M 1.0” Solid State Disk
Transcend Information Inc.
V1.6
6
Description
The 1-inch Solid State Disk is small in size, has a
huge capacity and low power consumption making
it perfect for use as a mobile storage solution in
devices such as, Mobile Phones, PDA and GPS
systems. This guide is written to provide general
installation and handling information, please use it
in conjunction with the Owner’s Manual for your
device or system.
Placement
Features
•RoHS compliant
•Fully compatible with 1.0-inch hard drive form factor
and interface (35-Pin FPC ZIF connector)
•Non-volatile Flash Memory for outstanding data
retention
•Built-in ECC (Error Correction Code) functionality and
wear-leveling algorithm ensures highly reliable of data
transfer
•Mode Supports:
Ultra DMA Mode 0 to Mode 5
Multi-Word DMA Mode 0 to Mode 2
PIO Mode 0 to Mode 4
•Supports ATA Security Commands
•Support S.M.A.R.T function (self-definition)
•Lower Power Consumption
•Shock resistance
•Power Supply: 3.3V ±5%
Dimensions
Side Millimeters Inches
A 40.00 ±0.30 1.575 ±0.012
B 30.00 ±0.20 1.181 ±0.008
C 5.00 ±0.50 0.196 ±0.020

T
T
TS
S
S6
6
64
4
4G
G
GS
S
SS
S
SD
D
D1
1
10
0
0-
-
-M
M
M 1.0” Solid State Disk
Transcend Information Inc.
V1.6
7
Specifications
* Note: Reference to the IEC 60068-2-1 and IEC 60068-2-56 Testing procedures; 48-hours chamber test on ASUS
M2N-MX, 1GB RAM, Windows
®
XP Version 2002 SP2.
Physical Specification
Form Factor 1-inch HDD
Storage Capacities 64 GB
Length 30.0 0 ±0.20
Width 40.00 ±0.30
Dimensions (mm)
Height 5.00 ±0.50
Weight 8 g
Connector 0.3 mm pitch 35-Pin Zero Insertion Force (ZIF) connector (P-ATA)
Environmental Specifications
Operating Temperature 0
℃ to 70 ℃
Storage Temperature 0
℃ to 70 ℃
Humidity
Operating Humidity (Non condensation) 0% to 95%
Storage Humidity (Non condensation) 0% to 95%
Power Consumption
Input Voltage DC 3.3V ±5%
Mode Maximum (mA)
Write 143
Read 119
Power Consumption
(DC 3.3V @ 25 ℃ )
Standby 3.8

T
T
TS
S
S6
6
64
4
4G
G
GS
S
SS
S
SD
D
D1
1
10
0
0-
-
-M
M
M 1.0” Solid State Disk
Transcend Information Inc.
V1.6
8
* Note : 25 ℃, test on ASUS M3N7B, 3GB RAM, IDE interface support UDMA5, Windows
®
XP SP3, benchmark utility
FDBENCH (version 1.02), copied file 100MB
Actual Capacity
Model P/N User LBA Cylinder Head Sector
TS64GSSD10-M 125,059,072 16383 15 63
* Note: FAT32 format
Reliability
Data Reliability Random 8-bit BCH ECC in 512 bytes
Data Retention 10 years [7 years operating (block erase cycle < 4K cycle) + 3 years storage]
Connector Durability 10 times
MTBF 4,400,000 hours
Interface Specification
Drivers No Device Driver Required
ATA-7 V3 Specification
PIO Mode 0 - 4
Multi-Word DMA Mode 0 -2
ATA Compatibility
UDMA Mode 0 - 5
Performance
Model P/N Capacity Read Write Random Read Random Write
PCMark05
HDD Score
TS64GSSD10-M 64GB 64851 39233 56952 11297 6358
Regulations
Compliance CE, FCC and BSMI

T
T
TS
S
S6
6
64
4
4G
G
GS
S
SS
S
SD
D
D1
