Trane IntelliPak Operating instructions

April 2010 RT-SVP04F-EN
Programming
Troubleshooting
Guide
IntelliPak™ I and II
Commercial Single Zone Rooftop Air
Conditioner with Variable Air Volume (VAV)
Controls
Model Number
IntelliPak I models S*HF*20-75, S*HL*20-75, S*HG*90-130, S*HK*90-130 Ton
W*HB, W*HE
IntelliPak II models S*HJ090-162, W*HCA-C

RT-SVP04F-EN © 2010 Trane All rights reserved
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Commonly Used Acronyms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Glossary of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
UCM Control System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Human Interface Module (Local = 1U2, Remote = 9U13 IntelliPak II) (1U65 IntelliPak I)
10
Unit Operation Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Password Protected Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
System Operating Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
STATUS Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
System Programming SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
SETUP Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Ventilation Override Definitions (with VOM installed) . . . . . . . . . . . . . . . . . . 66
Temperature Input Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
System Programming SETPOINTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
SETPOINT Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
System Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
CONFIGURATION Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
System Testing & Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
SERVICE MODE Menu (Local Human Interface only) . . . . . . . . . . . . . . . . . . . 108
DIAGNOSTICS Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Failure Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Communication Link Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Contents

RT-SVP04F-EN 3
Commonly Used Acronyms
For convenience, a number of acronyms and abbreviations are used throughout this
manual. These acronyms are alphabetically listed and defined below.
General Information
Ta b l e 1. A c r o n y m s
Act = active HGBP = Hot Gas Bypass
AH = Air Handler HGP = Hot Gas Bypass
Annunc = Annunciator Hi = high
AS = AirSide HI = where all caps Human Interface
Aux = auxiliary HO = History Only (Diagnostic)
BAS = building automation systems HVAC = heating, ventilation and air conditioning
BCI = BACnet®Communication Interface ICS = Integrated Comfort System
CCFM = hundreds of cubic-feet-per-minute IGV = inlet guide vanes
CCW = counterclockwise INFO = Information Only (Diagnostic)
cfm = cubic-feet-per-minute I/O = input/output
Cfg = Configured, configuration Indep = Independent
ckt = circuit IOM = installation/operation/ maintenance manual
Cmd = command IPC = interprocessor communications
Comp (s) = compressor, compressors IPCB = interprocessor communications bridge (module)
Cond = condenser, condensers IWC = inches water column
Config = configured, configuration LH = left-hand
Ctrl = control Lo = low
CV = constant volume LCI = LonTalk®Communication Interface
Cy = cycle LCI-I = LonTalk Communication Interface for IntelliPak
Module
CVDA = Constant Speed Fan (CV)/Discharge Air Temp Control Manif = manifolded
CVZT = Constant Speed Fan (CV)/Zone Temperature Control Max = maximum
CW = clockwise Min = minimum
DCV = Demand Control Ventilation Misc = miscellaneous
Dflt = default MCM = Multiple Compressor Module
Diag = diagnostic MDM = Modulating Dehumidification Module
Dmpr = damper Mod = modulating
DWU = Daytime Warm-up MPM = Multi-Purpose Module
E/A = exhaust air MWU = morning warm-up
ECEM = exhaust control/enthalpy module NSB = night setback panel
Econ = economizer, economizing Num = number
Ent = entering O/A = outside air
Evap = evaporator Occ = occupied
F/A = fresh air OVRD = override
Funct = function PAR = Partial System Disable, Auto Reset (Diagnostic)
GBAS = generic building automation system (module) PMR = Partial System Disable, Manual Reset (Diagnostic)
Pos = position

4RT-SVP04F-EN
General Information
Note: Echelon, LON, LONWORKS, LonBuilder, NodeBuilder, LonManager, LonTalk,
LonUsers, Neuron, 3120, 3150, the Echelon logo, and the LonUsers logo are
trademarks of Echelon Corporation registered in the United States and other
countries. LonLink, LonResponse, LonSupport, LonMaker, and LonPoint are
trademarks of Echelon Corporation.
Note: BACnet® is a registered trademark of the American Society of Heating,
Refrigeration and Air-conditioning Engineers Inc. (ASHRAE.)
Glossary of Terms
Carefully review these definitions since they are used throughout this document and
the Installation, Operation, Maintenance Guide (IOM). Knowledge of these terms is
essential in gaining an understanding of how these units operate.
Active SETPOINT. The SETPOINT which is currently being used for control by the
SETPOINT source selection.
BACnet®.An open, device networking communications protocol for controls. This
protocol utilizes BACnet and ANSI/ASHRAE Standard 135-2004 protocol which provides
building owners the capability to connect various types of building control systems or
subsystems together.
Pot = potentiometer SZ = single-zone (unit airflow)
PPM = parts per million TCI = Tracer communications interface (module)
HEAT = where all caps HEAT (module) Press = pressure
Propor = proportional Temp = temperature
psig = pounds-per-square-inch gauge pressure UCM = Unit Control (Module)
PWS = part-winding start Unocc = unoccupied
R/A = return air VAV = variable air volume
Refrig = refrigerant VCM = ventilation control module
RH = right-hand VDC = volts DC
RHI = Remote Human Interface Ventil = ventilation
rpm = revolutions-per-minute VFD = variable frequency drive
RT = rooftop unit VOM = ventilation override module
RTM = rooftop module VVDA=Variable Speed Fan (VAV)/Discharge Air Temp Control
SA = supply air W/ = with
SAP = supply air pressure w.c. = water column
Sat = saturated WU = warmup
SCM = Single Compressor Module XL = across-the-line start
Setpt = SETPOINT
SF = supply fan
SRC = source
Stg = stage
Stnd = standard
STP = SETPOINT
Sw = switch

RT-SVP04F-EN 5
General Information
Comparative Enthalpy. An economizer control strategy which compares return air
enthalpy with outdoor enthalpy. The air with the least heat content (enthalpy) is used
for cooling.
Compressor Protection Switch. A pressure switch installed on the suction line that
prevents compressor operation below the switch’s SETPOINT. The purpose is to prevent
no-flow scroll compressor operation.
Comm3/4. Trane proprietary network communication protocol.
Comm5. Trane's implementation of LonTalk or BACnet (an open network
communication protocol).
Condenser Pressure. The saturated condenser pressure measured on each circuit's(2)
condenser section on Evaporative Condenser units. Condenser pressure is converted
to Saturated Condenser Temperature for display on the Human Interface. The data
from these sensors is used in head pressure control.
Control Band. The range of temperatures or pressures which would normally be
maintained by the various control functions.
Control Point. The value of a SETPOINT that an algorithm is using at any given time.
Deadband. As applied to SA temp control, this refers to a range of temperatures
equally spaced above and below the SA temp control point in which the control
algorithm is satisfied.
Dehumidification Override High Zone Temp. The temperature in the critical zone on
VAV units where Dehumidification is disabled to prevent over-heating the space due to
excess reheat.
Dehumidification Override Low Zone Temp. The temperature in the critical zone on
VAV units where Dehumidification is disabled to prevent sub-cooling the space due to
insufficient reheat.
Demand Control Ventilation (DCV). An ASHRAE compliant ventilation scheme that
varies the Outside Air Damper minimum position or Fresh Air Flow (TRAQs) between
minimum and maximum ventilation SETPOINTs based on CO2level.
Dry Bulb. An outdoor temperature above which economizing will be disabled (unless
comparative enthalpy is the economizer control type being used.)
Economizer Zone Temp SETPOINT Suppression. a parameter used for setting the Zone
Temp SETPOINT at a lower value than the mechanical cooling zone temp SETPOINT.
Emergency Stop. A binary input on the RTM which allows unit shutdown with manual
reset when connected to a field-supplied switch.
Energy Recovery Wheel. A device incorporating a specially coated rotating disc that
spins across both outdoor and exhaust air streams transferring to or removing energy
from the incoming outdoor air prior to mixing with return air to increase unit efficiency.

6RT-SVP04F-EN
General Information
Evap Diff. Evap Diff is a calculated value indicating performance of a refrigeration
system. It is calculated by determining the difference between the Entering and Leaving
temperatures of the evaporator. If this value rises too high it may indicate a problem
with the system.
External Stop. A binary input on the RTM that allows unit shutdown, with automatic
reset, when connected to a field-supplied switch.
Hot Gas Bypass. A feature to reduce a refrigeration circuit's cooling capacity by
bypassing hot discharge line refrigerant directly to the evaporator coil of the system to
more effectively operate in low load conditions.
Humidification Control. During modes of continuous fan operation a relay is energized
when the Humidity measured in the controlled space drops below an adjustable
Humidification SETPOINT. The humidifier device is a user supplied device placed in the
supply air stream.
LonTalk. An open, device networking communications protocol for controls. This
protocol is defined in ANSI approved standard EIA/CEA-709.1-A-1999.
Low Ambient Compressor Lockout. A function which prevents compressor operation
at low outdoor ambient temperatures.
Night SetBack (NSB). Applies to the control of the rooftop unit during unoccupied
periods. Also refers to the NSB panel, a communicating wall sensor with night setback
capability.
Reference Enthalpy. An outdoor enthalpy value above which economizing will be
disabled.
Remote Human Interface. A human interface module designed to be mounted
remotely from the unit. There are some functional differences between a unit mounted
and a remote mounted human interface module.
Reset Amount Maximum. The maximum amount of reset allowed.
Reset End Temperature. The temperature at which the maximum reset amount will
occur.
Reset Start Temperature. The temperature at which reset will begin.
Return Fan Control. Return Fan Control is a feature which allows units to operate at a
higher external or duct system static pressure, or to reduce the load (horsepower
requirement) on the supply fan motor. The fan is placed in the return air path.
Return Fan Plenum Pressure. The area between the Exhaust and Return Dampers and
the outlet of the Return Fan defines the return plenum. The absolute static pressure
measured in this area is the Return Fan Plenum Pressure.

RT-SVP04F-EN 7
General Information
Return Plenum Pressure High Limit. This control feature, available on all return fan
options, shuts the supply fan and return fan off if the pressure in the return plenum
exceeds a non-adjustable SETPOINT of 3.5 iwc.
Space Pressure. The pressure in the building as measured by the Space Pressure
Transducer, referenced to outside (atmospheric) pressure.
Supply Air Pressure High Limit. A pressure limit to prevent unit casing and/or ductwork
over pressurization.
Statitrac™. A trademark for control of space pressurization.
Supply Air Pressure. The pressure in inches water column (IWC) of the supply duct
plenum or outlet as measured by the Supply Air Pressure Transducer, referenced to
local outside (atmospheric) pressure.
Supply Air Tempering. Turning on heat when the supply air temperature drops below a
preset value usually due to cold outside air being brought in to provide building
ventilation.
Supply Air Temperature Control Point. The revised value of supply air temperature
SETPOINT after supply air temp reset has been applied.
Supply Air Temperature Reset. A function that shifts the SA Temp SETPOINT an
amount based on the value of another parameter—typically Zone Temp or Outdoor Air
Temp. The purpose of this function is to lower unit capacity to better meet load
requirements.
Ta r g e t . Dynamic control point the unit is controlling to at any given time.
UCM Control System
Trane Large Commercial Rooftop Units are controlled by a microelectronic control
system that consists of a network of modules and are referred to as Unit Control
Modules (UCM).
The unit size, type (CV or VAV), heating functions, peripheral devices, options, exhaust
capabilities, etc. determine the number and type of modules that a particular rooftop
unit may employ.
The UCM receives analog and binary inputs, then processes this information and
supplies outputs in the form of modulating voltages, contact closures, etc. to control
damper actuators, fan motors, compressors, valves, electric heating coils and other
electrical devices in the unit to maintain set comfort levels.
The UCM provides some equipment protection functions both directly and indirectly,
such as duct pressure limits and compressor lockouts.
Listed below are the various modules that may be employed in a UCM control system.

8RT-SVP04F-EN
General Information
Rooftop Module (1U1 IntelliPak II) (1U48 IntelliPak I)
(Standard on all units) The RTM is the central processor of the system. It continuously
receives information from the other unit modules, sensors, the remote control panel,
and customer supplied relays. It then interprets this information and responds to
cooling, heating, and ventilation requests by directing the other modules in the system
to energize the proper unit components. It also directly initiates supply and exhaust fan
operations, and economizer operation.
Compressor Module (SCM/MCM) (IU3 IntelliPak II) (1U49 IntelliPak I)
The Compressor module, (Single Circuit & Multiple Circuit), upon receiving a request
for mechanical cooling, energizes the appropriate compressors and condenser fans. It
monitors the compressor operation through feedback information it receives from
various protection devices.
Heat Module (1U6 IntelliPak II) (1U50 IntelliPak I)
(Standard on all heating units) The Heat module directs the unit’s heater to stage up and
down to bring the temperature in the controlled space to within the applicable heating
SETPOINT.
Exhaust/Comparative Enthalpy Module (1U5 IntelliPak II) (1U52 IntelliPak I)
(Option - used with Statitrac and/or comparative enthalpy) The ECEM receives data
from the return air humidity sensor, the return air temperature sensor, and the return air
space pressure transducer to control the economizer, exhaust fan and the exhaust
dampers to maintain set space pressure.
Ventilation Control Module (7U14 IntelliPak II) (3U218 IntelliPak I)
(Option - used with TRAQ dampers, DCV, and Outdoor Air Preheat) The VCM receives
data from two velocity pressure sensors associated with front and back TRAQ
assemblies to measure fresh air flow entering the unit. These measurements are
converted to CFM and added to give total fresh air flow. This value can be used for
monitoring purposes, to maintain flow to a minimum fresh air flow SETPOINT, or to
maintain appropriate CO2levels in the controlled space using its space CO2sensor
input and the DCV feature. Without TRAQ assemblies installed the VCM can use DCV
and the CO2sensor input to control OA Damper minimum position to maintain CO2
levels in the space. A preheat control relay output is also provided on this module to
maintain tempered outdoor air during ventilation using the VCM Auxiliary Temperature
input. The preheat unit is user-supplied.
Multi Purpose Module (1U9 IntelliPak II) (1U105 IntelliPak I) (Optional - used
with Return Fan Control)
The MPM supports the function of return plenum pressure control by providing inputs
for measuring return plenum pressure, calibrating that reading, and providing an
output to control the return fan speed (if variable speed configured) in response to
control algorithm requests.

RT-SVP04F-EN 9
General Information
Modulating Dehumidification Module (1U15 IntelliPak II) (1U107 IntelliPak I)
(Optional - used with Dehumidification Control)
The MDM supports specific control inputs and outputs for Modulating Dehumidification
control including modulating Reheat and Cooling valve control as well as the Reheat
Pumpout Coil Relay output.
Generic Building Automation System Module (1U10 = GBAS 0-5V, 1U11 = GBAS
0-10V IntelliPak II) (1U51 = GBAS 0-5V/0-10V IntelliPak I) (Optional - used with
Non-Trane Building Control System)
The Generic Building Automation System (GBAS) module allows a non-Trane building
control system to communicate with the unit and accepts external SETPOINTs in form
of analog inputs (0 - 5 V or 0 - 10 V depending on the module selected) and a binary
Input for demand limit. Five (5) binary outputs are available on 0 - 5 V modules. One (1)
binary output and four (4) analog outputs are available on the 0 - 10 V modules. Refer to
the “Field Installed Control Wiring” section of the Unit Installation, Operation,
Maintenance Manual (IOM) for the control wiring to the GBAS module and the various
desired SETPOINTs with the corresponding DC voltage inputs.
Ventilation Override Module (VOM) (1U8 IntelliPak II) (1U53 IntelliPak I)
(Optional - used on units with special ventilation requirements)
The Ventilation Override module can control the unit’s air handling functions to perform
customer specified functions such as space pressurization, exhaust, purge, unit off, etc.
Interprocessor Communications Board (IPCB) (1U12 IntelliPak II) (1U55
IntelliPak I) (Optional - used with Optional Remote Human Interface)
The Interprocessor Communication Board expands communications from the unit UCM
network to a Remote Human Interface Panel. DIP switch settings on the IPCB module for
this application should be; Switches 1 and 2 “Off”, Switch 3 “On”.
BACnet Communication Interface Module (BCI) (1U66 IntelliPak II) (1U104
IntelliPak I) (Optional - used on units with Trane ICS or 3rd party Building
Automation Systems)
The BACnet Communication Interface module expands communications from the unit
UCM network to a Trane Tracer Summit, or a 3rd party building automation system that
utilizes BACnet, and allows external SETPOINT and configuration adjustment and
monitoring of status and diagnostics.
Lontalk Communication Interface Module (LCI) (1U7 IntelliPak II) (1U65
IntelliPak I) (Optional - used on units with Trane ICS or 3rd party Building
Automation Systems)
The LonTalk Communication Interface module expands communications from the unit
UCM network to a Trane Tracer Summit, or a 3rd party building automation system that
utilizes LonTalk, and allows external SETPOINT and configuration adjustment and
monitoring of status and diagnostics.

10 RT-SVP04F-EN
General Information
Human Interface Module (Local = 1U2, Remote = 9U13 IntelliPak II) (1U65 IntelliPak I)
The Human Interface (HI) Module illustrated in Figure 1 is the device which enables the
customer, building owner, or contractor, to communicate to the Rooftop unit the
necessary parameters for unit operation such as cooling and heating SETPOINTs,
demand limiting, ventilation override modes, etc.
The local (unit mounted) Human Interface and the Remote Human Interface Panel
functions are identical, except for Service mode which is not available on the Remote
Human Interface Panel.
The local HI Module is located in the unit’s main control panel. A small door located in
the unit’s control panel door allows access to the HI Module’s keypad and display
window.
There is a 2 line by 40 character LCD screen which provides status information for the
various unit functions as well as menus used to set or modify the operating parameters.
There is a 16 key keypad adjacent to the LCD screen, which allows the operator to scroll
through the various menus and make adjustments to the SETPOINTs, etc.
The information displayed in the LCD window will be top-level status information
unless the operator initiates other displays.
At power-up, the Human Interface LCD will display one of four initial screens illustrated
in the “General Status” section.
1. Unit Status (Unit Off or Stopped) (The unit is configured and operational, but is not
running). This screen shows state, mode, and function information when the unit is
off or stopped.
2. Unit Status (Unit On) (The unit is configured and operational, and is running). This
screen shows state, mode, and function information when the unit is on.
3. VOM Active (a ventilation override command was received) This screen shows that
the unit is in a Ventilation Override Mode.
4. No Configuration (the unit needs to be configured). This screen shows that required
configuration data is missing.
The LCD screen has a backlight that makes the information easier to read. The light will
go out if no keys are pressed for 30 minutes. If it goes out, simply press the STATUS
key.

RT-SVP04F-EN 11
General Information
Menu Keys
The six keys illustrated in Figure 2 in the MENU area (STATUS, SETPOINTS, SETUP,
CONFIGURATION, DIAGNOSTICS, and SERVICE MODE) are used to bring up the
various interactive menus where the user inputs and accesses unit operating data.
Pressing these keys will display the initial screen for the menu designated by the key’s
name. The following information describes the keys and their functions when viewing
the various menus.
If no key is pressed for 30 minutes while the LCD is displaying a menu screen, it will
revert back to the unit operating status screen.
STATUS Key
Pressing the STATUS key causes the LCD to display the operating status screen; i.e.
“On”, “Unit Stop”, “External Stop”, “Emergency Stop”, “Service Mode”. Pressing the
NEXT key allows the operator to scroll through the screens which provide information
such as air and refrigerant temperatures, humidity levels, fan operation, compressor
operation, heater operation, economizer positioning, exhaust operation, as well as
heating, cooling, and compressor lockout SETPOINTs. Pressing the STATUS key while
viewing any of the data screens will cause the LCD to go back to the operating status
screen.
Figure 1. Human Interface Module

12 RT-SVP04F-EN
General Information
SETPOINTS Key
Pressing the SETPOINTS key will cause the LCD screen to display the first of the
SETPOINT screens where the operator will designate default temperature and pressure
SETPOINTs. While scrolling through the SETPOINT screens, pressing this key again will
cause the LCD to display the first SETPOINT screen.
DIAGNOSTICS Key
Pressing the DIAGNOSTICS key at any time will allow the operator to view any unit
function failures. The LCD screen will display one of the diagnostic screens (depending
on which diagnostic, if any, is present). If no key is pressed for 30 minutes while the
screen is displaying diagnostic information, it will revert back to the operating status
display.
CONFIGURATION Key
Pressing the CONFIGURATION key will cause the LCD screen to display the first of the
configuration screens where the operator will designate unit configuration data such as
unit type, capacity, system control, etc....
This information was programmed at the factory. Pressing the configuration key at any
level in the configuration menu will display the first configuration screen.
Note: This key should be used if the unit’s configuration data is lost or new options are
added in the field, and to view current configuration.
SETUP Key
Pressing the SETUP key will cause the LCD screen to display screens where the
operator will designate various operating parameters such as temperature and
pressure ranges, limits, percentages, SETPOINT source selections, and sensor input
definitions for the control of the rooftop unit’s various operating modes. Pressing the
SETUP key at any level in the SETUP menu will display the first SETUP screen.
SERVICE MODE Key
Pressing the SERVICE MODE key causes the LCD to display the first of the service test
mode screens showing various unit components which may be turned on or off for the
particular test being performed. Once the status of these components is designated, the
LCD will display screens that allow the operator to designate the TEST START time
delay for each test.
Data Manipulation Keys
The six data manipulation keys illustrated in Figure 2, (ENTER, CANCEL, + (Plus), -
(Minus), PREVIOUS, and NEXT are used to modify the data within the screens (change
values, move the cursor, confirm choices, etc....)

RT-SVP04F-EN 13
General Information
ENTER Key
This key will confirm the new values that were designated by pressing the + (Plus) or -
(Minus) keys at all edit points. When viewing status and diagnostics screens, it has no
function.
CANCEL Key
After changing data, at an editable screen, but before confirming it with the ENTER key,
pressing the CANCEL key will return the data to its previous value. This key shall also
function to clear active diagnostics.
+ (Plus) Key
When viewing a SETPOINT screen, this key will increase the temperature or pressure
value of the SETPOINT. When working with a status menu, it will add the current status
display to the custom menu. When viewing the SETUP or service test screens, it will
increase SETPOINTs or toggle choices On or Off at each edit point.
- (Minus) Key
This key when viewing the SETPOINT screen will decrease the temperature or pressure
value of the SETPOINT. When viewing the SETUP or service test screens, it will
decrease SETPOINTs or toggle choices On or Off at each edit point. When viewing the
custom menu, pressing the - (Minus) key will remove the status screen from the custom
menu. When viewing diagnostics screens it has no function.
PREVIOUS Key
Pressing the PREVIOUS key causes the LCD to scroll backwards through the various
displays for each menu. At displays with multiple edit points, it moves the cursor from
one edit point to another.
NEXT Key
Pressing the NEXT key causes the LCD to scroll forward through the various displays
for each menu. At displays with multiple edit points it moves the cursor from one edit
point to another.
Unit Operation Keys
AUTO Key
Pressing the AUTO key at any time will cause the display to go to the top level status
display and, if the unit is shutdown, will cause the unit to begin operation in the
appropriate mode no matter what level in the menu structure is currently being
displayed. If the current display is an editable display, the AUTO key will confirm the
desired edit.

14 RT-SVP04F-EN
General Information
STOP Key
Pressing the STOP key will cause the unit to transition to the stop state. If the current
display is editable, pressing the STOP key will cancel the desired edit.
TEST START Key (SERVICE)
Pressing this key while viewing any screen in the SERVICE Mode menu will start the
service test. When viewing status, SETUP, SETPOINT, and diagnostics screens, it has no
function.
CUSTOM Key
The Custom menu is simply a status menu that contains screens that the user monitors
most frequently. The Custom menu can only contain five status screens. To create the
Custom menu, press the STATUS key, followed by the NEXT key (this brings up the
initial status screen). If you want to add this screen to the Custom menu, press the +
(Plus) key, if not, press the Next key again until a status screen appears that you would
like to add to the Custom menu. Pressing the + (Plus) key while viewing any of the
various status screens will add that screen to the Custom menu. Once the Custom
menu is programed it can be accessed by pressing the CUSTOM key. To remove a
status screen from the Custom menu, press the CUSTOM key, then press the NEXT key
until the status screen that you want to remove appears, then press the - (Minus) key.

RT-SVP04F-EN 15
General Information
General Status Display
Anytime the rooftop unit is powered up, or the STATUS, AUTO, or STOP keys are
pressed, the unit mounted Human Interface will display one of the following four
general status display screens. The operator will then be able to enter keystrokes which
will allow him to navigate through a set of menus and submenus in order to provide/
access various monitoring, SETUP, and configuration information. The Human Interface
will not display screens or parts of screens for which the unit is not configured.
Unit “Off” or “Stopped”
If at power up the unit is not running, the following display will appear on the Human
Interface LCD screen. When this screen is being displayed, the only functional keys are
the six menu keys (STATUS, SETPOINTS, DIAGNOSTICS, SETUP, CONFIGURATION,
and SERVICE MODE), the AUTO key, the CUSTOM key, and the STOP key.
Figure 2. Human Interface Keypad

16 RT-SVP04F-EN
General Information
Unit “On”
If the unit has entered an operating state (running), the following display will appear on
the Human Interface LCD screen. When this screen is being displayed, the only
functional keys are the six menu keys (STATUS, SETPOINTS, DIAGNOSTICS, SETUP,
CONFIGURATION, and SERVICE MODE), the AUTO key, the CUSTOM key, and the STOP
key.
Stop by Network Supply Fan ON Used With: Top Status Display (Shown
when unit is off or stopped)
Possible Values: Top/Left field: Unit
Off, Unit Stopped, External Stop,
Emergency Stop, Stop by Network, Unit
Starting, Service Mode Off; Top/Right
field: Supply Fan OFF, Supply Fan ON;
Bottom/Left field: (Blank),
Shutdown, Initializing, Freeze
Avoidance Active; Bottom/Right:
(Blank), (Diagnostics)
Initializing Diagnostics
Unit Off
Unit Stopped
External Stop
Emergency Stop
Stop by Network
Unit Starting
Service Mode Off
(Blank)
(Diagnostics)
(Blank)
Shutdown
Initializing
Freeze Avoidance Active

RT-SVP04F-EN 17
General Information
Emergency Override Active (units with LCI or BCI module)
If the unit has entered an Emergency Override mode of operation, one of the following
displays will appear on the Human Interface LCD screen.
Ventilation Override Mode
PRESSURIZE
Ventilation Override Mode
DEPRESSURIZE
Ventilation Override Mode
PURGE
Ventilation Override Mode
SHUTDOWN
Ventilation Override Mode
FIRE
VVDA OA Flow ___ CCFM Supply Fan
___________
CVZT
VVDA
CVDA
Occupied
Unoccupied
Morning WU
Daytime WU
Standby
Shutdown
Occupied TOV
Initializing
(Blank)
T
empering
ON
OFF
(Blank)
Diagnostics
______ ____ ________
Heat
Cool
OA Dmpr
Dehumid
Purge
Humidify
(Blank)
1-6
1-6
0-100%
OA Flow
(Blank)
Range
0-5980 CCFM
(Blank)
Freeze Avoidance

18 RT-SVP04F-EN
General Information
VOM Active
If at power up the unit is running and has entered a Ventilation Override mode of
operation, the following display will appear on the Human Interface LCD screen.
No Configuration
If at power up the unit has not been programmed with the necessary configuration data
for normal unit operation, the following display will appear on the Human Interface LCD
screen. When this screen is being displayed, the only functional key is the
CONFIGURATION key.
Note: This screen will only appear when the RTM has been field replaced. Refer to the
Configuration Menu.
Factory Presets
The UCM controlled unit has many operating functions which are preset at the factory,
but may be modified to meet the unique requirements of each job. The following list
identifies each of the unit’s adjustable functions and the value assigned to it. If these
factory presets match the application’s requirements, simply press the AUTO key at the
Human Interface module to begin unit operation (after completing the Pre-Start and
Start-Up procedures in the Installation, Operation, and Maintenance manual). If the
application requires different settings, turn to the listed page beside the function, press
the designated function menu key, then press and hold the NEXT or PREVIOUS key
until its screen appears on the LCD. Once the proper screen appears, simply follow the
programming instructions given below the applicable screen in this manual.
Note: Record any changes made to the factory-preset values in the corresponding
space provided.
VO Mode in Operation
(A,B,C,D,E)
Trouble Indicator
(Blank)
(Diagnostics)
Ventilation Override Mode ______
_____________
No Configuration Present
Press Configuration Key

RT-SVP04F-EN 19
General Information
Adjustable Function Factory Preset Changed To
To adjust
Press...
Control Parameters
Default system mode Auto SETUP
Demand limit definition for cooling None SETUP
Demand limit definition for heating None SETUP
Economizer control enable type Drybulb SETUP
Exhaust enable point 25% SETUP
Morning Warmup type Full SETUP
Supply air low limit 50 deg F SETUP
Unit Control Local SETUP
Coil Frost Cutout Temp 30 deg F SETUP
Evap Temperature Limit 35 deg F SETUP
OA Flow Calibration Gain (Front) 1.0 SETUP
OA Flow Calibration Offset (Front) 0 CFM SETUP
OA Flow Calibration Gain (Back) 1.0 SETUP
OA Flow Calibration Offset (Back) 0 CFM SETUP
OA Flow Calibration Data - Altitude: 0 feet SETUP
Unit Address (Comm3/Comm4 only) 1 SETUP
Default SETPOINTs
Economizer drybulb enable SETPOINT 75 deg F SETPOINTS
Low ambient compressor lockout (Std. units) 50 deg F SETPOINTS
Low ambient compressor lockout (Low ambient units) 0 deg F SETPOINTS
Occupied zone temp SETPOINT - cooling 74 deg F SETPOINTS
Occupied zone temp SETPOINT - heating 71 deg F SETPOINTS
Space pressure - deadband .04 iwc SETPOINTS
Space pressure - SETPOINT 0.08 iwc SETPOINTS
Occ Dehumidification 60% SETPOINTS
Occ Dehumid Hysteresis Offset 5% SETPOINTS
Unocc Dehumidification 60% SETPOINTS
Unocc Dehumid Hysteresis Offset 5% SETPOINTS
Supply Air Reheat Setpoint 70 F SETPOINTS
Supply Air Reheat Deadband 4 F SETPOINTS
Maximum Reheat Valve Limit 85% SETPOINTS
Dehumid Ovrd High Zone Temp Stpt 75 F SETPOINTS
Dehumid Ovrd Low Zone Temp Stpt 68F SETPOINTS
Cond Coil Purge Interval 90 min SETPOINTS
Unoccupied zone temp - cool 85 deg F SETPOINTS
Unoccupied zone temp - heat 60 deg F SETPOINTS
Unoccupied zone temp - morn warmup 72 deg F SETPOINTS
Min OA Flow - SETPOINT w\VCM Set per unit size SETPOINTS
Min OA Flow - deadband Set per unit size SETPOINTS
Preheat actuate temp 35 deg F SETPOINTS

20 RT-SVP04F-EN
General Information
Design Min CO2(DCV) 1000 PPM SETPOINTS
DCV Min CO28001/4002PPM SETPOINTS
DCV Min OA Flow Deadband 5 CCFM SETPOINTS
Design Min OA Flow (DCV) 220 CCFM SETPOINTS
DCV Min OA Flow 67 CCFM SETPOINTS
Design Min OA Damper Position(DCV) 15% SETPOINTS
DCV Min OA Damper Position 5% SETPOINTS
OA Damper Min Position (non-DCV) 15% SETPOINTS
Hydronic Heat Freeze Avoidance Open To: 0% SETPOINTS
Recovery Frost Avoidance Setpoint 27F SETPOINTS
Functions enable/disable
Compressor lead/lag Enable SETUP
Adjustable Function
Factory
Preset Changed To
To adjust
Press...
Morning warmup Enable SETUP
Supply air tempering Enable SETUP
Unoccupied economizer Enable SETUP
Unoccupied mechanical cooling Enable SETUP
Unoccupied heating Enable SETUP
Occupied Dehumidification Enable SETUP
Unoccupied Dehumidification Enable SETUP
Demand Control Ventilation Disable SETUP
Occupied Humidification Disable SETUP
Unoccupied Humidification Disable SETUP
GBAS Input/Output Definitions...
GBAS analog input definitions Not Assigned SETUP
GBAS output definitions SETUP
Information format
Text displays English SETUP
Unit displays English SETUP
RTM alarm output definitions Any Active Diagnostic SETUP
Sensor source selection for...
Monitor RTM Zone Temp SETUP
Morning warmup RTM Zone Temp SETUP
Occupied zone control RTM Zone Temp SETUP
Unoccupied zone control RTM Zone Temp SETUP
Space Humidity Control RTM Space Humidity SETUP
Dehumid OVRD Zone Temp RTM Zone Temp SETUP
SETPOINT source selection for...
Morning warmup Default SETUP
Occupied zone cooling Default SETUP
