TFC-210S20D3 Bi-Directional Single-Fiber Media Converter
transforms 10/100Mbps-TX UTP/STP media to 100Base-FX media
and vice versa. The 10/100Mbps-TX Port Auto-Negotiating 10 or
100Mbps connection speed with Auto-MDIX media type, the fiber
supports single-mode SC type connection. This converter will give
your Switch/Hub the ability to interface with fiber connection over a
distance up to 20 km.
TFC-210S20D3 (v1.0R)
10/100Mbps-TX to 100Base-FX
Dual-Wavelength Single-Mode Fiber Converter
TFC-210S20D3
rev:03.02.2007
• Compliant with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX, 100Base-FX standards
• One 10/100Base-TX Auto-Negotiation/Auto-MDIX RJ-45 port
• One 100Base-FX Dual-Wavelength Single-Mode Single-Strand SC-type Fiber port
• Supports LLCF (Link Loss Carry Forward)
• Provides Dip switch to set: UTP (Auto Negotiation/Full Duplex), Fiber (Hall Duplex/Full Duplex) , LLCF (Enable/Disable), Mode
(Pure Converter Mode/ Switch Converter Mode)
• 802.3x flow control for 10/100Base-TX port
• Plug & Play, Hot Pluggable
• Diagnostic LEDs
• Optional 19” Fiber Converter Chassis (TFC-1000) holds up to 10 Fiber Converters
• 5-Year Warranty
FEATURES

Frame Packet Size
Network Media
Protocol
Minimum Cable Length
Transfer Rate
Transfer Rate
Ports
Dip Switch
Diagnostic LED
Dimensions
Power Adapter
Weight
• IEEE 802.3 10Base-T • IEEE 802.3u 100Base-TX, 100Base-FX
• Dip Switch 1: ON: TX Port Fully Duplex OFF: TX Port Auto- Negotiation
• 10Base-T: UTP/STP Cat. 3, 4, 5, EIA/TIA-568 100-ohm
• 100Base-TX: UTP/STP Cat. 5, EIA/TIA-568 100-ohm
• 100Base-FX: 9/125um Single Mode Simplex SC-Type Cable, up to 20km
• CSMA/CD
• 50 Meters
• 64 to 1600 Bytes
• 1 x 10/100Base-TX RJ-45 Port • 1 x 100Base-FX Single-Mode Bi-Directional SC-Type Fiber Port
• 100Mbps (Half/Full Duplex)
• 9V DC, 700mA External Power Adapter
• Per Device: Power
• 3.1 Watts (max)
Standard
Hardware
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
10/100Mbps-TX to 100Base-FX Dual-Wavelength Single-Mode Fiber Converter
TFC-210S20D3 (v1.0R)
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
SPECIFICATIONS
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
• Dip Switch 2: ON: FX Port Half Duplex OFF: FX Port Full Duplex
• Dip Switch 3: ON: LLCF Enable OFF: LLCF Disable
• Dip Switch 4: ON: Pure Converter Mode OFF: Switch Converter Mode
* After changing the DIP Switch settings, power cycle the Fiber converter.
• Per port (TX): 100Mbps, Link/Activity, Full Duplex/Collision; (FX): Link/Activity, Full Duplex/Collision
• 85 x 125 x 25mm (3.35 x 4.92 x 0.98in.)
• 300g (10.6oz.)
20km
TFC-210S20D3 -14 -31
Sensitivity Power Budget (dBm) Distance
Wavelength
Media Power Output (dBm)
RX:1550nm (1480nm~1600nm) 17
TX:1310nm (1260nm~1360nm)
Humidity
Temperature
Certification
• Operating : 0°C ~ 45°C (32°F ~ 113°F) • Storage : -40°C ~ 70°C (-40°F ~ 158°F)
• 5% ~ 90% RH
• CE, FCC
(Single Mode)
WDM
*The Single-Strand WDM Single-Mode Fiber Converter TFC-210S20D3 must be paired with TFC-210S20D5.
RELATED PRODUCTSPACKAGE CONTENTS
TFC-210S20D5 10/100Mbps-TX to 100Base-FX Dual-Wavelength
Single-Mode Fiber Converter
• Power Adapter
• TFC-210S20D3
• Multi-Language Quick Installation Guide
TFC-1000 10-Bay Fiber Chassis
