GEN-X

INSTALLATION MANUAL

01_2018

Page 2

Dear Customer,

Thank you for choosing a TREESSE product. Welcome to our world of total well-being.

We would like to remind you that all our products are built with top quality materials

and are carefully tested according to safety standards.

This guarantee of quality and comfort is accompanied by strong innovation and

sought-after design.

Enjoy relaxation!

Tre S S.p.a. Group

Page 3

_TABLE OF CONTENTS

_ INTRODUCTION

- INSTALLATION MANUAL

- - SAFETY PROVISIONS- -

_ INSTALLATION

_ DOCUMENTATION

- - WARRANTY CONDITIONS

5

12

6

Page 4

- - WARRANTY CERTIFICATE

- - DISPOSAL AT END OF LIFE

ŸINSTALLATION MANUAL

This manual is a guide for the safe installation of TREESSE products. Therefore, you must read it very

carefully before proceeding with product installation.

This manual is of fundamental importance, therefore it must be carefully kept, for any future consultation.

TREESSE reserves the right to change the product as it deems appropriate without prior notification or

replacement

Ÿ

ŸSAFETY PROVISIONS

Before installing the equipment, please read this manual carefully and keep it in a safe place to be

consulted by the operators. If there are any missing parts, contact the manufacturer for additional

explanation.

Installation should be performed by experienced, qualified personnel in compliance with local and

national provisions relating to civil and industrial systems. The installer, before connecting the electrical

and hydraulic equipment, must ask the user to show him the Declaration of conformity of the systems of

the building. In the absence of such documentation, the manufacturer denies all liability for damage to the

equipment or the place in which the same is installed.

Interventions, tampering with or alterations not expressly approved in this manual, which do not comply

with the provisions laid down in this manual may lead to damages, injuries or death and will void the

warranty.

In case of malfunction of the product, if the warranty is in force, please refer only to our authorised service

centres using the contacts listed at the end of this manual.

Page 5

_ INTRODUCTION

_INSTALLATION

Page 6

_Buffer zones

Standards forbid any electrical installation (plug socket, switches, lights, etc.) in the zone surrounding the product for a

distance of at least 60 cm and a height of 230 cm.

min.

60 cm

min.

60 cm

MIN. 230 cm

_INSTALLATION

Page 7

Pull the tub out of the packaging, taking care to

hold it under the edge of the tub.

Put it near the place where it will be installed.

Remove the panels, unscrewing the holding

screws at the base and removing them

downwards.

If not already prepared, assemble the tap on

the tub according to instructions in the box of

the tap.

_INSTALLATION

Page 8

If not already prepared, assemble the drain

column with supply according to instructions in

the box of the part.

Connect the supply line to the tap deviator

The tub rests on no. 6 adjustable feet.

To ensure smooth operation of the tub you

must carefully level it.

ATTENTION

Incorrect execution of these regulations may

result in imperfect tightness of the door.

Initially, feet 2 and 5 are lifted off the ground. To

adjust the level, we will act only on feet 1, 3, 4

and 6.

The tub is adjusted in the factory with a height

on the edge over 96 cm.

At this stage it is not important if the tub does

not rest perfectly on the ground; this

adjustment will be made subsequently.

1 2 3

4

5

6

96

_INSTALLATION

Page 9

Position the tub in the installation corner and

place it perfectly level using the feet 1,3,4 and

6.

ATTENTION

To adjust the tub, act only on the feet and not

on the threaded rods.

All four feet mentioned above MUST rest on

the ground perfectly with the tub in installation

position.

Incorrect support can compromise the

tightness of the door.

Once positioning is obtained, lock the feet

using the nut on each of them.

Now you can adjust feet 2 and 5 until they

touch the floor, without forcing. Lock the feet

with the nut found on each of them.

ATTENTION

Feet 2 and 5 should not raise any of the

previously adjusted feet. Failure to do so would

compromise the stability and the structure of

the tub, especially the door seal.

Connect the tub drain to the ground fittings as

indicated in the technical data sheet.

Connect the tap to the wall fittings as indicated

in the technical data sheet.

_INSTALLATION

Page 10

Each tub is individually tested in the company

to guarantee its perfect operation.

During this phase of the installation, you must

test the product to ensure that all adjustments

made in the company have been maintained.

Due to improper transport and installation,

slight leak problems may arise occasionally.

In the event of leaks, on the lower part or along

the edge near the closure handle, given the

certainty of state-of-the-art assembly as

previously described, work on the shape of the

tub by opening and closing the front side.

To do this, on the frame at the centre front,

there is an upright with adjustable head

consisting of a plate with threaded rod screwed

onto the tub and by two nuts, one on front and

one on the rear side.

This system is able to slightly modify the

closing layout.

A) Base leak: it will be necessary to screw in

the rear nut on the riser bringing it to stop on

the plate assembled on the tub. Screw in the

external nut a half a rotation at a time until the

leak is resolved. Tighten the rear nut again on

the riser. This operation allows us to open the

front side.

B) Leak on top lateral side: you will need to

unscrew by half a turn to the front nut to the

upright and do the same on the rear nut until

you fix the leak. With this operation you have

closed the front side

ATTENTION

The regulations will be minimal to avoid

compromising tightness.

At the end of each adjustment, the two nuts

must be firmly tightened to the upright.

Middle upright

Plate

Front and rear

nut adjustment

_INSTALLATION

Page 11

Insert the panel again under the tub, starting

from the front side, then under the door and

lastly under the short side.

To lock the panel, insert it under the edge of the

tub, between the edge and the thrust springs.

Use the supplied wedges.

Fit back at the base of the panel the screws

previously removed.

Remove the wedges used for lifting.

_DOCUMENTATION

Page 12

_WARRANTY CONDITIONS

Under warranty, the manufacturer will repair or replace free of charge only the parts that have

manufacturing defects; therefore, the buyer cannot make use of the warranty to cancel the contract, to

ask for compensation for damages and the complete replacement of the product.

After the warranty expires, any support and repairs will be charged; the Authorised Service Centre called

by the customer will apply the rates in force, approved by the manufacturer.

The following are not covered by the warranty:

-light bulbs;

-protection fuses;

-masonry works which may be necessary to remove the defective parts;

-parts that may be faulty due to negligent use, incorrect installation or maintenance, transport, and in

general causes that cannot be directly attributed to manufacturing defects of the product. The

manufacturer cannot be held in any way liable for any damage to people, animals or property due to non-

compliance with the instructions given in this manual and in the service manual.

Any intervention performed in the absence of an obvious reasonable defect of the product, as well as the

installation, all expenses will be charged to the customer.

_ IMPORTANT NOTICE

The warranty will be effective only if:

- the purchaser is in possession of the document proving the actual date of purchase;

- installation, use and maintenance comply with the current regulations, the instructions given in the

installation and maintenance manual of the product, and also with the instructions of the manufacturer.

_WARRANTY CERTIFICATE

With this document, the manufacturer guarantees the product purchased for a period of:

- 2 years for the tub parts made of fiberglass. The warranty does not cover the taps, electrical and

hydraulic equipment that guarantee operation of the product even if sold with it.

-2 years for the remaining parts sold with the product.

The warranty enters into force from the date of purchase; said date shall be certified by the receipt or

invoice, or any other document proving the purchase of the goods.

Page 13

_DISPOSAL AT END OF LIFE

Pursuant to Art.13 of Legislative Decree no.49 on 2014 "Implementation of the WEEE Directive

2012/19/EU on electrical and electronic equipment waste"

_DOCUMENTATION

The crossed-out wheeled bin label specifies that the product was placed on the market after 13

August 2005 and that at the end of its service life should not be disposed of with other waste but

must be disposed of separately.

All the equipment is made from recyclable materials (stainless steel, iron, aluminium, galvanized steel

sheet, copper, etc.), about 90% by weight.

Put the equipment out of service for disposal by removing the power cord and any locking device of

compartments or cavities (if any).

It is necessary to pay attention to the management of this product at the end of its service life by reducing

negative impacts on the environment and improving the efficiency of resource use, applying the “polluter

pays" principle, ensuring prevention, preparation for reuse, recycling and recovery. Please note that

illegal and improper disposal of the product entails the application of the administrative sanctions stated

by current legislation.

Disposal considerations available in Italy.

In Italy, WEEE equipment must be delivered:

-to collection points (also called ecological stations or ecological platforms)

-to the dealer from whom you will purchase new equipment, who is obliged to withdraw the product for

free (“one for one” withdrawal);

Information on disposal in other countries of the European Union.

The Community directive on WEEE equipment has been implemented differently by each country.

Therefore, if you wish to dispose of this equipment please contact your local authorities or dealer and ask

them which is the correct method of disposal.

_NOTES

Page 14

.........................................................................................................................

_NOTES

Page 15

.........................................................................................................................

Gruppo Tre S s.p.a

01036 Nepi (Vt) Italy

S.S. Cassia Km. 36,400 - Industrial zone Settevene

Tel. (+39) 0761-527242 - Fax (+39) 0761 527223

e-mail: [email protected]

www.gruppotres.it
