Tranberg TEF 1107 User manual

R. Stahl Tranberg AS
E[email protected] | stahl-tranberg.com
Main office: Strandsvingen 6 | N-4032 Stavanger | Norway | T+47 51 57 89 00 | F+47 51 57 89 50
Office Oslo: Luhrtoppen 2 | N-1470 Lørenskog |Norway | T+47 24 08 44 10
IMPORTANT
Read this instruction carefully before installing the
product
INSTALLATION
TEF 1107 PUSH BUTTON
SAFE AREA
USER MANUAL
Subject to change without prior notice TUM1033 REV. C 17.07.2017

TEF 1107 PUSH BUTTON USER MANUAL
INTRODUCTION
Thank you for purchasing this product!
For installation, maintenance and assurance of a long life
of this product, please follow this manual.
CONTENT IN BOX
The product is fully assembled, and ready for installation.
SAFETY PRECAUTIONS
Note that changes made to the product and/or installation
of components which do not conform to the approval,
may be a safety violation. The manufacturer will in no
circumstance be held responsible for such activity.
For your health and safety, always use safety gear suited
for the task. Be certain to follow codes, regulations and/or
specific procedures that are related to the installation.
TOOLS REQUIRED
Regular tools required for installation:
• Screwdriver –Flat head.
• 25 mm wrench –for tightening the pressure nut.
MAINTENANCE INSTRUCTIONS
The push button should be inspected according to Company
routines. The manufacturer suggests regular check for
water intrusion/condensation which should be removed
immediately.
APPLICATIONS
• Switch for signals, horn or machines
APPROVALS
N/A

TEF 1107 PUSH BUTTON USER MANUAL
INSTALLATION INSTRUCTIONS
SPARE PARTS
Description Part No.
Green push button 5023 0075
Red push button 5023 0071
Cable gland, M25, marine 5591
Stopping plug, M25, marine 5590
Switch insert for 1107, 1 NO 5023 0073
Switch insert for 1107, 1 NC 5023 0072
Gasket, O-ring EPDM 66,4 x 1,78 5000 0027
Silicone cap for push-button 5023 0074
Be sure to install the cable in a way wich prevents water to
penetrate into the enclosure through the cable.
Ensure the cable glands provide a proper seal towards the
cables. Change the gaskets in the glands if required.
Unused cable glands should be replaced with a blind plug.
Terminate the cables directly to the switch. For safety rea-
sons, ensure both conductors are terminated to the 2-pole
switch.
723A108213

R. Stahl Tranberg AS
E[email protected] | stahl-tranberg.com
Main office: Strandsvingen 6 | N-4032 Stavanger | Norway | T+47 51 57 89 00 | F+47 51 57 89 50
Office Oslo: Luhrtoppen 2 | N-1470 Lørenskog |Norway | T+47 24 08 44 10
TEF 1107 PUSH BUTTON USER MANUAL
TECHNICAL DATA
Material: Brass
IP-rating: IP 56
Standard cable entries: 2 x M25 cable glands
2 x M25 stopping plugs
Area of use: Safe area / marine
Weight: 0,75 kg.
