Trillium FLOWAY Owner's manual

Document Name: 2001299-VTP-IOM-EN
Revision 3 Issue Date: December 12, 2014
FLOWAY® PUMPS
Vertical Turbine Pumps
Vertical Turbine Pumps
Installation, Operation, & Maintenance Manual
Copyright © 2014, Weir Floway, Inc.
Floway is a registered trademark of Weir Floway, Inc.
Weir Floway, Inc. (“the Company”) is the owner of the copyright and all confidential information in this
document. The document may contain information that is private, confidential or privileged. The document
must not be copied in whole or in part, in any form or by any means, and the information in it must not be
disclosed to any person, or used for any purpose other than the specific purpose for which it has been
provided, without the prior written consent of the Company.
Vertical Turbine Pumps
2001299 - VTP- IOM
“Copyright © 2019, Trillium Pumps USA, Inc.
Trillium Pumps USA, Inc. (“the Company”) is the owner of the copyright and condential information in this document. The document may contain information that is private, condential or
privileged. The document must not be copied in whole or part, in any form or by any means, and the information in it must not be disclosed to any person, or used for any other purpose other
than the specic purpose for which it is provided, without the prior consent of the company”.
INSTRUCTION MANUAL FOR
INSTALLATION, OPERATION AND MAINTENANCE
AND LIST OF PARTS
Vertical Turbine Pumps
2001299 - VTP- IOM
“Copyright © 2019, Trillium Pumps USA, Inc.
Trillium Pumps USA, Inc. (“the Company”) is the owner of the copyright and condential information in this document. The document may contain information that is private, condential or
privileged. The document must not be copied in whole or part, in any form or by any means, and the information in it must not be disclosed to any person, or used for any other purpose other
than the specic purpose for which it is provided, without the prior consent of the company”.
INSTRUCTION MANUAL FOR
INSTALLATION, OPERATION AND MAINTENANCE
AND LIST OF PARTS

II |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
II | IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Document Name: 2001299-VTP-IOM-EN Page i
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
FLOWAY® PUMPS
Vertical Turbine Pumps
Vertical Turbine Pumps
Installation, Operation, & Maintenance Manual
Revision Page
Revision Description Reviewed By Approved By Date
0 Initial Release - - -
1ERCO-1001843 DEB AW July 11, 2014
2ERCO-1002047 DEB ASP October 3, 2014
3ERCO-1002197 DEB FW December 12, 2014
4ERCO-1005648 SC DEB February 20, 2020
5ERCO-1005802 SC DEB May 13, 2020

III |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
III |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Document Name: 2001299-VTP-IOM-EN Page ii
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
Vertical Turbine Pumps
Table of Contents
1 Introduction ............................................................................................................................... 1
1.1 Scope of the Manual ........................................................................................................................................ 1
1.2 Intended Audience ........................................................................................................................................... 1
1.3 Disclaimer ........................................................................................................................................................ 1
1.4 Contact Information.......................................................................................................................................... 1
1.5 Glossary of Acronyms ..................................................................................................................................... 2
2 Safety.......................................................................................................................................... 3
2.1 Safety Symbols ............................................................................................................................................... 4
2.2 Mandatory Personal Protective Equipment ..................................................................................................... 4
2.3 Important Information....................................................................................................................................... 4
2.4 Intended Use.................................................................................................................................................... 7
2.5 Qualified Workers ............................................................................................................................................ 7
2.6 Markings and Approvals ................................................................................................................................. 8
2.7 Safety Equipment for the Pump ....................................................................................................................... 8
2.8 Fire Fighting ..................................................................................................................................................... 8
2.9 Emergency Procedures ................................................................................................................................... 8
3 General Information and Description ...................................................................................... 9
3.1 General Information ......................................................................................................................................... 9
3.2 Identification..................................................................................................................................................... 9
3.3 General Description ......................................................................................................................................... 9
3.3.1 Drivers ..........................................................................................................................................11
3.3.2 Discharge Head Assembly ...........................................................................................................11
3.3.3 Column Assemblies......................................................................................................................11
3.3.4 Bowl Assemblies ..........................................................................................................................11
3.3.5 Suction Vessel ..............................................................................................................................11
4 Pre-installation ........................................................................................................................ 12
4.1 Receiving and Unloading ............................................................................................................................... 12
4.2 Storage........................................................................................................................................................... 12
4.3 Uncrating and Cleaning ................................................................................................................................. 13
4.4 Lifting ............................................................................................................................................................ 13
4.4.1 Lifting Pump Components and Pump Assemblies....................................................................... 14
4.5 Installation Equipment and Tools ................................................................................................................... 17
4.6 Pre-installation Check List ............................................................................................................................. 17
5 Installation ............................................................................................................................... 19
5.1 General .......................................................................................................................................................... 19
5.2 Foundation ..................................................................................................................................................... 19
5.3 Suction Barrel Installation .............................................................................................................................. 20
5.4 Vertical Turbine Pump Installation for Wet Pit (Type VS1) ............................................................................. 20
5.5 Vertical Turbine Can Pump Installation (Type VS6) ....................................................................................... 22
5.6 Hollow Shaft Driver Installation ...................................................................................................................... 24
5.7 Solid Shaft Driver Installation......................................................................................................................... 27
5.8 Impeller Adjustment - General ....................................................................................................................... 29

IV |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
IV |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Document Name: 2001299-VTP-IOM-EN Page iii
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
Vertical Turbine Pumps
5.9 Impeller Adjustment - Hollow Shaft Driver ..................................................................................................... 31
5.10 Impeller Adjustment - Solid Shaft Driver (thrust bearing in driver)................................................................. 32
5.10.1 Adjustable Flanged Couplings..................................................................................................... 32
5.11 Impeller Adjustment - Solid Shaft Driver (thrust bearing in pump)................................................................. 32
5.12 Mechanical Seal............................................................................................................................................. 33
5.13 Packing Boxes ............................................................................................................................................... 33
5.14 Enclosing Tube Tension................................................................................................................................. 33
6 Commissioning and Operation .............................................................................................. 34
6.1 Pre-starting Checks ....................................................................................................................................... 35
6.2 Initial Start-up ................................................................................................................................................ 36
6.3 Packing Box Adjustment ............................................................................................................................... 36
6.4 Lineshaft Lubrication...................................................................................................................................... 37
7 Maintenance ............................................................................................................................ 39
7.1 Periodic Inspection, Condition Monitoring, and Preventative Maintenance ................................................... 39
7.2 Packing Box Maintenance ............................................................................................................................. 40
7.2.1 Packing Box Greasing ................................................................................................................. 40
7.2.2 Replacing the Packing................................................................................................................. 40
7.3 Start-up with New Packing ............................................................................................................................. 41
7.4 Auxiliary Packing Box Maintenance............................................................................................................... 41
7.5 Mechanical Seal Maintenance ...................................................................................................................... 42
7.6 Impeller Readjustment ................................................................................................................................... 42
7.7 Pump Lubrication ........................................................................................................................................... 44
7.8 Driver and Auxiliary Equipment Maintenance ................................................................................................ 44
8 Repairs .................................................................................................................................... 45
8.1 General .......................................................................................................................................................... 45
8.2 Equipment and Tools ..................................................................................................................................... 46
8.3 Packing Box Repairs...................................................................................................................................... 46
8.4 Mechanical Seal Repairs ............................................................................................................................... 46
8.5 Disassembly................................................................................................................................................... 46
8.6 Inspection and Cleaning ................................................................................................................................ 49
8.7 Replacement Parts ........................................................................................................................................ 50
8.8 Lubrication ..................................................................................................................................................... 50
8.9 Assembly ....................................................................................................................................................... 51
8.10 Tension Nut Assembly and Adjustment ......................................................................................................... 52
9 Decommissioning and Disposal ............................................................................................ 53
10 Troubleshooting ...................................................................................................................... 55
11 Parts ........................................................................................................................................ 57
11.1 Ordering Parts................................................................................................................................................ 57
11.2 Stocking Spare Parts...................................................................................................................................... 57
11.3 Returning Parts .............................................................................................................................................. 57
12 Parts List ................................................................................................................................. 58

V |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
V |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Document Name: 2001299-VTP-IOM-EN Page iv
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
Vertical Turbine Pumps
List of Figures
Figure 3-1:Major VTP Components................................................................................................................................ 10
Figure 4-1:Lifting Pumps from Horizontal to Vertical Position ........................................................................................ 15
Figure 4-2:Fabricated Head Lifting................................................................................................................................. 16
Figure 4-3:Cast Head Lifting .......................................................................................................................................... 16
Figure 4-4:Typical Clamping Fixture .............................................................................................................................. 16
Figure 4-5:Shaft Locking Plate ...................................................................................................................................... 18
Figure 5-1:Recommended Anchor Bolt Arrangement .................................................................................................... 20
Figure 5-2:Suction and Discharge Identification - Type VC Discharge Head................................................................. 23
Figure 5-3:Motor Guide Bushing Location ..................................................................................................................... 25
Figure 5-4:Hollow Shaft Driver Clutch ............................................................................................................................ 26
Figure 5-5:Driver Half Coupling Correctly Positioned..................................................................................................... 28
Figure 5-6:Types of Impellers......................................................................................................................................... 30
Figure 5-7:Adjustable Flanged Coupling for Solid Shaft Drivers .................................................................................... 32
Figure 7-1:Effect of Adjusting Semi-open Impellers....................................................................................................... 43
Figure 8-1:Correct Positioning of Wrenches on Shafting ............................................................................................... 48
Figure 8-2:Enclosing Tube and Lineshaft....................................................................................................................... 49
Figure 8-3:Tension Nut Assembly .................................................................................................................................. 52
Figure 12-1:Adjustable Flanged Coupling ...................................................................................................................... 58
Figure 12-2:Type A - Enclosed Lineshaft ....................................................................................................................... 59
Figure 12-3:Type CF - Open Lineshaft........................................................................................................................... 60
Figure 12-4:Type F and VF - Open Lineshaft................................................................................................................. 61
Figure 12-5:Type AF - Open Lineshaft ........................................................................................................................... 62
Figure 12-6:Type A - Open Lineshaft ............................................................................................................................. 63
Figure 12-7:Type VU - Enclosed Lineshaft..................................................................................................................... 64
Figure 12-8:Injection Lubrication Arrangement .............................................................................................................. 65
Figure 12-9:Type VC ...................................................................................................................................................... 66
Figure 12-10:Type VC .................................................................................................................................................... 67

VI |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
VI |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Document Name: 2001299-VTP-IOM-EN Page v
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
Vertical Turbine Pumps
List of Tables
Table 1-1:Acronyms ......................................................................................................................................................... 2
Table 2-1:Safety Symbols ................................................................................................................................................ 4
Table 2-2:Personal Protective Equipment ........................................................................................................................ 4
Table 5-1:Shaft Diameter Turns ..................................................................................................................................... 31
Table 6-1:Recommended Lineshaft Oil .......................................................................................................................... 37
Table 6-2:Recommended Lineshaft Oil .......................................................................................................................... 37
Table 6-3:Recommended Greases ................................................................................................................................ 38
Table 7-1:Standard Type Box ......................................................................................................................................... 40
Table 7-2:Hi-pressure Type Box..................................................................................................................................... 41
Table 8-1:Recommended Torque Values for Typical Fasteners.................................................................................... 51
Table 10-1:Troubleshooting Chart .................................................................................................................................. 55

1 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
1 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
1 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps Introduction
Document Name: 2001299-VTP-IOM-EN Page 1 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
1 Introduction
This IOM manual must be read thoroughly before installing or operating the pump. All instructions regarding
maintenance must be retained for reference.
The descriptions and instructions included in this manual cover the basic design of the equipment and
common deviations when possible. This manual does not cover all design details and variations nor does it
provide for every possible contingency which may be encountered. When information cannot be found in this
book, contact the nearest representative.
Do not operate this equipment other than in accordance with the instructions contained in this manual. This
equipment (or a prototype) has been shop tested and found satisfactory for the conditions for which it was
sold.
This equipment is capable of extended trouble-free operation when properly applied, installed and
maintained. These instructions present the basic information and methods required for proper installation,
operation and maintenance of vertical turbine pumps.
1.1 Scope of the Manual
This manual describes the installation, operation, and maintenance of Vertical Turbine Pumps. The
manual must be used as a reference only, in conjunction with any Trillium Pumps USA product-specific
information and training.
1.2 Intended Audience
This manual is intended for:
•Trillium Pumps USA service personnel.
• Personnel who have at least a basic level of trade/professional competency.
1.3 Disclaimer
Contact your local Trillium Pumps USA representative for any assistance.
• This manual provides basic information about the product. The product purchased may contain
equipment variations to this manual.
• Operating conditions specified in the manual may vary to the operating conditions of the product
installed on-site.
• Illustrations shown in the manual are for reference only and may not match the specific product.
1.4 Contact Information
Contact your local Trillium Pumps USA representative for any assistance or visit www.trilliumflow.com
WARNING
PERSONNEL INJURY
The pump must be installed, operated, and maintained only by personnel who are trained
and have sufficient knowledge about the hazards that may occur during pump operation.

2 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
2 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
2 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps Introduction
Document Name: 2001299-VTP-IOM-EN Page 2 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
1.5 Glossary of Acronyms
Acronym Description
ATEX Equipment for Potentially Explosive Atmospheres
EMC Electromagnetic Compatibility
ID Inside Diameter
IOM Installation, Operation, & Maintenance
ISO International Organization for Standardization
LOTO Lockout Tagout
MAWP Maximum Allowable Working Pressure
NPSHR Net Positive Suction Head Requirement
OD Outside Diameter
OEM Original Equipment Manufacturer
PED Pressure Equipment Directive
PPE Personal Protective Equipment
RMA Returned Material Authorization
SDS Safety Data Sheets
TIR Total Indicator Reading
TPI Threads Per Inch
VTP Vertical Turbine Pump
Table 1-1: Acronyms

3 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
3 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
3 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps Safety
Document Name: 2001299-VTP-IOM-EN Page 3 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
2 Safety
Legal requirements and local regulations may differ substantially with regard to particular safety requirements
and may be regularly modified by relevant authorities without notice. As a consequence, applicable laws and
regulations must be consulted to ensure compliance. The following cannot be guaranteed for its
completeness or continuing accuracy.
These instructions are intended to facilitate familiarisation with the product and its permitted use. Operating
the product in compliance with these instructions is important to help ensure reliability in service and avoid
risks. The instructions may not take into account local regulations. It is the responsibility of the purchaser of
the product to ensure such regulations are observed by all, including those installing the product. Always
coordinate repair activities with operations personnel and follow all plant safety requirements, applicable
workplace health and safety laws and regulations.
These instructions must be read prior to installing, operating, using and maintaining the equipment in any
region, worldwide. The equipment must not be put into service, until as a minimum, all the conditions relating
to workplace health and safety in the instructions, are met.
Information in these user instructions is believed to be reliable. In spite of all the efforts to provide correct and
necessary information, the content of this manual may appear insufficient and is not guaranteed as to its
completeness or accuracy.
DANGER
DANGER
Study this instruction manual carefully. Failure to follow the instructions can cause serious
personal injury, death, or property damage.

4 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
4 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
4 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps Safety
Document Name: 2001299-VTP-IOM-EN Page 4 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
2.1 Safety Symbols
2.2 Mandatory Personal Protective Equipment
2.3 Important Information
Illustration Safety Tool Description
DANGER DANGER Indicates a hazard with a high level of risk which, if
not avoided, could result in death or catastrophic
equipment damage.
WARNING WARNING Indicates a hazard with a medium level of risk
which, if not avoided, could result in serious or
moderate injury, or serious equipment damage.
CAUTION CAUTION Indicates a hazard with a low level of risk which, if
not avoided, could result in moderate or minor
injury, or moderate equipment damage.
NOTICE NOTICE Indicates important information for the user.
Table 2-1: Safety Symbols
Mandatory Personal Protective Equipment Description
Use the following personal protective equipment:
• Protecting Gloves
• Safety Vest
• Safety Shoes
• Safety Goggles
• Hard Hat
• Ear Plugs
• Safety Shield
Table 2-2: Personal Protective Equipment
DANGER
PERSONNEL INJURY
The equipment supplied can cause serious personnel injury or death if mishandled or
misused. Extreme caution must be exercised during the handling and operation of the
equipment.
DANGER
TOXIC VAPOURS FROM PUMPAGE
Appropriate risk assessment must be made regarding the nature of the product in the
pump and necessary safety precautions put in place to protect from exposure to product
vapours.

5 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
5 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
5 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps Safety
Document Name: 2001299-VTP-IOM-EN Page 5 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
DANGER
RISK ASSESSMENT
A comprehensive risk assessment of the installation site, pump equipment, and pumping
system must be completed prior to receiving the equipment. The risk assessment should
include but is not limited to the following: lifting procedures, pump equipment, system
piping, system valving, system operation and readiness, containment of pressurized fluid,
intake structures, electrical systems, hazardous materials and conditions, lock-out-tag-out
procedures, start-up and shutdown procedures, potential for reverse flow and/or reverse
pump rotation, water hammer, safety considerations for all personnel and public, and site
security including preventing access to the pump intake structure.
DANGER
PUMP SIGNAGE AND ACCESS
Do not allow anyone near the suction or open discharge of the pump during operation.
Pumps can create strong forces that will pin individuals. It is highly recommended to post
signage and restrict access to the pump suction and/or intake structure to prevent serious
injury or death.
DANGER
LOCKOUT-TAGOUT (LOTO)
• Prior to allowing any checking, maintenance, or other work on the equipment, all
hazardous energy sources (for example, electrical, mechanical, hydraulic, pneumatic,
etc.) must be isolated using an appropriate lockout-tagout procedure.
•Ensure that the intake and discharge openings are totally isolated from all potentially
pressurized connections and that they are, and can only be exposed to atmospheric
pressure.
• Drain the pump and isolate pipework before dismantling the pump. The appropriate
safety precautions must be taken when the pumped liquids are hazardous.
• Failure to follow appropriate LOTO procedures may result in serious personal injury or
death.
DANGER
GUARDS
Contact with rotating equipment can result in serious injury. Appropriate guards must be
installed at all times during operation. Any procedures requiring the removal of the
equipment guards must be performed by qualified personnel trained to perform such work.
DANGER
PERSONNEL INJURY FROM FALLS
Working at height may be required when working on equipment (for example, when
adjusting the impellers with a hollow shaft driver). Always wear appropriate PPE, such as a
safety harness and restraint system, when working at heights.

6 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
6 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
6 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps Safety
Document Name: 2001299-VTP-IOM-EN Page 6 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
DANGER
VAPORIZATION
• Do not operate the pump at low or zero flow conditions, or under any circumstances that
causes the pumped liquid to vaporize.
• Personnel injury and equipment damage could result from the high temperature and
pressures created if the pumping liquid vaporizes.
•Low or zero flow conditions must be avoided under any circumstances for any significant
period of time (more than 1 minute) due to the risk of heat/vaporisation of pumped fluid in
the casing that may cause subsequent explosion.
DANGER
THERMAL SHOCK
Do not feed very hot liquid into a cold pump or very cold liquid into a hot pump. Thermal
shock may cause damage to the internal components and rupture the pump casing.
DANGER
LIFTING DEVICE SAFETY
• Lifting devices of adequate capacity must be used whenever they are required.
• Safe workshop practices must be applied during all assembly and maintenance work.
• Personnel must never work under suspended loads.
DANGER
DANGER
Unapproved parts, unapproved pump construction, and misapplication (for example, foot
valves, non-OEM parts, worn/damaged/corroded/obsolete parts, mis-assembly, excess
pressure, unapproved fluids, etc.) may result in serious personal injury or death. Only use
supplied equipment for its intended purpose.
WARNING
SHARP EDGES
• Before handling, identify work parts that could be hazardous due to sharp edges. All
metal components must be considered to have sharp edges.
• Pump components can have sharp or jagged edges. Handle parts carefully, to prevent
damage to slings or personal injury.

7 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
7 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
7 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps Safety
Document Name: 2001299-VTP-IOM-EN Page 7 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
2.4 Intended Use
Vertical turbine pumps are built in a variety of designs and materials and for many applications/services. The
manufacturer’s IOM manual must be studied carefully and followed.
For the safety of operating personnel, note that the information contained in this manual applies only to the
fitting of genuine Floway parts and recommended spares.
If the conditions of service on the purchase order are going to be changed (for example liquid pumped,
temperature or duty), it is requested that the user seek the manufacturer’s written agreement before start-up.
2.5 Qualified Workers
All personnel involved in the assembly, installation, operation, maintenance, inspection, and
decommissioning of pump equipment must be qualified to carry out the work involved. If the personnel in
question do not already possess the necessary knowledge and skill, appropriate training and instruction must
be provided.
If required, the operator may engage the manufacturer/supplier to provide applicable training.
Always coordinate repair activities with operations and workplace health and safety personnel, and follow all
plant safety requirements and applicable workplace health and safety laws and regulations.
DANGER
GENUINE OEM PARTS
• Genuine OEM parts and accessories are designed, tested and incorporated into the
products to help ensure they maintain continued product quality and performance in use.
•As Trillium Pumps USA does not test the parts and accessories sourced from other
vendors, the installation of such parts and accessories may adversely affect the
performance and safety features of the products.
• The failure to properly select, install or use authorized parts and accessories is
considered misuse. Damage or failure caused by misuse is not covered by our warranty.
• In addition, any modification of Trillium Pumps USA products or removal of original
components may impair the safety of these products in their use.
WARNING
SERIOUS PERSONAL INJURY AND EQUIPMENT DAMAGE
• Pump units must only be used for their intended purpose. Refer to the Certified Outline
Drawing and other contract documents for construction and application details.
• The pumps must not be operated beyond their design MAWPs (suction and discharge
sides), temperature limits and speed limits specified for the application. These limits are
dependent on the pump type, configuration and materials used. If there is any doubt
about the suitability of the product for the intended application, contact Trillium Pumps
USA , referencing the serial number.

8 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
8 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
8 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps Safety
Document Name: 2001299-VTP-IOM-EN Page 8 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
2.6 Markings and Approvals
It is a legal requirement that machinery and equipment put into service within certain regions of the world
must conform to the applicable marking directives and standards such as CE marking directives covering
machinery and, where applicable, low-voltage equipment, EMC, PED, and ATEX.
Where applicable, the directives and any additional approvals cover important workplace health and safety
aspects relating to machinery and equipment and the satisfactory provision of technical documents and
workplace health and safety instructions.
To confirm the applying approvals, and if the product is CE marked, check the serial number plate markings
and the certification.
2.7 Safety Equipment for the Pump
Do not operate the pump without properly installed seal and coupling guards in place. If guards are removed
during maintenance or gland adjustment, they must be replaced prior to operating the pump.
For auxiliary equipment, standard workplace health and safety precautions must be followed and appropriate
instruction manuals consulted before and during installation, operation, adjustment, and maintenance.
2.8 Fire Fighting
A number of possible emissions or leakage of hazardous substances may be possible depending on the
product being pumped. Ensure you are familiar with site and local procedures and requirements.
2.9 Emergency Procedures
Ensure you are familiar with site and local procedures and requirements. If there is an emergency, follow site
and local procedures.
WARNING
EXPLOSIVE ATMOSPHERES
Prior to installing any equipment, determine the hazardous area classification and any
other requirements applicable to the specific location and confirm all equipment has the
required certifications.
WARNING
ROTATING PARTS
Personnel injury or illness may result from contact with rotating parts, seal leakage or spray
from the rotating shaft.
WARNING
GLAND ADJUSTMENT
During gland seal adjustment the fixed guard needs to be removed while the pump is
operational. When the guard is removed, the rotating shaft is exposed. Additional safety
management measures must be implemented to manage this specific hazard and only
suitable trained and qualified personnel must work on gland adjustment. The guard must
be replaced when adjustment is complete.

9 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
9 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
9 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps General Information and Description
Document Name: 2001299-VTP-IOM-EN Page 9 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
3 General Information and Description
3.1 General Information
Floway Pump's standard practice is to ship close coupled pumps assembled. Where long pump lengths,
shipping limitations, handling limitations and headroom limitations prevent complete assembly, we will ship
the pump sub-assembled. It is the responsibility of the installer to ask for assistance should it be required to
properly assemble and install the pump.
The duration of satisfactory service obtained from the equipment, in part, depends on proper installation and
maintenance.
This instruction manual provides basic guidelines for installation, operations and maintenance of the
equipment and other safety precautions required for personnel. Due to the many variations and custom
designed units it is impossible to cover every design variation or contingency which may arise. However, the
basic information contained herein will answer most questions.
3.2 Identification
• Should questions arise concerning the pump equipment, the complete pump serial number will be
required for identification. The pump serial number is stamped on metal nameplates affixed to the
discharge head and bowl assemblies.
•The driver has a separate nameplate attached to it.
•When requesting information on the driver, both the driver serial number and pump serial number must
be provided.
3.3 General Description
The major components of vertical turbine pumps include:
• Driver
• Discharge Head Assembly
• Column Assembly (when used)
• Bowl Assembly (with strainer as applicable)
• Suction Vessel (when used)

10 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
10 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
10 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps General Information and Description
Document Name: 2001299-VTP-IOM-EN Page 10 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
Refer to Figure 3-1 for one possible variant. Pumps less than 30 feet in length are typically shipped fully
assembled and ready for installation. The drivers, couplings and strainers (when used) are shipped
separately to prevent damage.
Figure 3-1: Major VTP Components
1
2
3
4
5
1. Driver (electric driver
illustrated)
2. Discharge Head Assembly
3. Column Assembly
4. Bowl Assembly
5. Strainer

11 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
11 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
11 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps General Information and Description
Document Name: 2001299-VTP-IOM-EN Page 11 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
3.3.1 Drivers
A variety of drivers can be used; however, electric motors are most common. In this manual, electric motor
drivers are grouped into two categories:
1. Hollow Shaft Drivers: where the pump shaft extends through a tube in the center of the motor shaft and
is connected to the driver by a clutch assembly at the top of the driver.
2. Solid Shaft Drivers: where the motor shaft is solid and projects below the driver mounting base. This
type of driver requires an adjustable coupling to connect to the pump.
3.3.2 Discharge Head Assembly
• The discharge head supports the driver, column, and bowl assemblies in addition to providing a
discharge connection (the type VU discharge connection is located on one of the column pipe sections
below the discharge head).
•A shaft sealing arrangement is located in the discharge head to seal the rotating shaft where it passes
from the stationary housing (liquid chamber). Typically, the shaft seal is either a mechanical seal
assembly or a packing box.
3.3.3 Column Assemblies
Column assemblies are of two basic types, either of which can be used on vertical turbine pumps:
1. Open Lineshaft Construction: utilizes the liquid being pumped to lubricate the lineshaft bearings.
2. Enclosed Lineshaft Construction: has an enclosing tube around the lineshaft and utilizes oil, grease or
injected liquid (usually clean water) to lubricate the lineshaft bearings (not used on barrel pumps).
Column assemblies consist of the following:
• Column Pipe: which connects the bowl assembly to the discharge head and carries the pumped liquid
to the discharge head. Column pipe is either threaded or flanged.
•Shaft: which connects the bowl shaft to the driver; and may contain bearings if required for the
particular unit.
• Enclosing Tube (if applicable): surrounds the lineshaft to contain the supplied lubrication.
3.3.4 Bowl Assemblies
The bowl assembly consists of the following:
• Impellers rigidly mounted on the bowl shaft which rotate and impart energy to the fluid.
•Bowls to contain the increased pressure and direct the fluid.
• Suction bell or case which directs the fluid into the first stage impeller.
• Bearings located in the suction bell (or case) and each bowl.
A separate instruction manual is available which provides construction details and repair instructions for
Floway bowl assemblies.
3.3.5 Suction Vessel
The suction vessel may consist of a barrel with or without suction fitting, to connect to customers piping
arrangement, or a storage tank with suitable opening to mount the pump.
Whatever the arrangement may be, it must provide:
• Adequate support for the unit
•A means of supplying the pump with liquid
NOTICE
Some units do not require a column assembly, as the bowl assembly is connected directly
to the discharge head.

12 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
12 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
12 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps Pre-installation
Document Name: 2001299-VTP-IOM-EN Page 12 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
4 Pre-installation
4.1 Receiving and Unloading
When receiving the shipment, extreme care must be taken while unloading.
• Use a forklift or crane to unload the equipment.
• Do not drop the unit, or any parts, as damage can cause trouble in assembly and operation of the units.
• Inspect the unit for signs of transit damage before beginning to uncrate or placing in storage. If damage
is evident notify the local transporting company agent before uncrating and file a claim with the agent.
4.2 Storage
• If the unit is to be stored prior to installation, carefully select a storage space where the unit will not be
subjected to excess moisture, extreme weather conditions, corrosive fumes, or other harmful conditions.
• Carefully inspect the unit and clean the rust spots on the machined surfaces with a fine emery cloth.
• Coat machined surfaces with a rust preventative.
• Protect the pump from any dust, dirt, or debris from entering the unit. Wrap all openings with a heavy
gauge polyethylene and tape tightly to seal.
• If the unit is stored for a long period of time it should be periodically inspected and cleaned as required.
• Contact the factory for special long term storage (greater than 4 months) requirements for the unit
supplied.
DANGER
LIFTING DEVICE SAFETY
• Use mechanical lifting devices to lift heavy or awkward components.
• Lifting devices must be in good condition, certified, and tagged.
• Lifting devices of adequate capacity must be used whenever they are required.
• Personnel must never work under suspended loads.
DANGER
LIFTING POINT SAFETY
Check that the lifting lugs are in suitable condition for lifting, before lifting pump parts.
NOTICE
These provisions are applicable to Trillium Pumps USA pump components only. For
the appropriate storage procedures for non-Trillium items (for example, drivers, mechanical
seals, auxiliary equipment, etc.), refer to specific requirements from the manufacturer.

13 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
13 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
13 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps Pre-installation
Document Name: 2001299-VTP-IOM-EN Page 13 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
4.3 Uncrating and Cleaning
If the unit appears undamaged proceed to uncrate following the instructions given below:
• Clean all the parts of any dirt, packing material or other foreign matter.
•Flush the pump inside and outside with clean water or a fluid compatible with pumpage. If the pump is
for potable water, a lightly chlorinated flush may be recommended.
•Clean all machined surfaces as these are coated with a rust preventative before shipment, which must
be removed.
•Remove any rust spots found on the machined surfaces with a fine emery cloth.
•Clean all threaded connections and any accessory equipment.
4.4 Lifting
CAUTION
DEFLECTION OF THE PUMP
To prevent deflection of the pump components, take appropriate precaution to prevent the
weight of the pump from resting on the suction bell or case, when lifting to vertical position.
Refer to Figure 4-1 on page 15.
NOTICE
Parts and accessories may be placed inside shipping containers or attached to skids in
individual packages. Inspect all containers, crates and skids for attached parts before
discarding.
DANGER
LIFTING DEVICE SAFETY
• Use mechanical lifting devices to lift heavy or awkward components.
• Lifting devices must be in good condition, certified, and tagged.
• Lifting devices of adequate capacity must be used whenever they are required.
• Personnel must never work under suspended loads.
DANGER
LIFTING POINT SAFETY
Check that the lifting lugs are in suitable condition for lifting, before lifting pump parts.
WARNING
LIFTING EXPERIENCE
All lifting and rigging must be performed by qualified and experienced personnel who are
familiar with safe lifting practices and requirements. A lifting plan should be established and
followed to ensure safe lifting of all equipment.
WARNING
PERSONAL INJURY
To avoid personal injury, all components and assemblies greater than 30 lbs. (14 kg)
should be lifted using mechanical methods.

14 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
14 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
14 |IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps Pre-installation
Document Name: 2001299-VTP-IOM-EN Page 14 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
4.4.1 Lifting Pump Components and Pump Assemblies
Refer to the certified outline drawing for approximate pump assembly weights.
Pump components and assemblies must only be lifted from the appropriate locations. If there is any doubt
regarding proper lifting methods and locations, contact your nearest manufacturer’s representative.
• Cans/Barrels must be lifted using appropriate lifting devices attached to the mounting plate.
• Discharge heads are fitted with lifting lugs suitable to support the entire weight of the pump. Typically
two or more lifting lugs are supplied, a minimum two point lifting method is required (refer to Figure 4-2
on page 16 for fabricated heads and Figure 4-3 on page 16 for cast heads).
• Column and bowl assemblies must be lifted using an appropriate clamping fixture. The fixture must
positively lock to the item being lifted and have adequate strength to support the assembly’s weight. A
common fixture design employs beams and threaded rods that can be fastened around the assembly
(refer to Figure 4-4 on page 16). When clamping to threaded column, the upper column coupling must
be fully installed to provide a stop for the lifting clamp placed below the coupling. If the column is
supplied with optional lifting lugs, those may be used to lift the assembly.
Lift devices (straps, chains, etc.) attached to the pump must not exceed a 45 degree angle to the vertical
position. Exceeding this angle could overload the lifting location (refer to Figure 4-2 on page 16).
When lifting an assembled pump, it must be supported at minimally two locations. When lifting to the vertical
position, use the discharge head lifting lug locations to lift the pump assembly (refer to Figure 4-1 on page
15). For pump units over 40 ft in length, the pump shall be assembled during installation vertically in place
over the mounting location.
If the unit is supplied with a separate motor stand (that is, a component bolted between the driver and
discharge head), do not lift the entire pump unit from the motor stand. The motor stand lifting lugs are for
lifting the motor stand assembly only.
WARNING
LIFTING DRIVERS AND AUXILIARY EQUIPMENT
Refer to the manufacturer’s instruction manual for proper lifting techniques of all drivers
and auxiliary equipment. Driver lifting locations must only be used to lift the driver. Do not
use the driver lifting locations to lift the assembled pump and driver.
WARNING
PERSONAL INJURY AND EQUIPMENT DAMAGE
Never lift any assemble by the bowl shaft or lineshaft. This can result in damage to the
shaft and personal injury.
WARNING
PERSONNEL INJURY
• Clamping fixtures that do not positively lock to the assembly being lifted may come loose
and cause personal injury. Always ensure the clamping fixture is of an appropriate design
to support the load and has secure means to lock onto the assembly being lifted.
• Do not lift bowl assemblies by placing lifting devices through the flange bolt holes, the
cast bowl flange holes may break through and result in dropping the load and personal
injury.
