TRIOBIKE CARGO User manual

2 KIDS KIT INSTALLATION MANUAL
ENGLISH V 1.0
CARGO
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

a
b
c
d
X22
X14
1 1
3 3
3
4
5 5
6 6
6 6
4
2b b
2
2
2
2
2
2
2
3
front panel
rear panel
bottom panelleft
panel
left
extension
right
extension
right
panel
a a
cc
d d
PARTS AND PLACEMENT
X2
X8
X4
X2
X2
X4
X2
X2
X2
X2
1
2
3
4
20
16
5
6
45
60
20
70
All manuals and user guides at all-guidesbox.com

4
INSTALLING THE 2 KIDS KIT
1- Place and fix the front panel and the Abrackets using bolts #1 + washers + nuts on the
back side. The brackets have to stay on top of the panel.
2- Place the brackets Band C on the frame, then put the bottom panel over them. The
frame, panel and brackets holes have to match. Fix everything using bolts #3 + nuts and
washers on the back side.
top
top
bottom
bottom
5
All manuals and user guides at all-guidesbox.com

6
4- Place the rear panel and brackets Das shown in the picture, and fix them on the
extension panels using bolts #5 + washers + nuts. The brackets have to stay in front of the
panel.
INSTALLING THE 2 KIDS KIT
7
INSTALLING THE 2 KIDS KIT
3- Place the extension panels as shown in the picture. Fix them on the bottom of the
external hole of brackets Cwith bolts #4 + nuts and washers.
All manuals and user guides at all-guidesbox.com

8
5- Mount the side panels connecting them to all the brackets using bolts #2 + nuts.
INSTALLING THE 2 KIDS KIT
9
6- Mount the 2 kids seat backrest using 4x bolt #6: from the rear, insert the bolts in the
threaded holes placed on the back of the backrest.
INSTALLING THE 2 KIDS KIT
All manuals and user guides at all-guidesbox.com

7- Once placed correctly, the backrest should stay on its position.
8- Place 2x Velcro stripes on the bottom panel and under the bench legs. The stripes have
to be aligned with the bench legs.
10 11
INSTALLING THE 2 KIDS KIT INSTALLING THE 2 KIDS KIT
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

9- Fix the bench pushing it towards the bottom panel.
INSTALLING THE 2 KIDS KIT
12
All manuals and user guides at all-guidesbox.com

TRIOBIKE A/S
Vesterbrogade 149, 1620 Copenhagen V - Denmark
phone: [phone]
[email protected] | www.triobike.com
