TFC-1000S70
1000Base-T to 1000Base-LX Single-Mode Fiber Converter (70Km) with SC-Type Connector
FEATURES
TFC-1600:
16-slot EIA-19" (2 Unit-Height) Chassis for
TFC series Media Converters
TFC-1000MSC:
1000Base-T to 1000Base-SX Multi-Mode Fiber
with SC Connector
TFC-1000S20:
1000Base-T to 1000Base-LX Single-Mode 20
km Fiber with SC Connector
TFC-1000S50:
1000Base-T to 1000Base-LX Single Mode 50
km Fiber Converter
TFC-1000S70:
1000Base-T to 1000Base-LX Single Mode 70
km Fiber Converter (Special order only)
To Order Please Call:
1-888-326-6061
ORDERING INFORMATION
Compliant with IEEE 1000Base-T and 1000Base-LX
One 10/100Base-T RJ-45 port
One 1000Base-LX Port w/ SC-Type Connector
Status LED indicators for Power, Link/Activity, Full-Duplex, and Speed
Wall-Mountable
Optional 19” system chassis with redundant power supply (TFC-1600),
holds up to 16 TFC series Media Converters
5-year Warranty
TRENDnet
TRENDware, USA
What's Next in Networking
RELATED PRODUCT
SPECIFICATIONS
Standards:
• IEEE 1000Base-TX and
1000Base-LX
Supported Frame Size:
• No limitation (Standard Ethernet and
Jumbo Frame)
Network Media:
• 1000Base-TX: Cat. 5, EIA/TIA-568
100-ohm UTP/STP, up to 100 meters.
• 1000Base-SX: Multi-Mode fiber optic
cable 50/125 µm up to 550 meters.
62.5/125 µm up to 220 meters
• 1000Base-LX: Single-Mode fiber
optic cable 9/125 or 10/125 µm, up
to 70 Km
Wavelength:
• 1300nm
Protocol:
• CSMA/CD
Ports:
• 1 x 1000Base-T
• 1 x 1000Base-LX
Data Transfer Rate:
• 1000Mbps
Diagnostic LEDs:
• Power, Link/Activity, Full-Duplex,
and Speed
Power Adapter:
• 7.5VDC, 1.5A (7.2 watts max.)
Temperature:
• Operating: 0° ~ 40° C (32° ~ 104° F)
• Storage: -25° ~ 70° C (-13° ~ 158° F)
Humidity:
• Operating: 10% ~ 90%
• Storage: 5% ~ 90%
(non-condensing)
TRENDnet's TFC-1000 series Fiber Media Converter
transforms 1000Base-T (Copper Gigabit) media to
1000Base-SX/LX (Fiber Gigabit) media and vice versa.
The 1000Base-T port supports full-duplex Gigabit
connection at wire speed with RJ45 connector. The fiber
Gigabit connection supports shortwave (SX) or longwave
(LX) laser optic with multi-mode or single-mode SC type
connector. This converter will give your Copper Gigabit
connection the ability to interface with fiber connection
over a distance up to 70 km. With the optional 16-slot EIA-
19" rack-mount chassis, the TFC series converters are the
perfect solutions for various fiber media
TFC-1000S70 (06-29-2004)
