AD5900-15™DATASHEET
!Sturdy flat-panel design.
!Allows one-mile range when
used on the Tx and Rx of a
FalconPlus system.
!Transmitter and receiver versions
available.
!Circular polarized for the best
propagation in weather.
!Right-hand and left-hand circular
polarizations available.
!Designed for use with FalconPlus ™
transmitters and receivers (as
shown, sold separately).
!Weatherproof.
!Cables and mounting hardware
included.
15dB 5.8GHz Circular Polarized Patch Antenna

AD5900-15™DATASHEET
[phone] • www.trangosys.com • 9939 Via Pasar, San Diego CA 92126 DS_AD590015.p65 02-05-21
AD5900-15
Electrical Properties
FREQUENCY RANGE
5725–5875 MHz
BANDWIDTH
150MHz (VSWR < 2.0:1)
ELEMENT GAIN
15dBi
FRONT-TO-BACK RATIO
> 15dB
AXIAL RATIO
< 3dB across band
E-PLANE BEAMWIDTH
> 18°
H-PLANE BEAMWIDTH
> 18°
POLARIZATION
right-hand circular (-R), left-hand circular (-L)
IMPEDANCE
50 Ohms nominal
AD5900-15
Mechanical Properties
PACKAGE
weatherproof white ABS radome with powder-
coated aluminum backplate
DIMENSIONS
9.5”×8.5”×2.25” with connector
CONNECTOR
SMA female bulkhead or SMA-RP bulkhead
CABLE
12” RG316DS with SMA-M transmitters
MOUNTING PROVISIONS
bracket model AMH-001 included for mounting on
23/8” diameter mast
Schematic shown from left to right:
front view, side view, bottom view.
Four models to choose from
PART NUMBER USED WITH RADIO POLARIZATION
AD5900-15-RP VTX5900 right-hand
AD5900-15-LP VTX5900 left-hand
AD5900-15-R VRX5900 right-hand
AD5900-15-L VRX5900 left-hand
8.500
1.00
3.777
4.665
9.470
