Trane XR13 Operation manual

Split System
Cooling
Product Data
XR 13
4TTR3018-060
1½ – 5 Tons
PUB. NO. 22-1790-08

© 2010 Trane 2 22-1790-08
Features and
Benefits
•Climatuff®compressor
• Efficiency up to 14.00 SEER
• All aluminum Spine Fin™ coil
•WeatherGuard™ fasteners
•Quick-Sess™ cabinet, easy service
access and refrigerant connections
with full coil protection
•DuraTuff™ base, fast complete drain,
weather proof
•Comfort "R"™ mode approved
• Glossy corrosion resistant finish
• Internal high/low pressure and
temperature protection
• 018, 024, 030 and 060 ship with start kit
• Liquid line filter-drier
• Tarpaulin gray cabinet with anthracite
gray badge & cap
• High pressure switch
• R-410A refrigerant
• S.E.E.T. design testing
• 100% line run test
• Low ambient cooling to 55°F as
shipped
• Low ambient cooling to 30°F with
AY28X079
• Low ambient cooling to 0°F with
BAYLOAM103
•Extended warranties available

22-1790-08 3
Contents
Features and Benefits 2
General Data 4
Product Specifications 4
A-weighted Sound Power Level [dB(A)] 4
Accessory Description and Usage 5
ARI Standard Capacity Rating Conditions 5
Model Nomenclature 6
Electrical Data 7
Dimensions 10
Mechanical Specification Options 11

4 22-1790-08
Product Specifications
Model No. 1 4TTR3018A1 4TTR3024A1 4TTR3030A1 4TTR3036B1
Electrical Data V/Ph/Hz 2 200/230/1/60 200/230/1/60 200/230/1/60 208/230/1/60
Min Cir Ampacity 9 12 15 18
Max Fuse Size (Amps) 15 20 25 30
Compressor CLIMATUFF
®
CLIMATUFF
®
CLIMATUFF
®
CLIMATUFF
®
RL Amps - LR Amps 6.4 - 38.6 8.8 - 57.8 11.1 - 63 13.9 - 71.8
Outdoor Fan FL Amps 0.7 0.7 0.7 0.7
Fan HP 1/8 1/8 1/8 1/8
Fan Dia (inches) 23.0 23.0 23.0 23.0
Coil Spine Fin™ Spine Fin™ Spine Fin™ Spine Fin™
Refrigerant R-410A 5/04-LB/OZ 5/10-LB/OZ 5/11-LB/OZ 7/14-LB/OZ
Line Size - (in.) O.D. Gas
3 1/2 5/8 3/4 3/4
Line Size - (in.) O.D. Liquid
3 1/4 5/16 5/16 3/8
Charge Spec. Subcooling 10° 10° 10° 12°
Dimensions H x W x D (Crated) 38 x 30.1 x 33 38 x 30.1 x 33 38 x 30.1 x 33 42 x 30.1 x 33
Weight - Shipping 223 224 224 219
Weight - Net 195 197 197 190
Start Components YES YES YES YES
Sound Enclosure YES YE S YE S Y ES
Compressor Sump Heat NO NO NO NO
Optional Accessories: 4
Anti-short Cycle Timer TAYASCT501A TAYASCT501A TAYASCT501A TAYASCT501A
Evaporator Defrost Control AY28X079 AY28X079 AY28X079 AY28X079
Rubber Isolator Kit BAYISLT101 BAYISLT101 BAYISLT101 BAYISLT101
Extreme Condition Mounting Kit BAYECMT001 BAYECMT001 BAYECMT001 BAYECMT001
Start Kit
Crankcase Heater Kit BAYCCHT300 BAYCCHT300 BAYCCHT300 BAYCCHT300
Seacoast Kit BAYSEAC001 BAYSEAC001 BAYSEAC001 BAYSEAC001
Low Ambient Kit BAYLOAM103 BAYLOAM103 BAYLOAM103 BAYLOAM103
Refrigerant Lineset 5 TAYREFLN5* TAYREFLN6* TAYREFLN2* TAYREFLN7*
1 Certified in accordance with the Unitary Air-Conditioner equipment certification program which is based on ARI Standard 210/240.
2 Calculated in accordance with N.E.C. Only use HACR circuit breakers or fuses.
3 Standard line lengths - 60'. Standard lift - 60' Suction and Liquid line.
For Greater lengths and lifts refer to refrigerant piping software Pub# 32-3312-0†. (†denotes latest revision)
4 For accessory description and usage, see page 5.
5 * = 15, 20, 25, 30, 40 and 50 foot lineset available.
General
Data
MODEL
SOUND POWER
LEVEL [dB(A)]
63 125 250 500 1000 2000 4000 8000
4TTR3018A1 76 47.5 60.4 63 70.3 69.8 69.3 59.3 50.9
4TTR3024A1 76 47.2 61.1 64.8 70.6 70.7 68.4 57.9 50.6
4TTR3030A1 76 49.3 61.1 66.2 70.3 70 67.4 58 51.6
4TTR3036B1 77 45.5 58.7 59.3 69.7 71.2 71.1 60.3 51.8
4TTR3042A1 76 54.9 58.7 61.6 67.2 69 67.7 60.4 53.7
4TTR3048A1 76 55.8 57 62.4 67.5 70.2 67.4 61.1 54.2
4TTR3060B1 76 51.8 55 64 67.7 73.5 65.5 60.2 52.3
Note: Rated in accordance with AHRI Standard 270-2008
A-weighted Sound Power Level [dB(A)]
A-WEIGHTED FULL OCTAVE SOUND POWER LEVEL dB - [dB(A)]

22-1790-08 5
General
Data
Product Specifications
Model No. 1 4TTR3042A1 4TTR3048A1 4TTR3060B1
Electrical Data V/Ph/Hz 2 208/230/1/60 208/230/1/60 208/230/1/60
Min Cir Ampacity 25 27 34
Max Fuse Size (Amps) 40 45 60
Compressor CLIMATUFF
®
- SCROLL CLIMATUFF
®
- SCROLL CLIMATUFF
®
- SCROLL
RL Amps - LR Amps 18.6 - 105 20.5 - 109 27.6 - 135
Outdoor Fan FL Amps 1.3 1.3 1.3
Fan HP 1/4 1/4 1/4
Fan Dia (inches) 27.6 27.6 27.6
Coil Spine Fin™ Spine Fin™ Spine Fin™
Refrigerant R-410A 7/00-LB/OZ 7/04-LB/OZ 8/06-LB/OZ
Line Size - (in.) O.D. Gas
3 3/4 7/8 7/8
Line Size - (in.) O.D. Liquid
3 3/8 3/8 3/8
Charge Spec. Subcooling 13° 10° 10°
Dimensions H x W x D (Crated) 38.4 x 35.1 x 38.7 38.4 x 35.1 x 38.7 46.4 x 35.1 x 38.7
Weight - Shipping 258 261 287
Weight - Net 225 227 251
Start Components NO NO YES
Sound Enclosure NO NO NO
Compressor Sump Heat NO NO YES
Optional Accessories: 4
Anti-short Cycle Timer TAYASCT501A TAYASCT501A TAYASCT501A
Evaporator Defrost Control AY28X079 AY28X079 AY28X079
Rubber Isolator Kit BAYISLT101 BAYISLT101 BAYISLT101
Extreme Condition Mounting Kit BAYECMT001 BAYECMT001 BAYECMT001
Start Kit BAYKSKT260 BAYKSKT260
Crankcase Heater Kit BAYCCHT301 BAYCCHT301
Seacoast Kit BAYSEAC001 BAYSEAC001 BAYSEAC001
Low Ambient Kit BAYLOAM103 BAYLOAM103 BAYLOAM103
Refrigerant Lineset 5 TAYREFLN7* TAYREFLN3* TAYREFLN3*
ARI Standard Capacity Rating Conditions
ARI STANDARD 210/240 RATING CONDITIONS —
(A) Cooling 80°F DB, 67°F WB air entering indoor coil, 95°F DB
air entering outdoor coil.
(B) High Temperature Heating 47°F DB, 43°F WB air entering
outdoor coil, 70°F DB air entering indoor coil.
(C) Low Temperature Heating 17°F DB, 15°F WB air entering
outdoor coil, 70°F DB air entering indoor coil.
(D) Rated indoor airflow for heating is the same as for cooling.
ARI STANDARD 270 RATING CONDITIONS — (Noise rating
numbers are determined with the unit in cooling operation.)
Standard Noise Rating number is at 95°F outdoor air.
Accessory Description and Usage
Anti-Short Cycle Timer — Solid state timing device that
prevents compressor recycling until five (5) minutes have
elapsed after satisfying call or power interruptions. Use in area
with questionable power delivery, commercial applications, long
lineset, etc.
Evaporator Defrost Control — SPST Temperature actuated
switch that cycles the condenser off as indoor coil reaches
freeze-up conditions. Used for low ambient cooling to 30°F
with TXV.
Rubber Isolators — Five (5) large rubber donuts to isolate
condensing unit from transmitting energy into mounting frame
or pad. Use on any application where sound transmission
needs to be minimized.
Hard Start kit — Start capacitor and relay to assist compressor
motor startup. Use in areas with marginal power supply, on long
linesets, low ambient conditions, etc.
Extreme Condition Mount Kit — Bracket kits to securely
mount condensing unit to a frame or pad without removing any
panels. Use in areas with high winds, or on commercial roof
tops, etc.

6 22-1790-08
Model
Nomenclature
Refrigerant Type
2 = R-22
4 = R-410A
TRANE
Product Type
W= Split Heat Pump
T = Split Cooling
Product Family
Z = Leadership – Two Stage
X = Leadership
R = Replacement/Retail
B = Basic
A = Light Commercial
Family SEER
0 = 10 3 = 13 6 = 16
1 = 11 4 = 14 8= 18
2 = 12 5 = 15 9 = 19
Split System Connections 1-6 Tons
0 = Brazed
Nominal Capacity in 000s of BTUs
Major Design Modifications
Power Supply
1 = 200-230/1/60 or 208-230/1/60
3 = 200-230/3/60
4 = 460/3/60
Secondary Function
Minor Design Modifications
Unit Parts Identifier
Outdoor Units
4T T R3 0 3 6 B 1 0 0 0A A
4 T E E 3 F 3 6 A 1 0 0 0 A A
Air Handlers-
Residential
Refrigerant Type
4 = R-410A
Application
TE = Fully Convertible
TG = Semi Convertible
TF = Front Return
TB = Modular Blower
Product Family
E = Leadership - Variable Speed
H = High Efficiency
C = Replacement/Retail
B = Basic
Flow Control
0 = No FlowControl
3 = TXV–Non-bleed
Feature Indentifier
0 = Standard Unit
F = Air-Tite™
D = Intergated Whole Home Air Cleaner
C = Communicating Air Handler
Nominal Capacity in 1000's (BTUH)
Major Design Change
Power Supply
1 = Single Phase
Electrical Connection
0 = Pig Tails
B = Circuit Breaker
D = Pull Disconnect
Future Option - Factory Installed Heater Nominal KW Value
Minor Design Change
Service Digit - Not Orderable
Furnace Configuration
TU = Upflow / Horizontal
TD = Downflow / Horizontal
Type
D = 80% Premium
X = 90% Premium
Number of Heating Stages
1 = Single Stage
2 = Two Stage
3 = Three Stage
Cabinet Width
A = 14.5" Cabinet Width
B = 17.5" Cabinet Width
C = 21.0" Cabinet Width
D = 24.5" Cabinet Width
Heating Input
080 = 80,000 BTUH
Major Design Change
Power Supply / Fuel
9 = 115 Volts / Natural Gas
F = 115 Volts / Natural Gas with Integrated ifD Filter
Airflow Capacity for Cooling
36 = 3 Ton Standard PSC Motor
H3 = 3 Ton High Efficiency Motor
V3 = 3 Ton Variable Speed Motor
Draft Inducer Speeds
1 = Single Speed
2 = Two Speed
V = Variable Speed
Minor Design Change
Service Digit – Not Orderable
TU D 1 B 0 8 0 A 9 H 3 1 A A
High Efficiency
Furnaces
Refrigerant Type
2 = R-22 4 = R-410A
Product Family
T = Premium (Heat Pump or Convertible Coil)
C = Standard (Cooling Only)
Coil Design
X = Direct Expansion Evaporator Coil
Product Family
C = Cased A Coil
A = Uncased A Coil
F = Cased Horizontal Flat Coil
Coil Width (Cased / Uncased)
A = 14.5" / 13.3" C = 21.0" / 19.8" H = 10.5"
B = 17.5" / 16.3" D = 24.5" / 23.3"
Refrigerant Line Coupling
0 = Brazed
Nominal Capacity in 000s of BTUs
Major Design Change
Efficiency
C = Standard S = Hi Efficiency
Refrigerant Control
3 = TXV – Non-Bleed
Coil Circuitry
H = Heat Pump
C = Cooling Only
Airflow Configuration
A = Upflow Only
U = Upflow / Downflow
H = Horizontal Only
C = Convertible – Upflow, Downflow, Left Airflow
M = Convertible – Upflow, Downflow, Left or Right Airflow
Minor Design Change
Unit Parts Identifier
HeatPump /
Cooling Coils
2T XCB0 3 6 AC 3HCA A

22-1790-08 7
4TTR3018,024,030A1, 036B1 4TTR3042A1
Electrical
Data
SCHEMATIC DIAGRAMS
(SEE LEGEND)

8 22-1790-08
4TTR3048A1 4TTR3060B1
Electrical
Data
SCHEMATIC DIAGRAMS
(SEE LEGEND)
PRINTED FROM D155205P01 REV00

22-1790-08 9
Electrical
Data
SCHEMATIC DIAGRAMS
LEGEND
SYMBOLS

10 22-1790-08
Dimensions
4TTR3 OUTLINE DRAWING
NOTE: ALL DIMENSIONS ARE IN MM (INCHES)
From Dwg. D152898
MODELS BASE FIG. A B C D E F G H J K
4TTR3018A 3 1 832 (32-3/4) 829 (32-5/8) 756 (29-3/4) 1/2 3/8 143 (5-5/8) 92 (3-5/8) 210 (8-1/4) 79 (3-1/8) 508 (20)
4TTR3024A 3 1 832 (32-3/4) 829 (32-5/8) 756 (29-3/4) 5/8 3/8 143 (5-5/8) 92 (3-5/8) 210 (8-1/4) 79 (3-1/8) 508 (20)
4TTR3030A 3 1 832 (32-3/4) 829 (32-5/8) 756 (29-3/4) 3/4 3/8 143 (5-5/8) 92 (3-5/8) 210 (8-1/4) 79 (3-1/8) 508 (20)
4TTR3036B 3 1 933 (36-3/4) 829 (32-5/8) 756 (29-3/4) 3/4 3/8 143 (5-5/8) 92 (3-5/8) 210 (8-1/4) 79 (3-1/8) 508 (20)
4TTR3042A 4 1 841 (33-1/8) 946 (37-1/4) 870 (34-1/4) 3/4 3/8 152 (6) 98 (3-7/8) 219 (8-5/8) 86 (3-3/8) 508 (20)
4TTR3048A 4 1 841 (33-1/8) 946 (37-1/4) 870 (34-1/4) 7/8 3/8 152 (6) 98 (3-7/8) 219 (8-5/8) 86 (3-3/8) 508 (20)
4TTR3060A 4 1 1045 (41-1/8) 946 (37-1/4) 870 (34-1/4) 7/8 3/8 152 (6) 98 (3-7/8) 219 (8-5/8) 86 (3-3/8) 508 (20)

22-1790-08 11
Mechanical
Specification Options
General
The 4TTR3 shall be fully charged from
the factory for matched indoor section
and up to 15 feet of piping. This unit must
be designed to operate at outdoor
ambient temperatures as high as 115°F.
Cooling capacities shall be matched with
a wide selection of air handlers and
furnace coils that are ARI certified. The
unit is certified to UL 1995. Exterior must
be designed for outdoor application.
Casing
Unit casing is constructed of heavy
gauge, galvanized steel and painted with
a weather-resistant powder paint.
Corrosion and weatherproof CMBP-G30
DuraTuff™ base.
Refrigerant Controls
Refrigeration system controls include
condenser fan and compressor
contactor. High and low pressure controls
are inherent to the compressor. Another
standard feature is the liquid line dryer.
Compressor
The Climatuff®compressor features
internal over temperature and pressure
protector, total dipped hermetic motor
and thermostatically controlled sump
heater. Other features include centrifugal
oil pump, and low vibration and noise.
Condenser Coil
The Spine Fin™ coil shall be continu-
ously wrapped, corrosion resistant all
aluminum with minimum brazed joints.
This coil is 3/8 inch O.D. seamless
aluminum glued to a continuous alumi-
num fin. Coils are lab tested to withstand
2,000 pounds of pressure per square
inch. The outdoor coil provides low
airflow resistance and efficient heat
transfer. The coil is protected on all four
sides by louvered panels.
Low Ambient Cooling
As manufactured, this unit has a cooling
capability to 55°F. The addition of an
evaporator defrost control permits
operation to 30°F. The addition of a low
ambient kit with TXV permits low ambient
cooling to 0°F.
Accessories
Thermostats — Heating/Cooling
(manual and automatic changeover).
Sub-base to match thermostat and
locking thermostat cover.
Evaporator Defrost Control — See Low
Ambient Cooling.
Outdoor Thermostat — Supplemental
heat outdoor ambient lockout from
46 to –10°F.

Literature Order Number SS-PRC007-EN 07/10
File Number —
Supersedes SS-PRC007-EN 2/02
Stocking Location PI Louisville & Webb/Mason Houston
Trane has a policy of continuous product and product data improvement and it reserves the right to change
design and specifications without notice.
Trane
www.trane.com
