AD5900-30
30dB Circular Polarized Dish Antenna
5.725 to 5.875 GHz
DATASHEET
!Sturdy Mounting system - ideal
for tower/pole mounting
!Allows a 7-mile range with the
FalconPlusTM
!Circular polarized for the best
propagation in weather
!Includes low-noise amplifier and
filter in feedhorn assembly
!Aluminum construction
!Includes cable
!Designed for use with FalconPlusTM
VRX5900TM receivers
!Available in right or left hand
circular polarization

[phone] • www.trangosys.com • 15070 Avenue of Science Suite 200, San Diego, CA 92128
AD5900-30-R Electrical Properties
Dish Parameters
FREQUENCY RANGE
5725–5875 MHz
ELEMENT GAIN
>30dBi for passive portion of dish
FRONT-TO-BACK RATIO
>30dB
E-PLANE BEAMWIDTH
>5o
H-PLANE BEAMWIDTH
>5o
POLARIZATION
right-hand circular (-R), left-hand circular (-L)
CROSS-POLARIZATION REJECTION
>15dB
BANDWIDTH
150 MHz (VSWR < 2.0:1)
AD5900-30-R
Mechanical Properties
PACKAGE
Feed: white ABS weatherproof construction
Dish: 3003-0, 050” thick aluminum with off-white
paint
DIMENTIONS
36” diameter by 15” deep with feed attached
CONNECTOR
SMA female bulkhead
CABLE
38” SMA-M to SMA-M double-braided RGS142
MOUNTING PROVISIONS
Azimuth-Elevation mounting hardware for 2 3/8”
diameter steel pole
WIND LOADING
Wind force at 100 mph: 340 lbs. at 60oangle
WEIGHT
5 lbs.
AD5900-30 DATASHEET
DS_5900-30-R.pmd 1-10-03
LNA/Filter Parameters
CASCADE GAIN
>6.5dB
INPUT COMPRESSION POINT
> -10dBm
VSWR
> 2:1 typical across bandwidth
POWER REQUIREMENT
6-12VDC, provided on center conductor at 25mA
(provided by VRX5900)
