TRENDnet TPE-101I User manual

TPE-101I Power over Ethernet Injector provides an innovative and
cost effective solution to a variety of Ethernet devices such as VoIP
phones or Wireless Access Points. Reduce costs by using existing
CAT5 cable to deliver both power and data where power source is
difficult to obtain.
TPE-101I (V2.0R)
TEW-503PI (07-28-2005) TPE-101I (V2.0R)
rev:12.07.2007
• Compliant with IEEE 802.3af Power over Ethernet (PoE) Standard
• Reduce Cabling for Wireless APs, IP Phone and any IEEE 802.3af Powered Device (PD)
• Supplies Power to PD up to 15.5 Watts
• Automatically Detecting PoE Terminals and Supplying Inline Power
• Advanced Auto-Sensing Algorithm Giving Power only to 802.3af end device
• High Safety Standards with Short Circuit Protection
• Supports Power Detection and Classification
• 5-Year Warranty
FEATURES
Power over Ethernet (PoE) Injector

Network Media
Diagnostic LEDs
Protocol
Topology
Ports
Data Lines
Power Consumption
Temperature
Humidity
Weights
Certification
Dimensions (LxWxH)
• IEEE 802.3 10Base-T • IEEE802.3u 100Base-TX • IEEE 802.3af Power over Ethernet
• 10Mbps: UTP/STP Cat. 3, 4, 5; Up to 100 Meters
• Power: Green
• Storage: -40°~ 70°C (40°F~ 158°F)
• 115 x 57 x 35mm (4.5 x 2.2 x 1.4 in.)
• 100Mbps: UTP/STP Cat. 5; Up to 100 Meters
• CSMA/CD
• Star
• 1 x DATA-IN Port (Data only)
• 15.5 Watts
• 1 x PoE-OUT Port (Data + Power)
• Pair 1: Pin 1, 2
• Input: Power supply: AC 100~240V, 50~60Hz, 0.3A
• Operating: 0°~ 45°C (32°F~ 113°F)
• 10%- 90% (non-condensing)
• FCC, CE
• 325g (11.6oz.)
Power
Standards
Hardware
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
Power over Ethernet (PoE) Injector
TPE-101I (V2.0R)
RELATED PRODUCTS
PACKAGE CONTENTS
TPE-S88
TPE-102S Power over Ethernet (PoE) Splitter
• Power Adapter (48VDC, 0.5A)
16-Port 10/100Mbps Web Smart PoE Switch
• TPE-101I
• Multi-Language User's Guide
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
SPECIFICATIONS
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
• Output: Class 0, 48V DC @ 15.4 watts ; Class 1, 48V DC @ 4 watts; Class 2, 48V DC @ 7 watts ; Class 3, 48V DC @ 15.4 watts
Power over Ethernet Splitter
(TPE-102S)
Power + Data
(PoE)
5V/7.5V/9V/12V Power
Data
Power over Ethernet Injector
(TPE-101I)
Power + Data (PoE)
Power
Data
Power
5V/7.5V/9V/12V DC Power
Data
Power + Data
Non-PoE Device which uses
5V/7.5V/9V/12V Power Input
Power
Data
Power + Data
Data
Power
8-Port 10/100Mbps
Fast Ethernet Switch
(TE100-S8)
Power over Ethernet Injector
(TPE-101I)
PoE Device
8-Port 10/100Mbps
Fast Ethernet Switch
(TE100-S8)
Power
Jack
Power
Jack
• Pair 2: Pin 3, 6
