OWNER’S GUIDE
Pub.No. 22-5185-01
Programmable Heat-Pump Thermostat
TAYSTAT 540
69-1229

2Pub. No. 22-5185-01
69-1229
FEATURES
The Trane Co. sells comfort systems.
Comfort is achieved through matching the
correct equipment and controls. This
thermostat is designed to provide the
maximum comfort for your needs.
Some of the basic offerings are:
•Program up to four time periods and
temperature settings to complement
your lifestyle.
•Set different schedules for weekdays
and weekends.
•Programs are permanently held in
memory in the event of a power failure.
•Indefinite temperature hold.
•Preprogrammed for your convenience.
M14312
FAN SYSTEM
Auto On Cool Off Heat Em. Ht.
Hold Select
PM
DECREASE KEY:
DECREASE
TEMPERATURE,
SET TIME, OR SCROLL
BACKWARD THROUGH
DAYS OF WEEK.
SELECT KEY: SET
CURRENT DAY AND
TIME, OR SET
PROGRAM DAY
AND TIME.
INCREASE KEY:
INCREASE
TEMPERATURE,
SET TIME, OR SCROLL
THROUGH DAYS OF WEEK.
HOLD KEY OVERRIDES PROGRAM
OR HOLDS TEMPERATURE INDEFINITELY.
LCD DISPLAY
FAN SWITCH
AUTO: FAN RUNS ONLY
WHEN SYSTEM OPERATES.
ON: FAN RUNS
CONTINUOUSLY.
SYSTEM SWITCH. SLIDE TO
COOL, OFF, OR HEAT FOR
PROGRAMMING. SLIDE TO
COOL, OFF, HEAT, OR EM. HT.
FOR CURRENT SETTING.

3Pub.No. 22-5185-01
69-1229
Your thermostat displays the current day, time, period, temperature and system ( for heating
or for cooling) in normal mode. In programming mode, only the setting or settings being
programmed display. For example “Sa Su” (Saturday Sunday) displays while programming the
weekend schedule. All settings are explained below:
TEMPORARY
PM
M14308
SET
Mo Tu We Th Fr Sa Su
WAKE LEAVE RETURN SLEEP
DURING NORMAL MODE, THE
CURRENT PERIOD DISPLAYS.
DURING PROGRAMMING,THE
PERIOD BEING PROGRAMMED
DISPLAYS (WAKE, LEAVE,
RETURN OR SLEEP).
FLAME DISPLAYS DURING
HEATING OR WHILE
PROGRAMMING HEATING
SETPOINT. SNOWFLAKE
DISPLAYS DURING COOLING
OR WHILE PROGRAMMING
COOLING SETPOINT.
CURRENT TEMPERATURE
DISPLAYS.HEATING AND
COOLING SETPOINT DISPLAYS
DURING PROGRAMMING.
TEMPORARY DISPLAYS
DURING TEMPORARY
TEMPERATURE HOLD.
SET DISPLAYS
WHILE SETTING
THE CLOCK.
CURRENT TIME DISPLAYS
IN NORMAL MODE. PERIOD
START TIME DISPLAYS IN
PROGRAMMING MODE.
CURRENT DAY DISPLAYS
IN NORMAL MODE.
MONDAY THROUGH FRIDAY
DISPLAY DURING WEEKDAY
PROGRAMMING MODE.
SATURDAY AND SUNDAY
DISPLAY DURING WEEKEND
PROGRAMMING MODE.

4Pub. No. 22-5185-01
69-1229
PROGRAMMING YOUR
THERMOSTAT
CLOCK
Setting the Current Day and Time
To set or reset the current day and time,
follow these instructions.
IMPORTANT
Always press the keys with your
fingertip or similar blunt tool. Sharp
objects like pen and pencil points will
damage the keyboard.
Note: To exit the programming mode at
any time, press Hold.
1. To set Current Time, press Select twice.
Press ▲or ▼to set current time.
Note: While setting the current time, SET
displays.
2. To set Day of Week, press Select
again. Press ▲or ▼to set current day.
SET
PM
M12591
3. Press Hold to exit programming mode.
M12593
SET

5Pub.No. 22-5185-01
69-1229
Organizing Your Schedule
Your thermostat can be set for four time periods (Wake, Leave, Return, and Sleep) for the
weekday schedule (Monday through Friday), and four time periods for the weekend schedule
(Saturday and Sunday). Without additional programming, your thermostat follows the same
preprogrammed schedule for both weekdays and weekends (see Table 1).
WAKE Choose the time you want your heating or cooling system to start to
reach your comfort temperature after the SLEEP period.
How? Consider the time required to reach your comfort level. Adjust the
Wake time to earlier when you know it will take the system longer to
reach your comfort temperature.
LEAVE Choose the time you want your heating or cooling system to start an
energy-saving mode while you are away at work or school.
How? Set the Leave temperature lower during heating season, and
higher during cooling season.

6Pub. No. 22-5185-01
69-1229
RETURN Choose the time you want your heating or cooling system to start to
reach your comfort temperature after the energy-savings LEAVE
period.
How? Consider the time required to reach your comfort level. Adjust the
Return time to earlier when you know it will take the system longer to
reach your comfort temperature.
SLEEP Set the time you want your heating or cooling system to start to reach
your sleep temperature.
To use this period as an energy-savings mode, set the temperature
lower during heating season, and higher during cooling season.

7Pub.No. 22-5185-01
69-1229
The preprogrammed schedule is shown in Table 1. You may keep this schedule or organize your
own. Schedules are adjustable as often as you wish. If you decide to keep this schedule, no
further programming is necessary.
Table 1. Preprogrammed Weekday and Weekend Schedule.
Period Time Heat Setpoint Cool Setpoint
Wake 6:00 AM 70°F (21°C) 78°F (26°C)
Leave 8:00 AM 62°F (17°C) 85°F (29°C)
Return 5:00 PM 70°F (21°C) 78°F (26°C)
Sleep 10:00 PM 62°F (17°C) 75°F (24°C)
To begin programming your weekday and weekend schedules, fill in Tables 2 and 3.

8Pub. No. 22-5185-01
69-1229
Customizing Your Weekday Schedule
Use Table 2 to organize your weekday schedule. Fill in the times and temperatures you want to
program. The names of the four periods are filled in for you.
Table 2. Your Weekday Schedule.
Period Start Time
Heating
Temperature
Cooling
Temperature
Wake
Leave
Return
Sleep

9Pub.No. 22-5185-01
69-1229
Customizing Your Weekend Schedule
Use Table 3 to organize your weekend schedule. Fill in the times and temperatures you want to
program. The names of the four periods are filled in for you.
Table 3. Your Weekend Schedule.
Note: Start Time is the time your thermostat begins to reach the desired temperature.
Note: The thermostat cannot be set higher than 99°F (37°C) or lower than 50°F (10°C).
Period Start Time
Heating
Temperature
Cooling
Temperature
Wake
Leave
Return
Sleep

10 Pub. No. 22-5185-01
69-1229
Setting the Weekday Program
IMPORTANT
Always press the keys with your
fingertip or similar blunt tool. Sharp
objects like pen and pencil points will
damage the keyboard.
1. Slide the SYSTEM switch to the setting
you want to program (Heat or Cool).
Throughout programming, the thermo-
stat displays a flame (heating) or
snowflake (cooling) to help you
identify which mode you are program-
ming. At the end of Setting the Week-
end Program, you are prompted to
return to this step to program the
opposite mode. Example shows Cool
setting.
NOTE: To exit the programming mode at
any time, press Hold (the thermostat
saves your changes).
M17336
FAN
Auto On
Hold Select
PM
SYSTEM SWITCH
SYSTEM
Cool Off Heat Em. Ht.

11 Pub.No. 22-5185-01
69-1229
2. Set weekday Wake time and tempera-
ture.
a. Press Select four times.Press ▲
or ▼to set Wake time.
Note: When setting the Weekday Program,
the days Mo Tu We Th Fr display.
3. Set weekday Leave time and tempera-
ture.
a. Press Select. Press ▲or ▼to
set Leave time.
AM
M17331
SET
Note: Schedule times are programmable in
increments of 15 minutes. For each
press, the time increases or decreases
by 15 minutes.
b. Press Select. Press ▲or ▼to
set Wake temperature.
M17332
SET
AM
M17333
SET

12 Pub. No. 22-5185-01
69-1229
b. Press Select. Press ▲or ▼to
set Leave temperature.
b. Press Select. Press ▲or ▼to
set Return temperature.
M17312
SET
4. Set weekday Return time and tempera-
ture.
a. Press Select. Press ▲or ▼to
set Return time.
PM
M12628
SET
M17314
SET
5. Set weekday Sleep time and tempera-
ture.
a. Press Select. Press ▲or ▼to
set Sleep time.
PM
M17315
SET

13 Pub.No. 22-5185-01
69-1229
b. Press Select. Press ▲or ▼to
set Sleep temperature. Setting the Weekend Program
Note: For initial programming, you must set
the weekday schedule as shown in
Setting the Weekday Program before
you can access weekend program-
ming. If your weekday is already
programmed, you can access weekend
programming by pressing Select 12
times.
1. Set weekend Wake time and tempera-
ture.
a. Press Select. Press ▲or ▼to
set Wake time.
M17316
SET
IMPORTANT:
Before pressing another key,
continue with Setting the Weekend
Program.
AM
M17317
SET

14 Pub. No. 22-5185-01
69-1229
b. Press Select. Press ▲or ▼to
set Wake temperature. Example
shows Cool setting.
Note: When setting the Weekend Program,
the days Sa Su display.
M17318
SET
AM
M17319
SET
b. Press Select. Press ▲or ▼to
set Leave temperature.
M17320
SET
2. Set weekend Leave time and tempera-
ture.
a. Press Select. Press ▲or ▼to set
Leave time.

15 Pub.No. 22-5185-01
69-1229
3. Set weekend Return time and tempera-
ture.
a. Press Select. Press ▲or ▼to
set Return time.
b. Press Select. Press ▲or ▼to
set Return temperature.
4. Set weekend Sleep time and tempera-
ture.
a. Press Select. Press ▲or ▼to
set Sleep time.
PM
M17321
SET
PM
M17323
SET
b. Press Select. Press ▲or ▼to
set Sleep temperature.
M17322
SET
M17324
SET

16 Pub. No. 22-5185-01
69-1229
5. Press Select. End displays. Temporary Temperature Hold
1. Press ▲or ▼key twice to set a
temporary temperature.
M17325
SET
6. Return to Step 1., Setting the Week-
day Program to program the opposite
mode, (heating) or (cooling).
Your weekday and weekend schedules are
now programmed.
PM
M17300
TEMPORARY
PM
M17326
Note: The temporary temperature setting
remains in effect until the next
program period. To cancel, press
Hold twice and wait five seconds.

17 Pub.No. 22-5185-01
69-1229
Indefinite Temperature Hold
The Hold key allows you to hold a tempera-
ture indefinitely. When Hold is active, Hld
displays continuously.
1. Press Hold.
2. Press ▲or ▼key to set indefinite
temperature setting.
System and Fan
Use the SYSTEM and FAN switches to
change the settings.
System Setting
To select the desired system setting, slide the
SYSTEM switch in the lower right corner of
the thermostat.
3. To cancel, press Hold and wait five
seconds.
M17327
M17336
FAN
Auto On
Hold Select
PM
SYSTEM SWITCH
SYSTEM
Cool Off Heat Em. Ht.

18 Pub. No. 22-5185-01
69-1229
SYSTEM settings control the thermostat
operation as follows:
Cool: Normal setting for months when your
home needs cooling (air condition-
ing). Digital display shows a
snowflake when cooling is on.
Off: Both heating and cooling are off.
Heat: Normal setting for months when your
home needs heating. Digital display
shows a flame when heating is
on.
Em. Ht.: Switch to this setting when your
home needs heat, but your equip-
ment needs servicing or is not
working properly. In this mode, the
thermostat controls only the backup
heat. The heat pump is off.
NOTE: In the programming mode, the
and indicate the system setting.
Fan Setting
To select the desired fan setting, slide the
FAN switch in the lower left corner of the
thermostat.
M17329
M17337
FAN
Auto On
FAN SWITCH
SYSTEM
Cool Off Heat Em. Ht.

19 Pub.No. 22-5185-01
69-1229
Auto: Normal setting for most homes.
Some systems may delay the fan
turning on and off with the equip-
ment.
On: The fan runs continuously. Use for
improved air circulation and air
quality.
▲
Emergency Heat
The Emergency Heat feature allows you to
“turn on” the electric heat section of the
system by moving the system switch to the
Em. Ht. position. The indicator flashes and
FAN
Auto On
FAN
SWITCH
M10273
points to Em Ht when the system is in
emergency heat mode. The indicator may
also point to Aux Ht if the system calls for
additional back-up heating.
Auxiliary Heat
The auxiliary heaters assist the heat pump
under normal conditions when low outdoor
temperature occurs. The indicator points to
Aux Ht when the auxiliary heating equipment
operates.
▲
▲
Set Room
M10287
INDICATOR
Em Ht
Aux Ht

20 Pub. No. 22-5185-01
69-1229
Minimum Off-Timing
Your thermostat comes equipped with a
minimum off-timer. At certain times during
heating or cooling, the system will not start up
again for at least five minutes after it turns off
(compressor is off and can’t be heard). This
occurs when you change the SYSTEM switch
position while the compressor is off or when
you change the temperature setting, causing
the compressor to turn off. The minimum off-
timer is also triggered during power interrup-
tion and power restoration. You will know the
minimum off time is in effect by a flashing
or on the display.
CAUTION
Equipment Damage Hazard.
Can cause permanent damage to
the compressor or other equipment.
To avoid possible equipment damage,
do not operate cooling when outside
temperature is below 50°F (10°C).
See equipment manufacturer instruc-
tions. To avoid possible compressor
damage, allow the compressor to
remain off for five minutes before
restarting.
