ARX-0123A Operation & Maintenance Manual
Before using ARX-0123A, please read the instructions.
Operation
1.Air Pressure: 6.0~7.0 kg/cm2 (85~100psi)
2.Setting up for Standard Length Nut Rivets: When using the standard length of nut rivet (10mm),
please ensuring that the Stroke Set Adaptor (#2) and Nose nut (#3) are fully threaded into the
Stroke adaptor cover (#5). Adjusting #2 & #3 parts for making rivet nut length A =length B.
3.Setting up for Short Nut Rivets : If using the shorter length of nut rivet, then screw the Stroke set adaptor (#2) out adjusting for the shorter
rivet.
4.Stroke Adjustment: The Stroke adaptor cover (#5) is the main stroke adjusting part for ARX-0123A, Stroke range is 2mm~10mm, Stroke
traction load that depending upon the size and material of nut rivet, also need to considering about the riveting thickness. Please set up
correcting stroke before using ARX-0123A for avoiding screw mandrel and rivet nut damaging. Connecting air and Holding trigger then
Turning #5 parts away or close to #6 parts (Connector Housing) for increasing or reducing stroke length, turning #5 one cycle away from #6
increasing 1mm stroke. The stroke range is 2mm when #5 part contacted with #6 part. Please refer to the table 1 adjusting stroke.
[Note] If the thickness of the riveting plate is less than 1.0 ±0.5mm. Please turn #5 away from #6 part slowly and carefully for avoiding to
damage the mandrel.
5. Holding rivet nut and turning clockwise #48(Safety Cap Nut) for screwing up rivet nut.
6. Pressing #53(Trigger) riveting. [Note] When the first riveting, please testing 1~2 rivet nuts freely for ensuring the correction stroke.
Table 1
Rivet Size
Suggestion Stroke
#5 turning away from #6 cycle
M3
2.0~2.3mm
0~0.5
M4
2.5~3.0mm
0.5~1
M5 (3/16”)
3.5~4.0mm
1.5~2.0
M6 (1/4”)
4.0~4.5mm
2.0~2.5
M8 (5/16”)
5.0~5.5mm
3.0~3.5
M10 (3/8”)
5.5~6.0mm
3.5~4.0
*Turing #5 one Cycle away from
#6 for Increasing 1mm Stroke.
*Holding trigger will
make turning #5 easier.
*Turning clockwise
#48(Safety Cap Nut) for
screwing up rivet nut..

2
7.Turning anti-clockwise #48(Safety Cap Nut) for loosening rivet nut.
Maintenance
When adjusting adaptor cover (#5) to the Max. stroke(10mm) without action after pressing trigger. It might be empty of Hydraulic Oil. Please
follow below steps to refill Hydraulic Oil.
1. Disconnect from air supply
2. Using spanner to remove cylinder cap #35 as in Fig. 1
3. Removing the piston assembly using pliers as in Fig.2
4. Fill with hydraulic oil, Viscosity ISO: VG46 as in Fig.3
5. Use silicone grease on wall of cylinder and piston as in Fig.4
6. Reassemble in reverse process.
Maintenance for Nut Riveter Head
1. Using spanner to remove Connector Housing #6
2. Using spanners to take apart the inner housing parts
3. loosening all parts
4. Lubricate the 1A ～1F Screw Mandrel and piston with silicone
grease.
5. Reassemble in reverse process.
Mandrel Replacement
1. Connecting air supply then pressing trigger and removing #3,
#2 and #5 parts as in Fig.5.
2. Disconnecting air supply then use spanner to luck #4 parts
and loosen the #1 mandrel as in Fig 6.
3. Using spanner to luck #4 parts and screw up the new or
another size #1 mandrel as in Fig.7.
4. Connecting air then pressing trigger and reassemble #3, #2,#5
parts.
5. Adjusting the gap of #5 between #6 around 1.5~2.0mm as in
Fig.8.
Fig.1
Fig.2
Fig.3
Fig.4
Fig.5
Fig.6
Fig.7
Fig.8
*Turning Anti-clockwise
#48(Safety Cap Nut) for
loosening rivet nut.
Loosen mandrel
Screw up
mandrel
1.5~2.0mm
