TRENDnet TI-F11SFP User manual

TI-F11SFP
Quick Installation Guide

Minimum Requirements
1
Package Contents
ŸTI-F11SFP
ŸQuick Installation Guide
ŸRemovable terminal block
ŸDIN-rail mount
ŸWall mount plates
1. Before You Start
ŸExisting network
ŸPower supply (TI-M6024)
2. Quick Reference
TV-IP322WI

2
3. Hardware Installation
ŸThe TI-F11SFP can be placed on a desktop, wall, or mounted to a DIN-rail.
1. Attach the DIN-rail mount bracket to the media converter.
2. Position the unit in front of the DIN-rail and hook the mount over the top
of the rail.
Mounting the unit Releasing the unit
DIN-rail Mounting Instructions
3. Rotate the media converter downward towards the rail to lock it into place.
You will know it is secure when you hear the click.
4. To remove the unit, pull down to clear the bottom of the DIN-rail and
rotate away from the rail.

3
1. Attach the wall mount plates to the media converter.
Wall Mounting Instructions
2. Mount the unit.
ŸTurn off the power before connecting any module or wire. The correct power
supply voltage (12 - 56 V DC or 18 - 36 V AC) is listed on the product label.
Check the voltage of your power source to make sure that you are using the
correct part. Do NOT use voltage greater than 12 - 56 V DC or 18 - 36 V AC,
as specified on the product label.
ŸCalculate the maximum possible current in each power wire and common
wire. Observe all electrical codes dictating the maximum current allowable
for each wire size. If the current surpasses the maximum ratings, the wiring
could overheat, causing serious damage to your equipment.
Safety Note
!

4
3. Connect your Ethernet cable, install an SFP module, and connect a fiber
cable to the media converter. Check the LEDs to confirm the connections
are established. Your installation is completed.
1. Connect the power supply (sold separately) to the included terminal block
(as shown below) and secure the screws.
Applying Power
2. Attach the terminal block to the unit, connect the neutral wire to the ground,
and supply power to the power adapter.
Note: Polarities must match.

4. Additional information
1. DIP Switch
ON: 100M
OFF: 1000M
Speed
ON: Off
OFF: Auto
SFP
Switch / Converter mode
LFP (Link Fault Pass through)
ON: Con.
OFF: SW
ON: LFP
OFF: Off
1
2
OFF
3
4
ON
5

Directives:
Low Voltage Directive 2006/95/EC
EMC Directive 2004/108/EC
RoHS Directive 2011/65/EU
REACH Regulation (EC) No. 1907/2006
TRENDnet hereby declare that the product is in compliance with the essential requirements and
other relevant provisions under our sole responsibility.
This product is herewith confirmed to comply with the Directives.
Product Information:
Product Name:
Model Number: TI-F11SFP
Trade Name: TRENDnet
Hardened Industrial 100/1000 Base-T to SFP Media Converter
Safety EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + A2: 2013
EMC
Person responsible for this declaration.
Date: August 2, 2015
Title: Director of Technology
Place of Issue: Torrance, California, USA
Name: Sonny Su
Signature:
TRENDnet, Inc.
20675 Manhattan Place
Torrance, CA 90501 USA
Manufacturer’s Name and Address
EN 55011: 2009 + A1: 2010 Class A
EN 55022: 2010 + AC: 2011 Class A
EN 61000-6-4: 2007 + A1: 2011
EN 55024: 2010
EN 61000-6-2: 2005 + AC: 2005

Limited Warranty
TRENDnet warrants its products against defects in material and workmanship, under normal use
and service. Specific warranty periods are listed on each of the respective product pages on the
TRENDnet website.
Garantie Limitée
TRENDnet garantit ses produits contre les problèmes de matériel ou de fabrication, dans des
conditions normales d'utilisation et de service. Les périodes de garanties précises sont
mentionnées sur chacun des pages produits du site web de TRENDnet.
Eingeschränkte Garantie
TRENDnet gewährt eine Garantie für seine Produkte im Falle von Material- und
Bearbeitungsdefekten, bei normaler Verwendung und Wartung. Spezielle Garantiezeiträume
werden auf jeder Produktseite auf der Website von TRENDnet genannt.
Garantía limitada
TRENDnet garantiza que sus productos carecen de defectos en el material y la fabricación, en
condiciones de uso y funcionamiento normales. Los periodos específicos de garantía figuran en
cada una de las páginas de producto del sitio web de TRENDnet.
Ограниченная гарантия
Компания TRENDnet предоставляет гарантию на свои изделия от дефектов материалов и
сборки при нормальном использовании и обслуживании. Конкретные гарантийные сроки
указаны на странице каждого продукта на сайте компании TRENDnet.
Garanzia limitata
TRENDnet garantisce i propri prodotti da difetti di materiali e manodopera, in condizioni di
normale uso ed esercizio. I periodi di garanzia specifici sono elencati sulle rispettive pagine di
prodotto sul sito TRENDnet.
Garantia Limitada
A TRENDnet garante seus produtos contra defeitos de material e mão de obra sob condições
normais de uso e serviço. Os períodos de garantia específicos estão listados em cada uma das
páginas dos respectivos produtos no site da TRENDnet.
Piiratud garantii
TRENDneti garantii hõlmab materjali- ja koostamisdefekte, mis ilmnevad toote tavapärasel
kasutamisel. Garantiiaja täpne pikkus konkretse toote puhul on leitav TRENDneti kodulehelt
vastava toote infolehelt.
