Vogue FS488 User manual

Model:
FS488
Digital
Platform Scale
Instruction manual
FS488_EN_A5_v1_20210517.indb 1FS488_EN_A5_v1_20210517.indb 1 2021/5/17 16:372021/5/17 16:37

2
EN
Features:
• Indicates the volume of milk and water
• Converts between metric and imperial measurements, for both weight and volume
• Low battery power / Overload indication
• High precision strain gauge sensor
• Zero and tare function
• Auto shut-off
• Increment: 1g / 0.1oz
• Maximum load capacity: 10kg / 22lb
To install or replace batteries
1. Remove the battery compartment cover (on the bottom of the appliance).
2. Insert 3 x 1.5V AAA batteries (not supplied), and ensure to follow polarity markings on the battery
compartment. Re-locate the battery compartment cover.
3. Position the appliance on a flat stable surface.
Note: It is important that the scale is level to ensure accuracy.
Screen:
Weight mode
Volume unit (ml)
Weight unit (lb:oz)
Weight unit (g)
Negative value
Zero weight Milk volume mode
Water volume mode
Tare weight
Volume unit (fl’oz)
Button function
Press to convert Mode/Unit in the sequence as below:
Weight mode (g) Water volume mode (ml) Milk volume mode (ml)
Weight mode (lb:oz) Water volume mode (fl’oz) Milk volume mode (fl’oz)
Zero / Tare
FS488_EN_A5_v1_20210517.indb 2FS488_EN_A5_v1_20210517.indb 2 2021/5/17 16:372021/5/17 16:37

3
EN
To Start Weighing:
Weighing mode
1. Place the scale on a solid and flat surface.
2. Place bowl (if used) on the scale before turning on the scale.
3. Gently press on the scale with your hand to turn on. Wait until LED shows ‘0’.
4. Press to convert to Weight mode.
5. Place items on the scale to start weighing, LED will show the weight reading.
Volume indication mode
1. Place the scale on a solid and flat surface.
2. Gently press on the scale with your hand to turn on. Wait until LED shows ‘0’.
3. Press to choose “Water” or “Milk” mode.
4. Put a liquid container on the scale platform. LED shows the weight of container.
5. Press to reset the reading to “0”.
6. Pour liquid (water or milk) into the container. LED shows the volume of the liquid.
“ZERO” or “TARE” function
To weigh different loads consecutively without removing previous loads from the scale:
1. Put first Load on the scale and get weight reading.
2. Press to reset the reading to “0” before adding next load. You can repeat this operation.
Condition 1: “ZERO” function
When total sum of all loads on scale is ≤4% of scale’s maximum weight capacity (4% here means 400g
with this scale), LED will show “-----” or “0 g” each time is pressed.
“-----” means reading is not stable. Please wait for a moment. “0 g” and meanwhile an icon “O” on the
left side of LED indicate ZERO function is activated. In this case, maximum weight capacity remains
unchanged.
Condition 2: “TARE” function
When total sum of all loads on scale is >4% of scale’s maximum weight capacity (4% here means 400g
with this scale), LED will show “-----” or “0 g” each time is pressed.
“-----” means reading is not stable. Please wait for a moment. “0 g” and meanwhile an icon “T” on the left
side of LED indicate TARE function is activated. In this case, maximum weight capacity is reduced by total
weight of all loads.
Under this condition:
• By pressing , you can see the total weight of all loads on the scale.
• To weigh more loads, just press to reset LED reading to ‘0’ again.
FS488_EN_A5_v1_20210517.indb 3FS488_EN_A5_v1_20210517.indb 3 2021/5/17 16:372021/5/17 16:37

4
EN
Shut off
Auto shut-off: Auto shut-off occurs if LED shows ‘0’ or shows the same weight reading for 2 minutes.
Warning indicators
Low battery.
Replace with new batteries.
Scale overloaded.
Remove items to avoid damage.
Cleaning, Care & Maintenance
• Clean the case with a damp cloth. Never immerse in water or use chemical/abrasive cleaning agents.
• Remove the batteries if the unit is not to be used for an extended period of time.
• With the hanging hole on the back, the unit can be hanged on the wall for storage.
Compliance
Dispose of depleted batteries in accordance with local regulations, within the EC there
are nominated disposal points for batteries.
The WEEE logo on this product or its documentation indicates that the product must
not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and
environmentally safe recycling process. For further information on how to dispose of
this product correctly, contact the product supplier, or the local authority responsible for
waste disposal in your area.
VOGUE parts have undergone strict product testing in order to comply
with regulatory standards and specifications set by international,
independent, and federal authorities.
VOGUE products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of VOGUE.
Every effort is made to ensure all details are correct at the time of going to press, however, VOGUE reserve the right to
change specifications without notice.
FS488_EN_A5_v1_20210517.indb 4FS488_EN_A5_v1_20210517.indb 4 2021/5/17 16:372021/5/17 16:37

DECLARATION OF CONFORMITY
