Triner Scale TS-700 Series Use and care manual

This document supplements the User’s Guide
www.trinerscale.com
Version 4.0
Calibration & Connectivity
TS-700 Series Digital Indicators
Full Function/Advanced Function Di
g
ital Indicator
TS-700 MS
TS-700 SS
TS-700 WB

Triner Scale & Mfg.Co., Inc.
8411 Hacks Cross Road
Olive Branch, MS 38654
[phone]
www.trinerscale.com
© 2013 Triner Scale. All rights reserved.

Calibration & Connectivity | TS-700 Series
1
Table of Contents
Specifications...................................................2
Load Cell Connections.....................................3
Serial Port Connections ...................................4
Calibrating a TS-700 Series Indicator...............6
Data Output Formats .....................................12
Error Codes ...................................................15
Factory Default Settings.................................16
!!!! CALIBRATION WARNING !!!!
Calibration AND inspection of calibration properties
is prohibited unless done so by
a qualified scale technician.
WARNING
The indicator has static sensitive
components.
Do not make any connections without
powering off the indicator.

Calibration & Connectivity | TS-700 Series
2
Specifications
TECHNICAL PARAMETERS
Resolution ...................... Display: 30,000
ADC................................ 2,000,000
Zero stability error ........... TK0 < 0.1μV//K
Span stability error .......... TKspn < ± 6 ppm//K
Sensitivity (internal)......... 0. 3 μV /d
Input voltage ................... -30~30mV DC
Excitation circuit.............. 5 VDC
Load Cell Max................. 8, 350Ω
AC power........................ AC100~250V
Operation temp ............... - 10 °C ~ + 40 °C
Operation humidity.......... ≤90% RH
Storage temp .................. - 40 °C ~ + 70 °C
NTEP CLASS III.............COC# 09-080
KEYPAD KEYS FUNCTIONS
*requires adjustment of parameter settings
Hold Hold weight on scale, or Hold peak weight*,
or Hold unstable/animal weight*
Total Total Weight: total of multiple weighings
Kg/lb Display weight in pounds or kilograms
Gross/
Tare
Tare container weight, display gross or net
weight
Zero Returns the indicated weight to “0”
Print Prints receipt (requires optional printer)
PC connectivity (requires PC software)

Calibration & Connectivity | TS-700 Series
3
Load Cell Connections
The indicator can connect with a maximum of
eight (8) 350Ωload cells, 4 wire or 6 wire
configurations.
Excitation voltage for the load cell is 5VDC, the
maximum output current is 120mA.
TS-700MS/WB Load Quick-Connect Pins
TS-700 SS Load Cell Terminal Block

Calibration & Connectivity | TS-700 Series
4
Serial Port Connection
RS232 CONNECTION
TS-700 MS
The RS232 DB9 serial port can be utilized to
connect the indicator to a peripheral device such
as a printer or remote display, or to interface the
indicator with a PC.
NOTE: PC interface requires Triner DataLog
PC™ software to be installed on the PC.
Indicator to PC Connection

Calibration & Connectivity | TS-700 Series
5
TS-700 SS
The 3-wire terminal block located on the main
board can be utilized to connect the indicator to
a peripheral device such as a printer or remote
display, or to interface the indicator with a PC.
NOTE: PC interface requires Triner DataLog
PC™ software to be installed on the PC.
TS-700 SS RS-232 Terminal Block
TS-700 WB
The RS232 3-pin quick-connect serial port can
be utilized to connect the indicator to a
peripheral device such as a printer or remote
display, or to interface the indicator with a PC.
NOTE: PC interface requires Triner DataLog
PC™ software to be installed on the PC.

Calibration & Connectivity | TS-700 Series
6
Calibrating a TS-700 Series Indicator
NOTICE: The TS-700 SS/MS/WB are
NTEP Class III Legal for Trade approved
and certified. Unlocking the calibration
parameters is not allowed by persons
other than qualified scale technicians.
ALL MODELS: Place the Indicator in
Calibration Mode and Determine if the
Calibration Parameters are Accessible
1) Power on the indicator.
2) Press the PRINT and HOLD keys. “C” will
display. Release the keys.
3) If the calibration parameters are accessible,
“C01” will display, with the 1 flashing. Proceed
to page 8, “CALIBRATION PROCEDURE”.
NOTE: If C08 Displays instead of C01, the
calibration switch must be adjusted. Disconnect
the AC adapter and power off the indicator.
DEFAULT SETTINGS CAUTION
Placing the indicator in calibration mode enables
access to the Default Settings Parameter, CO7.
NEVER activate Parameter C07 unless you are a
qualified scale technician,and:
A) You understand that all custom settings will be
deleted permanently, and
B) You understand how to restore all custom
parameters to the required settings based on the
scale’s specifications and usage.

Calibration & Connectivity | TS-700 Series
7
Calibration Switch, TS-700 MS: Remove the
screws and the back plate of the enclosure. A
white-capped calibration switch is located at the
bottom left corner of the circuit board. Press the
switch fully in and release. This will place the
switch in the up position, allowing access to the
calibration parameters. Loosely reattach the
rear plate.
Calibration Switch, TS-700 SS: Remove the
screws and the back plate of the enclosure. A
calibration switch is located at the bottom left
corner of the circuit board. Move the switch to
the “On” position, allowing access to the
calibration parameters. Loosely reattach the
rear plate.
Calibration Switch, TS-700 WB: Disconnect all
cables and cords. To remove the back plate of
the enclosure, place the indicator upside down
(not face down) on a work surface. Locate the
two slotted holes near the connection sockets.
Insert a flat blade screwdriver into each slot
(one at a time), pushing the blade inward while
angled towards the back of the indicator. This
will release the retaining prong and enable
removal of the back plate. Carefully lift the rear
plate.
A white-capped calibration switch is located at
the bottom left corner of the circuit board. Press
the switch fully in and release. This will place
the switch in the up position, allowing access to
the calibration parameters. Loosely reattach the
rear plate.
ALL MODELS: After enabling access to

Calibration & Connectivity | TS-700 Series
8
calibration parameters, proceed as follows:
CALIBRATION PROCEDURE
1) Power on the indicator.
2) Press the PRINT and HOLD keys. “C” will
display. Release the keys.
3) “C01” will display, with the 1 flashing. The
indicator is now is Parameter Settings mode.
Navigating in Settings Mode
When the indicator is in settings mode, refer to
the graphic printed below the key to determine
the keypad key’s function.
The and arrow keys are used to
increase/decrease the value of the flashing digit,
or to navigate up and down a list of preset
options.
The and arrow keys are used to move the
active digit over to the left or to the right.
The key and key can be used to move
forward or backward through the parameters.
Also, the key is used to enter/accept
changes after they have been made to the
parameter settings.
The key can be used to exit settings mode.
With the indicator in settings mode and the
calibration weight nearby, proceed with the
calibration process while referring to the
following chart:
NOTE: After completing and verifying the
calibration, set the calibration switch to the “Off”
position and securely fasten the rear plate.

Calibration & Connectivity | TS-700 Series
9
PARAMETER FUNCTION OPTIONS
C01
Default weighing unit 1 = kg 2 = lb
Description:
With C01 flashing, press the
key, then use the up or
down arrow keys to change
the parameter setting as
needed.
Press the key to accept
the setting and continue on
to the next parameter.
C02
Decimal location 0 = none 1 = one decimal place
2 = two decimal places
3 = three decimal places
Description:
With C02 flashing, press the
key, then use the up or
down arrow keys to change
the parameter setting as
needed.
Press the key to accept
the setting and continue on
to the next parameter.

Calibration & Connectivity | TS-700 Series
10
C03
Graduations 1 = one unit 2 = two units
5 = five units
10 = ten units
20 = twenty units
50 = fifty units
Description:
With C03 flashing, press the
key, then use the up or
down arrow keys to change
the parameter setting as
needed.
Press the key to accept
the setting and continue on
to the next parameter.
C04
Capacity Description:
With C04 flashing, press the
key, then use the left
and right arrow keys to
select the active digit, then
use the up and down keys to
adjust the digits to the
desired capacity, i.e.,
5,000.
Press the key to accept
the setting and continue on
to the next parameter.
C05
Zero Calibration 0 = skip zero calibration 1 = proceed with zero
calibration
Description:
With C05 flashing, press the
key, then use the up
arrow key to change the
parameter setting to 1.
Press the key to
proceed. The zero cal will
count down from 10.
Press the key to
proceed to the next
parameter.

Calibration & Connectivity | TS-700 Series
11
C06 Calibration 0 = skip calibration
1 = proceed with calibration
Description:
With C06 flashing, press the
key, then use the up
arrow key to change the
parameter setting to 1.
Press the key to
proceed. “Span” will briefly
display, then all digits will
display.
Load the weighing platform,
then adjust the displayed
digits to match the weight on
the platform, i.e, 4,000.
Press the key to
proceed. The indicator will
calibrate, then display
“CalEnd”.
PRESS THE KEY TO
ACCEPT THE
CALIBRATION AND EXIT
SETTINGS MODE.
CAUTION -- IMPORTANT NOTICE!!
After calibrating, be sure to exit settings mode
without activating parameter C07!
Parameter C07 is the parameter that can DELETE all
custom settings and reset the indicator to factory
settings.
C07
CAUTION!! FACTORY RESET…
Erases all
custom
settings!
0 = skip reset to factory
defaults
1 = proceed with reset to
defaults
Description:
To reset to factory defaults,
change the 0 setting to 1 and
press the key.

Calibration & Connectivity | TS-700 Series
12
Data Output Formats
REMOTE DISPLAY FORMAT
State A
Bits: 0,1,2
0 1 2
Decimal point
position
1 0 0 XXXXXX0
0 1 0 XXXXXXX
1 1 0 XXXXX-X
0 0 1 XXXX-XX
1 0 1 XXX-XXX
Bits: 3,4 Division
0 1 X1
1 0 X2
State B
BITS FUNCTION
Bits0 Gross = 0, net=1
Bits1 Symbol: positive = 0,negative =1
Bits2 Overload (or under zero)=1
Bits3 Dynamic = 1
Bits4 Unit: lb=0, kg=1
Bits5 Constant 1
Bits6 Constant 0

Calibration & Connectivity | TS-700 Series
13
State C
Bit2 Bit1 Bit0 unit
0 0 0 Kg or lb
0 0 1 g
0 1 0 t
Bit 3 printing=1
Bit 4 Extend
display=1
Bit 5 Constant
1
Bit 6 Constant
0
PC COMPUTER CONTINUOUS SENDING FORMAT
, , CR L
F
S 1 S 2 S 3 Data S 4
S1: Weight status:
ST = standstill
US = not standstill
OL = overload
S2: Weight mode:
GS = gross mode
NT = net mode
S3: Weight of positive and negative,
“+” or ” –“
S4: “kg” or “lb”
Data: Weight value, including decimal point
CR: Carriage return
LF: Line feed

Calibration & Connectivity | TS-700 Series
14
SERIAL INTERFACE RECEPTION COMMAND
RS232COM serial interface can receive simple
ASCII command.
Command word and role as follows:
Command Name Function
T TARE Save and clear tare
Z ZERO Zero gross weight
P PRINT Print the weight
R G.W/N.W Read gross weight or net weight
C Kg/lb Kg/lb conversion
G G.W Check gross weight at net weight mode
Data Format
Print Format
ID.NO...................004 (Serial No.)
Date:....................XX.XX. XX (yy.mm.dd)
Time:....................XX.XX.XX (hh.mm.ss)
GROSS................NNNNNN lb/kg
TARE...................NNNNNN lb/kg
NET .....................NNNNNN lb/kg

Calibration & Connectivity | TS-700 Series
15
Error Codes
ERROR CAUSE SOLUTION
uuuuuu
1. Overloaded condition.
2. Wrong connection at
load cell.
3. Load cell has quality
problem.
1. Reduce the weight.
2. Check load cell
connection
3. Inspect load cell.
Check the input and
output.
nnnnnn
1. Calibration is incorrect.
2. Bad connections.
3. Load cell has quality
problem.
1. Check scale is resisted
or not, foot is kept
level or not.
2. Check load cell
connection.
3. Check input and
output resistance of
load cell.
ERR1
Overweight calibration
error.
Incorrect weight input or
incorrect weight on
weighing platform.
1. Input weight correctly
during calibration.
2. Place correct weight
on weighing platform.
ERR2
Underweight calibration
error.
Incorrect weight input or
incorrect weight on
weighing platform.
The calibration weights
Minimum is 10% of
Max. cap.
Recommend 60%-
80% of Max. Cap.
ERR3
During calibration, the
input signal is negative. Check all connections.
Check load cell.
If connections and
load cell are okay,
PCB needs replacing.
ERR4 During calibration, the
signal is unstable. After the platform is
stable, start
calibration.
ERR5 Circuitry error Replace the PCB.

Calibration & Connectivity | TS-700 Series
16
Factory Default Settings
PARAMETER INSTRUCTION DEFAULT
C01 Calibration 1
C02 Decimal digits 0
C03 Resolution 1
C04 Max. capacity 10000
C05 Empty calibration 0
C06 Capacity calibration 0
C07 Restore default 0
C08 Warning tone 1
C09 Power-off automatically 0
C10 Power saving mode 0
C11 Hold function 0
C12 Disable kg/lb conversion 1
C13 Upper limit alarm 000000
C14 Under limit alarm 000000
C15 Inner code ----
C16 Date setting ----
C17 Time setting ----
C18 Serial interface data
output 0
C19 Serial interface Baud rate 3(9600)
C20 Zero manually 10
C21 Initial zero 10
C22 Zero tracking range 0

Calibration & Connectivity | TS-700 Series
17
C23 Zero tracking time 1
C24 Overload range 9
C25 Negative range 10
C26 Standstill time 1
C27 Standstill range 2
C28 Dynamic filter 0
C29 Noise filter 2
C30 Print format 0
C31 Analog signal options 1
C32 4~20mA testing 4
C33 Relay output setting 1
C34 Reserved 0
C35 Reserved 6
C36 Calibration location gravity 9.7936
C37 Destination gravity 9.7936
C38 Version No. check ----
C39 Reserved menu ----

Triner Scale & Manufacturing Co. Inc.
8411 Hacks Cross Road
Olive Branch, MS 38654
[phone]
www.trinerscale.com
