Triax 120 User manual

1
GB
UFO 100, 120
digital antenna
Mounting instructions
GB
TRIAX - your ultimate connection
891020A

2
GB
UFO 100, 120
digital antenna
Connection cable and assembly
Mount UFO on base
Ensure that the
UFO shells are
fully mated with
the bracket
A: Push forward
B: Push down
Secure with enclosed screws

3
GB
Mounting options on vertical or horizontal surface
Positioning the antenna:
Assemble brackets and desk
mount.
Positioning the antenna and
mark off holes for fixing.
Prepare the plastic base for mounting of U-clamp for mast bracket
Min. 80mm
Mounting on mast.

4
GB
UFO 100, 120
digital antenna
Mounting with centre mount (UFO 120 digital)
Positioning the antenna:
Centre mounting bracket and
deckmount. Position the antenna
and mark off holes for fixing.
Positioned antenna
and counter nut fixed.
Mounting with universal mount (UFO 120 digital)

5
GB
Troubleshooting guide
Problem Possible root cause Solution
Weak or missing signal
-check LED on power supply
(PSU)
NO light indicates no voltage.
Often this is coursed by a short
or a missing connection in the
coax-cable or the cable con-
nectors
Remove the cable from the
PSU, if the LED goes ON,
there is a short in the cable.
Then repair or replace the
cable.
If the LED is still off replace
the PSU.
Weak or missing signal
-check LED on power supply
(PSU)
-check LED on UFO
NO light indicates no voltage.
Often this is coursed by a short
or a missing connection in the
coax-cable or the cable con-
nectors
If the LED is ON at the PSU,
there is probably a missing
connection in the cable or
connectors.
Repair or replace.
Interference; herring-bone pat-
tern or white horizontal stripes
in the picture.
Interference is often caused by
different electronic equipment
- mobile phones, computers
or transmitters -being used in
close proximity to the UFO.
Increase the distance – in-
crease the height of the UFO
Ghosting; double pictures Ghosting is caused by the TV
signal being reflected from
buildings, large ships etc.
Changing position a few
meters, will often solve the
problem.

6
GB
UFO 100, 120
digital antenna
Application examples
IFP 529
+ 12 V
+ 5 V

7
GB
Centre mount
Art. No. 133225
Type
Art. No.
UFO 100
Digital
109100
UFO 120
Digital
109120
Frequency range FM
VHF
UHF
MHz
MHz
MHz
87.5-108
174-230
470-862
87.5-108
174-230
470-862
Channels FM/5-12/21-69 FM/5-12/21-69
Elements pcs. 1 1
Opening angle ver./hor. deg. 90/360 90/360
Windload N 5.5 5.5
Gain dB 28 28
Noise figure dB 2.5 2.5
Max. output voltage dBµV
108 108
Supply voltage V 5-24 5-24
Power consumption mA 50 50
D i m e n s i o n s l e n g t h
width
height
mm
mm
mm
325
255
65
325
255
65
Connector F-connectors F-connectors
Included
Mast bracket Ø25-60
Plastic base
Mast bracket Ø25-60
Plastic base
Universal mount
Centre mount
Plastic base
Art. No. 133220
Mast bracket
Ø25-60
Art. No. 133223
Universal mount
Art. No. 133222
IFP 529
Power inserter
Art. No. 339529
IFP 502
Power supply
Art. No. 339502
Technical data
Accessories

8
GB
DECLARATION OF CONFORMITY
TRIAX confirms that the product conforms to relevant EEC harmonized
standards and consequently can carry CE-mark.
Relevant harmonized standards:
EN 50083 and EN 60065
06-2009
