TRENDnet TEW-830MDR3K User manual

TEW-830MDR / TEW-830MDR2K / TEW-830MDR3K (V1)
Quick Installation Guide

Table of Contents
2. Hardware Installation
1 English
1. Before You Start

ENGLISH
1. Before You Start
Package Contents
TEW-830MDR
ŸWall mount screws
ŸQuick Installation Guide
ŸPower adapter (12V DC, 1.5A)
Ÿ1 x TEW-830MDR unit
ŸNetwork cable 0.5m (1.6 ft.)
ŸBroadband Internet
ŸMobile device with Android™ 7
ŸInstalled modem
Minimum Requirements
®
ŸiPhone with iOS 10
TEW-830MDR2K
Ÿ2 x Network cable 0.5m (1.6 ft.)
Package Contents
Ÿ2 x TEW-830MDR unit
ŸQuick Installation Guide
Ÿ2 x Power adapters
(12V DC, 1.5A)
ŸWall mount screws
1
Package Contents
Ÿ3 x TEW-830MDR unit
ŸQuick Installation Guide
TEW-830MDR3K
Ÿ3 x Power adapters (12V DC, 1.5A)
Ÿ3 x Network cable 0.5m (1.6 ft.)
ŸWall mount screws

ENGLISH
2. Hardware Installation
1. Connect the included network cable from the WAN port (blue) of
your router to your modem and connect the included power
adapter.
Note: If you purchased a mesh network kit with multiple units,
you can choose any of the units to set up first as the master. The
router may take up to one minute to boot up. When the router LED
changes from white to orange, this indicates that the router is
ready for setup. For the initial setup, do not power on any other
units except the single unit to be setup as master.
2
DC-IN WAN LAN USB

ENGLISH
3
3. After the app installation is complete, open the TRENDnet
Mesh app.
2. Using your mobile device, download and install the TRENDnet
Mesh mobile app by scanning the appropriate QR code below
for your mobile device.

ENGLISH
4
4. Click on the blue text link Wizard at the bottom of the screen to
start the router setup wizard and follow the steps to complete
the setup.
5. When reaching the final step, if setting up one router only, tap
Connect to TRENDnet Mesh now at the bottom of the screen
to connect to the router with the new settings and login.
Otherwise, if you are connecting additional mesh units to your
WiFi mesh network, tap Add more devices and follow the
remaining steps to add the new mesh unit to your WiFi mesh
network.
Wizard

ENGLISH
5
Note: The additional unit may take up to one minute to boot up.
When the unit LED changes from white to orange, this indicates
that the unit is ready for setup. Please make sure that the location
of the additional unit is within at least 3m (9.84 ft.) range of the
master router for initial setup.
6. When setup is completed, tap Login to access the router
management configuration.

ENGLISH
6
7. Your WiFi mesh network setup is complete.
Note: If you have more than one unit connected to your WiFi mesh
network, you can tap the additional units listed under the
Connection Status to determine if the unit is installed within
optimal range of the master router. If the range is indicated as too
far or too close, you can physically move additional units to
determine an optimal range and location through the app.

ENGLISH
7
TEW-830MDR, TEW-830MDR2K or TEW-830MDR3K within the
Product Download drop-down list.
Note: To download the latest version of the user's guide, please
go to https://www.trendnet.com/support and select the

ŸConsult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
ŸIncrease the separation between the equipment and receiver.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
ŸConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
ŸReorient or relocate the receiving antenna.
Operations in the 5.15-5.25GHz band are restricted to indoor usage only.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.

(i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour
une utilisation à l'intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes
de satellites mobiles utilisant les mêmes canaux;
This device complies with ISED's licence-exempt RSSs. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Industry Canada statement:
Avertissement:
Le présent appareil est conforme aux CNR d' ISED applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) le dispositif ne doit pas
produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y
compris un brouillage susceptible de provoquer un fonctionnement indésirable.
Caution :
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements ISED établies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé à plus de 20 cm entre le
radiateur et votre corps.
This equipment complies with ISED radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with greater than 20cm between
the radiator & your body.
(i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the
potential for harmful interference to co-channel mobile satellite systems;
(iii) lorsqu'il y a lieu, les types d'antennes (s'il y en a plusieurs), les numéros de modèle de
l'antenne et les pires angles d'inclinaison nécessaires pour rester conforme à l'exigence de la
p.i.r.e. applicable au masque d'élévation, énoncée à la section 6.2.2.3, doivent être clairement
indiqués.Radiation Exposure Statement:
(iii) where applicable, antenna type(s), antenna models(s), and worst-case tilt angle(s)
necessary to remain compliant with the e.i.r.p. elevation mask requirement set forth in section
6.2.2.3 shall be clearly indicated.
