TrailMaster MINI XRX User manual

1
Move carton to a clean location with 3
or more feet of room around the unit.
2
Remove outer cardboard from crate.
3
Remove all bolts from metal crate with
9/16” wrenches or socket.
4
Remove metal crating and unpack all
parts.
5
Place parts out on the floor and take
inventory making sure of proper quan-
tities. At this time, if missing or damaged
parts, call or email us.
6
Remove bolts and nuts at lower front A-
arms
GOKARTMASTERS.COM GOKARTMASTERS.COM
GOKARTMASTERS.COM GOKARTMASTERS.COM
GOKARTMASTERS.COM
GOKARTMASTERS.COM

7
Remove axle straps and discard.
8
Locate white box with battery.
9
See Battery Fill Procedure Instruction
Sheet. Fill battery according to Instruc-
tion Sheet . Let sit.
10
Lay out all hardware on a clean work
bench. Take inventory per hardware
list.
11
Locate one of the long cage bars.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
GOKARTMASTERS.COM
GOKARTMASTERS.COM
12
Place bar on front pin above head-
light.
GOKARTMASTERS.COM

15
Install with washer into front of bar
from the outside.
GOKARTMASTERS.COM
13
Place rear of bar onto pin at rear be-
hind seat.
14
Locate 2 long bolts, 4 nuts & 8
chrome cup washers.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
16
It may be necessary to align the hole
in the bar with a screwdriver.
17
Install a second cup washer and the
nut.
NOTE: DO NOT TIGHTEN AT THIS TIME.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
18
Install bolt, washers and nut at rear of
bar.
GOKARTMASTERS.COM

22
Place the side bar onto the passen-
ger’s side of the go-kart.
23
Turn the plastic cap with a pair of pli-
ers to align the side bar to the top
bar.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
19
Repeat steps 16-19 for the other top
bar.
20
Locate the passenger side bar.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
21
Locate 4 large bolts, 6 cup washers
and 2 nuts.
GOKARTMASTERS.COM
24
It is necessary to tap the plastic cap
all the way onto the bar. Use a plastic
or rubber mallet or a block of wood with a
standard hammer.
GOKARTMASTERS.COM

25
Install the top bolt & washer first.
Start the threads but do not tighten.
26
Now, install the bottom bolt and
washer from the front.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
27
Install the second washer and nut on
the bottom bolt.
NOTE: DO NOT TIGHTEN THE HARDWARE.
GOKARTMASTERS.COM
28
Repeat steps 20-27 for the driver’s
side bar.
29
Locate the top bar weldment assem-
bly.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
30
Locate 4 large bolts and 4 chrome
cupped washers.
GOKARTMASTERS.COM

31
Install the top bar assembly.
32
Start each of the 4 bolts with cupped
washer into the threads of the top bar.
NOTE: DO NOT TIGHTEN HARDWARE .
GOKARTMASTERS.COM
GOKARTMASTERS.COM
34
Locate 2 long bolts and 2 chrome
cupped washers.
35
Install the short bar behind the seats.
Start the bolts with washers into the
threads.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
33
Locate the short rear bar.
GOKARTMASTERS.COM
36
Tighten ALL of the bar bolts previ-
ously installed with a 10mm & 12mm
wrenches.
GOKARTMASTERS.COM

37
Locate the fuel tank.
NOTE: On some models, the fuel tank
is already installed on the engine. Check tank
mounting hardware to insure tight. Proceed
to Step 46.
38
Locate 4 long bolts and nuts and fuel
hose clamp.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
40
Install the 4 bolts and nuts into the
tank.
41
Tighten with a 10mm & 12mm
wrenches.
GOKARTMASTERS.COMGOKARTMASTERS.COM
39
Place the fuel tank onto the rear rack
with decal to the rear.
GOKARTMASTERS.COM
42
Locate the end of the fuel hose on top
of the engine.
GOKARTMASTERS.COM

43
Place the fuel hose clamp onto the
hose and push the hose onto the fuel
filter that’s already attached to the fuel tank.
44
Using pliers, place the fuel hose
clamp on the filter approximately
1/4” from the end of the hose.
.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
45
Turn fuel valve to ‘ON’ position.
GOKARTMASTERS.COM
46
Now, it’s time to install the rear
shocks. Remove the metal shipping
bar from the passenger’s side shock mounts.
NOTE: SAVE THE BOLTS & NUTS.
47
Discard this bar.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
48
Locate one (1) shock.
GOKARTMASTERS.COM

49
Place the top shock eye into the
bracket with the spring up. Reinstall
bolt and washer that was removed in Step 46.
50
Lift up on the rear rack and align bot-
tom shock eyelet with the bracket on
the rear swing arm.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
52
Tighten top and bottom shock bolts
with wrenches.
53
Repeat Steps 48-52 for the driver’s
side rear shock.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
51
Install bottom shock bolt and nut.
GOKARTMASTERS.COM
54
At this time, lift the rear of the go-kart
with the help of an assistant. Place the
kart on a jackstand. Be safe. Use caution.
GOKARTMASTERS.COM

55
Place the battery pad into battery tray
located behind the passenger’s seat.
56
Install the battery in the cart with the ter-
minals to the rear. First, install the positive
cable (red) to the ‘+” on the battery. Next, install
the negative cable (black or green) to the ’-’ on
the battery. NOTE: Use pliers to hold the nut while
using a Phillips head screwdriver to tighten the
screw.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
58
Place rubber battery strap over bat-
tery hook to the front of the battery
tray first. Then, pull the strap over the battery
and place it on the rear hook of the battery
tray. If necessary, use pliers.
GOKARTMASTERS.COM
57
Place gray plastic cover over bat-
tery.
GOKARTMASTERS.COM
59
Locate the set bolt on the sprocket
hub and tighten securely.
60
Locate the rear passenger’s side
wheel. This is one of the larger
wheels. The tread on top of the tire will point
towards the front of the go-kart & the air valve
stem will be facing towards the outside.
GOKARTMASTERS.COM
GOKARTMASTERS.COM

64
Install the cotter pin into the axle nut.
Bend one end of the cotter pin over
the end of the axle. Clip off other end with
cutters.
GOKARTMASTERS.COM
62
Place the largest washer and castle
nut onto the axle.
63
Tighten the castle nut securely and
align the holes in the axle with the
nut.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
61
Place the wheel onto the rear axle.
GOKARTMASTERS.COM
65
Install rubber hubcap over axle nut.
NOTE: Repeat Steps 60-65 for the driver’s
side rear wheel.
GOKARTMASTERS.COM
66
Lift front of go-kart and support with
jack stands.
GOKARTMASTERS.COM

67
Locate passenger’s side top spindle
nut and remove cotter pin.
NOTE: Save cotter pin.
68
Locate passenger’s side bottom spin-
dle nut and remove cotter pin.
NOTE: Save cotter pin.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
69
Tighten both nuts securely with a
17mm wrench.
GOKARTMASTERS.COM
70
Make sure the hole in the spindle
lines up with the castle nut.
71
Reinstall cotter pins. Bend and cut off
excess. Repeat Steps 67-71 on the
driver’s side spindle.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
72
Locate outer steering joints and tight-
en the nut securely using a 12mm
socket on the nut and a 12mm wrench on the
top.
GOKARTMASTERS.COM

73
Locate the front passenger’s side
wheel and place it on the passenger’s
side front axle. The tread on top should point
forward with the air valve stem to the outside.
74
Locate 2 castle nuts, 2 washers and 2
cotter pins.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
75
Install cotter pin and bend. Cut off
excess cotter pin. Repeat Steps 72-75
on the driver’s side.
GOKARTMASTERS.COM
76
Check tire pressure in all 4 tires. Set
to 10 PSI. You will need a low pres-
sure gauge to check the tire pressure.
GOKARTMASTERS.COM
77
Locate the throttle stop and tighten
the jam nut securely.
NOTE: Lowering this bolt will restrict the top
speed of the go-kart.
GOKARTMASTERS.COM
78
Locate the steering box clamps and
tighten all four (4) bolts and nuts se-
curely with 8mm & 10mm wrenches.
NOTE: Plastic connector should be next to the
metal clamp.
GOKARTMASTERS.COM

79
Locate the three (3) small bolts and
nuts.
80
Locate the steering wheel.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
81
Install the steering wheel with the center
spoke facing down & the front wheels
straight forward.
NOTE: If the steering wheel does not line up cor-
rectly with the front wheels, continue mounting the
steering wheel as close as possible.
GOKARTMASTERS.COM
82
Tighten bolts securely with two (2)
10mm wrenches.
83
Install the plastic steering wheel cap
by snapping it into place.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
84
If the steering wheel is not straight
when the front wheels are pointing
straight, locate the plastic gearcase on the
steering box.
GOKARTMASTERS.COM

86
Make sure the front wheels are
straight ahead and determine which
way the steering wheel needs to be turned to
align correctly.
85
Remove plastic cap from the bot-
tom of the plastic case with a screw-
driver.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
87
Remove steering shaft nut with
17mm socket.
GOKARTMASTERS.COM
88
Pull steering wheel and shaft out of
the gear. You may need to bump the
steering wheel gently.
89
Hold the gear in place with your
finger.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
90
Turn the steering wheel straight and
push the shaft back down into the
gear.
GOKARTMASTERS.COM

91
Reinstall the nut securely. Reinstall
the plastic cap by simply pushing it
into place.
92
Now, it’s time to align the steering.
Turn the steering wheel to straight
ahead.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
93
Stand approximately 10 feet in front
of the go-kart and look at the front
passenger wheel in relationship to the rear
passenger wheel.
GOKARTMASTERS.COM
96
Adjust the passenger tie rod ac-
cordingly to align the wheel.
GOKARTMASTERS.COM
94
The front wheel should be in a
straight line with the rear wheel or
parallel.
NOTE: The front of the go-kart is wider than
the rear.
95
The measuring tape in the pictures
is for sight reference ONLY!
GOKARTMASTERS.COM
GOKARTMASTERS.COM

97
Hold the rod with a 10mm wrench
and loosen the outer jam nut
(standard thread).
98
Now, loosen the inner nut
(backwards thread).
GOKARTMASTERS.COM
GOKARTMASTERS.COM
99
Now, adjust the wheel in or out by
turning the rod.
GOKARTMASTERS.COM
100
Hold the rod with a wrench and
tighten the jam nuts securely.
101
Repeat Steps 92-100 for the driv-
er’s side.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
102
For final front end alignment pro-
cedure, the front wheels should
turn toward each other approximately 1/4” to
1/2”.
GOKARTMASTERS.COM

103
Measure across the front wheels
that the front of the tires and at the
rear of the tires and adjust accordingly ac-
cording to the procedures in Steps 92-100.
104
Locate the foam padding and
place it on the top outside bars of
the go-kart.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
105
Remove air filter nut and cover.
GOKARTMASTERS.COM
106
Tighten inner air filter nut secure-
ly with fingers. Reinstall cover
and nut.
107
Locate the shift cam. Tighten both
cables with a 12mm wrench.
NOTE: This is ONLY on the Mini XRX-R
108
Cut and remove all strings on can-
opy top and pad covers and dis-
pose.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
GOKARTMASTERS.COM

109
You’re almost done! Just a few
pre-drive items to inspect, and
you will be ready to ride your new go-kart.
110
Locate oil dipstick on front of en-
gine behind the driver’s seat.
With the go-kart sitting on level ground, the
oil level should be to the top of the threads. If
not, fill with 10W30 oil.
111
Fill fuel tank 3/4 full with premi-
um high octane fuel.
NOTE: Follow all gasoline handling pre-
cautions and fuel can.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
GOKARTMASTERS.COM
112
It is highly recommended to use
a fuel additive or fuel stabilizer
such as Seafoam or Stabil. Follow manufactur-
er's instructions on the bottle.
113
If there is no passenger in the go-
kart, keep the seat belt buckled to
keep it from dragging the ground or from
being run over by the rear tire.
114
Make sure the fuel valve is on.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
GOKARTMASTERS.COM
