Trane UniTrane FCD Owner's manual

UniTrane™ FCD ducted fan coil units
Sizes 101-103-203-204-304-306-406-408-508-512-612-721
UniTrane™ FED ducted fan coil units
Sizes 100-200-300-400-500-600
Installation
Operation
Maintenance
July 2013
UNT-SVX10G-E4
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 1

General Information
UNT-SVX10G-E4
Foreword
These instructions are given as a
guide to good practice in the
installation, start-up, operation, and
maintenance by the user, of Trane
UniTrane™ CD/ ED fan coil units.
They do not contain full service
procedures necessary for the
continued successful operation of
this equipment. The services of a
qualified technician should be
employed through the medium of a
maintenance contract with a
reputable service company. Read
this manual thoroughly before unit
start-up.
Warnings and cautions
Warnings and Cautions appear at
appropriate sections throughout
this manual. Your personal safety
and the proper operation of this
machine require that you follow
them carefully. The constructor
assumes no liability for installations
or servicing performed by
unqualified personnel.
WARNING! : Indicates a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
CAUTION! : Indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury. It may also be
used to alert against unsafe
practices or for equipment or
property-damage-only accidents.
Safety recommendations
To avoid death, injury, equipment or
property damage, the following
recommendations should be
observed during maintenance and
service visits:
1. The maximum allowable
pressures for system leak testing
on low and high pressure side
are given in the chapter
"Installation". Always provide a
pressure regulator.
2. Disconnect the main power
supply before any servicing on
the unit.
3. Service work on the refrigeration
system and the electrical system
should be carried out only by
qualified and experienced
personnel.
Reception
On arrival, inspect the unit before
signing the delivery note.
Reception in France only:
In case of visible damage: The
consignee (or the site
representative) must specify any
damage on the delivery note,
legibly sign and date the delivery
note, and the truck driver must
countersign it. The consignee (or
the site representative) must notify
Trane Epinal Operations - Claims
team and send a copy of the
delivery note. The customer (or the
site representative) should send a
registered letter to the last carrier
within 3 days of delivery.
Note: for deliveries in rance, even
concealed damage must be looked
for at delivery and immediately
treated as visible damage.
Reception in all countries except
France:
In case of concealed damage: The
consignee (or the site
representative) must send a
registered letter to the last carrier
within 7 days of delivery, claiming
for the described damage. A copy
of this letter must be sent to Trane
Epinal Operations - Claims team.
Storage until installation
Units must be stored in a closed
environment, protected from
weather.
The humidity of the storage
environment shall not exceed 70%
relative humidity.
© 2013 Trane
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 2

General Information
3UNT-SVX10G-E4
Warranty
Warranty is based on the general
terms and conditions of the
manufacturer. The warranty is void
if the equipment is repaired or
modified without the written
approval of the manufacturer, if the
operating limits are exceeded or if
the control system or the electrical
wiring is modified. Damage due to
misuse, lack of maintenance or
failure to comply with the
manufacturer's instructions or
recommendations is not covered by
the warranty obligation. If the user
does not conform to the rules of
this manual, it may entail
cancellation of warranty and
liabilities by the manufacturer.
Maintenance contract
It is strongly recommended that you
sign a maintenance contract with
your local Service Agency. This
contract provides regular
maintenance of your installation by
a specialist in our equipment.
Regular maintenance ensures that
any malfunction is detected and
corrected in good time and
minimizes the possibility that
serious damage will occur. inally,
regular maintenance ensures the
maximum operating life of your
equipment. We would remind you
that failure to respect these
installation and maintenance
instructions may result in
immediate cancellation of the
warranty.
Training
To assist you in obtaining the best
use of it and maintaining it in
perfect operating condition over a
long period of time, the
manufacturer has at your disposal a
refrigeration and air conditioning
service school. The principal aim of
this is to give operators and
technicians a better knowledge of
the equipment they are using, or
that is under their charge. Emphasis
is particularly given to the
importance of periodic checks on
the unit operating parameters as
well as on preventive maintenance,
which reduces the cost of owning
the unit by avoiding serious and
costly breakdown.
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 3

Contents
UNT-SVX10G-E44
General information 2
Installation 5
Unit identification 5
General data 7
Operating limits (temperature and airflow) 11
Water quality recommendations 11
Handling the unit 12
Mounting the accessories 12
Mounting the unit in the ceiling 14
Ductwork connection 17
Water connection 19
Condensate drainage connection 23
Electrical connection 28
Connecting the thermostats 32
Main power supply 39
External static pressure and airflow curves 40
Water pressure drop curves 48
Pre-start checkout 53
Installation checklist 53
Commissioning 53
Maintenance 54
Servicing the electric heater 54
Accessing the filter 54
Servicing the coil 56
Servicing the fan motor assembly 57
Periodic maintenance 58
User guide 59
Thermostats Type L, M, N, P, E for CD 59
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 4

Installation
5UNT-SVX10G-E4
Unit identification
Units arrive on site with an
identification sticker with
pictograms, which clearly indicates
important information such as the
customer order number, job name,
unit model size, coil type, presence
of an electric heater, motor type,
unit handing, speed wiring, and so
on. (See igure 1)
Figure 1 - Unit identification sticker
2
1
8
9
10 7
345
FCD204
FCD204AWH5RJW1WABWWWAAWWW2EGW
UK CO6 2NS
1-3-5
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 5

UNT-SVX10G-E46
Installation
ƒ= Indicates the unit handing
„= Indicates the coil type
…= Indicates the presence of an
electric heater
‡= Indicates the factory-wired fan speeds (AC motor) or presence of EC
motor
 = Indicates the unit description
‚ = Indicates the ZN control configuration program
2-pipe cooling only
2-pipe heating only
2-pipe cooling + electric heater
2-pipe changeover, 2-way valve
2-pipe changeover, 3-way valve
2-pipe changeover + electric heater, 2-way valve
2-pipe changeover + electric heater, 3-way valve
4-pipe
ˆ= Indicates customer order number (max 25 alphanumeric characters)
‰= Indicates job name (max 25 alphanumeric characters)
Š= Indicates personal customer tag (max 22 alphanumeric characters)
1
Zone control
2
Cascade control
Water Right hand +
Electric Right
connection
Water Left hand +
Electric Right
connection
Water Right hand +
Electric Left connection
Water Left hand +
Electric Left connection
2 STD
2 HC
4
Standard coil
2-pipe high capacity
coil
4-pipe standard coil
STD
SQ
Electric heater. If
nothing, no electric
heater
Electric heater with
electro-mechanical
relay
Electric heater with
solid-state relay
3 - 4 - 5
1 = Low speed
3 = Medium speed
5 = High speed
4 HC
4-pipe high capacity
coil
Indicates presence of EC motor
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 6

7UNT-SVX10G-E4
Installation
Speed at ESP = 0Pa Unit size 101 103 203 204 304 306 406 408 508 512 612 721
Airflow (1) (m3/h) 188 271 321 415 438 642 642 1004 1110 1329 1411 2031
Standard coil,
cooling mode Air inlet conditions : 27°C/47%, Water : 7/12°C, Constant delta T°
Total/sensible
cooling capacity (1) (kW) 1.3/0.97 1.7/1.3 1.6/ 1.3 1.9/1.6 2.8/2.1 3.7/2.8 4.1/3.1 5.5/4.3 4.9/3.8 5.5/4.4 8.8/6.6 11.1/1.5
EER/Eurovent
Energy class (2) 50/F 53/E 45/F 45/F 53/E 58/E 65/E 58/E 50/F 33/G 49/F 39/F
Water flow (1) (l/s) 0.062 0.081 0.076 0.091 0.13 0.18 0.2 0.26 0.24 0.26 0.42 0.53
Water pressure
drop (1) (kPa) 16 24.8 5.8 8 13 21.6 25.3 42.9 45.8 55.3 40.9 42.5
Water content (l) 0.5 0.5 0.6 0.6 1.3 1.3 1.5 1.5 1.5 1.5 2.8 3.3
Water connection 1/2" ISO R7 female gas 3/4" ISO R7 female gas
Standard coil,
heating mode Air inlet : 20°C, Water inlet : 50°C, Water flow from cooling mode
Heating capacity (1) (kW) 1.5 1.9 2.3 2.8 3.5 4.8 5.2 7.3 6.8 7.8 10.2 14.2
COP/Eurovent
Energy class (2) 55/E 59/E 66/E 63/E 67/E 75/D 78/D 72/D 64/E 45/F 54/E 49/F
Water flow (1) (l/s) 0.062 0.081 0.076 0.091 0.13 0.18 0.2 0.26 0.24 0.26 0.42 0.53
Water pressure
drop (1) (kPa) 13.1 20.7 4.8 6.7 13.6 23 20.6 35.2 38.7 46.8 35.6 39.5
Electric heater
(option)
Electric heater (W) NA 500 500/750 500/1000 500/1500 500/1500 500/1500 1500/4000 1500/3000 1500/4000 1500/4000 1500/4000
Power supply (V-Ph-Hz) 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50
Power absorbed
(speeds 1/3/5) (W) 11/16/27 18/25/40 19/26/41 23/37/54 26/42/61 36/58/82 36/59/82 53/87/118 53/87/124 118/139/164 119/145/171 152/184/289
Absorbed current
(min/max) (A) - 2.2 2.2/3.3 2.2/4.3 2.2/6.5 2.2/6.5 2.2/6.5 6.5/17.4 6.5/13 6.5/17.4 6.5/17.4 6.5/17.4
Fan motor
Maximun external
static pressure (Pa) 40 60 60 60 90 90 90 90 90 90 90 90
Sound levels
Sound power level
(speeds 2/3/5) (3) (dB(A)) 28/32/42 40/47/54 41/47/54 39/49/ 56 38/47/53 43/53/59 46/55/61 45/54/60 45/56/61 52/59/64 50/58/63 49/64/53
Sound pressure level
(speeds 2/3/5) (4) (dB(A)) 19/23/33 31/38/45 32/38/45 30/40/47 29/38/44 34/44/50 37/46/52 36/45/51 36/47/52 43/50/55 41/49/54 40/55/44
NR evel
(speeds 2/3/5) (4) 17/17/25 28/34/40 29/34/40 27/37/43 25/34/40 30/41/47 34/43/48 31/40/46 32/43/48 36/45/51 35/43/49 36/50/39
NC evel
(speeds 2/3/5) (4) 16/15/23 26/33/39 27/33/39 26/35/41 23/32/39 29/39/45 32/41/46 29/38/44 30/41/46 35/44/49 34/41/47 34/49/38
Speed 1/3/5 -> speed low/medium/high
(1) At high speed acc. to Eurovent conditions
(2) EER Eurovent ratio and class definition (speed low/medium/high)
(3) Levels according to Eurovent specification 8/2 (ISO 3741/88) and Eurovent C Certification
(4) Values calculated from sound levels with hypothetical acoustic attenuation of 9dB
General data
Table 1 - General data - FCD without air connections
230V/50Hz/1pH, Reversible coil, 2 Pipes
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 7

UNT-SVX10G-E48
Installation
Table 2 - General data - FCD with inlet/discharge air connections (Dia. 200mm) and EU3 filter
230V/50Hz/1pH, Reversible coil, 2 Pipes
Speed at ESP = 50Pa Unit size 204 (*) 304 (*) 306 406 408 508 512 612 721
Airflow (1) (m3/h) 145 152 402 400 544 585 864 869 1990
Standard coil, cooling mode Air inlet conditions : 27°C/47%, Water : 7/12°C, Constant delta T°
Total/sensible cooling capacity (1) (kW) 0.84/0.
68
1.2/0.8
52.6/2 2.9/2.1 3.7/2.7 3.3/2.4 4.3/3.3 6.3/4.5 11/8.4
EER/Eurovent Energy class (2) 24/E 28/D 42/C 47/C 41/C 35/D 32/D 45/C 40/D
Water flow (1) (l/s) 0.04 0.056 0.13 0.14 0.18 0.16 0.2 0.3 0.53
Water pressure drop (1) (kPa) 1.9 2.5 11.6 13.5 20.7 22.2 35.2 22.1 41
Water content (l) 0.6 1.3 1.3 1.5 1.5 1.5 1.5 2.8 3.3
Water connection 1/2" ISO R7 female gas 3/4" ISO R7 female gas
Standard coil, heating mode Air inlet : 20°C, Water inlet : 50°C, Water flow from cooling mode
Heating capacity (1) (kW) 1.2 1.4 3.3 3.5 4.5 4.2 5.7 6.9 14
COP/Eurovent Energy class (2) 32/D 32/D 53/C 56/C 50/C 45/C 42/C 49/C 50/C
Water flow (1) (l/s) 0.04 0.056 0.13 0.14 0.18 0.16 0.2 0.3 0.53
Water pressure drop (1) (kPa) 1.5 2.5 10.1 10.9 16.7 18.7 29.7 19.1 38
Electric heater (option)
Electric heater (W) 500/
1000
500/
1500
500/
1500
500/
1500
1500/
4000
1500/
3000
1500/
4000
1500/
4000
1500/
4000
Power supply (V-Ph-Hz) 230-1-
50
230-1-
50
230-1-
50
230-1-
50
230-1-
50
230-1-
50
230-1-
50
230-1-
50 230-1-50
Power absorbed (speeds 1/3/5) (W) 23/37
/54
26/42
/61
36/58
/82
36/59
/82
53/87
/118
53/87
/124
118/13
9/164
119/14
5/171 146/254/283
Absorbed current (min/max) (A) 2.2/4.3 2.2/6.5 2.2/6.5 2.2/6.5 6.5/17.4 6.5/13 6.5/17.4 6.5/17.4 6.5/17.4
Fan motor
Maximun external static pressure (Pa) 50 70 70 70 70 70 70 70 70
Sound levels
Supply sound power level (speeds
2/3/5) (3) (dB(A)) 39/45/
47
38/46/
47
45/50/
54
42/48/
51
42/49/
52
46/53/
57
50/54/
58
47/50/
54 39/43/54
Return sound power level (speeds
2/3/5) (3) (dB(A)) 42/48/
50
43/49/
51
47/52/
55
45/50/
53
40/47/
51
51/56/
59
53/56/
59
50/53/
56 42/46/67
Radiated sound power level
(speeds 2/3/5) (3) (dB(A)) 31/40/ 44
31/40/
43
33/42/
47
33/41/
47
42/48/
53
42/48/
53
44/48/
53
44/49/
53 37/41/52
NR evel (speeds 2/3/5) (4) 20/25/
27
18/25/
27
24/31/
34
24/31/
34
22/30/
34
27/33/
36
31/34/
37
27/30/
33 20/24/34
NC evel (speeds 2/3/5) (4) 18/23/
25
16/23/
26
23/29/
33
23/29/
32
20/28/
33
25/32/
35
29/32/
35
26/28/
32
18/22/
32
Speed 1/5/6 -> speed low/medium/high
(1) At medium speed in compliance with Eurovent conditions
(2) EER Eurovent ratio and class definition (speed (low/medium/high)
(3) Levels according to Eurovent specification 8/2 (ISO 3741/88) and Eurovent C Certification
(4) Values calculated from sound levels with hypothetical acoustic attenuation of 20dB
(*) CD 204/304 performance at speeds 1/4/5 : sound power at speeds 2/3/4
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 8

9UNT-SVX10G-E4
Installation
Table 3 - General data - FED without air connections
230V/50Hz/1pH, Reversible coil, 2 Pipes
Speed at ESP = 0Pa Unit size 100 200 300 400 500 600
Airflow (1) (m3/h) 310 441 609 1014 1591 1591
Standard coil, cooling mode Air inlet conditions : 27°C/47%, Water : 7/12°C, Constant delta T°
Total / sensible cooling capacity (1) (kW) 1.4 / 1.1 1.9 / 1.6 3.3 / 2.5 5.2 / 4.1 6.1 / 4.9 9.7 / 7.3
FCEER / Eurovent Energy class (2) 186 / B 185 / B 174 / B 133 / A 87 / A 125 / A
Water flow (1) (l/s) 0.068 0.093 0.16 0.25 0.29 0.46
Water pressure drop (1) (kPa) 18.3 8.2 15.5 39 60.8 48.2
Water content (l) 0.5 0.6 1.3 1.5 1.5 2.8
Water connection 1/2" ISO R7 female gas
Standard coil, heating mode Air inlet : 20°C, Water inlet : 50°C, Water flow from cooling mode
Heating capacity (1) (kW) 1.9 2.7 4.3 6.9 8 11.4
FCCOP / Eurovent Energy class (2) 240 / B 250 / B 138 / A 173 / A 103 / A 42 / A
Water flow (1) (l/s) 0.068 0.093 0.16 0.25 0.29 0.46
Water pressure drop (1) (kPa) 15.1 6.9 13.6 38 60 48
Electric heater (option)
Electric heater (W) - 500 500 / 750 1000 / 3000 1000 / 3000 1000 / 3000
Power supply (V-Ph-Hz) 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50
Power absorbed (speeds 1/3/5) (W) 3.3/5.8/12 3.7/8.7/19 4.8/18/43 8/39/65 36/112/159 36/112/159
Absorbed current (min/max) (A) - 2.2 2.2/3.3 4.3/13 4.3/13 4.3/13
Fan motor
Maximun external static pressure (Pa) 50 60 90 90 90 90
Sound levels
Sound Power evel (speeds 1/3/5) (3) (dB(A)) 32/41/49 35/45/53 37/52/61 42/57/62 56/66/69 56/66/69
Sound Pressure evel (speeds 1/3/5) (4) (dB(A)) 23/32/40 26/36/44 28/43/52 33/49/53 46/56/60 46/56/60
NR evel (speeds 1/3/5) (4) 21/28/36 22/31/40 24/38/49 29/44/49 42/54/56 42/54/56
NC evel (speeds 1/3/5) (4) 19/27/34 20/30/38 22/37/47 27/42/47 40/52/50 40/52/50
Voltage range
Minimum voltage (V) 2 2.3 2.6 333
Maximum voltage (V) 5.1 5.8 7.6 997
Speed 1/3/5 -> speed low/medium/high
(1) At high speed in compliance with Eurovent conditions
(2) EER Eurovent ratio and class definition (speed low/medium/high)
(3) Levels according to Eurovent specification 8/2 (ISO 3741/88) and Eurovent C Certification or 400/500/600 as per voltages declared to Eurovent.
(4) Values calculated from sound levels with hypothetical acoustic attenuation of 9dB
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 9

UNT-SVX10G-E410
Installation
Table 4 - General data - FED with inlet/discharge air connections (Dia. 200mm) and EU3 filter
230V/50Hz/1pH, Reversible coil, 2 Pipes
Speed at ESP = 50Pa Unit size 200 300 400 500 600
Airflow (1) (m3/h) 104 376 449 827 963
Standard coil, cooling mode Air inlet conditions : 27°C/47%, Water : 7/12°C, Constant delta T°
Total / sensible cooling capacity (1) (kW) 0.65 / 0.5 2.3 / 1.7 3 / 2.2 4.2 / 3.2 6.8 / 5
EER / Eurovent Energy class (2) 84 / B 100 / A 128 / A 78 / B 110 / A
Water flow (1) (l/s) 0.031 0.11 0.14 0.2 0.33
Water pressure drop (1) (kPa) 1.2 8.1 14.4 34.7 25.8
Water content (l) 0.6 1.3 1.5 1.5 2.8
Water connection 1/2" ISO R7 female gas
Standard coil, heating mode Air inlet : 20°C, Water inlet : 50°C, Water flow from cooling mode
Heating capacity (1) (kW) 0.81 3 3.6 5.1 7.6
COP / Eurovent Energy class (2) 98 / A 191 / A 148 / A 86 / B 119 / A
Water flow (1) (l/s) 0.031 0.11 0.14 0.2 0.33
Water pressure drop (1) (kPa) 0.97 7.1 11.6 20.3 22.4
Electric heater (option)
Electric heater (W) 500 500 / 750 1000 / 3000 1000 / 3000 1000 / 3000
Power supply (V-Ph-Hz) 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50
Power absorbed (speeds 1/3/5) (W) 3.7/8.7/19 4.8/18/43 6/25/46 23/69/100 25/76/109
Absorbed current (min/max) (A) 2.2 2.2/3.3 4.3/13 4.3/13 4.3/13
Fan motor
Maximun external static pressure (Pa) 50 70 70 70 70
Sound levels
Supply sound power level (speeds 2 / 3 / 5) (3) (dB(A)) 32/38/47 39/46/56 36/52/58 47/57/60 47/57/60
Return sound power level (speeds 2 / 3 / 5) (3) (dB(A)) 35/40/48 40/47/56 36/52/58 50/60/63 50/60/63
Radiated sound power level (speeds 2 / 3 / 5) (3) (dB(A)) 29/34/42 31/37/46 32/46/51 40/50/53 40/50/53
NR evel (speeds 2 / 3 / 5) (4) 13/17/25 19/26/36 16/34/39 27/37/40 27/37/40
NC evel (speeds 2 / 3 / 5) (4) 10/15/24 17/25/34 14/32/37 25/35/38 25/35/38
Voltage range
Minimum voltage (V) 2.3 2.6 3 3.5 3
Maximum voltage (V) 5.8 7.6 977
Speed 1/5/6 -> speed low/medium/high
(1) At medium speed in compliance with Eurovent conditions
(2) EER Eurovent ratio and class definition (speed (low/medium/high)
(3) Levels according to Eurovent specification 8/2 (ISO 3741/88) and Eurovent C Certification or 400/500/600 as per voltages declared to Eurovent.
(4) Values calculated from sound levels with hypothetical acoustic attenuation of 20dB
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 10

Installation
11UNT-SVX10G-E4
Operating limits at air side
(temperature and airflow)
Cooling mode
The unit must not be installed in an
environment where the temperature
exceeds 40°C.
Heating mode
The discharge air temperature must
not exceed 70°C to avoid damaging
the internal unit insulation.
The manufacturer recommends to
not exceed 55°C discharge air
temperature to ensure ideal comfort
and avoid air stratification.
Operating limits at water
side
Water pressure must not exceed
15 bar.
Water temperature must not
exceed 95°C.
Minimal water temperature
depends on glycol percentage.
Water quality
recommendations
At installation and then yearly, the
manufacturer recommends having
water analyzed for bacteria (ferro-
bacteria, bacteria generating H2S
and reducing sulfates) and also a
chemical analysis, to avoid
corrosion and scaling. The water
circuit must include water treatment
devices: filters,
additives,intermediate exchangers,
purges,vents, isolating valves,
etc.depending on the results of
these analyses.
CAUTION! Proper Water
Treatment!
The use of untreated or improperly
treated water in this equipment may
result in scaling, erosion, corrosion,
algae or slime. It is recommended
that the services of a qualified water
treatment specialist be engaged to
determine what water treatment, if
any, is required. Trane assumes no
responsibility for equipment failures
which result from untreated or
improperly treated water, or saline
or brackish water
CAUTION! Coil
recommendation
Coil must not be used in a corrosive
environment, to prevent corrosion
of aluminium components. Coated
fin is available as an option.
Contact your local Trane sales office
for advice.
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 11

Installation
UNT-SVX10G-E412
Handling the unit
WARNING! Wear protection gloves
when handling the unit. When
removing the unit from its pallet, do
not handle it by pipes, spigots,
valves, drain pan, control panel, or
fresh air inlet. Take precaution to
not damage the unit.
Mounting the accessories
Mount all accessories before
mounting the unit in the ceiling.
Each accessory available for the fan
coils is supplied with its connection
diagram. ollow these instructions.
You can obtain additional copies
from your local sales office.
Possible positions on the unit are
shown in igure 2.
Fresh air controller
Different fresh air controllers are
available as a factory-mounted
option.
• D 100 mm duct connection
• D 125 mm duct connection
• ixed airflow controller 30 m3/h
for D 100 mm duct
• ixed airflow controller 45 m3/h
for D 100 mm duct
• Adjustable controller 60-130 m3/h
for D 125 mm duct
CAUTION! In all cases, the fresh air
spigot must be connected to a
filtered and pre-treated air supply
(i.e. air handling unit)
Constant maximum airflow =
-10/+20%
Delta P (upstream/downstream) =
50-200 Pa
Figure 2 - Possible air intake positions
A = resh air duct placed at air intake
B = resh air duct place at air discharge
L = Left hand configuration
R = Right hand configuration
1 = Airflow
2 = resh air intake possibility, in compliance with unit size and configuration
2
1
2
R
L
1
1
1
1
1
1
1
2
2
2
2
2
2
AB
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 12

Installation
13UNT-SVX10G-E4
Adjusting the 60-130 m3/h airflow
controller
WARNING! Ensure that the plastic
membrane is always positioned as
indicated in igure 4.
Adjust the fresh air controller (ø
125 mm only) by placing the two
plastic restrictors as indicated in
igure 5.
Figure 3 - Fresh air adapter
1 = resh air controller
Figure 4 - Fresh air controller membrane
1 = resh air controller
2 = Membrane
3 = Top
4 = Bottom
1
1
2
3

4
Figure 5 - Position of restrictors on the 60 to 130 m3/h fresh air controller
60 m3/h 75 m3/h
90 m3/h 130 m3/h
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 13

Installation
UNT-SVX10G-E414
Mounting rubber isolators
4 rubber isolators are supplied,
fixed on the drain pan. Mount the
isolators on the casing, below the
fixation hole, as shown in igure 6.
Figure 6 - Mounting rubber isolators
1 = Rubber isolator
2 = 1 lock nut or 2 nuts
3 = Key (fixation) hole
WARNING! Do not lift the unit
upwards on the threaded rods more
than 12 mm when installing or
when it is installed. This may cause
one or more isolators to come out
of position from the unit sheet
metal keyhole and the unit could
fall.
Mounting conical water connectors
Two or four conical connectors are
supplied with seals, fixed on the
drain pan. Place the seal on the
connector then screw the connector
onto the water valve. Tighten the
screw to 25 N.m.
Mounting flexible hoses
Screw the hoses onto the valve
inlets/outlets and connect to water
lines.
Mounting the condensate pump kit
Refer to the notice supplied with the
accessory.
1
2
3
Mounting the unit in the
ceiling
Two methods can be used to mount
the unit in the ceiling. A minimum
of 3 fixation points are necessary up
to the unit size 408. When there are
3 fixation points, place two screws
on one side of the unit, and one
centered on the opposite side.
1. The unit is held against the
ceiling using an elevator and is
fixed with a cartridge drill.
2. The threaded rods are fixed to
the ceiling first, and then the unit
is hung on the rods.
Units are to be suspended from the
ceiling on threaded rods or lag
screws supplied by the installer. The
holes are located on the top of the
unit. Refer to Table 5 for drilling
distances and to igure 7 for hole
locations.
Drill into the ceiling according to the
dimensions shown in igure 7.
ix the 3 or 4 suspension rods or
lag screws into the ceiling.
Units can be placed against the
ceiling. Design enough space
between 2 units for maintenance
(control box, water connections and
drain pan access. See igure 8.
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 14

Figure 7 - Hole locations
Table 5 - Drilling distances
(1) If the threaded rod diameter is smaller than 6 mm, use a washer.
Number of
suspension points ABCDØ hole Ø threaded rods (1)
Unit size (mm) (mm) (mm) (mm) (mm) (mm)
FCD 101-103
FED 100 3/4 478 463 585.4 338 15.1 6
FCD 203-204
FED 200 3/4 628 463 713.2 338 15.1 6
FCD 304-306
FED 300 3/4 858 463 922.2 338 15.1 6
FCD 406-408
FED 400 3/4 1008 463 1063.2 338 15.1 6
FCD 101-103
FED 100 3/4 478 579 713.2 338 15.1 6
FCD 203-204
FED 200 3/4 628 579 713.2 338 15.1 6
FCD 304-306
FED 300 3/4 858 579 922.2 338 15.1 6
FCD 406-408
FED 400 3/4 1008 579 1063.2 338 15.1 6
FCD 304-306 High
capacity
FED 300 High capacity 4 858 637 1068.5 15.1 6
FCD 406-408 High
capacity
FED 400 High capacity 4 1008 637 1192.5 15.1 6
FCD 508-512-FED 500 4 1158 637 1321.5 15.1 6
FCD 612-FED 600 4 1458 637 1591 15.1 6
FCD 721 4 1458 729 1630 15.1 6
C
D
B
A
Installation
15UNT-SVX10G-E4
ø 160
250mm
ø 200
Without air duct
connection
With air duct
connection
With or without air
duct connection
Figure 8 - Clearance recommendations
E
(mm) F (mm) G (mm) H (mm)
FCD 101-103-203-204-304-306-406-408-508-512-612
FED 100-200-300-400-500-600 141 143 210 276
FCD 721 141 143 255 253
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 15

Installation
UNT-SVX10G-E416
Mount the unit, with a slight slope
towards the drain pan outlet as
shown in igures 9 and 10. Ensure
that sufficient service access is
provided around the unit for
maintenance.
CAUTION! If the unit is not
mounted with a slight slope, the
condensates will not drain correctly
through the hole provided. Refer to
igures 9 and 10. In order to be sure
that the unit is correctly installed, it
is highly recommended to make a
test filling in the drain pan with
water and make sure that water
does not overflow.
Figure 9
1 = Drain pan outlet
Figure 10
+ 2 mm
- 2 mm
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 16

Installation
17UNT-SVX10G-E4
Ductwork connection
Tables 6-7 list all the possible
connections.
Ducts must be connected to spigots
by means of duct tape. They must
never be screwed. Make sure that
the entire spigot surface area is
covered. Push the duct as far as
possible onto the spigot towards
the unit to get the best air tightness.
All open spigots should be
connected to ceiling grilles or
diffusers using normally equal duct
runs to minimize the damping
requirements at the grilles. Unused
spigots must be sealed. To ensure
maximum performances of the unit,
the ductwork must be as short as
possible, with a minimum number
of bends.
Table 6 - Inlet and outlet connections - FCD
101 103 203 204 304 306 406 408 508 512 612 721
Circular connection ø 160 mm
ø 160
1
or
22222
or
333
or
444
or
555
or
6-
Circular connection ø 200 mm
ø 200
111 or
2
1
or
2
1
or
2
2
or
3
2
or
3
2
or
3
2
or
3
3
or
4
3
or
45
Oblong connection, equivalent ø
250 mm
250mm
11111 or
2
1
or
2
1
or
222
or
3
2
or
3
2
or
3
3
or
4
Rectangular connection for (39 mm
deep)
194 x
418 mm 194 x 568 mm 194 x 798 mm 194 x 948 mm 194 x 1098 mm 194 x 1398 mm 238 x 1398 mm
Rectangular connection for Trane
discharge grille
(80 mm deep) 152 x
403 mm 152 x 503 mm 152 x 803 mm -- -
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 17

Installation
UNT-SVX10G-E418
Table 7 - Inlet and outlet connections - FED
FED 100 FED 200 FED 300 FED 400 FED 500 FED 600
Circular connection ø 160 mm
ø 160
1 or 2 2 2 or 3 3 or 4 4 or 5 5 or 6
Circular connection ø 200 mm
ø 200
1 1 or 2 2 or 3 2 or 3 2 or 3 3 or 4
Oblong connection, equivalent ø 250 mm
250mm
111 or 2 1 or 2 22
Rectangular connection for (39 mm deep)
194 x 418 mm 194 x 568 mm 194 x 798 mm 194 x 948 mm 194 x 1098
mm 194 x 1398 mm
Rectangular connection for Trane
discharge grille
(80 mm deep) 152 x 403 mm 152 x 503 mm 152 x 803 mm ---
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 18

Installation
19UNT-SVX10G-E4
Water connection
Refer to igure 11 to locate and
identify the inlet and outlet water
connections.
CAUTION!The coil headers are not
designed to withstand the torque
necessary to tighten the connector.
Use a suitable counter-spanner.
Tighten to torque 25 N.m
The water inlet is on the bottom of
the coil and the water outlet is on
the top of the coil.
On 4-pipe coils, the heating
connections are located on the right
hand side of the coil (see igure 11).
Figure 11 - Vent and drain positions on straight or inclined coil
V = Vent
D = Drain
C = Cooling piping
H = Heating piping
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 19

Installation
UNT-SVX10G-E420
Table 8 - Water connection types and diameters
Unit size 101/103 203/204 304/306 406/408 508/512 612 721
Standard 2-pipe coil
Customer connection Ø1/2" Gas Ø1/2" Gas Ø1/2" Gas Ø1/2" Gas Ø1/2" lat gasket Ø3/4" lat gasket Ø3/4" lat gasket
Hi h Efficiency 2-pipe coil
Customer connection Ø1/2" Gas Ø1/2" Gas Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø3/4" lat gasket Ø3/4" lat gasket
Standard 4-pipe coil
Customer connection cooling circuit Ø1/2" Gas Ø1/2" Gas Ø1/2" Gas Ø1/2" Gas Ø1/2" lat gasket Ø3/4" lat gasket Ø3/4" lat gasket
Customer connection heating circuit Ø1/2" Gas Ø1/2" Gas Ø1/2" Gas Ø1/2" Gas Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket
Hi h Efficiency 4-pipe coil
Customer connection cooling circuit Ø1/2" Gas Ø1/2" Gas Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø3/4" lat gasket Ø3/4" lat gasket
Customer connection heating circuit Ø1/2" Gas Ø1/2" Gas Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket
Unit size 101/103 203/204 304/306 406/408 508/512 612 721
Standard 2-pipe coil
Customer connection Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø3/4" lat gasket Ø3/4" lat gasket
Hi h Efficiency 2-pipe coil
Customer connection Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø3/4" lat gasket Ø3/4" lat gasket
Standard 4-pipe coil
Customer connection cooling circuit Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø3/4" lat gasket Ø3/4" lat gasket
Customer connection heating circuit Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket
Hi h Efficiency 4-pipe coil
Customer connection cooling circuit Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø3/4" lat gasket Ø3/4" lat gasket
Customer connection heating circuit Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket Ø1/2" lat gasket
1 = ree issue valve(s) from customer (terminal block only)
W = Without valve
UNT-SV 10G-BAT1_Mise en page 1 7/26/2013 2:41 PM Page 20
