Weslo WLIVEL14718.0 User manual

Model No. WLIVEL14718.0
Serial No. ___________
serial no.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
USERʼS MANUAL
Visit our website
www.iconsupport.eu
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: [email protected]
Write:
ICON Health & Fitness, Ltd.
Unit 4,
Westgate Court, Silkwood Park,
OSSETT
WAKEFIELD
WF5 9TT
UNITED KINGDOM
CUSTOMER SERVICE

2
TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ASSEMBLY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
HOW TO OPERATE THE ELLIPTICAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
CONSOLE FEATURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
MAINTENANCE AND TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
EXERCISE GUIDELINES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
EXPLODED DRAWINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
NOTES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
ORDERING REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Last page

3
IMPORTANT PRECAUTIONS
1. Before beginning any exercise program, con-
sult your physician. This is especially impor-
tant for persons over age 35 or persons with
pre-existing health problems.
2. Use the elliptical only as described in thi
manual.
3. It is the responsibility of the owner to ensure
that all users of the elliptical are adequately in-
formed of all precautions.
4. The elliptical is intended for home use only.
Do not use the elliptical in a commercial, rental,
or institutional setting.
5. Keep the elliptical indoors, away from mois-
ture and dust. Place the elliptical on a level sur-
face, with a mat beneath it to protect the oor
or carpet. Make sure that there is at least 3 ft.
(0.9 m) of clearance in the front and rear of the
elliptical and 2 ft. (0.6 m) on each side.
6. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
7. Keep children under age 12 and pets away
from the elliptical at all times.
8.The elliptical should not be used by persons
weighing more than 254 lbs. (115 kg).
9. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the elliptical. Always wear athletic
shoes for foot protection while exercising.
10. Hold the handlebars or the upper body arms
when mounting, dismounting, or using the elip-
tical.
11. The pulse sensor is not a medical device.
Various factors may affect the accuracy of heart
rate readings. The pulse sensor is intended
only as an exercise aid in determining heart
rate trends in general.
12. The elliptical does not have a freewheel; the
pedals will continue to move until the ywheel
stops. Reduce your pedaling speed in a con-
trolled way.
13. Keep your back straight while using the el-
liptical; do not arch your back.
14. Over exercising may result in serious injury
or death. If you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
WARNING : To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your elliptical before using your elliptical. ICON
assumes no responsibility for personal injury or property damage sustained by or through the
use of this product.

4
115 Kg
This drawing shows the location(s) of the warning
decal(s). If a decal is missing or illegible, see
the front cover of this manual and request a
free replacement decal. Apply the decal in the
location shown. Note: The decal(s) may not be
shown at actual size.
BEFORE YOU BEGIN
Thank you for purchasing the Weslo® EliCity. The
elliptical provides an array of features designed to
make your workouts at home more effective and
enjoyable.
For your benet, read this manual carefully be-
fore you use the elliptical.
If you have questions after reading this manual,
please see the front cover of this manual. To help
us assist you, note the product model number and
serial number before contacting us. The model
number is WLIVEL14718.0 and the location of the
serial number decal is under the main frame.
WARNING DECAL PLACEMENT

5
S17 S19 1PCS
M8x40 4PCS
35
M10X57 4PCS
9
16x89 2PC
S
26
M8x55 2PCS
31 M10X45 4PCS
30
S=10 13 14 15 17 ! 5 1PCS
13
14
38 M8*15 4PCS 56 M8*30 2PCS
S6 1PCS
S8 1PCS
S13, 14 1PCS
ASSEMBLY
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove
the packing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver and an adjustable wrench.
As you assemble the exercice bike, use the drawings below to identify small parts. The number in pa-
rentheses below each drawing is the key number of the part, from the PART LIST near the end of this
manual. The number following the parentheses is the quantity needed for assembly.
Note: If a part is not in the hardware kit, check to see if it has been preassembled.

6
STEP 1
Attach the Front bottom tube (2) and Rear bottom
tube (3) onto the Main frame (1) with Square neck
bolt (9), Arc washer (11), Acorn nut (12) as shown.
STEP 2
Connect Extension wire (44) well with Sensor wire
(43). Connect Tension controller (45) well with Ten-
sion cable (42), ensured the Cable has been con-
nected correctly as shown. Finally x Handlebar
post (4) onto the Main frame (1) with Inner Hex bolt
(38) and Arc washer (36) as shown.

7
STEP 3
1. Fix Right Swing arm (6R) onto the long axis of Handlebar post (4) with Hex bolt (33), Spring washer (51),
Flat washer (34), Wave washer (25) and Long axis (39). Don’t lock it.
2. Fix the Right Connecting rod (5R) on the Crank (14) with Right Pedal bolt (26R), Wave washer (25), Spring
washer (15) and Nylon nut (16R). Don’t lock it.
3. Connect the Right Swing arm (6R) and Right Connecting rod (5R) with Hex bolt (31), Flat washer (20),
Nylon nut (21);then lock the Hex bolt (33), Hex bolt (31) and Nylon nut (16R);at last cover the Cap (22), End
cap (17), Cap (52)
4. Fix the Left Swing arm (6L) and Left Connecting rod (5L) onto the long axis of Handlebar post (4) and crank
in the same way.
5. Lock the Pedal (29L/R) on the Left/Right Connecting rod (5L/R) with Hex bolt (30), Flat washer (28), Nylon
nut (27)
Attention! There are Right and Left Pedal hinge bolt. Separately install the Right Pedal hinge bolt CLOCK-
WISE and the Left Pedal hinge bolt COUNTERCLOCKWISE. You can turn the crank so to install the Pedal
bolt (L/R) smoothly.

8
Step 4 :
Fix the Handlebar (53) on the Handlebar post (4) with
the Inner hex round head bolt(56), Spring washer(55),
Flat washer(54) ,then cover the Handlebar clamp(57).
Step 5:
Fix the Right Handlebar (7R) onto the Right Swing arm
(6R) with Square neck bolt (35), Arc washer (36) and
Acorn nut (37) as shown. Fix the Left Handlebar (7 L)
onto the Left Swing arm (6 L) in the same way.
Step 6:
1. Pull the wire of the computer (50) out of the hole of
the Console Bracket (49), x the Console (50) onto the
console bracket (49);
2. Connect the wire of the computer (50) with Exten-
sion Wire (44); Put the Computer Bracket (49) on the
Handlebar Post (4).
Now your tness equipment is ready to be used

9
HOW TO USE THE ELLIPTICAL
HOW TO EXERCISE ON THE ELLIPTICAL
EXERCISER
To mount the elliptical exerciser, hold the upper body
arms and step onto the pedal that is in the lowest
position. Then, step onto the other pedal. Push the
pedals until they begin to move with a continuous
motion.
Note: The pedal discs can turn in either direction. It is
recommended that you move the pedal discs in the
direction shown by the arrow; however, for variety,
you may turn the pedal disc in the opposite direction.
The upper body arms are designed to add upper-
body exercise to your workouts. As you exercise,
push and pull the upper body arms to work your
arms, shoulders, and back. To focus on lower-body
exercise, hold the upper body arms but do not push
or pull them as you exercise.
To dismount the elliptical exerciser, wait until the
pedals come to a complete stop. Note: The elliptical
exerciser does not have a free wheel; the pedals will
continue to move until the ywheel stops.
When the pedals are stationary, step off the highest
pedal rst. Then, step off the lower pedal.
When you are nished exercising
If the pedals do not move for several minutes and the
buttons are not pressed, the console will turn off and
the display will be resetéconomies des piles.

10
Inspect and tighten all parts of the elliptical regularly.
Replace any worn parts immediately.
To clean the elliptical, use a damp cloth and a small
amount of mild detergent.
Important: To avoid damaging the console, keep
liquids away from the console and keep the console
out of direct sunlight.
BATTERY REPLACEMENT
If the console display becomes dim, the batteries
should be replaced; most console problems are the
result of low batteries.
To replace the batteries, pull off the battery cover and
place two SIZE-AAA (UM-4) batteries into battery
housing on back of monitor. Insure that the batteries
are correctly positioned and battery springs are in
proper contact with batteries.
Replace battery cover and insure it is tightly closed.
Be aware that the battery life is approxlimatky 1 year
under normal usage.
If the display is illegible or only partial segments
appear, remove batteries and wait 15 seconds
before reinstalling.
NOTE: Removing the batteries will erase computer
memory.
MAINTENANCE AND TROUBLESHOOTING
