INSTALLATION GUIDE
ISSUE 9.1
TRILOGY COMMUNICATIONS LIMITED
26 Focus Way
Andover
Hampshire
SP10 5NY
United Kingdom
Telephone. [phone]
Fax. [phone]
www.trilogycomms.com
DIGITAL INTERCOM

The Copyright of the information and drawings in this
document is the property of Trilogy Communications Limited
of Andover, Hampshire and is neither to be reproduced in
whole or in part, nor disclosed to a third party, without the prior
written consent of Trilogy Communications Limited.
The information in this document has been carefully compiled
and checked for accuracy. However, Trilogy Communications
Limited accepts no responsibility for inaccuracies which may
occur and, further, reserves the right to make changes to
specification or design without prior notice.
Comments or correspondence concerning this manual should
be addressed to The Documentation Manager at the address
given at the front of this User Guide.
DOCUMENT NUMBER 50096601.doc ISSUE 9.1
Issue
Date
Reason for Change
Approved
7
29 July 2006
Panel range additions and general
updates
7a
05 August 2006
Draft submitted
8
27 November 2007
500-07-50 Connections added
9
18 November 2008
Changes to Beltpacks
9.1
20 October 2011
Updated panel wiring

Commander Installation Guide
Issue 9.1
Trilogy Communications Limited
Page 3 of 81
ERRATA SHEET
This sheet contains information regarding errors in this user guide.
Date
Description
-
None

Commander Installation Guide
Page 4 of 81
Issue 9.1
Trilogy Communications Limited
CONTENTS
1. INTRODUCTION..................................................................................................7
1.1 OPTIONS AVAILABLE AND MODULE TYPE NUMBERS........................................................ 7
2. INSTALLATION...................................................................................................9
2.1 INTRODUCTION ............................................................................................................ 9
2.2 UNPACKING ................................................................................................................. 9
2.3 RACK MOUNTING ......................................................................................................... 9
2.4 SYSTEM ASSEMBLY.................................................................................................... 10
2.4.1 500-08 Series Changeover Card ....................................................................... 11
2.4.2 500-02 Series Talkback Controller Card............................................................ 12
2.4.3 500-01 Series TDM Controller Card .................................................................. 13
2.4.4 500-25-00 E1 Network Link Card ...................................................................... 14
2.4.5 500-10 Series Misc. I/O (GPI) Cards. ................................................................ 14
2.4.6 500-06 Series Matrix Cards............................................................................... 15
2.5 MAINS CONNECTION AND FUSING ............................................................................... 16
2.5.1 500-15-30 series power supply.......................................................................... 16
2.5.2 Earthing Requirements...................................................................................... 16
2.6 STARTING THE SYSTEM............................................................................................... 17
3. CONNECTING TO THE MATRIX ......................................................................19
3.1 CONNECTING THE MATRIX PORTS ............................................................................... 19
3.2 CONNECTING THE PC TO THE COMMANDER SYSTEM.................................................... 19
3.2.1 Connection via a PC COM port using RS232 .................................................... 19
3.2.2 Connection via a 500-16-03 Download Converter Box ...................................... 20
3.3 INSTALLING PATHFINDER............................................................................................ 21
3.4 OTHER MATRIX CONNECTIONS ................................................................................... 23
3.4.1 Matrix Ports – RJ-45.......................................................................................... 23
3.4.2 Camera Connector ............................................................................................ 23
3.4.3 Serial Link (RS232 / RS422) ............................................................................. 24
3.4.4 Alarms............................................................................................................... 24
3.4.5 Miscellaneous I/O Card Connector Pin-Out ....................................................... 25
3.5 CONFIGURING THE GAIN OF CAMERA INPUTS. .............................................................. 30
3.5.1 Link setting on 500-06-02 .................................................................................. 30
4. NETWORKING ..................................................................................................31
4.1 CONNECTING NETWORKED SYSTEMS .......................................................................... 31
4.1.1 500-26 Network Rear Connector Unit (RCU)..................................................... 31
4.2 SERIAL NETWORKING ................................................................................................. 33

Commander Installation Guide
Issue 9.1
Trilogy Communications Limited
Page 5 of 81
5. CONTROL PANELS ..........................................................................................35
5.1 INTRODUCTION........................................................................................................... 35
5.2 CURRENT RANGE ....................................................................................................... 35
5.3 CONTROL PANEL FACILITY COMPARISON TABLE........................................................... 36
5.4 500-41-XX SERIES DESKTOP PANELS ......................................................................... 37
5.5 500-31-51 16 KEY PLUS DIAL PAD CONTROL PANEL ...................................................... 38
5.5.1 Specification ...................................................................................................... 38
5.5.2 500-3x-5x Series Standard Control Panel Rear View ........................................ 39
5.5.3 500-3x-5x Series Control Panel Connections .................................................... 39
5.5.4 500-3x-5x Series DIP Switch Settings ............................................................... 41
5.6 500-43-50 12 WAY ROTARY ENCODER EXPANSION PANEL ........................................... 42
5.6.1 Specification ...................................................................................................... 42
5.6.2 Rear Connector Layout ..................................................................................... 42
5.7 500-42-50 1U, 10 LEVER KEY PANEL WITH LED DISPLAYS. ........................................... 43
5.7.1 Specification ...................................................................................................... 43
5.7.2 Rear Connecor Layout ...................................................................................... 43
5.7.3 Connections ...................................................................................................... 43
5.8 CONTROL PANEL GPIO EXTERNAL CIRCUITRY............................................................. 45
5.9 500-31-60 STANDARD FACILITY 16 KEY CONTROL PANEL .............................................. 46
5.9.1 Specification ......................................................................................................
46
5.9.2 Rear Panel Layout............................................................................................. 46
5.10500-33-00 /500-45-00 /500-46-00 RANGE ................................................................ 48
5.10.1 Specification ...................................................................................................... 48
5.10.2 Connections ...................................................................................................... 48
6. COMMANDER PROGRAMMING KIT ...............................................................51
6.1 INTRODUCTION........................................................................................................... 51
6.2 TTPROG SOFTWARE................................................................................................... 51
6.2.1 Set-up Routine .................................................................................................. 51
6.2.2 Starting the programme..................................................................................... 52
6.2.3 Connecting the Hardware.................................................................................. 53
6.2.4 Completing the reprogram sequence................................................................. 53
6.3 PROGRAMMING WITH THE 500-16-03 DOWNLOAD CONVERTER..................................... 54
7. OTHER EQUIPMENT ........................................................................................55
7.1 BELTPACKS................................................................................................................ 55
7.2 TELEPHONE INTERFACES............................................................................................ 56
7.2.1 Telos ONE alignment ........................................................................................ 57
7.3 RT EQUIPMENT .......................................................................................................... 58
7.4 500-22-00 ICIS-1 ISDN INTERFACE............................................................................ 58
7.4.1 500-22-00 ICIS-1 ISDN Interface Connector Pin-Outs....................................... 58
7.5 500-23-00 ICIS-2 ISDN INTERFACE............................................................................ 60

Commander Installation Guide
Page 6 of 81
Issue 9.1
Trilogy Communications Limited
8. LEGACY HARDWARE ......................................................................................61
8.1 MATRIX CARDS .......................................................................................................... 61
8.1.1 Gain setting on 500-06-00 ................................................................................. 61
8.1.2 Gain setting on 500-06-01 ................................................................................. 62
8.2 POWER SUPPLIES ...................................................................................................... 62
8.3 MATRIX DOWNLOAD ................................................................................................... 62
8.3.1 Computer Operating Systems – Important Note ................................................ 62
8.3.2 Installing an ARCHIPEL Download Card in a P.C.............................................. 63
8.3.3 Installing a CardPort ISA to PCMCIA adaptor into a desktop PC....................... 64
8.3.4 Installing a Sundance SMT104 PCMCIA download card in a laptop computer. . 64
8.3.5 Black Box IC114A PCMCIA serial adaptor card. ............................................... 65
8.4 MATRIX PORTS –D9 .................................................................................................. 66
8.5 LEGACY CONTROL PANELS......................................................................................... 67
8.5.1 Legacy Control Panel Facility Comparison Table .............................................. 67
8.5.2 500-3x-3x Series Control Panels ....................................................................... 68
8.5.3 500-30 Series DIP Switch Settings.................................................................... 70
8.5.4 500-40-0x Series Expansion Panels.................................................................. 71
8.5.5 Connecting via structured cabling...................................................................... 74
8.5.6 500-39-30 / 31 1U 12 key Panel with loudspeaker............................................. 75
8.5.7 500-3x-5x Series Control Panels ....................................................................... 76
8.5.8 500-43-51 1U, 8 REN level control panel .......................................................... 76
9. SPECIFICATION ...............................................................................................77
9.1 GENERAL................................................................................................................... 77
9.2 MATRIX AUDIO SPECIFICATION (USING 500-06-02 MATRIX CARDS) ................................ 77
9.3 REAL TIME PERFORMANCE ......................................................................................... 77
9.4 PANELS ..................................................................................................................... 77
9.5 MISCELLANEOUS I/O CARD......................................................................................... 78
9.6 P.C. .......................................................................................................................... 78
10. CONTROL PANEL CONFIGURATION .............................................................79
10.1500-3X-5X SERIES INTERNAL PANEL SWITCH SETTINGS ............................................... 79
10.2500-41 DESKTOP PANEL INTERNAL SETTINGS ............................................................. 79
10.3500-31-60 –PROGRAMMING CUT SWITCH OPERATION.................................................. 80
10.3.1 Test function...................................................................................................... 80
11. 500-16-03 DOWNLOAD CONVERTER SUPPLEMENTARY INFORMATION..81
11.1SAFETY PRECAUTIONS ............................................................................................... 81
11.2TRANSPORTATION AND STORAGE................................................................................ 81
11.3MAINS CONNECTOR AND PLUG ................................................................................... 81
11.4FUSES....................................................................................................................... 81
11.5REMOVAL OF COVERS ................................................................................................ 81
11.6BAUD RATE ............................................................................................................... 81
11.7LOOP BACK TEST MODE .............................................................................................. 81

Commander Installation Guide
Issue 9.1
Trilogy Communications Limited
Page 7 of 81
1. INTRODUCTION
This manual provides installation information for the Commander Digital Intercom
system. Cabling and pin-out information is included for all of the Trilogy manufactured
items plus some commonly used third party equipment. Other information relating to the
hardware configuration will be useful if the system is upgraded or expanded in the future.
•Section 2covers the matrix assembly and installation, to the point where the matrix
may be powered
•Section 3 covers all of the cabling necessary to complete the installation.
•Section 4 provides information on connecting multiple matrices to form a network.
•Section 5 gives wiring details for the range of Trilogy control panels.
•Section 6 explains the Commander re-programming software, which may be used to
update hardware.
•Section 7 provides information on installing other equipment (e.g. telephones, radio
talkback).
•Section 8 provides information about hardware which is no longer supplied by
Trilogy with new systems.
•Section 9 gives the system specification for matrix hardware, control panels and the
configuration computer.
For further assistance please contact Trilogy Communications Technical Support
Department at the address given at the front of this document. You may also contact us
by e-mail at:
[email protected]
1.1 OPTIONS AVAILABLE AND MODULE TYPE NUMBERS
Please contact our Sales Department for a listing of the current module types.
Due to the nature of talkback systems, any given installation may have some custom
items. Trilogy Communications prides itself on its ability to tailor standard components to
meet specific requirements and is willing to discuss any other customisation as required.

Commander Installation Guide
Page 8 of 81
Issue 9.1
Trilogy Communications Limited

Commander Installation Guide
Issue 9.1
Trilogy Communications Limited
Page 9 of 81
2. INSTALLATION
2.1 INTRODUCTION
Follow the sequence below, step by step, to install the Commander matrix.
•Unpack the matrix
•Fit the matrix frame and power supplies into the equipment bay
•Load the modules into the matrix frame, in sequence
•Apply power to the system and check basic operation.
•Connect control panels and check operation with the supplied flash ram configuration.
•Set up the configuration PC.
2.2 UNPACKING
Carefully unpack the equipment from its transit material and check each item for signs of
damage.
Check the contents of the boxes against our despatch note and your original order to ensure
that you have received the correct parts.
In the event that the unit has been damaged or does not match your order, immediately
contact Trilogy Communications at the address given at the front of this guide.
2.3 RACK MOUNTING
The Central Matrix is built in multiples of 6U. The depth (excluding mating connectors) is
420mm. Control Panels are standard 19” rack mounting units; most panels are 2U although
a series of 1U panel are available and custom panels may be 3U or larger. The Power
Supply requires additional space – see Section 2.5 for further details.
It is most likely that a system contractor or Trilogy personnel will install the central matrix.
Suitable care should be taken with cooling and ventilation within the equipment bay. There
are a number of internal connections between racks of multiple rack systems. Refer to the
Technical Guide or Trilogy Communications for further details.
In a multi frame system, the ports are located as
follows:
Frame 6 Ports 481 - 576
Frame 5 Ports 385 - 480
Frame 4 Ports 289 - 384
Frame 3 Ports 193 - 288
Frame 2 Ports 97 - 192
Frame 1 Port 1 - 96

Commander Installation Guide
Page 10 of 81
Issue 9.1
Trilogy Communications Limited
2.4 SYSTEM ASSEMBLY
If the system is multi-frame (i.e. > 96 ports), it will be supplied with frame 1 at the bottom and
frames 2,3,4 etc. ascending from there. Some earlier systems were supplied with the frames
configured in descending order.
The system modules will normally be packed separately for transit. Carefully remove all of
the packing materials taking care to leave the modules in their anti-static protection for as
long as possible.
Module variants are indicated by the type suffix, e.g. 500-06-00. In general, there is
complete backward compatibility between all versions of the modules. Modules supplied as
part of a complete system are compatible and will have been system checked accordingly.
Identify the modules and fit them into the frame in the following order:
1. 500-08 Changeover Module. See section 2.4.1.
2. 500-02 Talkback Controller (main controller only) See section 2.4.2.
NOTE: Items 1 and 2 may be supplied pre-assembled. Check carefully!
3. 500-01 TDM Controller (main controller only). See section 2.4.3.
4. Optional 500-10 Misc. I/O (GPI) Modules. See section 2.4.5.
5. Optional 500-25 Network Cards. See section 2.4.4.
6. 500-06 Matrix Cards. See section 2.4.6.
The diagram below shows the correct location within each frame.
Please note the positions of the modules. Incorrect location of modules will
result in damage to the electronics.
If in doubt, contact Trilogy BEFORE switching on the power.
Matrix Cards
Main TDM Controller
Main Talkback Controller
Standby Talkback Controller
Standby TDM Controller
Matrix Cards 3 - 15
Changeover Module
