Treadmill RT500 User manual

RT500RT500
110V and 220V 12T

Table Of Contents
Read all precautions and instructions in this manual before using this
equipment.
! CAUTION
Important Safety Instructions-------------------------------------------------------------------- 3
Before You Start-------------------------------------------------------------------------------------- 6
Main Parts List---------------------------------------------------------------------------------------- 7
Warning------------------------------------------------------------------------------------------------ 8
Using Method---------------------------------------------------------------------------------------- 9
Warm Up Exercises--------------------------------------------------------------------------------- 10
Power Requirements------------------------------------------------------------------------------ 11
Console Information------------------------------------------------------------------------------- 12
Moving Instructions------------------------------------------------------------------------------- 13
Parts List---------------------------------------------------------------------------------------------- 14
Exploded View-------------------------------------------------------------------------------------- 18
Console Panel Functions------------------------------------------------------------------------- 22
Electrical Connection----------------------------------------------------------------------------- 31
Belt Adjustment and Maintenance------------------------------------------------------------ 33

─ 3 ─
Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed,
including the following:
Read all instructions before using this Treadmill:
DANGER - To reduce the risk of electric shock:
1. Always unplug this appliance from the electrical outlet immediately after
using and before cleaning.
2. Do not reach for a plug that has fallen into water. Unplug immediately.
3. Do not use while bathing or in a shower.
4. Do not place or store the treadmill where it can fall or be pulled into a tub or
sink. Do not place in or drop into water or other liquid.
WARNING - To reduce the risk of burns, fire, electric shock, or injury to
persons:
1. An appliance should never be left unattended when plugged in. Unplug from
outlet when not in use, and before putting on or taking off parts.
2. Do not operate under blanket or pillow. Excessive heating can occur and cause
fire, electric shock, or injury to users.
3. Close supervision is necessary when this treadmill is used by, on, or near
children, invalids, or disabled persons. Keep children away from extended
back, foot support (or other similar parts).
4. Use this treadmill only for its intended use as described in this manual. Do not
use attachments not recommended by the manufacturer.
5. Never operate this treadmill if it has a damaged cord or plug, if it is not working
properly, if it has been dropped or damaged, or dropped into water. Return the
Treadmill to a service center for examination and repair.
6. Do not carry this treadmill by supply cord or use cord as a handle.
7. Keep the cord away from heated surfaces.
8. Never operate the treadmill with the air openings blocked. Keep the air
openings free of lint, hair, and the like. Never operate on a soft surface such as
a bed or couch where the air openings may be blocked.

─ 4 ─
Important Safety Instructions
9. Never drop or insert any object into any opening.
10. Do not use outdoors.
11. Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
12. To disconnect, turn all controls to the off position, then remove plug from
outlet.
13. Connect this Treadmill to a properly grounded outlet only. See Grounding
Instructions.
14. The equipment is designed for commercial use, Maximum load is 180KG.
SAVE THESE INSTRUCTIONS
GROUNDING INSTRUCTION
This product must be grounded. If it should malfunction or breakdown,
grounding provides a path of least resistance for electric current to reduce the
risk of electric shock. This product is equipped with a cord having an equipment-
grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with
all local codes and ordinances.
DANGER - Improper connection of the equipment-grounding conductor
can result in a risk of electric shock. Check with a qualified electrician or
serviceman if you are in doubt as to whether the product is properly grounded.
Do not modify the plug provided with the product - if it will not fit the outlet,
have a proper outlet installed by a qualified electrician.
This product is rated more than 15 amperes and is for use on a circuit having a
nominal rating of 120 volts and is factory-equipped with a specific electric cord
and plug to permit connection to a proper electric circuit. Make sure that the
product is connected to an outlet having the same configuration as the plug.
No adapter should be used with this product. If the product must be
reconnected for use on a different type of electric circuit, the reconnection
should be made by qualified service personnel.

─ 5 ─
Important Safety Instructions
CAUTION - Risk of Injury to Persons - To Avoid Injury, use extreme caution
when stepping onto or off of a moving belt. Read Instruction Manual Before
Using.
ATTENTION - Risque des blessures aux personnes - Pour éviter des
blessures, avec une extrême prudence en marchant sur ou hors d'une ceinture
mobile. Lisez le manuel d'instruction avant utilisation.
CAUTION - To Reduce The Risk Of Injury From Moving Parts - Unplug
Before Servicing.
ATTENTION - Pour réduire le risque de plessures des pièces mobiles -
Débranchez avant l'entretien.
WARNING - To Reduce the Risk of Electric Shock - Unplug Before Cleaning
or Servicing.
AVERTISSEMENT - Pour réduire le risque du choc électrique -
Uébranchez avant le nettoyage ou l'entretien.

─ 6 ─
Before You Star t
Remember to take the time to review owner's manuals before you start.
1. Before using this treadmill or starting any exercise program, consult your
physician and accompanied by specialized person. Adjust the speed not
over 8KMH.
2. Take the time to perform the stretching exercise provided to avoid injury.
3. If you have heart problems, and/ or the other diseases, do not use the
treadmill programs without receiving approval from your physician.
4. Stop exercising or call physician if you feel uncomfortable.
5. Do not leave children unsupervised and disabled person near or on the
treadmill. Should be accompanied by supervisors.
6. Running is oxygen exercise, recommended 30 minutes per time is
reasonable.
7. Wear comfortable, good-quality walking or running shoes and appropriate
clothing. Do not with fibre clothing to avoid electrical shock and damage
the treadmill.
8. Do note us the treadmill with bare feet, sandals, socks of stockings to
avoid any risk of injuries. Wear comfortable shoes or cotton socks.
9. Failure to follow these instructions will void the treadmill warranty.
10. If the supply cord is damaged, it must be replaced by the manufacturer or
its service agent or a similarly qualified person in order to avoid a hazard.

─ 7 ─
Main parts list

War ning
─ 8 ─
Before using this treadmill or starting any exercise program, It is
important to review this manual and the following precautions.
Adjustment and Use remote controller
Power switch
1. Always unplug the treadmill after using to keep the life of treadmill and
avoid any risk of injuries.
2. In order to protecting your treadmill, spattering water on the machine
must be forbidden.
If the ground in user's house is not level, please adjust the adjust support
properly which is marked as A in the below figure to make the machine at a
leveled place. After adjusting tighten the hex nut by using the double-ended
spanner.

─ 9 ─
Using Method
Please read carefully and using follow the functions:
1. put the plug in the socket, turn on the switch.
2. grasp the handle firmly, stand on the treadmill.
3. clip the clothes using the safety clip.
4. you can operate this device according as the manual set the lowest speed, first
then increase the speed gradually.
5. you should grasp the handle firmly by one hand, when you operating the
console.
6. Take care to use treadmill. Start from low speed handed to the uprights leaving
from treadmill after reducing speed and stopping all functions.
7. Press Safety Switch on emergency.
8. Keep warm and relax your body after workout.
Exercise time and exercise frequency at a time:
Exercise time: 30minuates----Normal;
Exercise frequency: Warm your body by 10---20minutes under 8Kph,
then increase speed accordingly.
CE Switch and Safety Switch Introduction
When the treadmill is running, the user can
press the red safety switch directly if he
wants to stop it. Then the treadmill will stop
slowly. If the user encounters emergency
when he using the treadmill he should haul
the safety clip linked with red wire, it will
triger the safety switch to step.
Operation:
1. Press the CE switch and keep it at the low position, tie the safety clip to your
cloth, then start the treadmill for exercise.
2. If there is any emergency, the clip tied to your cloth will pull the CE switch and
it will come to the origal position. In the mean time, the treadmill will stop
completely and the main power will be cut.
Warning: When use above methed to stop running, the running belt will last
running for several seconds before completely stop.

─ 10 ─
War m Up Exercises
EXERCISE GUIDELINES
WARNING! Before beginning this or any exercise program, you should consult your
physician. This is especially important for individuals over the age of 35 or individuals
with pre-existing health problems.
Warming up prepares the body for the exercise by increasing circulation, supplying more
oxygen to the muscles and raising body temperature. Begin each workout with 5 to 10
minutes of stretching and light exercise to warm up. The photos on this page show
several forms of basic stretching you may perform before your workouts. In order to
achieve an adequate warm-up, perform each stretch three times.
TOE TOUCH STRETCH
Stand, bending your knees slightly and slowly bend forward
from your hips. Allow your back and shoulders to relax as you
reach down toward your toes as far as possible. Hold for 15
counts, then relax. This will stretch your hamstrings, back of
knees, and back.
HAMSTRING STRETCH
Sit with one leg extended. Bring the sole of the opposite foot
toward you and rest it against the inner thigh of your
extended leg. Reach toward your toes as far as possible. Hold
for 15 counts, then relax. This will stretch your hamstrings,
lower back, and groin.
CALF/ACHILLES STRETCH
With one leg in front of the other, reach forward and place
your hands against a wall. Keep your back leg straight and
your back foot flat on the floor. Bend your front leg, lean
forward and move your hips toward the wall. Hold for 15
counts, then relax. To cause further stretching of the Achilles
tendon, bend your back leg as well. This will stretch your
calves, Achilles tendons, and ankles.
QUADRICEPS STRETCH
With one hand against a wall for balance, reach back and
grasp one foot with your other hand. Bring your heel as close
to your buttocks as possible. Hold for 15 counts, then relax.
This will stretch your quadriceps and hip muscles.
INNER THIGH STRETCH
Sit with the soles of your feet together and your knees
outward. Pull your feet toward your groin area as far as
possible. Hold for 15 counts, then relax. This will stretch your
quadriceps and hip muscles.

Power Requirements
IMPROPER CONNECTION OF THE EQUIPMENT GROUNDING CONNECTOR
CAN RESULT IN A RISK OF AN ELECTRIC SHOCK. CHECK WITH A QUALIFIED
ELECTRICIAN OR SERVICE MAN IF YOU ARE IN DOUBT AS TO WHETHER THE
PRODUCT IS PROPERLY GROUNDED. DO NOT MODIFY THE PLUG PROVIDED
WITH THE PRODUCT. IF PLUG WILL NOT FIT THE OUTLET, HAVE A PROPER
OUTLET INSTALLED BY A QUALIFIED ELECTRICIAN.
This treadmill can be seriously damaged by sudden voltage changes in your
home's electrical power. Voltage spikes, surges, and noise interference can
result from weather conditions or from other appliances being turned on or off.
This treadmill must be grounded to reduce the risk of electrical shock.
Grounding provides a path of least resistance for electric current should the
treadmill malfunction. Always plug the power cord into an appropriate outlet
that is properly installed and grounded in accordance with all local codes and
ordinances.
─ 11 ─

─ 12 ─
Console Infor mation
Before beginning your workout, check your normal resting heart rate. Place your
fingers lightly against your neck, or against your wrist over the main artery. After
finding your pulse, count the number of beats in 10 seconds. Multiply the number
of beats by six to determine your pulse rate per minute. We recommend taking your
heart rate at these times; at rest, after warming up, during your workout and two
minutes into your cool down, to accurately track your progress as it relates to better
fitness.
During your first several months of exercising, the AHA recommends aiming for the
lower part of the target heart rate zone-60%, then gradually pro-gressing up to 75%.
According to the AHA, exercising above 75% of your maximum heart rate may be
too strenuous unless you are in top physical condition. Exercising below 60% of
your maximum will result in minimal cardiovascular conditioning.
Check your pulse recovery rate – If your pulse is over 100 bpm five minutes after you
stop exercising, or if it's higher than normal the morning after exercising, your
exertion may have been too strenuous for your current fitness level. Rest and reduce
the intensity next time.
Fitness Safety The target
heart rate chart indicates
average rate zones for
different ages. A variety of
different factors (including
medication, emotional
state, temperature and
other conditions) can
affect the target heart rate
zone that is best for you.
Your physician or health
care professional can help
you determine the exercise
intensity that is approp-
riate for your age and
condition.

─ 13 ─
Moving Instructions
Caution! To avoid the risk of injury, never attempt to move the treadmill while it is
operating. To reduce the possibility of injury while lifting, bend your legs and keep
your back straight. As you raise the treadmill, lift using your legs, not your back. In
order to raise or lower the treadmill safely, you must be able to lift 220 pounds
(100kg). It is suggested you always use the aid of a second person when moving the
treadmill.
Lift the treadmill back then move it to the desired location. Carefully put down it on
the position. Do not attempt to move the treadmill over an uneven or rough surface.
Note: The treadmill's angle can not exceed 30 degrees when lifted the treadmill back.

─ 14 ─
Par ts List-110V
Item No. Description QTY Item No. Description QTY
1 Console Frame 1 53 Earphone Hole Plug 1
2 Left Upright 1 54 A-Zone Up Cover 1
3 Right Upright 1 55 A-Zone Down Cover 1
4 Deck Frame 1 56 Emergency Switch Key 1
5 Elevating Frame 1 57 Fan Key 7
6 Left Handle Frame 1 58 Cool Down\Pause Key 1
7 Right Handle Frame 1 59 Limit Key Fixing Plate 1
8 Console Plate Frame 1 60 Emergency Switch Baffle 1
9 Motor Fixing Plate 1 61 Air Grid 1
10 Dust Proof Plate 1 62 Air Up Cover 1
11 Front Motor Cover Fixing L Plate 2 63 A-Zone Insert 1
12 Motor Cover Fixing L Plate 2 64 Console Back Cover 1
13 Eleavate Rotational Sleeve 2 66 Start Key 1
14 Front Cover Fixing Plate 2 67 Console Bottom Plate 1
15 Console Linked Plate 1 68 Switch Fixing Plate 1
16 Middle Z Fixing Plate 1 69 Pulse Fixing Plate 2
17 Running Belt 1 70 Pulse Sheet 4
18 Controller U Fixing Plate 1 71 Nylon Shaft 1
19 Elevating Frame Fixing Shoulder Bolt 2 72 Left Side 1
20 Motor Cover 1 73 Right Side 1
21 Left Front Decorative Cover 1 74 Left Steel Side 1
22 Right Front Decorative Cover 1 75 Right Steel Side 1
24 Running Board 1 76 Reposition Rack 1
25 Left Rear Adjusting Seat 1 77 Restrict Spring 1
26 Right Rear Adjusting Seat 1 80 Console Component 1
27 Left Rear Decorative Cover 1 81 Flat Head Hexagon Riveted Nuts M8 4
28 Right Rear Decorative Cover 1 82 Countersunk Head Hexagon Riveted Nuts M5 18
29 Middle Protective Cover 1 83 Phillip Screw M4*40 2
30 Switch Cover 1 84 Phillip Screw M5*15 39
32 Front Roller 1 85 Phillip Screw M5*20 4
33 Rear Roller 1 86 Phillip Screw M5*35 6
35 Left Handle 1 87 Phillip Screw St2.9*6.5 17
36 Right Handle 1 88 Phillip Screw St2.9*9.5 4
37 Console Left Up Cover 1 89 Phillip Screw St4.2*13 9
38 Console Right Up Cover 1 90 Phillip Screw St4.2*50 4
39 Console Left Down Cover 1 91 Hex Head Bolt M6*15 4
40 Console Right Down Cover 1 92 Socket Head Cap Screw M8*15 4
41 Fan Fixing Plate 1 93 Socket Head Cap Screw M8*20 8
43 Left Routing Cover 1 94 Socket Head Cap Screw M8*55 2
44 Right Routing Cover 1 95 Hex Nut M4 2
45 Left Bolt Cover 1 96 Locknut M8 2
46 Right Bolt Cover 1 97 Washer Φ9*Φ22*2 14
47 Cup Holder 1 98 Split Damping Ring Φ9 1
48 Left Signing Light Fixing Plate 1 99 Clip Nut 4
49 Right Signing Light Fixing Plate 1 100 Safe Key Clamp 1
52 Console Signing Light Cover 2 101 Console Overlay 1

─ 15 ─
Par ts List-110V
Item No. Description QTY Item No. Description QTY
102 Sign Paster 1 178 Phillip Screw M6*30 6
104 A Zone Up Overlay 1 179 Socket Head Cap Screw M6*60 2
105 A Zone Down Overlay 1 180 Socket Head Cap Screw M6*20 20
108 Console Pcb 1 181 Locknut M3 2
109 Key Board 1 182 Locknut M8 12
110 Joint 1 1 183 Washer Φ11*Φ23*2 6
111 Joint 2 1 184 Hexagon Socket Countersunk Head Cap Head Screw M8*35 6
112 Joint 3 1 185 Circlip For Shaft 2
113 12V Power Wire 1 186 Washer 4
114 Switch Pcb 1 187 Socket Head Cap Screw M8*15 2
115 Fan 1 188 Socket Head Cap Screw M8*30 10
116 Pulse Plate 1 189 Socket Head Cap Screw M8*80 2
117 Linked Wire Fron Pulse Pcb To Pcb 1 190 Hex Head Bolt M10*165 2
118 Pulse Connect Wire 1 191 Hex Head Bolt M10*180 2
119 Receptor 1 193 Power Wire Fixing Plate 1
120 Spd And Incl Harness 1 194 Band Cable 10
122 Emergency Switch 2 195 Double Wrench 1
123 Emergency Switch Wire 2 196 Lug Wrench 1
124 Console Wire Up 1 197 Hexagonal Socket Wrench 1
125 Ferrite 3 198 Double Wrench 1
126 Ferrite 2 199 Lug Wrench 1
150 Adjust Bumper 2 200 Hexagonal Socket Wrench 1
151 Bumper A 4 201 Tape 3.8
152 Bumper B 4 204 Phillip Screw St4.2*16 4
153 Bumper 4 205 Wheel 2
154 Insulation Bumper 1 206 Locknut M10 4
156 V-Belt 1 207 Locknut M12 2
158 Neck Bush 4 208 Washer Φ9*Φ22*2 10
159 Clip Nut M6 6 209 Circuit Break Switch 2
160 Insulation Spacer 4 210 Earth Wire 1
161 Carriage Bolt M8*40 1 211 Motor 1
162 Countersunk Head Hexagon Riveted Nuts M5 12 212 Transducer 1
163 Countersunk Head Hexagon Riveted Nuts M6 2 213 Main Switch 4
164 Flat Head Hexagon Riveted Nuts M6 18 214 Connect Wire 1
165 Flat Head Hexagon Riveted Nuts M8 6 215 Console Wire Down 2
166 Hex Flange Nut M8 9 216 Connect Wire 2
167 Hex Flange Nut M16 2 221 Protective Sleeve 1
168 Hex Head Bolt M8*150 6 224 Actuator 1
169 Hex Head Bolt M10*25 4 225 Power Outlet 1
170 Hex Head Bolt M10*50 1 226 Power Wire 1
171 Hex Head Bolt M10*130 1 227 Ferrite 1
172 Phillip Screw M3*10 2 228 Ferrite 2
174 Phillip Screw M4*10 2 260 Ground Bumper 1
175 Phillip Screw M4*8 5 261 Serrated Lock Washers Φ10 4
176 Phillip Screw St4.2*13 18 262 Serrated Lock Washers Φ8 4
177 Phillip Screw M5*20 14

─ 16 ─
Par ts List-220V
Item No. Description QTY Item No. Description QTY
1 Console Frame 1 53 Earphone Hole Plug 1
2 Left Upright 1 54 A-Zone Up Cover 1
3 Right Upright 1 55 A-Zone Down Cover 1
4 Deck Frame 1 56 Emergency Switch Key 1
5 Elevating Frame 1 57 Fan Key 7
6 Left Handle Frame 1 58 Cool Down\Pause Key 1
7 Right Handle Frame 1 59 Limit Key Fixing Plate 1
8 Console Plate Frame 1 60 Emergency Switch Baffle 1
9 Motor Fixing Plate 1 61 Air Grid 1
10 Dust Proof Plate 1 62 Air Up Cover 1
11 Front Motor Cover Fixing L Plate 2 63 A-Zone Insert 1
12 Motor Cover Fixing L Plate 2 64 Console Back Cover 1
13 Eleavate Rotational Sleeve 2 66 Start Key 1
14 Front Cover Fixing Plate 2 67 Console Bottom Plate 1
15 Console Linked Plate 1 68 Switch Fixing Plate 1
16 Middle Z Fixing Plate 1 69 Pulse Fixing Plate 2
17 Running Belt 1 70 Pulse Sheet 4
18 Controller U Fixing Plate 1 71 Nylon Shaft 1
19 Elevating Frame Fixing Shoulder Bolt 2 72 Left Side 1
20 Motor Cover 1 73 Right Side 1
21 Left Front Decorative Cover 1 74 Left Steel Side 1
22 Right Front Decorative Cover 1 75 Right Steel Side 1
24 Running Board 1 76 Reposition Rack 1
25 Left Rear Adjusting Seat 1 77 Restrict Spring 1
26 Right Rear Adjusting Seat 1 80 Console Component 1
27 Left Rear Decorative Cover 1 81 Flat Head Hexagon Riveted Nuts M8 4
28 Right Rear Decorative Cover 1 82 Countersunk Head Hexagon Riveted Nuts M5 18
29 Middle Protective Cover 1 83 Phillip Screw M4*40 2
30 Switch Cover 1 84 Phillip Screw M5*15 39
32 Front Roller 1 85 Phillip Screw M5*20 4
33 Rear Roller 1 86 Phillip Screw M5*35 6
35 Left Handle 1 87 Phillip Screw St2.9*6.5 17
36 Right Handle 1 88 Phillip Screw St2.9*9.5 4
37 Console Left Up Cover 1 89 Phillip Screw St4.2*13 9
38 Console Right Up Cover 1 90 Phillip Screw St4.2*50 4
39 Console Left Down Cover 1 91 Hex Head Bolt M6*15 4
40 Console Right Down Cover 1 92 Socket Head Cap Screw M8*15 4
41 Fan Fixing Plate 1 93 Socket Head Cap Screw M8*20 8
43 Left Routing Cover 1 94 Socket Head Cap Screw M8*55 2
44 Right Routing Cover 1 95 Hex Nut M4 2
45 Left Bolt Cover 1 96 Locknut M8 2
46 Right Bolt Cover 1 97 Washer Φ9*Φ22*2 14
47 Cup Holder 1 98 Split Damping Ring Φ9 1
48 Left Signing Light Fixing Plate 1 99 Clip Nut 4
49 Right Signing Light Fixing Plate 1 100 Safe Key Clamp 1
52 Console Signing Light Cover 2 101 Console Overlay 1

─ 17 ─
Par ts List-220V
Item No. Description QTY Item No. Description QTY
102 Sign Paster 1 179 Socket Head Cap Screw M6*60 2
104 A Zone Up Overlay 1 180 Socket Head Cap Screw M6*20 20
105 A Zone Down Overlay 1 181 Locknut M3 2
108 Console Pcb 1 182 Locknut M8 12
109 Key Board 1 183 Washer Φ11*Φ23*2 6
110 Joint 1 1 184 Hexagon Socket Countersunk Head Cap Head Screw M8*35 6
111 Joint 2 1 185 Circlip For Shaft 2
112 Joint 3 1 186 Washer 4
113 12V Power Wire 1 187 Socket Head Cap Screw M8*15 2
114 Switch Pcb 1 188 Socket Head Cap Screw M8*30 10
115 Fan 1 189 Socket Head Cap Screw M8*80 2
116 Pulse Plate 1 190 Hex Head Bolt M10*165 2
117 Linked Wire Fron Pulse Pcb To Pcb 1 191 Hex Head Bolt M10*180 2
118 Pulse Connect Wire 1 193 Power Wire Fixing Plate 1
119 Receptor 1 194 Band Cable 10
120 Spd And Incl Harness 1 195 Double Wrench 1
122 Emergency Switch 2 196 Lug Wrench 1
123 Emergency Switch Wire 2 197 Hexagonal Socket Wrench 1
124 Console Wire Up 1 198 Double Wrench 1
125 Ferrite 3 199 Lug Wrench 1
126 Ferrite 2 200 Hexagonal Socket Wrench 1
150 Adjust Bumper 2 201 Tape 3.8
151 Bumper A 4 204 Phillip Screw St4.2*16 4
152 Bumper B 4 205 Wheel 2
153 Bumper 4 206 Locknut M10 4
154 Insulation Bumper 1 207 Locknut M12 2
156 V-Belt 1 208 Washer Φ9*Φ22*2 10
158 Neck Bush 4 209 Circuit Break Switch 2
159 Clip Nut M6 6 210 Earth Wire 1
160 Insulation Spacer 4 211 Motor 1
161 Carriage Bolt M8*40 1 212 Transducer 1
162 Countersunk Head Hexagon Riveted Nuts M5 12 213 Main Switch 4
163 Countersunk Head Hexagon Riveted Nuts M6 2 214 Connect Wire 1
164 Flat Head Hexagon Riveted Nuts M6 18 215 Console Wire Down 2
165 Flat Head Hexagon Riveted Nuts M8 6 216 Connect Wire 2
166 Hex Flange Nut M8 9 221 Protective Sleeve 1
167 Hex Flange Nut M16 2 222 Inductance 1
168 Hex Head Bolt M8*150 6 223 Filter 1
169 Hex Head Bolt M10*25 4 224 Actuator 1
170 Hex Head Bolt M10*50 1 225 Power Outlet 1
171 Hex Head Bolt M10*130 1 226 Power Wire 1
172 Phillip Screw M3*10 2 227 Ferrite 1
174 Phillip Screw M4*10 2 228 Ferrite 2
175 Phillip Screw M4*8 5 260 Ground Bumper 1
176 Phillip Screw St4.2*13 18 261 Serrated Lock Washers Φ10 4
177 Phillip Screw M5*20 14 262 Serrated Lock Washers Φ8 4
178 Phillip Screw M6*30 6

─ 18 ─
Exploded View-110V

─ 19 ─
Exploded View-110V

─ 20 ─
Exploded View-220V
