Triax CCS-2 2001 User manual

TRIAX - your ultimate connection
A
CLASS
KLASSE
Assembly Instructions
GBArt. Nr. 325157
CCS-2 2001
Head-End Digital Modulator
HDTV / COFDM

- 2 - CCS-2 2001
Contents
1 Safety regulations and notes........................................................................4
2 General information ....................................................................................5
2.1 Packing contents............................................................................5
2.2 Meaning of the symbols used..........................................................5
2.3 Technical data...............................................................................5
2.4 Description ...................................................................................6
2.5 Software query..............................................................................7
2.6 How the TPS module works.............................................................7
Station selection ............................................................................7
Changing the Transport stream and ORGNET-ID................................7
Changing the NIT..........................................................................8
3 Assembly....................................................................................................8
3.1 Installing the cassette......................................................................8
3.2 EMC regulations............................................................................9
3.3 Overview of the cassette ..............................................................10
3.4 Connecting the cassette................................................................10
3.5 Retrofitting a CA module ..............................................................11
4 The control panel at a glance.....................................................................12
4.1 Menu items.................................................................................12
4.2 Control panel..............................................................................12
5 Programming............................................................................................13
5.1 Preparation.................................................................................13
5.2 Notes on programming via the control software .............................13
5.3 Notes on level setting...................................................................13
5.4 Programming procedure...............................................................14
5.5 Programming the cassette ............................................................16
Selecting the cassette ...................................................................16
Output signal ..............................................................................17
Output level...........................................................................17
Modulator .............................................................................17
Output parameter...................................................................17
COFDM parameters ....................................................................18
COFDM settings..........................................................................21
Bandwidth of the output signal .................................................21
Carrier modulation .................................................................21
Inverting the user signal...........................................................21

- 3 - CCS-2 2001
Transmission parameters...............................................................22
Transmission mode .................................................................22
Code rate..............................................................................22
Guard interval .......................................................................22
Transmitter identification...............................................................23
Output channel / Output frequency ...............................................24
Setting the output frequency.....................................................24
Setting the output channel........................................................24
Input parameters .........................................................................25
LNB oscillator frequency..........................................................25
Input symbol rate....................................................................26
DVB mode.............................................................................26
Setting the input frequency.......................................................27
Station selection .....................................................................28
Descrambling Stations.............................................................28
Service ID (SID)......................................................................28
Operation with a CA module........................................................31
PID monitoring .......................................................................31
CA module............................................................................31
Output data rate..........................................................................32
Transport stream ID and the ORGNET-ID.........................................33
Network Information Table (NIT)....................................................34
NIT version............................................................................35
Software update..........................................................................36
Factory reset...............................................................................37
Saving settings ............................................................................37
5.6 Programming via the control software ............................................38
Quick setup via configuration file ..................................................38
Creating/exporting a configuration file.....................................38
Importing a configuration file ...................................................40
Service-ID (SID) ...........................................................................41
6 Final procedures........................................................................................43
7 Channel and frequency tables....................................................................44

- 4 - CCS-2 2001
1 safety regulations and notes
• Assembly, installationandservicing should becarriedoutby authorised
electricians.
 • Switchofftheoperatingvoltageofthesystembeforebeginningwithassem-
bly or service work or pull out the mains plug.
 • Donotperforminstallationandserviceworkduringthunderstorms.
 • Installthesystemsoitwillnotbeabletovibrate…
 - inadust-free,dryenvironment
 - insuchamannerthatitisprotectedfrommoisture,fumes,splashingwa-
ter and dampness
- somewhere protected from direct sunlight
- not within the immediate vicinity of heat sources
- in an ambient temperature of 0 °C to +50 °C. In case of the formation of
condensation wait until the system is completely dried.
 • Ensurethatthehead-endstationisadequatelyventilated.Donotcoverthe
ventilation slots.
 • Bewareofshortcircuits
 • Noliabilityisacceptedforanydamagecausedbyfaultyconnectionsor
inappropriate handling.
 • Observetherelevantstandards,regulationsandguidelinesontheinstalla-
tion and operation of antenna systems.
 • ThestandardsIEC/EN/DINEN50083resp.IEC/EN/DINEN60728must
be observed.
 • For further information please read the assembly instructions for the head-
end station used.
• Test the software versions of the head-end station and the cassette and
update them if necessary. The current software versions can be found at
"www.triax.com".
Take action to prevent static discharge when working on the device!
Electronic devices should never be disposed of in the household rubbish. In
accordance with directive 2002/96/EC of the European Parliament and the
European Council from January 27, 2003 which addresses old electronic and
electrical devices, such devices must be disposed of at a designated collection
facility. At the end of its service life, please take your device to one of these
public collection facilities for proper disposal.

- 5 - CCS-2 2001
2 general information
2.1 PaCking Contents
1 Cassette CCS-2 2001 2 HF cables
1 Brief assembly instructions 1 CD (Montageanleitungen)
2.2 meaning of the symbols used
Important note
—> General note
 •  Performingworks
2.3 teChniCal data
The devices meet the following EU directives:
 2006/95/EC,2004/108/EC
The product fulfils the guidelines and standards for CE labelling.
Unless otherwise noted all values are specified as "typical".
HF input
Frequency range: ....................................................... 925…2150MHz
Level range: ............................................................ 60dBμV…80dBμV
Return loss: ..................................................................................> 8 dB
DVB-S modes: ............................................ QPSK 1/2 ,2/3 ,3/4 ,5/6 ,7/8
DVB-S2 modes: ...................QPSK 1/2 ,3/5 ,2/3 ,3/4 ,4/5 ,5/6 ,8/9 ,9/10
8PSK 3/5 ,2/3 ,3/4 ,5/6 ,8/9 ,9/10
Symbol rate DVB-S:.......................................... QPSK: 2…45MSymb/s
Symbol rate DVB-S2:........................................ QPSK:10…30MSymb/s
 8PSK:10…31MSymb/s
COFDM modulator
Signal processing: ......................................................... DIN EN 300744
Transmission modes: ................................................................2k,4k,8k
Types of modulation:........................................ QPSK,16QAM,64QAM
Code rates:............................................................ 1/2,2/3,3/4,5/6,7/8
Guard intervals: ......................................................... 1/4,1/8,1/16,1/32

- 6 - CCS-2 2001
HF output
Frequency range: ............................................. 42.0MHz…860.0MHz
Channels: ..........................................................C5…C12,C21…C69
Types of modulation:........................................ QPSK,16QAM,64QAM
Output level: ............................................................................. 96 dBμV
Output impedance:......................................................................... 75 Ω
Connections
SAT inputs:.............................................................................2 F sockets
HF output: ...........................................................................1 IEC socket
Connection strip (10-pin): ..................for supply voltages and control circuits
RS-232 socket: ..................................... serial interface for software update
Common Interface: ...........................several channels can be descrambled.
2.4 desCriPtion
The cassette converts services (programmes) modulated in DVB-S-/DVB-S2
standard into one outgoing COFDM modulated signal according to DIN EN
300744 for feeding into a cable network . The cassette has two SAT inputs and
one HF output. It is equipped with two channel strips (" A " and " B ")
TPS
Tuner A
Tuner B
CA Modul
Modulator HF Output
The channel strips are indicated in the head-end station display with "Bx …A"
and "Bx …B". Using one adequate CA module scrambled stations of two trans-
ponders can be descrambled . The control of the cassette takes place via the
control unit of the head-end station.
Two LEDs provide an indication of the SAT IF input signal quality based on
their colour (only when stations are selected). Additionally the quality of the
transportstreamreceivedisdisplayed("CN…").TheintegratedTPSmodule
(Transport Stream Processing) processes the data of the transport streams.
The COFDM modulated HF output signals are sent through the HF output of the
cassette to the output collector. The common output level of the channel strips
can be set at the output collector.
Software update for the operating software of the cassette is possible via satellite.

- 7 - CCS-2 2001
 Whenthehead-endstationisswitchedon,thetwo-lineLCdisplayshowsthe
software version of the control unit. To operate this cassette the software version
of the control unit must be "V 44" or higher. You can find the current operating
softwareforthecontrolunit,thesoftware"BE-Flash"andthecurrentassembly
instructions on the website "www. triax.com ".
The cassette is intended for use in CSE 3300 head-end systems.
2.5 soft ware query
Control unit
 If necessary, you can activate the indication of the software version of the
control unit manually:
 • Pressanytwokeysonthecontrolunitofthehead-endstationsimultaneously
untilthedisplaygoesdarkandthesoftwareversion,e.g."V 44" appears.
Cassette
 Thesoftwareversionofthecassette,e.g."V 44",isshowninthedisplayafter
activating the cassette (see page 16).
2.6 how the tPs module works
 After decoding QPSK or 8PSK -modulated signals, the demodulated data
streamscanbeaccessedviatheintegratedTPSmodule.Thesedatastreams,
alsocalledtransportstreams,containseveralstationsinalltheircomponents
(video,audio,dataandserviceinformation),whichcanbechangedusingthe
TPS module.
station seleCtion
 Individual stations can be selected. This reduces the data rate and, conse-
quently,theoutputsymbolrate.Additionallystationsofthedifferenttransport
streams can be assembled to a new transport stream.
Changing the transPort strea m and orgnet-id
The transport stream ID can be changed. If the stations of two transponders are
combined into one transport streams a new identification must be allocated to
realise the channel search of the settop boxes connected without mistakes.
If the ORGNET-ID is changed a new NIT must be generated.

- 8 - CCS-2 2001
Changing the nit
The transport stream contains data in the form of tables which the receiv-
ers evaluate and require for convenient use. The TPS module can adjust the
"Network Information Table" (NIT) to accommodate the new station data. The
"NIT" contains data which is required by the set-top boxes connected to the
cable network for the automatic search feature.
3 assembly
3.1 installing the Casset te
– Ensure the head-end station is mounted so it will not be able to vibrate.
Avoid,forexample,mountingthehead-endstationontoaliftshaftorany
other wall or floor construction that vibrates in a similar way.
– Before installing or changing a cassette unplug the power cable from the
mains power socket.
 • Removethefasteningscrews1of an unoccupied slot from the bracket of
the head-end station.
 • Insertthecassetteinthisslotandpushitintothehousing.
 • Alignthecassetteandapplyslightpressuretoconnectittotheconnections
of the board and the HF bus bar.
 • Fastenthecassettewiththescrews1.
0°
1
1

- 9 - CCS-2 2001
3.2 emC regulations
To comply with the current EMC regulations, it is necessary to connect the lines
leading in and out of the head-end station using cable terminals.
When mounting the cassette in a head-end station which is installed in a 19"
cabinet, make sure the connections leading in and out for the 19" cabinet are
made using cable terminals.
CLASS
KLASSE
The attenuation of shielding of the connection lines for antenna must meet the
requirements for "Class A".
 • Inserttherequirednumberofcableterminalsintheopeningsprovidedin
the head-end station or in the 19 " cabinet.
Tighten the nuts of the cable terminals until the teeth on the lock washers put under
have penetrated the exterior coating and a good connection is made between the
housing / 19" cabinet and cable terminals.

- 10 - CCS-2 2001
3.3 overview of the Casset te
2
3
5
6
4
11D-SUB socket "RS 232"
2 Slot for CA module
3 SAT input " A " (channel strip " A "
4 Status LED of input " A "
5 SAT input " B " (channel strip " B ")
6 Status LED of input " B "
The operating software of the cassette can be updated via the
9-Pin D-SUB socket "RS-232" using a PC or notebook and the
software "BE-Flash". You can find the current operating soft-
ware on the website "www.triax.com".
3.4 ConneCting the Cassette
 • ConnecttheHFconnectionstotheinputs 3(channel strip " A ") and 5
(channel strip " B ") .
