Trane MCW509AMUA0 User manual

Owner Manual
Split System
High Wall mounted type
MCW509AMUA0
MCW512AMUA0
MCW518AMUA0
MCW524AMUA0
00_CV_3P102561-6F.fm 1 ページ ２００３年５月３０日 金曜日 午前１０時１７分

2
01EN3P102561-6F.p65 03/06/04, 9:22Page 2 AdobePageMaker6.5J/Win

3
READ BEFORE OPERATION
■Safety Precautions .................................................... 4
■Names of Parts
●Indoor unit, Receiver explanation,
Outdoor unit ..................................................... 7
●Indoor unit, Opening the front grille,
Outdoor unit ..................................................... 8
●Remote controller ............................................ 9
■Preparation Before Operation
●Remote controller .......................................... 10
●Indoor unit ..................................................... 11
OPERATION
■DRY • COOL • FAN Operation .................................. 12
■Adjusting the Air Flow Direction
●Adjusting the horizontal blade (flap) ................. 12
●Adjusting the vertical blade (louvre) ................. 13
■POWERFUL Operation ............................................ 13
■Timer Operation
●OFF TIMER operation .................................... 14
●ON TIMER operation ..................................... 14
CARE
■Care and Cleaning
●Cleaning the air filters .................................... 15
●Cleaning the indoor and outdoor units
and the remote controller ................................ 16
●Replacing air purifying filters ........................... 16
●Cleaning the front grille ................................... 16
●Check ........................................................... 17
●Before a long idle period ................................. 17
TROUBLE SHOOTING
■Trouble Shooting
●These cases are not troubles ......................... 18
●Check again .................................................. 19
●Call the dealer immediately ............................ 20
CONTENTS
01EN3P102561-6F.p65 03/06/04, 9:22Page 3 AdobePageMaker6.5J/Win

4
Safety Precautions
■Read the following warnings and cautions
carefully before operating the system and
use it correctly.
■This manual classifies the precautions to the
user into two categories on the right.
Be sure to follow all as they are all important
to ensure safety.
■After reading this manual, keep it in a place
easily accessible to the user for future
reference.
WARNING
●Do not expose your body to the cool air for a long time, do not cool the room too much.
It will affect your physical conditions and cause health problems.
●Do not put a finger, a rod or other objects into the air outlet or inlet.
As the fan is rotating at a high speed, it will cause injury.
●Do not attempt to repair, relocate, modify or reinstall the air conditioner by yourself.
Incorrect work will cause electric shocks, fire etc. For repairs and reinstallation, consult the dealer
where you bought the air conditioner.
●
If anything abnormal such as a burning smell occurs, stop the operation immediately and turn the breaker OFF.
Continued abnormal operation will cause troubles, electric shocks, fire etc. If anything is
abnormal, consult the dealer where you bought the air conditioner.
●If the air conditioner is not cooling or heating properly, the refrigerant may be leaking, so
see the dealer where the unit was purchased. Check with a qualified repairman before
attempting any repairs, which might accompany addition of refrigerant.
The refrigerant used in the air conditioner is safe. Although leaks should not occur, if for some reason any
refrigerant happens to leak into the room, make sure it does not come in contact with any flame, such as fan
heaters, kerosene heaters, or gas ranges, as this may result noxious substances being generated.
CAUTION
●Do not use the air conditioner for preservation purposes.
Do not use it for preserving precision instruments, foods, plants, animals, works of fine arts etc.
Performance or quality may deteriorate and animal or plant life may be shorter.
●Do not operate the air conditioner with a wet hand.
It may cause an electric shock.
●Ventilate the room from time to time.
Be careful especially when using a burning appliance in the same room. Insufficient ventilation
may cause shortage of oxygen.
●Before cleaning, be sure to stop the operation and turn the breaker OFF.
As a fan is rotating at a high speed, cleaning during operation may cause injury.
●After a long use, check the unit stand and fittings for damage.
The unit may drop and cause injury if damage is left unrepaired.
●Do not stand or sit on the outdoor unit. Do not place any object on the unit.
The object or the person may fall down or drop, causing injury.
●Do not pull at the conduit or hang anything on it.
Otherwise it will cause fire or electric shock.
WARNING
Failure to follow a warning is very likely
to result in such grave consequences as
death or serious injury.
CAUTION
Failure to follow a caution may result in
serious injury or property damage, and
in certain conditions, may result in a
grave consequence.
01EN3P102561-6F.p65 03/06/04, 9:22Page 4 AdobePageMaker6.5J/Win

5
●Do not place under the indoor or outdoor unit anything which must be kept away from
moisture.
Indoor unit : moisture in the air may condense and drip in certain conditions.
outdoor : during cooling operation, condensation may drip from the piping connections.
●Do not wash the unit with water.
It may cause an electric shock.
●Do not place a burning appliance in places exposed to the air flow from the unit or under
the indoor unit.
It may cause incomplete combustion or deformation of the unit from heat.
●Do not place a vessel containing water on the unit.
Water may penetrate into the unit and degrade electrical insulations, resulting in an electric
shock.
●Do not expose plants or animals directly to the air flow.
It may cause adverse effects on the plant or the animal.
●Do not block air inlets nor outlets.
Impaired air flow may result in insufficient performance or troubles.
●Do not allow children to mount on the outdoor unit or avoid placing any object on it.
Falling or tumbling may result in injury.
●Depending on the usage environment, water may leak from the air conditioner.
If this happens, contact your Trane Dealer.
Installation
WARNING
●Do not attempt to install the air conditioner by yourself.
Consult the dealer or a qualified technician.
Incorrect work will result in water leakage, electric shocks or fire. For installation, consult the
dealer where you bought the unit or a qualified technician.
●The air conditioner must be grounded.
Incomplete grounding may result in electric shocks. Do not connect the ground line to a gas pipe,
water pipe, lightning rod, or a telephone ground line.
CAUTION
●Depending on the environment, a ground fault interrupter might be installed.
Lack of a ground fault interrupter might result in electric shocks.
●Do not install the air conditioner in places where flammable gas may leak.
If leaked gas should accumulate near the unit, fire may occur.
●Arrange the drain hose to ensure smooth drainage.
Incomplete drainage may cause wetting of the building, furniture etc.
●Do not connect the air conditioner to a power supply different from the specification.
It may cause trouble or fire.
01EN3P102561-6F.p65 03/06/04, 9:22Page 5 AdobePageMaker6.5J/Win

6
Installation site
■To install the air conditioner in the following types of environments, consult the dealer.
●Places with an oily ambient or where steam or soot occurs.
●Salty environment such as coastal areas.
●Places where sulfide gas occurs such as hot springs.
●Places where snow may block the outdoor unit.
The drain from the outdoor unit must be discharged to a place of good drainage.
Consider nuisance to your neighbours from noises
■For installation, choose a place as described below.
●A place solid enough to bear the weight of the unit which does not amplify the operation noise
or vibration.
●A place from where the air discharged from the outdoor unit or the operation noise will not
annoy your neighbours.
Electrical work
●For power supply, be sure to use a separate power circuit dedicated to the air conditioner.
System relocation
●Relocating the air conditioner requires specialized knowledge and skills. Please consult the dealer
where you bought the air conditioner if relocation is necessary for moving or remodeling.
01EN3P102561-6F.p65 03/06/04, 9:22Page 6 AdobePageMaker6.5J/Win

7
ON
OFF
Front grille
Indicator lamps
Grille tab
Operation lamp (green)
Flap (horizontal blade)
(See page 12.)
TIMER lamp (yellow)
The louvre is inside of the air
outlet.
(See page 12.)
Air outlet
Louvre (vertical blades)
ON/OFF button
Air inlet
Air purifying filter
Air purifying filters are
attached to the inside of
the air filters.
(See page 14.) (See page 14.)
Indoor unit
Receiver explanation
Names of Parts
Room temperature
sensor:
•It senses the air
temperature around
the unit.
Mode
COOL
Air flow rate
AUTO
Temperature setting
72˚F
•Push this button once to
start operation. Push
once again to stop it.
•This button is useful
when the remote
controller is missing.
•The operation mode refers to the following table.
ON/OFF button
•It receives signals from the
remote controller.
•When the unit receives a
signal, you will hear a short
beep.
Before opening the front grille, be sure to stop the
operation and turn the breaker OFF. If the power is
on, the fan may rotate inside and may cause injury.
CAUTION
Receiver:
Outdoor unit
<MCW509AMUA0 • MCW512AMUA0>
01EN3P102561-6F.p65 03/06/04, 9:22Page 7 AdobePageMaker6.5J/Win

8
Indoor unit
<MCW518AMUA0 •
MCW524AMUA0>
Opening the front grille
How to open the front grille : (See page 15)
Names of Parts
Outdoor unit
Front grille
Indicator lamps
Grille tab
Diffuser
OPERATION lamp (green) CLEANING lamp (red)
TIMER lamp (yellow)
The louvre is inside of the air outlet.
(See page 12.)
•Lights up when the air filters need cleaning.
(See page 15.)
Air outlet
Louvre
(vertical blades)
(See page 12.)
(See page 14.)
Flap
(Horizontal blade)
ON/OFF button
Air inlet
Air purifying filter
Air purifying filters are attached
to the inside of the air filters.
Air filter
Room temperature sensor:
•It senses the air temperature around the unit.
•It receives signals from
the remote controller.
•When the unit receives
a signal, you will hear
a short beep.
Before opening the front grille, be sure to stop the
operation and turn the breaker OFF. If the power is
on, the fan may rotate inside and may cause injury.
CAUTION
Receiver:
•Push this button once
to start operation.
Push once again to
stop it.
•The operation mode refer to the following table.
ON/OFF button
COOL
Mode
72˚F
Temperature setting
AUTO
Air flow rate
•This button is useful when the remote controller is missing.
01EN3P102561-6F.p65 03/06/04, 9:22Page 8 AdobePageMaker6.5J/Win

9
C
F
ON
TEMP
ON/OFF
MODE
ON
OFF
TIMER
FAN
SWING
CANCEL
POWERFUL
Transmitter
It sends signals to the indoor unit.
ON/OFF button
Press it once to start operation.
To stop it, press it once again.
CLOCK button
(See page 11.)
TIMER CANCEL button
It cancels the timer setting.
FAN setting button
It selects the air flow rate setting.
SWING button
(See page 12.)
It changes the temperature
setting.
Display
It displays the
current settings.
(In this illustration,
each section is
shown with all its
displays ON for the
purpose of
explanation. Some
models may not
show all its
indications.)
ON TIMER button
(See page 14.)
TIMER Setting button
It changes the time setting
MODE selector button
It selects the operation mode.
POWERFUL button
(See page 13.)
TEMPERATURE
adjustment buttons
Open
the
cover.
OFF TIMER button
: DRY
: COOL
: FAN
Names of Parts
Remote controller
01EN3P102561-6F.p65 03/06/04, 9:22Page 9 AdobePageMaker6.5J/Win

10
Remote
controller
holder
Set.
Receiver
+–
–+
2
3
1
Position + and
–correctly!
About batteries
●When replacing the batteries, use
batteries of the same type, and replace
the two old batteries together.
●When the system is not used for a long
time, take the batteries out. In case the
remote controller is not used for a long
time remove all batteries in order to
prevent liquid leak of the battery.
●When the operation display screen of the
remote controller is hard to see and the
reception become hard, replace the
batteries with new AAA batteries.
●The attached batteries are provided for the
initial use of the system.
The usable period of the batteries may be
short depending on the manufactured date
of the air conditioner.
●Pressing two or more buttons
simultaneously may cause the strange
display of the Remote controller.
The Remote controller is not malfunction.
In this case take the batteries out and
reset them.
Remote controller
Press with a finger and slide the front
cover to take it off.
Set two dry batteries (AAA).
Set the front cover as before.
●This will cause the figures on the display
to flash. Set the clock at this point.
1
2
3
■■
■■
■Operating the remote controller
● To use the remote controller, aim the transmitter at
the indoor unit. If there is anything to block signals
between the unit and the remote controller, such as
a curtain, the unit will not operate.
● Do not drop the remote controller. Do not get it wet.
● The maximum distance for communication is about
23 ft.
● To remove, pull it upwards.
■■
■■
■To fix the remote controller
holder on the wall
Choose a place from where the signals reach
the unit.
Fix the holder to a wall, a pillar, etc. with the
screws supplied with the holder.
Place the remote controller in the remote
controller holder.
1
2
3
■■
■■
■Setting the batteries
ATTENTION
ATTENTION
About the remote controller
●Do not put the remote controller in the
following places.
•In direct sunlight.
•In vicinity of a heater.
●Dust on the signal transmitter or receiver
will reduce the sensitivity. Wipe off dust
with soft cloth.
●Signal communication may be disabled if
an electronic-starter-type fluorescent lamp
(such as inverter-type lamps) is in the
room. Consult the dealer if that is the case.
●If the remote control signals happen to
operate another appliance, move that
appliance to somewhere else, or consult
the dealer.
Preparation Before Operation
01EN3P102561-6F.p65 03/06/04, 9:22Page 10 AdobePageMaker6.5J/Win

11
Preparation Before Operation
■■
■■
■Setting the air purifying filters
Indoor unit
●Holding down ( ) or ( ) button
rapidly increases or decreases the time display.
■■
■■
■Setting the clock
Press .
Press
TIMER
to set the clock to the present
time.
■■
■■
■Turn the breaker ON
●On normal power-up operation, the louver
will open completely and the close. (This is a
normal procedure.)
Pull out the air filters.
●Push upwards the
tab at the center of
each air filter, then
pull it down.
2
Open the front grille.
●Hold the grille by the tabs on the two sides
and lift it until it stops with a click.
(about 60°)
1
Set the air purifying filters.
●Attach an air purifying filter to each air filter.
(See page 15 “Care and cleaning”)
Set the air filters in their original
positions and close the front grille.
●Operation without air filters may result in
troubles as dust will accumulate inside the
indoor unit.
3
4
1
is displayed.
2
AM
Display
blinks.
3Press .
blinks.
(Now the clock is set.)
PM
Display
PM
Display
NOTE
Please note
●When the main power switch is turned on, some
watts of electrictly is being used even if the
system is not operating.
Turn off the main power supply switch for saving
energy.
●If you are not going to use the air conditioner for
a long period, for example in spring or autumn,
turn the breaker OFF.
●
Use the air conditioner in the following conditions.
Mode
COOL
DRY
Operating conditions
Outdoor temperature : 60 to 115 °F
Indoor temperature : 64 to 90 °F
Indoor humidity : 80% max.
Outdoor temperature : 60 to 115 °F
Indoor temperature : 64 to 90 °F
Indoor humidity : 80% max.
If operation is continued out of this range
•A safety device may work to stop the operation.
(In multi system, it may work to stop
the operation of the outdoor unit only.)
•Condensation may occur on the indoor unit and drip.
•A safety device may work to stop the operation.
•Condensation may occur on the indoor unit and drip.
Tips for saving energy
●Be careful not to cool the room too much.
Keeping the temperature setting at a
moderate level helps save energy.
Recommended temperature setting
For cooling: 79°F –82°F
●Cover windows with a blind or a curtain.
Blocking sunlight and air from outdoors
increases the cooling effect.
●Clogged air filters cause inefficient
operation and waste energy. Clean them
once in about every two weeks.
Don’t touch the metal parts of the indoor
unit. If you touch those parts, this may
cause an injury.
01EN3P102561-6F.p65 03/06/04, 9:23Page 11 AdobePageMaker6.5J/Win

12
The air conditioner operates with the settings of
your choice.
From the next time on, the air conditioner will
operate with the same settings.
Press
MODE
and select a mode.
●Each pressing of the button advances the
mode setting in sequence.
Press
ON/OFF
.
Then
OPERATION
lamp lights up.
■■
■■
■To stop:
Press
ON/OFF
once again.
Then OPERATION lamp goes off.
■■
■■
■ To change the temperature setting:
●At smaller air flow rates, the cooling
effect is also smaller.
DRY • COOL • FAN
Operation
1
2
COOL mode
Press ( ) to raise the temperature and
press ( ) to lower the temperature.
Set to the temperature you like.
DRY or FAN mode
The temperature
setting is not
variable.
■■
■■
■ To change the air flow rate setting:
COOLmode
Five levels of air flow rate setting
from “”to “”plus “”are
available.
DRY or FAN mode
The air flow rate
setting is not
variable.
Press
FAN
.
ON
OFF
■■
■■
■To change the air flow direction:
(See page 12.)
Adjusting the Air
Flow Direction
You can adjust the air flow direction to
increase your comfort.
Adjusting the horizontal
blade (flap)
To stop the flap at an
angle you like, press
SWING
.
●When
SWING
is selected, the flap swinging
range depends on the operation mode. (See
the figure.)
●The real flap angles are differ from the
display of remote controller.
Press
SWING
.
●Every time the button is pressed, “”
appears or disappears.
....... The flap automatically
swings up and down.
ATTENTION
●Always use a remote controller to adjust
the flap angle. If you attempt to move it
forcibly with hand when it is swinging,
the mechanism may be broken.
Notes on flap angles
In FAN mode or COOL mode
When stop operation
Upper limit in cooling
Lower limit in cooling
0˚
25˚
DRY •COOL
FAN
<MCW509AMUA0 •MCW512AMUA0>
<MCW518AMUA0 •MCW524AMUA0>
Display
Display
01EN3P102561-6F.p65 03/06/04, 9:23Page 12 AdobePageMaker6.5J/Win

13
POWERFUL
Operation
POWERFUL operation quickly maximizes the
cooling effect in any operation mode.You can
get the maximum capacity with a touch of a
button.
●Pressing the (POWERFUL) button during
operation starts POWERFUL operation.
●POWERFUL operation ends in 20 minutes.
Then the system automatically operates
again with the settings which were used
before POWERFUL operation.
●During you use “POWERFUL operation”, the
other functions will not go on.
Press .
■■
■■
■To cancel POWERFUL operation:
1
Notes on POWERFUL operation
●In COOL mode
To maximize the cooling effect, the capacity
of outdoor unit must be increased and the air
flow rate be fixed to the maximum setting.
The temperature and air flow settings are not
variable.
●In DRY mode
The temperature setting is lowered by 5°F
and the air flow rate is slightly increased.
●In FAN mode
The air flow rate is fixed to the maximum
setting.
Display
Press .
ATTENTION
● Be careful when adjusting the louvre. In-
side the air outlet, a fan is rotating at a
high speed.
Adjusting the vertical blade
(louvre)
Adjusting the Air
Flow Direction
Hold the lever and move the louvre.
(You will find a lever on the left-side and the
right-side blades.)
<MCW509AMUA0 •MCW512AMUA0>
<MCW518AMUA0 •MCW524AMUA0>
01EN3P102561-6F.p65 03/06/04, 9:23Page 13 AdobePageMaker6.5J/Win

14
Timer Operation
● Check that the clock is correct.
If not, set the clock to the present time. (See page 11.)
Timer functions are useful for automatically
switching the air conditioner on or off at night or
in the morning.You can also use OFF TIMER
and ON TIMER in combination.
●NIGHT SET MODE
When the OFF TIMER is set, the air
conditioner automatically adjusts the
temperature setting (1°F up in COOL) to
prevent excessive cooling for your pleasant
sleep.
Press
OFF
while the air conditioner
is operating.
Press
CANCEL
.
■■
■■
■To cancel the timer:
Press
OFF
once again.
Then the TIMER lamp goes off.
Press
TIMER
until the time setting
reaches the point you like.
● Every pressing of either button increases or
decreases the time setting by 10 minutes.
Holding down either button changes the
setting rapidly.
2
3
Then the TIMER lamp
lights up.
is displayed.
blinks.
* Previous time setting
appears on display.
OFF TIMER operation
1
Notes on OFF TIMER
ON TIMER operation
Press
ON
while the air conditioner is
not operating.
Press
ON
once again.
■■
■■
■To cancel the timer:
Then the TIMER lamp goes off.
●Check that the clock is correct. If not, set the
clock to the present time (See page 11).
1
is displayed.
blinks.
* Previous time setting
appears on display.
2
Press
TIMER
until the time setting
reaches the point you like.
●Every pressing of either button
increases or decreases the time setting
by 10 minutes. Holding down either
button changes the setting rapidly.
3
Then the TIMER lamp lights up.
Combining ON TIMER and OFF TIMER
Present time: 11:00 PM
(The unit operating)
OFF TIMER at 0:00 a.m.
ON TIMER at 7:00 a.m. Combined






(Example)
ATTENTION
■In the following cases, set the timer again.
●After a breaker has turned OFF.
●After a power failure.
●After replacing batteries in the remote controller.
●When TIMER is set, the present time is not displayed.
●Once you set ON, OFF TIMER, the time setting is kept in the
memory. (The memory is canceled when remote controller
batteries are replaced.)
●When operating the unit via the ON/OFF Timer, the actual
length of operation may vary from the time entered by the
user.(Maximum approx. 10 minutes.)
●A sample setting for combining the two timers
is shown below.
Notes on ON, OFF TIMER
AM
Display
AM
Display
ON
OFF
AM
Display
AM
Display
ON
OFF
AM AM
Display
Press
CANCEL
.
01EN3P102561-6F.p65 03/06/04, 9:23Page 14 AdobePageMaker6.5J/Win

15
Push
Care and Cleaning
Before cleaning, be sure to stop the
operation and turn the breaker OFF.
Open the front grille.
● Hold the grille by the tabs on the two sides
and lift it unitl it stops with a click. (about 60°)
Pull out the air filters.
●Push a little upwards the
tab at the center of each
air filter, then pull it down.
Take off the air purifying filters and
clean them.
● Wash them with
water, or clean them
with a vacuum
cleaner.
● If the dust does not
come off easily, wash
them with neutral
detergent thinned
with lukewarm water,
then dry them up in the shade.
Set the air purifying filters and the
air filters as they were and close the
front grille.
4
(It is recommended to clean them every two weeks.)
< MCW509AMUA0 • MCW512AMUA0 >
CAUTION
● Insert claws of the filters into slots of the front
panel. The front grille should lock at both sides
and at the point in the middle. Push the grille
at the 3 points indicated by .
1
3
2
Cleaning the air filters
<MCW518AMUA0 •MCW524AMUA0>
Open the front grille.
● Hold the grille by the tabs on the two sides
and lift it unitl it stops with a click. (about 60°)
Pull out the air filters.
●Push a little upwards
the tab at the center of
each air filter, then pull
it down.
Take off the air purifying filters and
clean them.
●Wash them with
water, or clean them
with a vacuum
cleaner.
●If the dust does not
come off easily,
wash them with
neutral detergent
thinned with lukewarm water,
then dry them up in the shade.
Set the air purifying filters and the
air filters as they were and close the
front grille.
4
NOTE
●Insert claws of the filters into slots of the
front panel. The front grille should lock at
both sides and at the point in the middle.
Push the grille at the 4 points indicated
by .
●In a dusty environment, clean the air
filters at least once in every two weeks.
●Operation with dusty air filters lowers
the cooling and capacity and wastes
energy.
1
3
2
Push
01EN3P102561-6F.p65 03/06/04, 9:23Page 15 AdobePageMaker6.5J/Win

16
Fit the key
into the slot.
Slide up the lever.
CAUTION
Clean the front grille.
● You may wipe it with a soft cloth soaked in water.
● Only neutral detergent may be used.
● You may wash the grille with water. After washing,
dry it with cloth, then dry it up in the shade.
Remove the front grille.
● Supporting the front grille with one hand, release
the lock by sliding down the lever with the other
hand.
● To remove the front grille, pull it toward yourself
with both hands.
Cleaning the front grille
You may remove the front grille for cleaning.
● When removing or attaching the front grille, use a
robust and stable stool and watch your steps carefully.
● When removing or attaching the front grille, support
the grille securely with hand to prevent it from falling.
● For cleaning, do not use water hotter than 130°F, benzine,
gasoline, thinner, nor other volatile oils, polishing
compound, scrubbing brushes nor othe hard materials.
● After cleaning, make sure that the front grille is securely
fixed.
1
3
2
4Attach the front grille.
● Set the 3 keys of the front grille into the slots
and push them in all the way.
● Supporting the front grille with one hand, fit the
lock by sliding up the lever with the other hand.
● Close the front grille slowly in this state. (Push
the grille at the 3 points, two at both sides and
in the middle.)
Open the front grille.
●Hold the grille by the tabs on the two sides
and lift it until it stops with a click.
Care and Cleaning
Air filter
Air purifying
filter frame
• Hold the recessed
parts of the frame
and unhook the four
claws.
Detach the
filter element
and attach a
new one.
Set the air
filters as they
were and
close the front
grille.
(Push the grille
at the 3 points,
two at both sides
and in the
middle.)
5
1
32
Open the front grille and pull out the
air filters.
Take off the air
purifying filters.
●Wipe them with dry soft cloth.
For cleaning, do not use water hotter than
130°F, benzine, gasoline, thinner, nor other
volatile oils, polishing compound, scrubbing
brushes nor other hard stuff.
(It is recommended to replace them every
three months.)
● Air purifying filters need to be replaced regularly.
Attach the air
purifying filter.
NOTE
●To order air purifying filters, contact the
dealer where you bought the air conditioner.
●Once the air purifying filter element gets
dirty, it is not reusable but must be thrown
away.
●Operation with dirty air purifying filters :
•cannot clean the air.
•results in poor cooling.
•may cause odour.
Cleaning the indoor and outdoor
units and the remote controller
Replacing air purifying filters
Item
Air purifying filter (with frame)
Air purifying filter (without frame)
Part No.
KAF918A41
KAF918A42
4
< MCW509AMUA0 • MCW512AMUA0 >
01EN3P102561-6F.p65 03/06/04, 9:23Page 16 AdobePageMaker6.5J/Win

17
Before a long idle period
1
2
Press
MODE
and select “”.
Press
ON/OFF
.
1 Operate the fan alone for several
hours on a fine day to dry out the
inside.
2 Clean the air filters and set them
again.
3 Take out batteries from the remote
controller.
4 Turn OFF the breaker for the room air
conditioner.
Check that the base, stand and other
fittings of the outdoor unit are not
decayed or corroded.
Check that nothing blocks the air
inlets and the outlets of the indoor
unit and the outdoor unit.
Check that the earth wire is not
disconnected or broken.
Check that the condensate comes
smoothly out of the drain hose during
COOL or DRY operation.
●If no drain water is seen, water may be
leaking from the indoor unit. Stop
operation and consult the dealer if this is
the case.
Check
<MCW518AMUA0 •MCW524AMUA0>
Care and Cleaning
Clean the front grille.
● You may wipe it with a soft cloth soaked in water.
● Only neutral detergent may be used.
● You may wash the grille with water. After
washing, dry it with cloth, then dry it up in the
shade.
Remove the front grille.
● Supporting the front grille with one hand, release
the lock by sliding down the lever with the other
hand.
● To remove the front grille, pull it toward yourself
with both hands.
1
3
2
4Attach the front grille.
● Set the 3 keys of the front grille into the slots
and push them in all the way.
● Supporting the front grille with one hand, fit the
lock by sliding up the lever with the other hand.
● Close the front grille slowly in this state. (Push
the grille at the 4 points, two at both sides and
two in the middle.)
Open the front grille.
●Hold the grille by the tabs on the two sides
and lift it until it stops with a click.
Side up the lever.
Fit the key
into the slot.
01EN3P102561-6F.p65 03/06/04, 9:23Page 17 AdobePageMaker6.5J/Win

18
Trouble Shooting
●●
●●
●These cases are not troubles.
The following cases are not air conditioner troubles but have some reasons. You may just continue
using it.
Case
Operation does not start soon.
●When ON/OFF button was
pressed soon after operation
was stopped.
●When the mode was reselected.
The outdoor unit emits water or
steam.
Mists come out of the indoor unit.
The indoor unit gives out odour.
The outdoor fan rotates while the
air conditioner is not in operation.
The operation stopped suddenly.
(OPERATION lamp is on)
Explanation
●This is to protect the air conditioner.
You should wait for about 3 minutes.
■In COOL or DRY mode
•Moisture in the air condenses into water on the cool surface of
outdoor unit piping and drips.
■This happens when the air in the room is cooled into mist by the cold
air flow during cooling operation.
■This happens when smells of the room, furniture, or cigarettes are
absorbed into the unit and discharged with the air flow.
(If this happens, we recommend you to have the indoor unit washed
by a technician. Consult the dealer where you bought the air
conditioner.)
■After operation is stopped:
•The outdoor fan continues rotating for another 60 seconds for system
protection.
■While the air conditioner is not in operation:
•When the outdoor temperature is very high, the out door fan starts
rotating for system protection.
■For system protection, the air conditioner may stop operating on a
sudden large voltage fluctuation.
It automatically resumes operation in about 3 minutes.
01EN3P102561-6F.p65 03/06/04, 9:23Page 18 AdobePageMaker6.5J/Win

19
Trouble Shooting
●●
●●
●Check again
Please check again before calling a repair person.
Case
The air conditioner does not
operate.
(OPERATION lamp is off)
Cooling effect is poor.
Operation stops suddenly.
(OPERATION lamp blinks.)
An abnormal functioning
happens during operation.
Check
●Hasn’t a breaker turned OFF or a fuse blown?
●Isn’t it a power failure?
●Are batteries set in the remote controller?
●Is the timer setting correct?
●Are the air filters clean?
●Is there anything to block the air inlet or the outlet of the indoor and the
outdoor units?
●Is the temperature setting appropriate?
●Are the windows and doors closed?
●Are the air flow rate and the air direction set appropriately?
●Are the air filters clean?
●Is there anything to block the air inlet or the outlet of the indoor and the
outdoor units?
Clean the air filters or take all obstacles away and turn the breaker OFF.
Then turn it ON again and try operating the air conditioner with the remote
controller. If the lamp still blinks, call the dealer where you bought the air
conditioner. If the lamps stop blinking after the above steps, there is no
malfunction.
●The air conditioner may malfunction with lightning or radio waves. Turn the
breaker OFF, turn it ON again and try operating the air conditioner with the
remote controller.
01EN3P102561-6F.p65 03/06/04, 9:23Page 19 AdobePageMaker6.5J/Win

20
Trouble Shooting
●●
●●
●Call the dealer immediately.
WARNING
■When an abnormality (such as a burning smell) occurs, stop operation and
turn the breaker OFF.
Continued operation in an abnormal condition may result in troubles, electric shocks
or fire.
Consult the dealer where you bought the air conditioner.
■Do not attempt to repair or modify the air conditioner by yourself.
Incorrect work may result in electric shocks or fire.
Consult the dealer where you bought the air conditioner.
If one of the following symptoms takes place, call the dealer immediately.
■The power cord is abnormally hot or damaged.
■An abnormal sound is heard during operation.
■The safety breaker, a fuse, or the ground fault
interrupter cuts off the operation frequently.
■A switch or a button often fails to work properly.
■There is a burning smell.
■Water leaks from the indoor unit.
Turn the breaker
OFF and call the
dealer.
■After a power failure
The air conditioner automatically resumes
operation in about three minutes. You
should just wait for a while.
■Lightning
If lightning may strike the neighbouring area,
stop operation and turn the breaker OFF
for system protection.
We recommend periodical maintenance
In certain operating conditions, the inside of the air conditioner may get foul after several
seasons of use, resulting in poor performance. It is recommended to have periodical
maintenance by a specialist aside from regular cleaning by the user. For specialist
maintenance, contact the dealer where you bought the air conditioner.
The maintenance cost must be born by the user.
Disposal requirements
Dismantling of the unit, treatment of the refrigerant, oil and eventual other parts, should
be done in accordance with the relevant local and national regulations.
01EN3P102561-6F.p65 03/06/04, 9:23Page 20 AdobePageMaker6.5J/Win
