Scott GENIUS 2023 User manual

2022 GENIUS / GENIUS ST | ENGLISH 1
|
2023 SCOT T
GENIUS/GENIUSST
M A N UA L

2022 GENIUS / GENIUS ST | ENGLISH 2
|
GENIUS / GENIUS ST
GEOMETRY & TECHNICAL DATA 03
HEADSET ADJUSTMENT 05
SETTING SAG 06
TWINLOC & TRACLOC 07
CABLE ROUTING 08
SPARE PARTS 10
MANUFACTURE’S GUARANTEE 12
LEGEND
T2
10Nm
TORQUE REQUIRED TORX TOOL SIZE
HEX TOOL SIZE
TORQUE AMOUNT
TASK DIFFICULTY
NO GREASE REQUIRED
GREASE REQUIRED
CARBON GREASE REQUIRED
THREADLOC REQUIRED
CONTENT
THE GENIUS/GENIUS ST SHOULD BE ADJUSTED EXACTLY TO THE RIDER FOR MAXIMUM SAFETY
AND RIDEABILITY.
Please contact your authorized SCOTT dealer for advice in order to avoid technical problems or any harm.
BEARING FIT REQUIRED

2022 GENIUS / GENIUS ST | ENGLISH 3
|
GENIUS / GENIUS ST
GEOMETRY & TECHNICAL DATA
MY23 GENIUS/ST SM /ST MED /ST LG /ST XL /ST
AHead tube angle °65.1 63.9 65.1 63.9 65.1 63.9 65.1 63.9
BHead tube length mm 90 90 100 100 120 120 135 135
CTop tube horizontal mm 570.1 570.1 602.2 602.2 631.3 631.3 659.3 659.3
Dstandover height mm 728.5 728.5 738.5 738.5 753.5 753.5 768.5 768.5
EBB offset mm -33 -33 -33 -33 -33 -33 -33 -33
FBB height mm 342.5 342.5 342.5 342.5 342.5 342.5 342.5 342.5
G Wheelbase mm 1182 1195 1216 1229 1249 1263 1281 1294
IBB center to TST mm 380 380 410 410 440 440 470 470
JSeat angle ° 76.8 76.8 77.1 77.1 77.2 77.2 77.4 77.4
K Chainstay mm 440 440 440 440 440 440 440 440
L Reach mm 430 430 460 460 485 485 510 510
M Stack mm 617 617 626.1 626.1 644.2 644.2 657.8 657.8
Fork Rake mm 44 44 44 44 44 44 44 44
Trail mm 125.8 125.8 125.8 125.8 125.8 125.8 125.8 125.8
SEATPOST mm 31.6
SEATPOST CLAMP mm 34.9
TRAVEL mm 150 Rr 160 Ft
SHOCK LENGTH mm 185
SHOCK STROKE mm 55
HARDWARE M.FRAME mm Trunnion
HARDWARE LINKAGE mm 8 X 20
MAX ROTOR mm 180 Rr 203 Ft
MAX CHAINRING Tooth 34
MAX TYRE WIDTH in 2.6
MAIN PIVOT / CHAINSTAY mm 61802-2RS x 2
LINKAGE / SEATTUBE mm 61806-2RS x 2
LINKAGE / SEATSTAY mm 61802-2RS x 2
SEATSTAY / CHAINSTAY mm 61801-2RS x 4

2022 GENIUS / GENIUS ST | ENGLISH 4
|
GENIUS / GENIUS ST
GENIUS / GENIUS ST
GEOMETRY & TECHNICAL DATA CONT.
Please observe the maximum seatpost insertion
so not to damage the frame.
Small: 173 mm Max Insertion
Medium: 204 mm Max Insertion
Large: 234 mm Max Insertion
X-Large: 265 mm Max Insertion
Please note that on the small sized frame it
is only possible to use a 500 ml water bottle,
with a side entry cage.

2022 GENIUS / GENIUS ST | ENGLISH 5
|
GENIUS / GENIUS ST
It is important to install the headset correctly
depending on the set up required. There are
two types of headset cups.
0° & 0.6° ( 64° & 65°) These can be indentified
from the stamp on the inner surface of the
headset cup
The headset is available in two options:
288251 SYN HEADSET ZS56/28.6-ZS56/40 MTB
290060 SCO HEADSET CUP KIT SPARK 22
Do not use a standard headset tool
to remove these plastic headset
cups.
GENIUS / GENIUS ST
HEADSET ADJUSTMENT
Slacker
Steeper

2022 GENIUS / GENIUS ST | ENGLISH 6
|
GENIUS / GENIUS ST
GENIUS / GENIUS ST
SAG ADJUSTMENT
01 02
Wear your normal riding gear, set the
sage meter to zero & the twinloc in
the open position.
If the sag value is not to your liking
within the sag range indicated, adjust
the shock pressure as indicated above.
Gently sit on the bike allowing the
sag meter to move. Once completed
dismount the bike gently. Check the
value.
The sag indicator is available as a separate
part. Check with your Authorised Scott
Dealer for the correct installation.
297094 SCO SAG INDICATOR GENIUS 23

2022 GENIUS / GENIUS ST | ENGLISH 7
|
GENIUS / GENIUS ST
GENIUS / GENIUS ST
TWINLOC & TRACLOC
GENIUS NAME PART NO. CAM TYPE DROPPER
GENIUS 900 TWINLOC TSP3 290009 BLUE CAM YES
GENIUS 910 TWINLOC TSP3 290009 BLUE CAM YES
GENIUS 920 TWINLOC TSP3 290009 BLUE CAM YES
GENIUS 930 TWINLOC TSP3 290009 BLUE CAM YES
GENIUS 940 TWINLOC TSP3 290009 BLUE CAM YES
GENIUS ST
GENIUS ST 900 TRACLOC 291219 N/A YES
GENIUS ST 910 TRACLOC 291219 N/A YES
GENIUS ST 920 TRACLOC 291219 N/A YES
CONTESSA GENIUS
CONTESSA GENIUS
ST 910 TRACLOC 291219 N/A YES
CONTESSA GENIUS
920 TWINLOC 290009 BLUE CAM YES
The Genius Twinloc follows the same system as the Spark 2022.
The Genius ST is rear Tracloc only: 291219 BLD TRACLOC LINKIN 22

2022 GENIUS / GENIUS ST | ENGLISH 8
|
GENIUS / GENIUS ST
GENIUS / GENIUS ST
CABLE ROUTING
Rear Brake
Dropper Seatpost
For the alloy frames
there will be a
protective rubber
sleeve inside the
headtube for the
cables.
297134 SCO CABLE GUIDE H-TUBE INNER SCALE AL 23
Foam tubing: 277026 SCO CABLE ANTI-RATTLE LINER 90CM 20

2022 GENIUS / GENIUS ST | ENGLISH 9
|
GENIUS / GENIUS ST
GENIUS / GENIUS ST
CABLE ROUTING
Twinloc / Tracloc
Rear Derailleur

2022 GENIUS / GENIUS ST | ENGLISH 10
|
GENIUS / GENIUS ST
GENIUS / GENIUS ST
SPARE PARTS
297672 SCO CABLEGUIDE & BB COVER GENIUS 23
296606 SCO CHAINGUIDE GENIUS 23
296609 SCO AXLE RWS REAR 148X12 GENIUS PLUG 23
297673 SCO MAIN PIVOT SPARK 22 / LUMEN 23
296610 SCO SWINGARM REP KIT GENIUS 23
297086 SCO STEM ACCESSORY COVER COMBO 22
10Nm

2022 GENIUS / GENIUS ST | ENGLISH 11
|
GENIUS / GENIUS ST
GENIUS / GENIUS ST
SPARE PARTS CONT.
297522 SCO STEM SPACER/TOP CAP GENIUS 23
Spacers included: 2 x 5 mm / 2 x 10 mm / 2 x 2 mm
(Compression Ring & Stem Cap Assembly)
The kit fits all stem options, Hixon IC / Combo /
AM 1.5 / AM 2
419615 SCO GENIUS CARBON 23 CS / ST PROT
419616 SCO GENIUS ALLOY CS / ST PROTECTORS
297277 SCO CABLE / SHOCK DT COVER GENIUS 23
25Nm
286000 SCO DROPOUT SRAM UDH 21
297671 SCO DROPOUT SHIMANO UDH DM 23
Reverse Thread

2022 GENIUS / GENIUS ST | ENGLISH 12
|
MANUFACTURER’S GUARANTEE,
When purchasing a new SCOTT bicycle from an authorized SCOTT dealer, SCOTT grants a
manufacturer’s guarantee subject to the following provisions.
CONDITIONS
The manufacturer’s guarantee is only granted to the first-time buyer of a SCOTT bicycle who has
purchased it from an authorized SCOTT dealer. The manufacturer’s guarantee only applies if the
bicycle is registered to the first buyer at www.scott-sports.com within ten days of purchase.
DURATION
The manufacturer’s guarantee is granted from the date of purchase for a period of five years on
bicycle frames and rear ends. The guarantee period is reduced to three years, if the SCOTT bicycle
is not serviced at least once a year by an authorized SCOTT dealer. Maintenance services must be
carried out in accordance with the maintenance instructions in the SCOTT manual and must be
confirmed there by the stamp and signature of the authorized SCOTT dealer.
For frames and rear ends of Category 5 bicycle models and for rigid forks manufactured by
SCOTT, the duration of the manufacturer’s guarantee is limited to two years.
If a defect on the SCOTT bicycle is remedied within the scope of a manufacturer’s guarantee or a
warranty claim, the duration of the manufacturer’s guarantee is not extended. The manufacturer’s
guarantee ends, when the first-time buyer transfers ownership of the SCOTT bicycle to a third
person.
ASSERTION
The manufacturer’s guarantee is provided by SCOTT Sports SA, Route du Crochet 11, 1762 Givisiez,
Switzerland. The buyer must inspect the SCOTT bicycle immediately after purchase and notify
his authorized SCOTT dealer at once in writing of any obvious defects. Hidden defects must be
reported immediately after their discovery. In the event of a guarantee claim, the SCOTT bicycle
must be handed over to an authorized SCOTT dealer. The latter will contact SCOTT to remedy the
defect. The assertion of a guarantee claim always requires the presentation of the original proof
of purchase as well as the proof of maintenance service in the SCOTT manual.
Performance of SCOTT in the event of a guarantee claim
In the event of a guarantee claim, SCOTT will, at its own discretion, repair the defect or replace
the defective product with a product of similar quality, whereby colour and model deviations are
possible. If a repair or replacement is not possible, a purchase price refund will be made taking
into account previous use. SCOTT is entitled to commission third parties to remedy the defect.
LIMITATIONS
The manufacturer’s guarantee applies exclusively to frames, swingarms and rigid forks of SCOTT
bicycles. Bicycle components are excluded from this manufacturer’s guarantee.
The manufacturer’s guarantee does not apply to normal wear and tear, damage caused by
accidents or other excessive force on the SCOTT bicycle, corrosion, improper maintenance,
incorrect assembly and assembly of unsuitable components or accessories as well as cosmetic
defects, for example in the varnish.
The manufacturer’s guarantee does not apply to SCOTT bicycles that have been used in a rental
shop.
MISCELLANEOUS
These manufacturer’s guarantee provisions apply to all SCOTT bicycles as of model year 2023.
Statutory warranty rights of the buyer and guarantees of component manufacturers (Shimano,
SRAM etc.) remain unaffected by this
manufacturer’s guarantee.
The place of jurisdiction for all disputes in
connection with this manufacturer’s guarantee
is Freiburg, Switzerland. This manufacturer’s
guarantee is subject to Swiss law to the
exclusion of all legislation that refers to foreign
law.
