Transform QK022 User manual

FROM ORDINARY TO OUTSTANDING
Model
#1000680509
QK022
Stainless steel dual bowl sink*
INSTALLATION MANUAL
*Faucet not included
*

2
BEFORE YOU START
1. Inspect your unit before proceeding. Check surface for any
flaws or damage. Your unit has been manufactured with
304 stainless steel providing an extremely durable surface.
Once you unpack your unit check for dents, bends, bumps
or scuff marks. If any damage is noticed, do not install.
Report damage immediately.
2. Please read all the instructions carefully and keep for
future reference.
3. Protect the entire surface during installation.
Your installation must comply with all local plumbing building
codes. Have a qualified tradesman do or approve your
plumbing installation.
WARNING: Always wear safety goggles and gloves in order to
avoid any personal injuries.
CONTENTS:
• Stainless steel sink x 1 pc
• Mounting clamps and screws x 10 pcs
• Strainer x 2 pcs
TOOLS REQUIRED
• Tape measure
• Carpenter’s square
• Pencil
• Saber-saw / Jig-saw
• llirdcirtcelE
• Drill bit - minimum 3/8 in (10 mm)
• Pipe wrench
• 3/8 in (10 mm) hex driver or Phillips screw driver
• Plumber’s putty
• Silicone sealant
COUNTER TOP PREPARATION
Before cutting countertop, check very carefully that the sink
will cover ALL of the area traced for cut out.
If the sink is used for replacement, please ensure that the cut
¾91xni03(mm205xmm187sipotretnuocruoynituo
in) with rounded corners as per diagram that follows.
¾
If the sink is being installed in a new countertop, place the
sink upside down on the countertop. Centre the sink left to
right on the sink cabinet making sure that it will not interfere
inside with the structure of the cabinet or the countertop. The
unit should be placed so that it is parallel to the front of the
countertop and it clears the overhang of the countertop and
the face of the cabinet. Trace the outline then draw a new line
10 mm (3/8 in) inside the outline, this will be the cut line as
mm187ebdluohseniltucedisniehtfoezisehT.wolebnwohs
.)ni¾91xni¾03(mm205x The size of the sink is
larger than the cutout and MUST have rounded
corners. Do not cut the opening with square corners.
19 ¾ in
502 mm
30 in
781 mm
¾
Radius:
1.5 in
(38 mm)
AFTER THE CUTOUT IS DRAWN
Using a 2 inch (5.1 cm) hole saw, carefully drill 4 corner holes
inside the cut line and use a saber-saw or jig-saw to start
cutting along the cut line. Place a support underneath the
cutout portion of the countertop to prevent it from falling
during cutting. Cut opening on cut line inside the perimeter of
sink. Note: Formica countertop installation only is illustrated.
Contact your countertop distributor for the best method of
cutting other materials such as marble, hard synthetics, etc.
Insert the sink into the hole in the countertop to test the fit.
Make adjustment to the hole if necessary. Once the of the
sink in the countertop is precise, place the sink on a blanket
and proceed with the next step.
Perimeter
of sink
Cutout
Perimeter
of sink
Cutout
3/8 in
(9.5 mm)
Illustrations may vary from actual product
ATTENTION
Before beginning installation, read all instructions first. Save
these instructions for future use. Carefully check the product
and its components for damage prior to installation.
IF THERE IS ANY DAMAGE OR IF YOU ARE MISSING
PARTS, PLEASE CALL CUSTOMER SERVICE TOLL FREE AT
1-877-333-0098 (MONDAY TO FRIDAY, 8:30 AM TO 5:00
PM, EST). INSTALLING A DAMAGED UNIT WILL VOID THE
WARRANTY.
DO NOT RETURN TO THE PLACE OF PURCHASE BEFORE
CALLING THE TOLL FREE NUMBER. DO NOT DISPOSE OF
PACKAGING UNTIL YOU ARE SATISFIED WITH YOUR
NEW SINK.
• Rolled Grid x 1 pc

3
STRAINER INSTALLATION
SINK INSTALLATION
1. Test the whole assembly to see if it properly in the
countertop. Adjust cut-out if necessary.
3. Carefully place sink right side up and insert bolts in
notches, putting clamps flat against the sink.
1. Apply a sealing ring of plumber’s putty to the underside
of strainer flange and insert the strainer body in the sink.
2. Assemble the rubber gasket, friction washer and locknut
onto the strainer body from under the sink.
3. Hand tighten the locknut. Do not over tighten the
locknut, as it may split or deform the body of the strainer.
4. Repeat the process with the other strainer.
5. Assemble plastic flange and tail pipe (not supplied)
together, then engage the connecting nut through the tail
pipe and flange to the lower threaded part of strainer body
and lock connecting nut by hand. Do not over tighten the nut.
FAUCET INSTALLATION (not supplied)
Attach the faucet to the sink following the manufacturer’s
instructions.
Strainer
basket
Strainer
body
Strainer
body
Rubber
gasket
Friction
washer
Locknut
Plastic
flange
Tail pipe
(not supplied)
Connecting nut
Plumber’s putty
or sealant

4
5. Tighten the screws progressively following the pattern
that follows, until the sink rim is flush with countertop.
Check the alignment as you tighten so that the front of
the sink is parallel to the front of the countertop. Check all
connections for leaks. Adjust and re-tighten if necessary. Do
not over tighten.
Countertop
Sealant
Sink
1
7
5 3 4 6
2
8
6. Connect strainers to drain pipe (connections not provided).
7. Connect the water supply to faucet (connections not
provided).
CARE AND MAINTENANCE
Your sink is manufactured with the highest grade 304 stainless
steel. It will provide you many years of enjoyment with the
proper care and maintenance.
•After use, always rinse your sink with tap water to dilute
and remove any deposits. Avoid any residue of food,
detergent, soap, grease or condiment to dry or sit for
extended periods of time on the surface of the sink. Towel
dry after use when possible to avoid water spots. Should
these occur, clean with a mild solution of vinegar and water
followed by a good rinse.
•Liquid soap, a general household cleaner or a weak solution
of vinegar and water should be used for regular cleaning.
Never use abrasive products as they will dull and scratch
the finish.
•Scouring pads should be of a plastic nature recommended
for use in stainless steel sinks. They should only be used in
the bowls of the sink and the scrubbing should be done in
the direction of the satin finish lines. Do not use scouring
pads on the deck as they will dull the finish.
•Never use steel wool pads as they will leave iron particles
on the sink and will lead to corrosion. For the same reason
never leave mild steel or cast iron pans on your sink for
extended periods of time.
PARTS LIST
PART PART NUMBER
Topmount clips
Rubber gasket
and friction washer
Basket for strainer
Rolled grid
4. Lower the sink into the countertop.
QH 0001
QH 0002
QK021
QK020
If you are missing or require replacement parts, please contact our
customer service department at 1-877-333-0098 (Monday to
Friday, 8:30 am to 5:00 pm, EST) or email us at
[email protected]. Identify the required
part(s) and have the replacement part number ready when you call.

5
WARRANTY
This unit is warranted to the original purchaser to be free of defects in material
and workmanship for one (1) year from the date of purchase. Conglom Kitchen
& Bath will repair or replace, at its option, the unit or its equipment in
accordance with the following terms and conditions.
WARRANTY LIMITATIONS
Our warranty does not cover defects, damage, or failure caused by the common
carrier, installer, user, or other person, or resulting from, without limitation, any
of the following:
• Change in colour or finish due to chemical usage.
• Damage due to the use of steel wool on the stainless steel surface.
• Improper installation not in accordance with manufacturer’s instructions.
• Dents, bumps, and scratches incurred during shipping, handling, or
installation.
• Damage caused by failure to follow care and cleaning guidelines.
• Alterations made to the unit by the purchaser or installer.
• Damage caused by accidental impact, fire, flood, freezing, and normal wear.
• Bends and warping caused by forced connections, over-tightened fittings,
and inadequate support during installation.
In addition, Conglom Kitchen & Bath WILL NOT BE RESPONSIBLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES or losses arising from any cause
(e.g., water damage to carpet, ceiling, loss of use, etc.) including its own
negligence; damages to, respecting, or resulting from plated parts when
chemicals are used in or on the unit; optional equipment not manufactured by
Conglom Kitchen & Bath; or defects that should have been discovered before
installation. This limited warranty does not include labor, transportation, or
other costs incurred in the removal and/or reinstallation of the original unit
and/or installation of a replacement unit; any costs relating to obtaining access
for repair; or loss of use, including loss of sales, profit or business advantage of
any kind under any circumstances.
This warranty does not extend to commercial or institutional use or installation.
It is the responsibility of the installer/owner to determine specific local code
compliance prior to installation of the product. Conglom Kitchen & Bath makes
no representation or warranty regarding, and will not be responsible for any
code compliance. Conglom Kitchen & Bath does not warrant connections of
water supply fittings and piping, or fill systems. Nor is it responsible for damage
to the shower panel which occurs during any installation procedure.
WARRANTY CLAIM PROCEDURE
If a claimable defect occurs, please fill out a claim form through our website at
www.conglomkb.com or contact our customer service department at
1-877-333-0098 (Monday to Friday, 8:30 am to 5:00 pm, EST).
Before you make your claim call, please make sure you have:
1. The description of the product
2. Proof of sale
3. Details regarding the defect
4. Name and address of the owner and installer
Claims must be filled out in writing and returned within six (6) months of
appearance of defect. Failure to comply with this stipulation will make the
warranty null and void. We reserve the right to a thirty-day (30) delay following
receipt of claim in which to inspect the product. We assume no responsibility
for labor costs or removing/replacing a previously installed product
or transportation or return of a product.
St-Laurent, Québec, H4S 2C3
Tel: [phone]
www.conglomkb.com
Made in Malaysia
