Trelawny TCG125L User manual

CONCRETE GRINDER
Original instructions
540.2010 • 540.2020
TCG125L •TCG125

1
6
12
3
2
4
5
7
910
8
11
13
2 3
45
1

3
Original instructions
EN
Contents
Introduction........................................................................................................................................................................................... 3
Technical specications .................................................................................................................................................................... 5
General power tool safety warnings............................................................................................................................................... 6
Concrete grinder safety warnings .................................................................................................................................... 7
Know your product ............................................................................................................................................................ 7
Operation............................................................................................................................................................................ 7
Maintenance ...................................................................................................................................................................... 9
UNPACKING
Due to modern mass production techniques, it is unlikely that your power tool is faulty or that a part is missing. If you nd
anything wrong, do not operate the tool until the parts have been replaced or the fault has been rectied. Failure to do
so could result in serious personal injury.
ASS EM BLY
The concrete grinder is packed fully assembled except for the diamond cup wheel.
Introduction
Your new TRELAWNY power tool will more than satisfy your expectations. It has been manufactured under stringent
TRELAWNY Quality Standards to meet superior performance criteria. You will nd your new tool easy and safe to oper-
ate, and, with proper care, it will give you many years of dependable service.
WARNING:
Carefully read through these original instructions before using your new TRELAWNY power tool Take special
care to heed the Warnings. Your TRELAWNY power tool has many features that will make your job faster and
easier. Safety, performance, and dependability have been given top priority in the development of this tool,
making it easy to maintain and operate.
Do not dispose of electrical products together with household waste!
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for recycling advice.
ENVIRONMENTAL PROTECTION
The machine, accessories and packaging should be sorted for environmental-friendly recycling.
The plastic components are labelled for categorised recycling.

4
TCG 125L • TCG 125
EN
DESCRIPTION OF SYMBOLS
The rating plate on your tool may show symbols. These represent important information about the product or instruc-
tions on its use.
Double insulated for additional protection
Spindle thread: M14
Conforms to the relevant European Directives
Refer to original instructions
YYYY-Www Production period, where the variable symbols are:
YYYY - year of manufacture, ww - calendar week number

5
Original instructions
EN
Technical specications
Model TCG 125L TCG 125
Part Number 540.2010 540.2020
Voltage 110V~ 5 0Hz 230V~50Hz
Power input 1010 W 1400 W
No load speed 8000 min-1 10500 min-1
Spindle thread M14 M14
Spindle thread length 20 mm 20 mm
Cup wheel arbor Ø22.23 mm Ø22.23 mm
Cup wheel maximum diameter 125 mm 125 mm
New cup wheel maximum thickness 22 mm 22 mm
Dust extraction port diameter Ø35 mm Ø35 mm
Overall dimensions - Lenght / Width / Height 325/190/200 mm 325/190/200 mm
Weight (EPTA Procedure 01/2003) 3.1 kg 3.1 kg
Safety class (EN 60745-1) II II
NOISE AND VIBRATION INFORMATION (Measured values determined according to EN 60745.)
Noise emission
A-weighted sound pressure level LpA 91 dB (A) 91 dB (A)
Uncertainty КpA 3 dB 3 dB
A-weighted sound power level LwA 102 dB (A) 102 dB (A)
Uncertainty КwA 3 dB 3 dB
Wear hearing protection!
Vibration emission*
Total vibration values (vector sum in the three axes) determined according to EN 60745:
Grinding concrete
Vibration emission value ah6.0 m/s26.0 m/s2
Uncertainty K 2.0 m/s22.0 m/s2
* The vibration emission values are determined according to 6.2.7 EN 60745-1.
The vibration emission level given in this information sheet has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of
exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for dif-
ferent applications, with different accessories or poorly maintained, the vibration emission may differ. This may signi-
cantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched
off or when it is running but not actually doing the job. This may signicantly reduce the exposure level over the total
working period.
Maintain the power tool and the accessories and keep your hands warm during operation to reduce the harmful effect
of vibrations.
Dust from material such as paint containing lead, some wood species, minerals and metal may be harmful. Contact
with or inhalation of the dust may cause allergic reactions and/or respiratory diseases to the operator or bystanders.
Certain kinds of dust are classied as carcinogenic such as oak and beech dust especially in conjunction with additives
for wood conditioning (chromate, wood preservative). Material containing asbestos must only be treated by specialists.
▪Where the use of a dust extraction device is possible it shall be used.
▪To achieve a high level of dust collection, use vacuum cleaner for wood or for wood and/or minerals together with
this tool.
▪The work place must be well ventilated.
▪The use of a dust mask of filter class P2 is recommended.
Follow national requirements for the materials you want to work with.
All models are equipped with electronic device for soft start and restriction of starting current to 16 A. Models feature
safety upon mains drop-out. In case of mains drop-out or unplugging for more than 0.5 s the power tool remains
switched off and can be started only after switching off and on the ON/OFF switch. (This safety feature is described in
part “Operation”.)

6
TCG 125L • TCG 125
EN
General power tool
safety warnings
WARNING! Read all safety warnings and
all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1. WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3. PERSONAL SAFETY
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with
your finger on the switch or energising power tools
that have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing
or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving
parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
4. POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the power
tool for operations different from those intended
could result in a hazardous situation.

7
Original instructions
EN
5. SERVICE
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
Concrete grinder
safety warnings
WARNING: Before connecting a tool to a power
source be sure that the voltage supply is the same as that
specied on the nameplate of the tool.
▪A power source with a voltage greater than that
specified for the tool can result in serious injury to the
user, as well as damage to the tool.
▪If in doubt, do not plug in the tool.
▪Using a power source with a voltage less than the
nameplate rating is harmful to the motor.
Always wear eye and ear protection
and use a dust mask. The dust and abrasive particles
separated during operation may seriously injure your
health.
▪Hold power tool by insulated gripping surfaces
only, when performing an operation where the
cutting accessory may contact hidden wiring or
its own cord. Cutting accessory contacting a “live”
wire may make exposed metal parts of the power tool
“live” and could give the operator an electric shock.
WARNING: Always switch off and unplug the
power tool prior to any adjustment, servicing or main-
tenance.
▪Never switch on the grinder under load, and leave it
down only after final rotation stop.
▪Always keep the cord away from the working area of
the cup wheel.
▪Fasten the cup wheel only by a special wrench, using
the original base support washer and lock nut.
▪Do not use damaged cup wheels.
WARNING: The grinding accessory continues
rotation even after the machine is switched off.
▪Never apply side pressure to stop the cup wheel
rotation after switching off the grinder.
▪The outer metal parts and the bits may get hot after
continuous operation.
▪Use clamps or a vice to secure your work whenever
possible.
▪Always switch off the machine and wait until the
spindle has come to a complete standstill before
placing it down.
▪Do not force the machine: let the tool do the work at a
reasonable speed. Overloading will occur if too much
pressure is applied and the motor slows resulting in
inefficient work and possible damage to the motor.
▪Rags, cloths, cord, string and the like should never be
left around the work area.
▪Remove any nails, screws, etc. from the processed
surface.
▪Before using the tool on an actual work piece, switch
on and let it run for a while. Operate the tool at least
200 mm away from your face and body.
▪Always be sure you have a firm footing. Be sure no
one is below when using the tool in high locations.
▪Hold the power tool firmly.
▪Keep your hands away from rotating parts. Do not
touch the bit or the work piece immediately after
operation - they may be extremely hot and you may
get serious burns.
▪The tool must be used only for its prescribed purpose.
Any use other than those mentioned in this Manual
will be considered a case of misuse. The user and not
the manufacturer shall be liable for any damage or
injury resulting from such cases of misuse.
▪To use this tool properly, you must observe the
safety regulations, the assembly instructions and
the operating instructions found in this Manual. All
persons who use and service the machine have to
be acquainted with this Manual and must be informed
about its potential hazards. Children and frail people
must not use this tool. Children should be supervised
at all times if they are in the area in which the tool is
being used. It is also imperative that you observe the
accident prevention regulations in force in your area.
The same applies for general rules of occupational
health and safety.
▪The manufacturer shall not be liable for any changes
made to the tool nor for any damage resulting from
such changes.
Even when the tool is used as prescribed it is not
possible to eliminate all residual risk factors. The
following hazards may arise in connection with the tool’s
construction and design:
▪Damage to hearing if effective hearing protection is
not worn.
▪Always unplug the machine prior to any adjustment,
servicing or maintenance including replacing the
accessories.
▪The power tools must not be used outdoors in rainy
weather, or in moist environment (after rain) or in close
vicinity with easily flammable liquids and gases. The
working place should be well lit.
Know your product
Before using the power tool, familiarize yourself with all
the operating features and safety requirements.
Use the tool and accessories only for the applications
intended. All other applications are expressly ruled out.
1. Spindle
2. Wheel guard
3. Base support washer
4. Diamond cup wheel
5. Flat support washer
6. Lock nut

8
TCG 125L • TCG 125
EN
7. ON/OFF switch
8. Spindle lock button
9. Brush shield
10. Fastening bracket
11. Auxiliary handle
12. Lock nut wrench
13. Screw
Operation
This power tool is supplied from single-phase alternating
current mains only. It is double insulated according
to EN 60745-1, IEC 60745 and can be connected to
grounded or not grounded sockets. This power tool is
radio suppressed in compliance with EMC Directive
2004/108/EC.
This power tool is designed for rough and ne grinding
concrete and rock material with the purpose of
refurbishing before laying plaster and protective coating.
The machine is designed for dry grinding only.
PRIOR TO INITIAL OPERATION
▪The machine may be delivered with the wheel
mounted at the factory. Ensure that the wheel is
mounted properly and fixed reliably prior to the initial
and any following operation.
▪Make sure the power supply voltage corresponds to
the value indicated on the name plate with technical
data of the tool.
▪Always check the position of ON/OFF switch. The
power tool must be connected to the power supply
socket only when this switch is in OFF position.
▪Make sure that the cord and the plug are in order. If the
replacement of the supply cord is necessary, this has
to be done by the manufacturer or his agent in order
to avoid a safety hazard.
WARNING: Always switch off and unplug the
power tool prior to any adjustment, servicing or main-
tenance.
▪Always use the auxiliary handle and hold the machine
firmly with both hands for maximum control over
torque reaction or kickback upon starting. (Fig. 1)
SWITCHING ON - SWITCHING OFF
Before plugging in the tool, always check to see that the
switch trigger actuates properly and returns to the “OFF”
position when released.
1. To switch on: Push the slider of the switch slider (7)
forward until its front end sags thus xing itself. (Fig. 2)
2. To switch off: Press the back lifted end of the switch
slider (7) and release it in order to move back in its
initial position. (Fig. 3)
ELECTRONIC DEVICE
This power tool is equipped with an electronic device
featuring:
▪Safety upon mains drop-out: In case of mains drop-
out (or temporary drop-out for time t > 0,5 s), when the
ON/OFF switch is in ON position, the machine should
not operate after supply recovering. To start operating
the machine, first switch off and then switch on the
lever of ON/OFF switch.
▪Soft start and overload protection: This feature
ensures starting without jerks and prevents origination
of supply voltage fluctuations;
▪Virtually constant speed under wide range of loads;
▪Brief overload protection: Upon major brief overloads
a current overload protection actuates, which reduces
harshly the rotation speed. To resume normal
operation withdraw the machine from the material.
▪Thermal overload protection: Upon minor long
overloads, the thermal overload protection actuates.
The electronic device switches the machine off
before the temperature reaches critical value. The
normal operation is disabled. After cooling down for
3-5 minutes the machine can be operated again. To
resume operation switch the trigger off and on again.
WHEEL GUARD
The wheel guard (2) must always be mounted on the
machine!
ASSEMBLY, REPLACING AND ADJUSTING
THE CUP WHEEL POSITION
Make sure the cup wheel diameter and thickness do not
exceed the values stated in the technical specications.
The maximum admissible speed indicated on the wheel
must not be less than the machine no load speed.
Fix the spindle (1) by pressing the lock button (8) on the
gear case.
WARNING: Never press button (8) while the
spindle is still rotating!
With this button depressed turn the spindle till its
pronounced going deeper. Unscrew lock nut (6) by the
lock nut wrench (12).
In view of the cup wheel wear and in order to achieve
optimum dust extraction a possibility is provided to adjust
the cup wheel position to the wear of the cup wheel.
When placing a new cup wheel arrange the components
on the spindle in the following order: base support
washer (3); cup wheel (4); lock nut (6) with its at end
towards the cup wheel as shown on Fig. 4.
WARNING: Placing the lock nut (6) with its
convex end towards the cup wheel shall make tighten-
ing the cup wheel impossible.
In case the cup wheel is half worn out or more, arrange
the components on the spindle in the following order: at
support washer (5); cup wheel (4); lock nut (6) with its
convex end towards the cup wheel as shown on Fig. 5.
WARNING: Placing the lock nut with its flat
end towards the cup wheel shall obstruct centring the
cup wheel thus causing excessive vibration and may
result in personal injury.

9
Original instructions
EN
WARNING: After replacing the wheel, operate
the machine with the new wheel at no load mode for
minimum 30 seconds. Vibrating or otherwise improp-
erly rotating wheels must be replaced immediately and
discarded.
In case of changing the cup wheel position adjust it or
replace the brush shield if necessary.
ADJUSTING (REPLACING) THE BRUSH
SHIELD POSITION
The brush shield (9) ensures decreasing the dust
emission in the environment to the utmost. The brush
shield wears out along with the wheel. When replacing
the wheel if necessary change the brush as well. Loosen
the screw in bracket (10) and remove the old brush.
Place the new brush, taking care that the edge of the
wheel guard (2) contacts the brush rib. Place the bracket
(10) back and fasten it.
AUXILIARY HANDLE
The auxiliary handle (11) is fastened to the gear case
through two screws. Always use the auxiliary handle
and hold the machine rmly with both hands. (Fig. 1)
DUST EXTRACTION
This power tool should only be used with a dust extraction
system. In addition, always wear approved dust mask.
Always make sure the vacuum cleaner that you use is
designed for extraction of masonry dust. Connect the
vacuum cleaner to the dust extraction port on the wheel
guard.
RECOMMENDATIONS
When grinding do not apply pressure to the processed
surface by bearing down on the machine but move the
wheel smoothly. Upon overloading the built-in electronic
protection will actuate and the speed of the wheels will
be reduced considerably.
To resume normal speed draw the machine back from
the processed material. Use the appropriate type of
wheel for the specic operation and the material.
In case the screws (13) loosen they have to be tightened
rmly. Prior to tightening you must lay thread locking
adhesive over each screw thread.
ACCESSORIES TO BE USED WITH THIS
POWER TOOL
Diamond cup wheel Ø125 x Ø22.23 x 22 mm
WARNING! These accessories or attachments are
recommended for use with your TRELAWNY tool
sp ec i  e d in th i s ma nu al . Th e us e of any ot h er ac c e s so r i e s
or attachments might present a risk of injury to persons.
Only use accessory or attachment for its stated purpose.
If you need any assistance for more details regarding
these accessories, ask your local TRELAWNY service
centre.
Maintenance
WARNING: Always ensure that the tool is
switched off and unplugged before attempting to per-
form inspection or maintenance.
BRUSH REPLACEMENT
This power tool is equipped with auto-stop brushes.
When the carbon brushes are worn out, the machine
switches itself off. In this case both brushes must be
replaced simultaneously with genuine brushes at
TRELAWNY service centre for warranty and post-
warranty service.
GENERAL INSPECTION
Regularly inspect all fasteners and ensure they are
properly tightened. Should any of the screws be loose,
retighten it immediately to avoid hazards.
In case the screws (13) loosen they have to be tightened
rmly. Prior to tightening you must lay thread locking
adhesive over each screw thread.
Re-lubricate all moving parts at regular intervals.
If the replacement of the supply cord is necessary, this
has to be done by the manufacturer or his agent in order
to avoid a safety hazard.
CLEANING
For safe operation always keep the machine and its
ventilation slots clean.
Regularly check to see if any dust or foreign matter
has entered the grills near the motor and around the
switches. Use a soft brush and/or air jet to remove any
accumulated dust. Wear safety glasses to protect your
eyes whilst cleaning.
Exterior plastic parts may be cleaned with a damp cloth
and mild detergent if necessary.
WARNING: Never use alcohol, petrol or other
cleaning agent. Never use caustic agents to clean
plastic parts.
WARNING: Water must never come into
contact with the tool.
IMPORTANT! To assure product safety and reliability,
repairs, maintenance and adjustment (including brush
inspection and replacement) should be performed
by certied service centres or other qualied service
organisations, always using genuine replacement parts.

10
TCG 125L • TCG 125
EN
TCG 125L • TCG 125
Notes
Carefully read the entire Original Instructions before
using this product.
The manufacturer reserves the right to make changes
and improvements to the products and to alter
specications without prior notice.
Specications may differ from country to country.

Pos. No. Ref.No. Description
1540.147747 Gear box HD
2540.361366 Screw К 4Х25 TORX 20
3540.330335 O-ring 16X2B
4540.117795 Lock button
5540.330704 O-ring 5x1,5 NBR 70
654 0.11516 5 Spring
754 0.11780 0 Nut M8x1
854 0.158 6 3 6 Gear set 3,44
9540.933756 Bearing НК0709
11 540.157335 Gasket 13,5
12 54 0.156 478 Rubber bush
13 540.331437 Bearing 629 2RSL P63 LDS
18SpA
14 540.157339 Prole washer set
16 540.157311 Bearing cover
17 540.360673 Screw М4Х12
18 540.152579 Fan
19 540.331509 Bearing 626 2RSL
20 54 0.15732 0 Armature set
20a 5 40.145 6 65 Armature set
21 54 0.129 08 7 Elastic sleeve
22 540.117798 Spacer washer
23 540.117799 Spacer washer
24 540.330732 Circlip А35-1D
25 54 0.1130 91 Spacer washer
26 540.331622 Bearing 6300-2RS (10x35x11)
27 54 0.153 58 6 Felt 30x19.2x6
28 54 0.153 921 Spindle
29 540.330336 O-ring 50X2B
30 54 0.158 26 0 Bearing bed HD
31 54 0. 3 61131 Screw H2-M4x12
37 54 0.158 261 Bearing bed set HD
38 540.157299 Diffuser L 50-55
39 540.361430 Screw 3.9x69
40 540.159064 Stator set HD
40a 540.145 664 Stator set HD
TCG 125L • TCG 125
Pos. No. Ref.No. Description
41 540.159403 Body L50-55
42 540.159392 Button
43 540.1573 0 0 Guiding switch lever L
44 540.146782 P r e s s u r e s p r i n g 0 , 4 х 4 х 2 5
45 540.102100 Switch PS8
45a 540.153548 Switch APB-2114 Defond
46 540.153056 Brush
47 540.153057 Brush with a switch
48 540.12 9 0 82 Brush holder set
49 540.254364 Spiral spring
50 540.361360 Screw К 4Х9.5 TORX 20
51 540.256500 Cord clamp
52 540.152759 Cord protector
53 540.145129 Cord with a plug
53a 5 40 .1743 0 6 Cord with a plug 16A/110V
54 540.159 0 98 Electronic block
54a 5 4 0.145 6 6 0 Electronic block
56 540.159 417 Couple cover set
57 540.361328 Screw K4x18 TORX 20
58 540.361367 Screw К 4Х37/25 TORX 20
59 540.116757 Rubber bush
60 540.154699 Auxiliary handle set
61 540.360396 Bolt D-2 M8X16
62 540.361086 Washer 1-8
63 540.361342 Screw M6X6 DIN 914
64 540.1582 6 6 Disk guard 52
65 540.154693 Internal wire
66 540.174 411 Gasket
67 540.1582 6 5 Disk guard
68 540.152929 Back up disc washer
69 540.174267 Inner Flange
70 540.1218 3 8 Locking nut
71 540.150015 Special spanner 200
72 540.157990 Spring
73 540.146454 Spanner SW 13 DIN 894
Parts with “a” prex related to TCG 125L

www.trelawnyspt.co.uk
Email: [e-mail]
Tel: [phone]
Fax: [phone]
DECLARATION OF CONFORMITY
We,
Trelawny SPT Limited of
Trelawny House, 13 Highdown Road, Sydenham Industrial Estate, Leamington Spa,
Warwickshire, CV31 1XT, United Kingdom,
Declare that under our sole responsibility for supply/manufacture of the product
Name of product
Part Numbers
Year of production
to which this document related is in conformity with the provisions of the following Directive(s),
Normative Documents and their relevant Standards:
2006/42/EC MACHINERY DIRECTIVE
2004/108/EC DIRECTIVE OF ELECTROMAGNETIC COMPATIBILITY
2011/65/EC RoHS DIRECTIVE
EN 60745-1, EN 55014-1, EN 55014, EN 61000-3-2, EN 61000-3-3
Registered Ofce: Trelawny SPT Ltd, Trelawny House, 13 Highdown Road, Sydenham Industrial Estate, Leamington Spa, Warwickshire, CV31 1XT, United Kingdom
Date and place of issue,
1st January 2014
Leamington Spa, England.
Rob Chapman,
Commercial Director.
DOCUMENT No. Q:57/4
CONCRETE GRINDER
540.2010; 540.2020
2014
