Triarch 31742/26 User manual

ASSEMBLY INSTRUCTIONS FOR 31742-26
1. Before beginning the assembly, carefully unpack and identify all parts referring to the illustration.
2. Unravel the supply power and ground wires and pass the holes of fixture loop. Thread the fixture
loop onto the coupling at the top of fixture body. Hand tightens until snug.
3. Thread the top of stem with the hex nut into the coupling at the underside of fixture body. Hand
tightens until snug.
4. Locate the arm. Attach the arm to the fixture body and the column with ball nuts as shown in the
illustration.
5. Carefully place the glass panel onto the fixture body and secure with ball stud as shown in the
illustration.
6. Install proper bulbs (not provided) to the sockets referring to the markings and labels on fixture for
maximum wattage.
7. Locate the tube, cap A, check ring, glass, rubber washer and steel washer. Carefully pass the
center holes of tube, cap, glass, rubber washer and steel washer through the stem and secure
with hex nut.
8. Install cap B through the protruding stem and secure with finial.
9. Restore power to the installation point ON. Retain this sheet for future reference.
01.06
IF IN DOUBT ABOUT ELECTRICAL INSTALLATION,
CONSULT A LICENSED ELECTRICIAN!
Ball stud
Glass panel
Glass
Stem
Check ring
Tube
Fixture body
Ball stud
Arm
Ball stud
Column
Finial
Steel washer
Hex nut
Rubber washer
Cap A
Cap B
