Triax SR 110 User manual

Triax SR 110
Digital Satellite Receiver
Operating Manual
305112
Copyright © Triax UK Ltd, E&EO 2008 Triax UK Ltd
Triax UK reserves the right to change or amend specifications without prior notification

2
Table of Contents
Table of Contents 2
Table of Contents continued 3
Receiver Overview 4
Remote Control 5
Layout Features 6
Foreword 7
Safety Instructions 8
Safety Instructions: Continued 9
Correct Handling of Batteries 10
Explanation of the safety instructions 11
Contents Supplied 12
Description 13
Pre-Programmed Satellites 14
Pre-Programmed Satellites Continued 15
Connecting the receiver 16
Fitting the satellite cable 17
Fitting the satellite cable Illustration 18
Scart cable connection 19
Phono / AV Cinch cable connection 20
Connection of a digital audio receiver 21
Aligning the satellite dish 21-25
Remote Control 26
Receiver 27
Screen fade-in during programme change 28
User interface on TV screen 29
Menu structure 30
Navigating through the menus 31
Channel (symbol: TV set) 32-33
49
Receiver Receiving decoder that converts the IF satellite signals
into video and audio signals.
SCART 21-pin connector to connect the TV set to the receiver.
Swap function Swap between the current and last viewed
programme.
Transponder Satellite bandwidth 27MHz wide which several digital pro-
grammes can be broadcast simultaneously on one
transponder.
VCR Abbreviation for Video Cassette Recorder.
Glossary continued
Warranty Period
This product has a 12 month guarantee from the date of purchase. In the unlikely event
of any issues during this period, please return to the installer / retailer with your proof of
purchase.

48
AC Alternating Current 230V 50Hz
DC Direct Current Voltage 13V/18V
Cinch connector Phono / AV Coaxial connector for the connection of TV
set or stereo system.
DiSEqC Digital Satellite Equipment Control
Digital system with which the receiver can control vari-
ous components of the outer unit. It is employed par-
ticularly to choose between several satellite positions
(e.g. Astra and Eutelsat).
DVB Digital Video Broadcasting
Broadcasting of digital TV programmes.
EPG Electronic Programme Guide
F-Type connector IEC60169-24(f) Satellite connector
FTA Free-to-air services
Free services that can be received without special de-
coders.
LNB Low Noise Block Converter
Converts high frequency signals from the satellite into
a lower IF frequencies 950-2150 MHz
MPEG-2 International standard for the transmission of video
signals.
Mute Key on the remote control unit to mute the sound.
OSD On Screen Display
PID ID number of a received data stream.
The PIDs ensure that a station can be received in its
entirety.
Glossary
3
Installation (symbol: satellite dish) 34
System setup (symbol: receiver) 35
System setup (symbol: receiver) Continued 36
Tools (symbol: toolbox) 37
Special function keys 38
Special function keys Continued 39
Using Fast Text Functions 40
Using Fast Text Functions Continued 41
Disassembly 42
Trouble Shooting 43
Trouble Shooting Continued 44
Technical Specifications 45
Technical Specifications Continued 46
Declaration of Conformity 47
Glossary 48
Glossary Continued 49
RF Output Channel set up 35
Table of Contents: Continued

4
Power switch
DATA
RS232
Receiver Overview: SR 110
Front of receiver
Back of receiver
ON/OFF CH + CH-
47
The manufacturer herewith declares that this product meets the
following directives and standards:
Low voltage directive 73/23/EEC
EN 60 065
European EMC Directive 89/336/EEC
EN 55 013
EN 55 020
EN 61000-3-2
EN 61000-3-3
Appliance type/Type: Digital Satellite Receiver SR 110
Declaration of Conformity

46
Power supply
Mains input voltage 100-240 V ~, 50/60 Hz
Power input approx. 10 W (operation with single LNB)
Operating temperature 0 ºC ~ +40 ºC
Storage temperature – 40 ºC ~ + 65 ºC
Technical Specification
Dear Customer,
Should you require technical assistance and in the event
that your supplier was unable to help you, please contact:
Technical Support
Triax UK
Abergorki Industrial Estate
Treorchy
Rhondda-Cynon-Taff
South Wales
CF42 6DL
Tel:[phone] + Option 5 for technical assistance
Email: tech[email protected]k
www.triax.co.uk
Manufacturer Details
5
Remote Control

6
Layout Features
NO Symbol Explanation
1 Standby Switching on and standby mode
2 0-9 Select programme directly, number input
3 FAV Display own favourites list
4 TV/ Radio Switch between TV mode and Radio mode
5 TV / SAT Switch between normal and satellite dish
6 OK In normal operation: display current programme list. In the
menu: confirm menu item
7 V- Reduce volume / Cursor movement to the left
8 Back Quit menu or menu item
9 INFO Display of the current programme’s reception data (Sat-finder
function)
10 Mute Mute sound setting
11 Timer Display Timer
12 Recall Change to the previously selected programme
13 Zoom increase picture size Freeze picture
14 CH ▲ Change to next higher programme position/Cursor movement
upwards
15 List Display TV programme listings
16 V+ Increase volume / Cursor movement to the right
17 Menu Display main menu
18 CH ▼ Change to next lower programme position / Cursor movement
downwards
19 EPG Electronic Programme Guide Now and Next
20 Text Display teletext
21 M/P Multi-picture function, display picture preview
22 Audio Change audio mode
45
Receiver
Dimensions in mm (W × D × H) 280 × 157 × 44
Weight in grams, approx. Receiver 1100 g
Remote control unit 80 g (less batteries)
Input frequency range 950 MHz ~ 2150 MHz
IF Band width 55 MHz/8 MHz (below 5MS/s)
LNB power supply 13/18 V, 0.30 A max.
Spikes overload protection
LNB control 22 KHz ± 2 KHz, 0.6 V pp ± 0.2 V
DiSEqC control Version 1.0, Version 1.2, Tone-Burst
A/B
Symbol rate 1 ~ 35 MS/s
Bit current MPEG-2 ISO/IEC 115200 Bit current
specification
Input speed Max. 15 Mbit/s
Error correction (FEC) 1/2, 2/3, 3/4, 5/6, 7/8, auto
Video MPEG-2 MP@ML
Audio MPEG -1/2 Audio layer 1 or layer 2
Height / width ratio 4:3 Letterbox, 4:3 Pan Scan, 16:9
Video resolution 720 x 576 (Pal), 720 x 480 (NTSC)
Audio mode Left, right, stereo, AC3 digital sound
Connection options
LNB IF input Type F, IEC 169-24
TV-SCART (output only) Video CVBS, Audio L, R
VCR-SCART (output and input) Video CVBS, Audio L, R
RCA (CINCH) Audio L,R
SPDIF, COAXIAL Digital audio output
Technical Specification

44
Program. place visible,
TV set showing no image
The system is not connected correctly.
Check the connection of the SCART cable.
The TV set is not in AV mode.
Switch the TV set to the appropriate AV input.
Poor picture, blocking
fault, formation of small
blocks, no sound
The aerial is not aligned precisely with the satellite.
Align your aerial more precisely. To do this, use
the
INFO key on the remote control unit.
Signal indication for the aerial alignment will be
shown.
The LNB is defective. Replace the LNB.
No picture, no sound,
signal strength present,
no signal quality.
Satellite dish is aligned with the wrong satellite.
Bad reception of: Tele5,
DSF etc.
Cordless phone causing interference (DECT stan-
dard).
Move cordless phone, use better quality satellite
cable.
The remote control unit
does not work.
Batteries discharged.
Replace batteries.
The remote control unit is aligned wrongly.
Align the remote control unit with the front of the
receiver and ensure that nothing is placed between
remote control unit and receiver.
Programme has got a
new frequency.
Delete TV channel, then carry out automatic search
run.
Trouble Shooting continued
If faulty function still cannot be corrected, please contact your dealer.
7
This operation manual helps you to use your digital receiver, called a receiver for
short:
as intended,
safely and
to the best advantage
We assume that the user of the receiver has a general knowledge of how to handle
consumer electronics equipment. Everyone who:
 fits,
 connects,
 operates,
 cleans or
 disposes of
this receiver must have taken note of the complete contents of this operating manual.
Please always keep this operating manual near the receiver.
Layout Features
Various elements of the operating manual are provided with specified layout
features. You can thus easily distinguish whether it involves
 normal text,
 itemisation, or
 a sequence of actions.
Foreword

8
Read through the safety instructions carefully, before you start
operating the receiver.
Pay attention to all warnings and information on the device and in the operating
manual.
Electrical connection
Disconnect the receiver from the mains socket if there is an operating malfunction.
Note: in spite of turning off the power switch on the back, the receiver is still powered
up.
To avoid the risk of fire and of an electric shock, do not expose the receiver either to
rain or Other humidity.
Never open the housing. Otherwise there is the risk of an electric shock.
Only connect the receiver to a professionally installed 100-240V, 50-60 Hz mains
power socket.
The total LNB power consumption must not exceed 300 mA.
Disconnect from mains supply when not in use for a long period of time.
During thunderstorms disconnect the mains plug of the receiver from the power
socket.
If foreign bodies or liquid should get into the receiver, disconnect the mains plug from
the power socket immediately.
Safety Instructions
43
Trouble Shooting
Symptom Possible cause and remedy
Can't find satellite, or no
signal
Example: ASTRA 19E
Key 1 (Pre-programming: "The First“)
INFO key ("The First“, FR11837)
Both signal AND quality are 0 %
Align vertical mirror to the south.
Turn a few millimetres to the left, wait about 3
seconds, then repeat until both signal AND quality
are shown.
With a signal of about 60 %, the black background will
disappear, and a TV image will appear.
For a different satellite, please select a current pro-
gramme from the pre-programmed channel list, then
press the INFO key.
Front display dark,
no clock time visible
Power cable not connected.
Connect the power cable to the mains socket.
Switch on main switch.
Short circuit at the aerial supply possible: Check
connections.
Clock time visible Receiver is in standby mode.
Press the POWER key on the remote control unit (or
on the receiver). The receiver will switch on and the
programme will be shown on the TV screen.
No sound or picture, but
menu displays of the
receiver present.
The aerial is not aligned with the satellite.
Align your Satellite Dish
No signal (with symbol).
Check the cable connection from LNB to
receiver and from receiver to the connected units.
Align your Satellite Dish.

42
 Separate the receiver and the connected units from the power supply.
 Unscrew the LNB cable from the receiver.
 Remove the batteries from the remote control unit if you are not going to use
the receiver for quite some time.
 Pack the receiver, the cables and the remote control unit in the carton.
 Store the receiver and all accessories in a dry and dust-free place.
 Protect the receiver against frost.
Disassembly
Cleaning
Clean the receiver housing only with a dry cloth.
Caution!
The receiver must never get wet. Never clean it with a wet cloth. Do not use any
cleaning products containing solvents, these can damage the surface of the
housing.
9
Safety Instructions Continued
Do not kink or crush the power cable. If the power cable is damaged, you must get the
receiver repaired by qualified competent person before using it again. Otherwise there is
a risk of an electric shock.
Never let children tamper with the receiver.
Always have servicing work done by qualified competent person.
Correct Location
Place the receiver on a solid, flat support.
Avoid the proximity of:
Heat sources
Naked flames
Appliances with a strong magnetic field
Do not place containers with liquid in them on the receiver.
Avoid direct sunlight and places with unusually high amounts of dust.
Never cover up the ventilation slots. Make sure the receiver has sufficient ventilation.
Do not put any heavy objects on the receiver.
When you bring the receiver out of a cold into a warm environment, condensation may
be formed inside the device. In this case wait about one hour before operating it.

10
Keep out of reach of Children.
Batteries can contain toxins.
Leaking batteries can cause damage to the remote control. If the receiver is not used
for a long time, take the batteries out of the remote control.
Batteries may contain toxins that damage the environment. For this reason, it is
absolutely essential that you dispose of the batteries in accordance with the legal
provisions that are in force in your country at the time. Never throw batteries away in
your normal household refuse.
Under no circumstance throw the receiver and batteries away in the normal household
refuse. This a requirement of the WEEE directive.
Correct Handling of Batteries
41
RECALL
When pressing the RECALL key, you will switch back to the previously chosen programme.
Via Info key: Acoustic signal for aligning the satellite aerial.
Press the INFO key for this purpose. Besides the current reception parameters, you will also be shown
signal strength and signal quality. In addition, you can activate an acoustic signal using the 1 key.
A signal tone will be output via the TV set. The louder and higher the signal, the better the dish is
aligned.
Via 0 key: Sleep timer
During normal operation, you can access the sleep timer via the 0 key (zero key). The following settings are
available: switched off, 10, 30, 60, 90, 120 minutes. After this time, the receiver will be switched off auto-
matically.
Pause
Press the PAUSE key for this purpose. The TV image will be "frozen". Press the PAUSE key again to de-
activate this feature.
Using Fast text Functions continued

40
The coloured keys on the remote control unit are used for Fast text and will become
active after calling up a further Teletext page. You can navigate there directly via the
small coloured keys on the remote control unit.
 Press the desired key.
M/P Multipicture
Please press the M/P key in order to access Multipicture mode. On your screen will
now appear 9 programmes in parallel, starting with the current programme.
You can navigate the yellow marking using the keys CH▼, CH▲, V+ and V-. The
marked programme is in real time, the non-marked programmes show only still pic-
tures.
In order to activate the desired programme, you mark it and then press the OK key or
the EXIT key.
When pressing the EXIT key, you leave the Multipicture mode. The programme that
was marked last will appear as a full image on your screen.
MUTE
When pressing the MUTE key, the sound is switched off. When pressing the MUTE
key again, the sound is switched on again.
FAV
 Press the FAV key.
On the screen will appear your specified favourites (see above).
 Select a programme from your list of favourites.
 To select, press the OK key.
 Using the V+ and V - keys, you can switch between the
programme groups.
Using Fast text Functions
11
In the operating manual you will find the following categories of safety instructions:
Danger!
Instructions with the word DANGER warn you of possible personal injury.
Caution!
Instructions with the word CAUTION warn you of possible damage
to property or the environment.
These instructions contain special information for economical use of the receiver.
Use as Intended
The receiver is used for receiving unencrypted digital satellite programmes (free-to-
air). It is exclusively intended for this purpose and may only be used for this. This also
includes adherence to all information in this operating manual, in particular the safety
instructions.
Any other use is deemed to be not as intended and can lead to damage to property or
even personal injury. In addition it means the immediate
invalidation of the warranty.
The manufacturer accepts no liability for damage which arises from use which is not
as intended.
Explanation of the Safety Instructions

12
Use double Screened Benchmark cable Such as TX100 on the installation to ensure good
signal levels and minimise local interference which could cause freeze framing and pixilation.
No. Quantity Explanation
11 Receiver
21 Remote control
32 Batteries – type LR 03/AAA/1.5 V
41 Scart Lead
-1 Operating manual (not shown)
Contents Supplied
39
AUDIO
Using the audio key, you can select the sound track if a station offers multi-channel
sound. Furthermore, here you can activate the Dolby Digital mode (for which you will
need additionally a Dolby Digital system; the connection is made at the rear of the unit
via the COAXIAL socket).
EPG
Electronic Programme Guide. Please press the EPG key to activate this function. The
programme list will appear.
Using the CH▲ and CH▼ keys, you can choose a programme. On the right-hand
side, the current and following programme is indicated. Now and Next
TEXT
Teletext is an information system which displays teletext on your TV set. In order
to receive Teletext, the selected station must support this function. When chang-
ing programmes, the TXT symbol will be displayed. In order to switch on Teletext,
press the TEXT key.
 If you want to switch off Teletext, press either the EXIT or the TEXT key.
Special Function Keys: continued

38
Switching between TV and SAT
Using the "TV/SAT“ key, you can switch between TV function and
Satellite function.
However. This function must be available on your TV set.
 Press the "TV/SAT“ key repeatedly, until the desired function is achieved.
Switching between TV and Radio
Using the key TV/Radio, you can switch between TV function and DVB-Radio
function.
The receiver is now transmitting a radio programme and displaying a background
image.
 In order to switch back to the TV programme, press the TV/Radio key on the
remote control unit.
ZOOM
You can enlarge an image section using the zoom function.
 Press the ZOOM key twice.
 You can select the image section using the keys
CH▼, CH▲, V- and V+.
Every time you press the ZOOM key, the image section will be enlarged in maximum 6
stages. When you press the key for a seventh time, the image returns to its original
size. You can leave this mode using the EXIT key.
LIST
Press the "LIST" key once.
As already described above under the menu item "Programme", you have the
opportunity here to edit the programme list.
Special Function Keys
13
With the receiver you can receive unencrypted digital satellite
programmes (free-to-air) via a satellite dish.
You do not need to programme the receiver for the time being. The most important
broadcasters and satellites are pre-programmed.
The satellite dish must be aligned to the desired satellite.
The receiver searches for additional new programmes as soon as you launch the
automatic transmitter scan for this satellite. Satellites that are not pre-programmed can
be added.
You can easily carry out all receiver settings via the user interface (menu) on the TV
screen.
The multilingual user interface supports the following languages:
German Greek Croatian
Czech Danish Dutch
Hungarian Norwegian Polish
Slovakian Swedish English
French Turkish Spanish
Slovenian Italian Portuguese
Finnish
Description

14
Further Setting Characteristics:
Software update via the RS 232 port on the back of the device
Short switch-over time, fast booting process when switching on
Saving of the last programme viewed (Last Station Memory)
Fully compatible with MPEG-2 and DVB
MPEG-„-Video (MP@ML), MPEG-1 Audio Layer 1, Layer 2
LNB control 13/18V (Tone 0/22 kHz), max. LNB 300mA
Symbol rate 1–35 Mb/s and frequency input 950–2150 MHz
Manual PID input possible
3 operating buttons on the front panel
Plug and Play
Power consumption in standby mode sensationally around 2 watts.
1 favourites list and 8 programme groups
Automatic transmitter scan
Transmitter list editor
Analogue sound output via Phono / AV Cinch plug (stereo), volume control via remote
control possible
AC 3 coaxial output (digital audio, SPDIF)
2 Euro SCART connections, for TV and video recorder (VCR)
CVBS video output signal
Astra1 19E Türksat 42 E Sirius2 5E
Amos/Atlantic 4-5W Astra/Eurobird. 28E HispaSat 30W
Eutel W2 16E HellaSat 39E Astra 23.5E
Hotbird 13E
Pre-programmed Satellites:
37
Tools (Symbol: Toolbox)
Sub Menu Description
Factory Reset Password required, All settings are default back to Factory
settings if the receiver is reset.
Note* By pressing and holding the standby button down for 10
seconds the receiver will default back to Factory settings,
all personal settings will be lost.
Software Update Software upgrade is a service function and can only be
done by using the RS232 connector on the back of the
receiver.
Games The receiver has 3 pre-programmed games
Information Displays the latest hardware and software version.

36
In order to avoid damage to the satellite system, the LNB voltage shall always be
switched off in single cable systems.
Timer Setting Table
Sub Menu Description
Timer Number Selection of Timer Number 1-8
Timer Mode Type of repetition (once, daily, weekly, monthly, yearly, off).
If set to “OFF” the timer is de-activated
Wake Up Channel If Timer-service setting is “massage” The following selection
options are available:Birthday, Anniversary, General
Timer Service Switch between the functions programme timer and
memory
Wake Up Date Input Date
On Time Input Time
Duration Duration of switch-on time
Load default
OSD setting
OSD factory setting can
be restored.
Parental Lock Factory Password is 0000 (Password settings)
Installation lock Switching password input on/off in the main
menu item Installation.
Channel lock Switching password input on/off for locked
programmes
(child protection)
New password Determining a new password
(new password must be remembered)
Confirm Password Confirm Password
LNB power Switching LNB-power supply on and off. Preset is ON.
System Setup Symbol: Receiver Continued
15
In standby mode loop-through function for connecting an analogue receiver
Superfast videotext with an 800-page memory
Digital DVB radio reception, radio background display
When changing programmes you get further programme information in a display.
DiSEqC 1.0, 1.2, Goto X, is supported, if appropriate aerial installations are connected
SWAP function (via recall button)
Screen formats can be set at 4:3, 16:9 and automatic (letterbox)
Multi-function timer, 8-fold and coupled to EPG, sleep-timer
Electronic Programme Guide (EPG) (Now and Next)
SCPC/MCPC reception standard C/Ku band satellites
Automatic selection of the television standard with video converter
Digital sat-finder optical + acoustic for alignment of the dish.
In addition you can process the programme lists of the receiver with an appropri-
ate programme editor using your computer. Please adhere to the information on
our home page for doing this.
Pre-programmed Satellites: Continued

16
The receiver is connected to your satellite dish via pre-installed satellite cable.
It is recommended that the satellite cable is installed by a qualified
competent person.
Do not connect the receiver to the mains power supply until you have connected it
properly to all devices and to the dish. Otherwise the receiver may be damaged.
The braiding and the inner conductor of the coaxial cable carry electrical current
during operation.
Connecting the Digital Satellite Receiver
35
System Setup Symbol: Receiver
Submenu Description
Audio Language
First audio Pre-selection of audio language (if offered by
station)
Second audio Pre-selection of audio language (if offered by
station)
TV System
Display mode Selection of transmission system
Standard selection: Auto
Aspect mode Selection of image format
Standard selection: Auto
Video Output Only the video signal CVBS is offered
Dolby Digital Only if the receiver is connected to a digital
amplifier via the co-axial digital audio output
will you activate this function.
RF System PAL I, fully agile CH 21– CH68
Channel Setup Start-up channel Switch on and off, determination of the desired
TV or radio switch-on programme.
Time & Timer setting Time Possibility of time and time zone
input. (see example: Receiver
to Summer Time.
Timer See following table
OSD setting Subtitle display Activating subtitle
OSD timeout Menu fade-in time during switchover
in seconds (OSD time lock)
OSD
transparency
Menu transparency
Setting up RF output Channel
Select the RF output channel number with V+ or V- keys. Fully agile C21 to C69.
The default RF output channel is CH38 (PAL BG) UK uses Select PAL I,
System /TV System,RF System - PAL BG press V+ or V- keys to change to PAL I
Back to Exit

34
Installation Symbol: Satellite Dish
Submenu Description
Satellite Satellite selection, Example: Astra1 19° East)
LNB type Select LNB type (Standard setting is Universal)
22 KHz Activating 22 KHz Note: with LNB type Universal the
activation is automatic
DiSEqC Select DiSEqC level
DiSEqC
Switch
Select DiSEqC command
Example:
Astra and Hotbird double reception
Astra = 1 / 4
Hotbird = 2/ 4
Deactivate for controlling the motor (invalid)
Positioner You can access the DiSEqC motor control menu via
the OK key. Please consult the operating guide of
your DiSEqC motor.
Polarity Horizontal, Vertical, H/V (Automatic)
TP Scan (manual
channel search run)
With this search function, you can search the pre-set frequen-
cies (transponder) individually. The transponder data can be
changed manually.
This process is started using "Search".
Preset Scan Searching through pre-programmed frequencies (transponder).
(Normal automatic search run)
Auto Scan
(unique function, can
be carried out without
any prior knowledge),
Here, you can search completely through a selected satellite
(example:Astra1 19° East) for new programmes. No particular
details are required for this. You can choose to search for free or
all TV and radio programmes.
This process is started using "Search".
Particularly recommended for Türksat
17
Satellite Cable fitting Instructions
Fitting the Satellite Cable
(Assembly diagram on the following page)
For fitting the F-connector onto the coaxial cable you need wire strippers and
wire-cutting pliers.
Cut 8 mm of coaxial cable at each end down to the inner core.
Carefully strip 10 mm of the outer insulation off, so that the braiding is free.
Push the braiding back over the outer insulation, so that it is not
touching the inner wire.
Remove the inner dielectric up to 2 mm in front of the braiding
Twist the F-connector onto the braiding, until the connector comes up against the
inner insulation.
There must be no braiding overlapping at the back of the connector end.
Shorten the inner core with wire-cutting pliers, so that it protrudes a maximum of 1 mm
out of the connector.

18
F-Type Connector fitting Instructions
Screw the F-connector of the coaxial cable onto the “LNB IN” connection on the
receiver. The other end of the coaxial cable should be firmly screwed onto the LNB.
33
1: Delete
Using the 1 key, selected stations can be marked for deletion. Please confirm
selection using the OK key.
2 :Skip
Using the 2 key, selected stations can be marked for jumping. Please confirm
selection using the OK key. Selected stations will then be jumped during zapping
(channel hopping). Direct input will still be possible.
3 :Lock
Using the 3 key, selected stations can be marked for locking. Please confirm selection
using the OK key. Selected stations will then require a password (protection of
children).
4: Create
You can get into edit mode via the 4 key. Here, you can change individual parameters
as you like. Please confirm selection using the OK key.
5: Edit
You can get into the New Input mode via the 5 key. By directly inputting a frequency
and the PID, you can enter a new programme.
6: Delete All
Using the 6 key, all stations can be marked for deletion. Thereafter, individual
programmes can be removed from the selection using the 1 key. Please confirm se-
lection using the OK key.
Type (Programme group)
Here, you can allocate selected programmes to certain programme groups (types) as
you like. Please confirm selection using the OK key. You can leave the menu by
pressing the EXIT key.
Channel:Symbol TV set continued

32
Channel:Symbol TV set
Submenu Description
1Favourite, 2Move, 3Find, 4Sort, 5Edit,
6 Type, ▲▼Select, -- Group, OK Enter,
BACK
Radio Channel List As Above
TV Channel List
Delete all Deleting the whole programme list.
To do so: Input password (Factory setting 0000) and confirm warning message query
with Yes.
1:Favourite
You determine your Favourite by pressing the 1 key. Next to the relevant pro-
grammes, a heart symbol will appear.
2:Move
When the 2 key is pressed, the Shift symbol appears behind the marked programme.
Using the CH+ and CH- keys, the programme is moved to the required location. The
action must be confirmed with OK.
3:Find
Programme Search function. Stations can be found selectively by entering alphabetic
characters on the OSD keyboard.
4:Sort
Sorting the complete programme list according to options on offer. The list must be
confirmed with OK. As long as nothing has been confirmed, the last status before
confirmation can be recalled using "New Calculation".
5:Edit
After inputting the password (Factory setting 0000), new
selection options appear.
19
Connection with SCART Cable
Connection with a SCART cable
Plug the SCART cable into the “TV” SCART socket on the receiver.
Connect the SCART cable to the TV set. Follow the operating instructions of the TV
set.
If you wish to connect a video recorder, plug a SCART cable into the “VCR” SCART
socket on the receiver. Follow the operating instructions of the video recorder.
The SCART cable is included in the package supplied.
Connection Diagram

20
If you wish to connect a stereo system, connect the Phono AV
connector with the “AUDIO R” and “AUDIO L” sockets of the receiver.
Connection of a Digital Audio Receiver
If you want to use the 5-channel audio transmission (Dolby Digital Sound/AC3), you
must connect your digital audio receiver with the coaxial output of the receiver.
Caution!
Adhere absolutely to the information for connection in the operating
manual of your digital audio receiver/amplifier.
Caution!
Never connect the Phono input of your stereo system with the receiver, which
can destroy your stereo system.
Adhere absolutely to the information for connection of a cinch cable in the
Connection with Phono / AV Cinch Cable
31
You can navigate through the menus using the keys CH+, CH-, V+, V-. The chosen
menu items will be marked. Selection is via the OK key. You can leave the menu
using the EXIT key. Any changes must also be confirmed. Additionally, the numeric
keypad is required for further
submenus.
In every menu, you will be shown at the bottom a Notes line which also offers all
selection options.
Example: Set Receiver to Summer Time.
Key MENU, select System Settings, select Time & Timer Settings, OK key, select
Display Time, OK key. Under the point GMT, set Shift "GMT+02:00“. Leave the menu
using the EXIT key.
Settings for Central Europe:
Summertime: GMT+02:00
Wintertime: GMT+01:00
Navigating through the menus
