MDC MOD X 2021 User manual

www.marketdirect.com.au Ph: 1300 494 494 1
OWNER’S MANUAL
EDITION: 2021 - Version 1
MOD X
OFFROAD CAMPER TRAILER
www.marketdirect.com.au
* January 2020 AU Model shown.

www.marketdirect.com.au Ph: 1300 494 494 2
Contents
Use of Product .......................................................................0
Servicing...................................................................................0
My Mod X ................................................................................1
Section 1. Introduction.......................................................2
Terminology & Abbreviations..........................................3
Tow vehicle and Trailer Compatibility ..........................3
Specications .........................................................................4
Store Locations......................................................................5
Contact Details......................................................................5
Bearings and Seals................................................................5
Safety Information ...............................................................6
Modications to The Product..........................................6
Jacking Your Camper ..........................................................7
Electrical Safety ....................................................................8
Vehicle Electrical Requirements.....................................9
Brake Controller ...................................................................9
Correct Vehicle Wiring for MDC Campers ................9
Trailer Lights Australia..................................................... 10
Charging Camper............................................................... 10
Vehicle with smart alternator ....................................... 10
Gas & Appliance Safety ................................................... 11
Gas Certication................................................................ 11
General Safety .................................................................... 11
Gas Cylinder Safety .......................................................... 11
Rated Shackles.................................................................... 12
Attaching Chains................................................................ 12
Connecting the Electrics................................................. 12
Using the Camper.............................................................. 13
Load Distribution Guide.................................................. 13
Ball Weight........................................................................... 13
Effects of Weight Distribution ..................................... 13
Tyre Pressures .................................................................... 14
Pre-Trip Inspection............................................................ 14
Tyres ....................................................................................... 14
Wheel Nuts.......................................................................... 14
Hitch and Chains................................................................ 14
Fire Extinguisher................................................................ 14
Brakes & Breakaway System......................................... 14
Lights ...................................................................................... 14
Hitches................................................................................... 15
Towing with Trucks ........................................................... 15
Hitch ....................................................................................... 15
Canvas Care......................................................................... 16
Seasoning the Canvas ...................................................... 16
Protecting Seams and Screens ..................................... 16
Zipper Care .......................................................................... 16
Protecting from Mould.................................................... 16
Care of Paint and Surfaces............................................. 17
Paintwork ............................................................................. 17
Washing................................................................................. 17
Polishing ................................................................................ 17
Protection............................................................................. 17
Internal Surfaces................................................................ 17
Setting up your Camper.................................................. 18
Choosing a Spot to Set Up.............................................. 18
Levelling Your Camper..................................................... 18
Site Power............................................................................. 19
Preparing for Bad Weather ........................................... 19
Storage & Care.................................................................... 20
Long Term Storage ............................................................ 20
Interior................................................................................... 20
Exterior.................................................................................. 20
Securing Your Camper..................................................... 20
Brakes and Handbrake - Electric................................. 21
Features................................................................................. 21
Operation ............................................................................. 21
Handbrake............................................................................ 21
Adjuster Cable Type ......................................................... 21
Correct Use of Your Electric Brakes...........................22
Important Safety Notice................................................. 22
Brake Adjustment.............................................................. 22
Brake Cleaning and Inspection..................................... 22
Brake Lubrication .............................................................. 22
Magnets................................................................................. 23
Wheels and Tyres .............................................................. 24
Highway................................................................................. 24
Off Road................................................................................ 24
Suspension ........................................................................... 24
Shock Absorbers & Bushes............................................ 24
Electrical Systems.............................................................. 25
Chargers & Inverters........................................................ 25
Battery Care........................................................................ 25
Gas & Water Systems....................................................... 26
Hot Water System............................................................. 26

www.marketdirect.com.au Ph: 1300 494 494 3
Water Pumps....................................................................... 26
Connecting the Gas .......................................................... 26
Useful Accessories ............................................................ 26
Levelling Blocks .................................................................. 26
Wheel Chocks..................................................................... 27
Covers .................................................................................... 27
Stone Protection ................................................................ 27
Trouble Shooting................................................................ 28
Electrical ............................................................................... 28
Water...................................................................................... 29
Gas........................................................................................... 29
Brakes ....................................................................................30
Handy Tips ........................................................................... 31
Driving Off Road................................................................ 31
Trip Planning........................................................................ 32
Warranty Statement ........................................................ 33
Maintenance........................................................................ 37
Wheel Nuts.......................................................................... 37
Hitch ....................................................................................... 37
Trailing Arm Pivot Bolts................................................... 37
Mechanical Maintenance ...............................................38
Wheels and Tyres ..............................................................38
Brakes ....................................................................................38
Bearings and Seals.............................................................38
Suspension ........................................................................... 38
Travel Record ...................................................................... 39
Maintenance Schedule .................................................... 41
Supplier Contact Details................................................. 53
Video Tutorials.................................................................... 55

www.marketdirect.com.au Ph: 1300 494 494 1
Copyright © Market Direct Group Pty Ltd 2021 All Rights Reserved
All les and information contained in this Owner’s Manual are copyright by Market Direct Group Pty Ltd, and may not be
duplicated, copied, modied, or adapted, in any way without our written permission. Our Owner’s Manual may contain our
service marks or trademarks as well as those of our afliates or other companies, in the form of words, graphics, and logos.
Your use of our Owner’s Manual does not constitute any right or license for you to use our service marks or trademarks,
without the prior written permission of Market Direct Group Pty Ltd.
Our Content, as found within our Owner’s Manual, is protected under Australian and foreign copyrights. The copying,
redistribution, use or publication by you of any such Content, is strictly prohibited. Your use of our Owner’s Manual does not
grant you any ownership rights to our Content.
DISCLAIMER: This manual is provided in good faith and Market Direct Group Pty Ltd.
may amend or update this owner manual from time to time.
Use of Product
The intent and purpose of this manual is to assist owners in the correct use and operation of the product and outline the
servicing schedule to be followed, ensuring the correct maintenance of the product.
Servicing
Servicing information contained in this owner manual is provided for those who have appropriate technical skills and relevant
to the subject matter the publication deals with in regard to maintenance and repairs. The servicing content of this manual
assumes a satisfactory technical knowledge and mechanical skills and experience. It is not suitable for people who are not
trained or qualied in the subject matter it deals with. If you do not have the appropriate skills and experience, or if you do not
have access to appropriate tools and equipment, you may injure yourself or others around you and/or you may cause damage
to the Caravan you are working on, including making it unsafe. Users of this owner manual must:
• Read all content thoroughly. It is especially important to have a good understanding of all the contents shown in the
INTRODUCTION and SAFETY Sections of this publication.
• Use only the correct tools and equipment for all repairs and servicing.
• If part replacement is necessary, replace the part with the same part number or equivalent part. DO NOT replace it with
a part of inferior quality.
• Observe all ‘Cautions’ and ‘Notices’ to reduce the risk of personal injury during service or repair, or improper service or
repair that may damage the Caravan or render it unsafe.
• Understand that the ‘Cautions’ and ‘Notices’ in this publication are not exhaustive because it is impossible to warn of all
possible hazardous consequences that might result from failure to follow the instructions in this publication.
• You must carry out your own risk assessments as you work.
Market Direct Group Pty Ltd. does not accept any and all liability which may arise because a user of this
publication fails to follow directions in the publication or safe work methods associated with use and
maintenance of the product.
Those without the required skills, knowledge, tools, and experience to work on and maintain this product should seek the
services of a suitably qualied person or business. This publication is based on the latest product information at the time of
release. However, specications and procedures are subject to change without notice.

www.marketdirect.com.au Ph: 1300 494 494 1
My MOD X
DISCLAIMER: By receiving this handbook, you confirm there you have read and agree to all
the terms and conditions and understood the use and maintenance care of MDC®
NAME:
MODEL:
VIN:
BUILD DATE:
TARE:
ATM:
TYRE SIZE:
DEALER:
ADDRESS 1:
ADDRESS 2:

www.marketdirect.com.au Ph: 1300 494 494 2
Section 1. Introduction
WELCOME TO MDC
Off road caravanning is a rewarding way to travel and see our great country. Owning an AusRV Caravan or
Hybrid Caravan will afford you the opportunity to travel to remote places and stay in comfort. It is the intention
of MDC for you to have the best possible owner experience and enjoy the great outdoors.
ATM (Aggregate Trailer Mass) Rating: The total permissible mass of the Trailer. This includes the coupling mass
and whatever you add as payload (e.g. water, gas, luggage) up to the specified rating. The ATM Rating must not
be exceeded.
GTM (Gross Trailer Mass) Rating: The total permissible mass that can be supported by the wheels/ tyres of
the Trailer. This includes whatever you add as payload (e.g. water, gas, equipment and luggage), but does not
include the mass supported by the tow vehicle.
The GTM Rating must not be exceeded.
Tare Weight: The total weight of the trailer (load on tyres plus coupling load) with all options and fittings as
supplied by the manufacturer, with empty water tanks, excluding fluids not essential for operation on public
roads, and without luggage or personal effects.
Campers for illustration purposes only.

www.marketdirect.com.au Ph: 1300 494 494 3
Terminology & Abbreviations
Ball Weight: The downward load exerted on the tow point of the vehicle by the trailer.
GCM: (Gross Combination Mass): This is the total allowable combined mass of tow vehicle and trailer as
determined by the tow vehicle manufacturer.
Camber: Camber angle is the measure in degrees of the difference between the wheel’s vertical alignment
perpendicular to the surface. If a wheel is perfectly perpendicular to the surface, its camber would be 0
degrees. Camber is described as negative when the top of the tyre begins to tilt inward towards the chassis rail.
Toe In/out: Negative toe, or toe out, is the front of the wheel pointing away from the centreline of the vehicle.
Positive toe, or toe in, is the front of the wheel pointing towards the centreline of the vehicle.
Toe can be measured in linear units, at the front or rear of the tyre, or as an angular deflection. In the case of
MDC products, the “toe in” is measured in millimetres at the front of the tyre from the chassis rail.
Tow vehicle and Trailer Compatibility
Your tow vehicle manufacturer has applied a maximum towing capacity to the vehicle which is the Aggregate
Trailer Mass (ATM) and a maximum Gross Combination Mass (GCM). These specifications MUST NOT be
exceeded. It is your responsibility to know, understand and follow these specifications. Vehicle manufacturers
may also specify or recommend “Weight Distribution Bars” when towing under certain conditions. You MUST
ensure this is compatible. with the vehicle and trailer combination.
DANGER – Exceeding manufacturer weight and combination limits can result
in loss of control leading to death or serious injury. Your tow vehicle and hitch
must be rated for the Gross Vehicle Weight of the trailer.
DANGER

www.marketdirect.com.au Ph: 1300 494 494 4
Specifications
LENGTH 4.216m
HEIGHT (HIGHEST) 2.017m
DRAWBAR 100x50x5 FEA tested and fully ADR62 compliant
TOWBALL WEIGHT 106kg
TARE WEIGHT Approx. 851kg
ATM 1900kg
SIZE CLOSED 2017(H) x 1929(W) x 4216(L)
STYLE Camper Trailer
SUSPENSION Tough Trax Trailing Arm Suspension with duel shock absorbers and coil
spring
WHEEL/TYRE INFO x3 Brand New 16” (Toyota 6 stud pattern)
STONE GUARD Full Cover Stone Guard
BRAKES 12” Electric Brakes
GAS CYLINDERS 1 x 9kg gas cylinder holder
JERRYCAN HOLDER 1 x 20L jerry can holder
KITCHEN CONSTRUCTION Slide out stainless steel kitchen top and sink
WATER TANK 80L Poly Tank with Steel guard
TOILET Not Supplied
JOCKEY WHEEL 10” Swing up and Lockable
STABILISER LEG 4 x heavy duty lockable and adjustable drop-down
LIGHTS LED submersible tail lights and number-plate light
CHARGER 12v Automatic 15a 7 stage charger
HITCH ADR complied poly block offroad hitch 2,000kg

www.marketdirect.com.au Ph: 1300 494 494 5
QUEENSLAND
Brisbane
3/711 Beaudesert Rd
Rocklea QLD 4107
Caboolture
4 Boeing Place
Caboolture QLD 4510
NEW SOUTH WALES
Sydney
1/12 Avalli Road,
Prestons NSW 2170
Newcastle
Unit 1, 2364 Pacic Hwy
Heatherbrae NSW 2324
VICTORIA
Melbourne
126 Canterbury Rd
Kilsyth South VIC 3137
Campbelleld
1551 Sydney RD
Campbelleld VIC 3061
WESTERN AUSTRALIA
Welshpool
18 Bellows Rd
Welshpool WA 6106
SOUTH AUSTRALIA
Adelaide
1246 South Rd
Clovelly Park SA 5042
Store Locations
NATIONAL TOLL FREE WARRANTY HOTLINE SPARE PARTS
1300 4X4 4X4
1300 494 494
1300 MDC CARE
1300 632 2273
1300 MDC PARTS
1300 632 72787
Bearings and Seals
Bearings are a consumable item should be removed, inspected, and repacked with grease every
5,000km and replaced every 10,000km as best practice. See maintenance schedule for guidance.
Bearing Number: Inner Bearing
25590 Cone: 25520
Bearing Number: Inner Bearing
25590 Cone: 25520
Bearing Number: Inner Bearing
25590 Cone: 25520

www.marketdirect.com.au Ph: 1300 494 494 6
Safety Information
WARNING - Before using this product, you should read this manual, and those manuals
supplied by component manufacturers applicable to this product.
This manual is supplied as a reference to required maintenance of the product. Failure to use and maintain the
product in accordance with what is outlined in this manual may affect your warranty.
Incorrect and/or insufcient maintenance may cause product failure resulting in property loss, damage or
injury or death. Maintenance intervals are critical for normal use, extreme use may require shorter or additional
maintenance intervals. Manual content does not imply express or other any warranty, the owner should read the
limited warranty terms included in this booklet.
Before using this product, you should be certain your tow vehicle is suitably rated and equipped to tow the product
safely and legally. The trailer and vehicle pairing must we within the safe “Maximum Towing Capacity”,
“Ball Weight Capacity” and “Gross Combination Mass” as stated by the vehicle manufacturer.
This camper is tted with electric brakes and requires an electric brake controller.
WARNING: BALL LOADING (DOWNWARD LOAD ON TOW HITCH) MUST NOT EXCEED 200KG OR THE
MAXIMUM ALLOWABLE LOAD BY THE VEHICLE MANUFACTURER OR TOW BAR RATING, WHICH EVER IS
THE LOWEST. Exceeding these limits may result in an accident causing serious injury or death and/or property
damage.
It is important to load your camper correctly to distribute weight evenly and achieve a suitable ball weight load and
prevent loading in a manner that can cause a camper to sway and/or roll excessively left and right. The industry
optimum ball weight on a camper is between 9 and 11% of the total camper weight. MDC campers t into this
category and 10% should be used as the starting point.
Modications to The Product
Gas Systems
The installed gas system on this product is an approved and certied installation. Any changes, modications or
adjustment may render the system non-compliant and dangerous. Market Direct Group Pty Ltd does not condone,
recommend, or otherwise consent to any modications, adjustment, addition or tampering in any way with the
installed gas system on any and all products.
Chassis
All MDC chassis are fully engineered and veried using Finite Element Analysis (FEA) software. This ensures that
the chassis for each model passes the relevant regulations and design rules as originally provided to the customer.
Any modication to the chassis or drawbar whatsoever (no matter how minor) will inevitably change this – whether
it impacts the towing dynamics, expected loads and stress points, safety chain attachment points, overall trailer
length etc. Market Direct Group Pty Ltd does not condone, recommend, or otherwise consent to any modications,
adjustment, addition or tampering in any way with the drawbar, safety chains or safety chain attachment points.

www.marketdirect.com.au Ph: 1300 494 494 7
Jacking Your Camper
Your trailer is tted with purpose built jacking points and from January 2021 supplied with a suitable jack. An
appropriately rated bottle jack is an acceptable alternative, however when using the jacking point beneath the
trailing arm, ensure the jack is of a retracted height that will t under the jacking point when the tyre is deated.
• The jack is to be used on level rm ground wherever possible.
• The wheels of the trailer should be chocked, and no person should remain inside the trailer whilst it is being
• jacked.
• No person should place any portion of their body under a trailer that is supported by a jack.
• The trailer should be attached to the towing vehicle whilst being jacked.
• When performing maintenance ensure suitably rated jack stands are used.
• Do not rely on the trailer being supported by the jack.
Under the trailing armUnder the chassis

www.marketdirect.com.au Ph: 1300 494 494 8
Electrical Safety
Failure To Follow These Instructions May Result In Death Or Serious Injury!
Warning
When working with electrical equipment or lead acid batteries, have someone
nearby in case of an emergency.
Study and follow all the battery manufacturer’s specic precautions when installing,
using, and servicing the battery connected to the inverter.
Wear eye protection and gloves.
Keep unit away from moist or damp areas.
Avoid dropping any metal tool or object on the battery. Doing so could create a
spark or short circuit which goes through the battery or another electrical tool that
may create an explosion.
Warning
Shock Hazard! Keep Away From Children
Avoid moisture. Never expose unit to snow, water, etc.
Unit provides 230 VAC, treat the AC output socket the same as regular wall AC
sockets at home.
Read and understand the information in the manual before operating this
equipment
The 240v electrical system in your camper has been certied by a trade qualied person. Under no circumstances
should an unqualied person interfere with, modify, or repair this system. An RCD safety device is tted to this
camper for your safety.
• Always use a 15amp lead to connect to mains power.
• Do not modify the earth pin to accommodate a lesser lead.
• When connecting to 10amp mains, always use an approved adapter.
• Never coil power leads when in use. Lay the lead out in lengths in a safe manner that prevents
creating a trip hazard.

www.marketdirect.com.au Ph: 1300 494 494 9
Vehicle Electrical Requirements
Brake Controller
All MDC campers and campers require an electric brake controller to be tted to the tow vehicle by law.
There is a wide range of controllers available that are suitable.
Correct Vehicle Wiring for MDC Camper
If your camper is tted with a breakaway system (Cruizer HS, Robson XTT), to comply with national laws on
breakaway systems, you must supply a maintenance charge to the battery/batteries that power the system should it
be activated. In all MDC products, the breakaway is powered by the house batteries in the camper. For this purpose
and Anderson plug connection is tted to all MDC campers on the drawbar. Your vehicle will need to be tted with
a power supply to a 50 amp Anderson plug near the towbar so the trailer can be connected. The vehicle only needs
to supply power while it is running so a voltage sensitive relay or switching device may be used to protect the start
battery when the car engine is stopped.

www.marketdirect.com.au Ph: 1300 494 494 10
This wiring is for the Mod X
Trailer Lights Australia
Plug type – 7 Pin Flat (7 pin round by request)
Pin 1 Yellow Left Indicator
Pin 2 Black Reversing Signal
Pin 3 White Earth Return
Pin 4 Green Right Indicator
Pin 5 Blue Service Brakes
Pin 6 Red Brake Lights
Pin 7 Brown Taillights, clearance lights and side markers
Charging Camper
Plug Type – 50 amp Anderson Plug
Vehicle without smart alternator:
The Anderson plug can be connected to the start battery on the vehicle and should include the following to protect
the start battery.
1. 50 amp relay to stop power supply when vehicle is not running
2. 50 amp fuse or circuit breaker at the battery
Vehicle with smart alternator:
The Anderson plug can be connected to the start battery on the vehicle and should include the following to protect
the start battery.
1. a) A DC to DC charger will need to be installed in the camper to activate the smart alternatorthrough
the vehicle ECU to sense the camper batteries and charge to full capacity.
b) The vehicle smart alternator function will need to be turned off in the vehicles ECU to fully charge
the camper batteries.
2.50 amp relay to stop power supply when vehicle is not running
3.50 amp fuse or circuit breaker at the battery

www.marketdirect.com.au Ph: 1300 494 494 11
Gas & Appliance Safety
Gas Certication
Your Camper has been supplied gas tested and certied. Any additions or alterations to the gas system must be
performed by an authorised person and will require re-certication and testing. Also note any alterations may affect
your warranty on both the system and appliances.
General Safety
• Your Camper may have a number of gas safety labels afxed throughout containing important information. All
instructions are to be followed and the labels shall not be removed for any reason.
• Make sure to close appliance valves before opening the cylinder valves.
• Where readily accessible, check connections at the appliances, regulator, hoses and cylinders periodically for
leaks with soapy water (or an equivalent) – this should be done every time a cylinder is changed or at least
annually.
CAUTION – the ammonia present in some soaps and detergents can react with brass ttings and cause such ttings
to crack after a short period of time. Therefore, caution should be exercised when using soap solutions on brass ttings
and all connections should be rinsed thoroughly with fresh water as soon as possible after the application of the soap
solution.
• Never use a match or ame when checking leaks.
• Never use cooking appliances for comfort heating.
• In the event of a re, immediately close cylinder valve if safe to do so.
• Appliances must not be altered without the authorisation of the manufacturer.
• In the event of an accidental gas leak, close cylinder valve and ventilate the area using a safe method until the air
is clear.
• Flexible hoses are used between the LP Gas Cylinder and regulator as well as between your slide-out kitchen
cooker (if tted) and the gas bayonet. These exible hoses are easily accessible and shall be inspected regularly
by a competent person.
Gas Cylinder Safety
• LP Gas cylinders have a 10-year lifespan between inspection and re-certication. Always use gas cylinders that
are within their compliance date.
• For drawbar mounted cylinders (if applicable), orient the cylinder relief valves of both cylinders discharge away
from both the trailer and towing vehicle as shown.
• For gas cylinders stored in a dedicated LP Gas Locker ensure the locker is kept closed at all times unless changing
or operating the cylinders.
• Close cylinder valves when appliances are not in use or while refuelling is in progress.operating the cylinders.
• Ensure cylinder valves are closed to prevent the unintended release of gas from a cylinder.

www.marketdirect.com.au Ph: 1300 494 494 12
Gas Appliance Safety
• Gas appliances are certied and have a ame safeguard feature to stop gas ow in the event of the ame going
out. Never interfere with this function or replace appliances with a non-certied type.
• Slide-out kitchens with cookers should only be operated with an annex fully erected. Failing to do so may affect
the safety and operation of the gas appliance.
• Slide-out kitchens with cookers must only be used with a exible connecting hose that is disconnected from
thegas bayonet tting when in its stored position. Under no circumstances permanently connect this appliance.
• Only approved and suitable gas appliances with ame safeguard systems shall be connected to the gas bayonet(if
tted).
Safety Chains and Shackles
Rated Shackles
Always use load rated shackles applicable to the weight of your trailer.
Attaching Chains
When attaching chains, you must always cross them and attach each chain to the diagonally opposite side of the
towbar. Ensure chains are not too long and where necessary attach to links further back from the end.
Periodically check the chains for visual wear or damage. If worn or damaged, arrange for these to be replaced with
approved, certied and suitably rated chains.
Connecting the Electrics
When connecting ensure the electric cables to your tow vehicle cannot drag on the road or foul the coupling. If
necessary, use zip ties or like keep them neat and safe from damage.

www.marketdirect.com.au Ph: 1300 494 494 13
Using the Camper
WARNING: BALL LOADING (DOWNWARD LOAD ON TOW HITCH) MUST NOT EXCEED 200KG OR THE
MAXIMUM ALLOWABLE LOAD BY THE VEHICLE MANUFACTURER OR TOW BAR RATING, WHICH EVER IS
THE LOWEST. Exceeding these limits may result in an accident causing serious injury or death and/or property
damage.
•Always load evenly to both sides of the camper
• Load heavy weight over or as close to over the axle as possible and as low as possible.
• Never load in a manner that causes the ball weight to exceed the limit of the tow vehicle.
• Ensure no items can move during travel. Secure all items to prevent damage to the camper.
• Consider water tank levels and how they may affect the balance front and back and
the percentage of ball weight.
Load Distribution Guide
The diagram below illustrates best placements of items based on weight.
Ball Weight
When loading your camper, the ideal ball weight once loaded is around 10% of the total weight of the camper. Use a
ball weight scale to identify the ball weight and load the camper in a manner that achieves the desired weight. Ideally,
once loaded the rst time, take the camper to a weigh bridge, and measure the total weight loaded including the
weight on the jockey wheel. When the total weight is known, adjust the load locations to meet the desired balance
considering 10% is the generally accepted benchmark.
Effects of Weight Distribution
The distribution of weight in a camper can inuence the handling and erformance of the van. Overloading the front
or rear may cause adverse handling and sway. Additionally, overloading the front or back can induce a pendulum
effect that can cause dangerous sway and cause an accident.

www.marketdirect.com.au Ph: 1300 494 494 14
Tyre Pressures
Tyre pressures have a large effect on the handling of your camper. Tyres that are under the recommended pressure
for the campers’ actual weight can cause a dangerous sway. It is important to follow the correct pressure guide.
The guide below indicates pressure for the axle load stated or GTM not the ATM which includes ball weight.
Pressures are cold ination applicable to the standard Goodride 265/75R16 tyres tted.
Actual Axle Weight Pressure PSI
Single Axle
Pressure Kpa
Single Axle
900kg 20psi 137Kpa
1000kg 22psi 152Kpa
1200kg 27psi 186Kpa
1400kg 32psi 220Kpa
1600kg 37psi 255Kpa
1800kg 42psi 290Kpa
1900kg 44psi 303Kpa
Pre-Trip Inspection
Tyres
Before any trip check the following
•Correct tyre pressures
• Tyres are in good condition free from damage and uneven wear.
• Tread is of legal and acceptable depth.
Wheel Nuts
• Ensure wheel nuts are tensioned to the correct torque using a torque wrench.
• All wheel nuts are in place.
Hitch and Chains
• Ensure hitch and chains are free of damage.
•Hitch locking mechanism functions correctly.
• Hitch is properly lubricated.
•Hitch articulates correctly.
Fire Extinguisher
•Extinguisher is properly mounted and within date.
• Extinguisher charge gauge is in green.
Brakes & Breakaway System
• Brakes operate correctly when both operated by manual control and via pedal.
Lights
• Ensure all trailer lights are functioning.

www.marketdirect.com.au Ph: 1300 494 494 15
Hitches
Towing with Trucks
If you intend to tow your caravan with a truck or heavy commercial vehicle you should t a hitch system to minimise
the lash effect of the commercial suspension and distance from the rear axle to the tow point. Truck suspension can
be harsh, particularly in off road conditions. The long distance between the axle centre and the point of attachment
can be quite long further exacerbating the effect putting stress on components.
Using a shock absorbing hitch will reduce the effect considerably.
Hitch
Your camper is tted with an ADR compliant Polyblock Off-Road hitch. It is important to maintain and inspect the
hitch regularly as per the maintenance schedule. The hitch should be attached to the vehicle tow bar as pictured
with the spring loaded “T” pin in place and the “R” clip inserted below. Always use the correct size tongue so that the
Polyblock receiver cannot twist or rotate on the tongue.

www.marketdirect.com.au Ph: 1300 494 494 16
Canvas Care
Seasoning the Canvas
The process of seasoning your canvas before use is an important one but fortunately an easy process. This process is
best done on a warm sunny day with no rain expected.
• Set up your camper and annex with all doors and windows zipped up and closed
• Using your garden hose apply a light spray of water over all the external canvas areas. Wet out the canvas
without allowing water to pool in any section then allow to dry thoroughly.
• Repeat the process of wetting and allowing to try another 2 times.
• On the third wetting check for any leaks in the canvas particularly along the seams. If a seam is weeping water
through, allow the canvas to thoroughly dry then apply a wax stick along the area of the seam. This is done by
lightly rubbing the wax stick over the area. Once applied wet the canvas and check again. NOTE: It is not unusual
for seams that aren’t able to be seam sealed with tape to weep after seasoning. This is not a reection of canvas
or workmanship but simply a characteristic of canvas tents. If the leak persists, contact your AusRV customer
representative.
Protecting Seams and Screens
Seams: When erecting any canvas tent, it is vitally important that you don’t stress the canvas by overtightening when
adjusting the poles. The most common cause of damage to canvas is over tensioning. Adjusting the tent should give
the canvas good shape but the material should be relaxed. If you can see the stitching exposed in a seam, then the
canvas is under strain and the pole should be backed off.
Screens: Fly mesh screens are vulnerable to damage by poles rubbing against it. When packing up your camper it is
important to close windows with both inner and outer canvas zipped up thus protecting the mesh. Never leave door
screens rolled up when packing your camper as this can cause harsh creases and damage the screen. Mesh damage
by owner misuse is not a warranty issue.
Zipper Care
Few parts of your camper work as hard as zippers particularly if you have young children. To get the maximum
service life from zippers there are precautions and maintenance you can do. Never force a zipper. If it jams or
becomes difcult back it up and start again ensuring the two rows are feeding evenly into the slide without one row
having much greater weight of canvas than the other. Avoid having doors half zipped when the tent is in use. Leaving
the slide in a poor position while the door canvas aps around, or people access the door pushing the canvas out
of the way can loosen and damage the teeth. Always fully open or close the entry doors on your tent. Dry lubricant
spray is a great way to make zipping up your tent easier. Apply a light coating of dry lubricant along the length of the
zipper as needed.
Protecting from Mould
Mould is very difcult to clean once a tent is affected. There are several ways you can prevent the occurrence of
mould on your canvas. Never leave your camper packed away wet. If you must leave a campsite with wet canvas
be sure to open and dry out your tent thoroughly at the very rst opportunity when you get home. Mould can
develop in just a couple of days so don’t take the risk. When packing up even a dry tent it is important to check
under the mattress that there is no build-up of condensation overnight. Body heat on a mattress can create enough
temperature difference with the exterior for moisture to form under it. If left unchecked this can cause mould
when your camper is stored. Bird droppings can damage your canvas due to the Ph level. Always clean off any
animal dropping as soon as possible. When storing your camper between
camping trips it is recommended you pack a couple of moisture absorber packs
into your camper. On soft oor campers these are best placed beside the
mattress, on hard oor camper they should be packed inside the main body.
Using these packs is critical in tropic regions due to the humidity as when the
inside temperature of the camper drops overnight, the moist air can turn into
condensation which in turn will cause mould.
