs
prevent slips as well as damage to paint. The engine support is designed only to support the engine so that parts or
mechanisms underneath the engine, which normally have limited access, can be reached.
2. BEFORE USE
Prior to each use conduct a visual inspection by checking for abnormal conditions, such as cracked joints and damaged,
loose, or missing parts.
3. OPERATING INSTRUCTIONS
1. Refer to the vehicle owner’s manual of the engine to be lifted to determine the lifting points.
2. Park the car on a flat surface, apply the parking brakes and chock the wheels.
3. Never try to move a running or hot engine. Allow sufficient time for the engine to cool down entirely before beginning
any operations.
4. Loosen Spreader Knobs (2) and adjust Standing Block (8) and Bracket (9), to locate Rubber Cushions (10) over the gutter
lips adjacent to the fenders of the car.
5. Centre the engine support bar assembly over the engine and tighten the Spreader Knobs (2)
6. Attach the Chains (12) to the engine at the appropriate lifting points, then loop the Chains securely to the flange on the
bottom of the Adjustable Screw Hooks (11).
7. Turn the Screw Hook Handles (5) clockwise until the Chains are taut and the engine is held securely.
8. Loosen engine mounts. Turn the Screw Hook Handles (5) at 1/4 clockwise turns until the entire engine’s weight is
supported by the chains. Continue to loosen and disconnect the engine mounts.
9. Never work on the engine while it is supported only by the Engine Support Bar. Moving the engine whilst it is
suspended only by the Engine Support Bar can cause the Engine Support Bar to fail or shift, resulting in serious personal
injury and/or property damage.
10. To prevent accidents, lower and reconnect the engine when finished working. The Engine Support Bar is not intended
to be used as a long-term suspension device.
11. Clean, then store the tool indoors out of children’s reach.
4. STORAGE
This Engine Support Bar should always be stored in a dry location on a level surface.
5. MAINTENANCE
Replace or repair damaged parts. Use recommended parts only. Non-authorised parts may be dangerous and will
invalidate the warranty.
Keep the Engine Support Bar clean for best and safest performance.
6. SERVICE & REPAIR
Any Engine Support Bar found damaged in any way, or found to be worn or operates abnormally should be removed from
service until repaired by an authorised service agent. Owners and / or operators should be aware that repair of this product
may require specialised equipment and knowledge. Only authorised parts, labels and decals shall be used on this equipment.
Annual inspection of the engine stand is recommended and can be made by an authorised repair facility to ensure that your
equipment is in optimum condition and that the equipment has the correct decals and safety labels specified by the
manufacturer.

04/20 Product Code: 1020T
Made in China to TQB Brands Pty Ltd specifications Page 5
Visit us at www.tqbbrands.com.au
PARTS DIAGRAM
PARTS LIST
Part
Description
Qty
Part
Description
Qty
1
Beam
1
7
Bolt M12x25
2
2
Spreader Knob
2
8
Standing Block
2
3
Washer
2
9
Standing Bracket
2
4
Handle Sleeve
4
10
Rubber Cushion
4
5
Screw Hook Handle
2
11
Adjustable Screw Hook
2
6
Washer
2
12
Chain
2

04/20 Product Code: 1020T
Made in China to TQB Brands Pty Ltd specifications Page 6
Visit us at www.tqbbrands.com.au
WARRANTY
Tradequip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective
materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the
guarantee period is ninety days from the date of purchase.
Should the machine develop any fault, please return the complete tool to your nearest authorised warranty repair agent or contact
TQB Brands Pty Ltd Warranty team –[e-mail].
If upon inspection it is found that the fault occurring is due to defective materials or workmanship, repairs will be carried out free
of charge. This guarantee does not apply to normal wear and tear, nor does it cover any damage caused by misuse, careless or
unsafe handling, alterations, accident, or repairs attempted or made by any personnel other than the authorised TQB Brands Pty
Ltd repair agent.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised.
Your TQB Brands Pty Ltd guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your
proof of purchase within the 12month period.
Consumer Guarantee
Our goods come with a guarantee that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have
the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
