Triple S Ultron 18BA User manual

OWNER'S MANUAL
IMPORTANT: READ OWNER'S MANUAL CAREFULLY
MODEL
Ultron 18BA
8050905
REV.01(07-2018)

2SSS Ultron 18BA
OPERATOR MANUAL
READ OPERATOR MANUAL CAREFULLY!
Specifications and parts are subject to change without notice.
PROTECT THE ENVIRONMENT
Please dispose of packaging materials, old machine components
such as batteries, hazardous uids, including antifreeze and oil, in an
environmentally safe way according to local waste disposal regulations.
Always remember to recycle.
HOW TO ORDER PARTS
Please contact your local Triple S distributor, www.triple-s.com. Having the following
information available will be helpful:
• Machine model name
• Serial number from serial plate
• Part # and quantity (do not order by page number)

SSS Ultron 18BA 3
OPERATOR MANUAL
TABLE OF CONTENTS
SAFETY PRECAUTIONS......................................................................................................4
MACHINE COMPONENTS...................................................................................................5
MACHINE SETUP & INSTALLATION....................................................................................6
MACHINE OPERATION.................................................................................................7
TANK DRAINING..................................................................................................................8
BATTERY CHARGING.........................................................................................................8
PREVENTATIVE MAINTENANCE.......................................................................................9
BASIC TROUBLESHOOTING............................................................................................10
TECHNICAL SPECIFICATIONS..........................................................................................11
PARTS LIST...................................................................................................................12-26
WEARABLE PARTS...............................................................................................27
WIRING DIAGRAM.....................................................................................................28

4SSS Ultron 18BA
OPERATOR MANUAL
SAFETY PRECAUTIONS
This machine is intended for commercial use. It
is designed exclusively to scrub hard oors in an
indoor environment and is not constructed for any
other use. Only use recommended accessories.
All operators shall read, understand and exer-
cise the following safety precautions:
1. Do not operate machine:
-Unless trained and authorized.
-Unless you have read and understand the
operators manual.
-In ammable or explosive areas.
-If not in proper operating condition.
-In outdoors areas.
2. Before starting machine:
-Make sure all safety devices are in place
and operate properly.
3. When using machine:
-Go slow on inclines and slippery
surfaces.
-Follow all safety guidelines.
-Be very careful when using the machine in
reverse.
-Reduce speed when turning.
-Report and x any damage to machine prior
to operating it.
-Never allow children to play on or
around.
-Do not operate on inclines that exceed 5%
(3°).
4. Before leaving or servicing machine:
-Stop on level surface.
-Turn off machine.
5. When servicing machine:
-Read operators manual thoroughly prior to
operating or servicing this machine.
-Use manufacturer supplied or approved
replacement parts.
-Secure machine with wheel blocks prior to
jacking the machine up.
-Use approved jack or hoist to safely elevate
the machine.
-Disconnect batteries prior to working on
machine.
-Wear gloves when handling batteries or
battery cables.
-Avoid any contact with battery acid.
-Avoid moving parts. Do not wear loose tting
clothing while servicing machine.
WARNING: Batteries emit hydrogen
gas. Explosion or re can result from hy-
drogen gas. Keep sparks and open ames
away! Keep battery compartment open
when charging.
WARNING: Flammable materials can
cause an explosion or re. Do not use am-
mable materials in tanks.
WARNING: Flammable materials or
reactive metals can cause explosion or re.
Do not pick up.
WARING: Repairs are to be completed
by a Triple S Dealer. Any repairs completed by
unauthorized persons will avoid the warranty.

SSS Ultron 18BA 5
OPERATOR MANUAL
MACHINE COMPONENTS
1. Solution tank
2. Recovery tank
3. Clear cover, Recovery tank
4. Control handle bar
5. Battery meter
6. Vacuum motor switch
7. Brush motor switch
8. Circuit breaker
9. Clear cover, Battery charger
10. Drain hose
11. Clear tube, solution tank sight gauge
12. Squeegee lift lever
13. Vacuum hose
14. Squeegee assembly
15. Rear parking wheel
16. 8-inch wheels
2
1
34
5
6
7
8
9
10
12
13
14
15
16
11
17. Control trigger
18. Recovery tank support stand
19. Vacuum motor
20. Batteries
21. Solution tank ll-port
22. Pressure adjusting handle
23. Scrub head
24. Splash Guard
25. Motor hub lock pin
17 19
20
21
22
23
24
25
18

6SSS Ultron 18BA
OPERATOR MANUAL
UNCRATING MACHINE
Be sure and check packing carton for any damage.
Immediately report any damage to carrier. Check
the contents of package to ensure that the
following items are included:
• Machine
• Requires 2-12V Batteries
• Squeegee assembly
• Battery Charger
• Pad Driver or Brush
INSTALLING BATTERIES
The batteries are already in the machine upon
delivery; However you will need to connect the
cables to the battery posts.
WARNING: Batteries emit hydrogen gas.
Explosion or re can result from hydrogen
gas. Keep sparks and open ames away! Keep
battery compartment open when charging.
1. Turn off the machine.
2. Lift the Recovery tank (see machine
components, P5 item #2) to access the battery
compartment.
3. Carefully place the two batteries into the
compartment as shown in gure below.
DO NOT DROP BATTERIES INTO
COMPARTMENT!
4. Connect battery cables to posts as shown in
drawing below.
RED to POSITIVE and BLACK to NEGATIVE.
MACHINE SET UP
PRE-OPERATION CHECKS
1. Sweep or dust mop the surface to be cleaned.
2. Check battery meter to make sure batteries are
fully charged. (See BATTERY CHARGING).
3. Check that squeegee is properly installed.
4. Check that brush / pad is properly installed.
INSTALLING PAD DRIVER OR BRUSH
1. Ensure that the machine is turned off.
2. Lift the Squeegee lift lever (see machine
components, P5 item #12) to the upward
postion.
3. Lift the Scrub head (see machine components,
P5 item # 23) by pushing down the Control
handle bar (see machine components, item
4), while the Rear parking wheel (see mahcine
components, P5 item #15 ) will touch the oor.
4. If using a Pad Driver, rst attach the appropriate
pad to the pad driver surface.
5. Turn the brush motor hub until the slot with the
spring clip is visible through the scrub head
window.
6. Mount the pad driver or brush to the brush
motor hub by lining up the three studs with the
three holes in the brush motor hub. Once in the
holes, rotate the driver toward the spring clip to
lock the pad driver into place.
If necessary, press down on the Motor hub lock
pin (see machine componts, P5 item # 25) to
lock motor hub in place.
MOUNTING THE SQUEEGEE ASSEMBLY
1. Lift the Squeegee lift lever to the upward
position.
2. Mount the Squeegee assembly (see machine
components, P5 item #14) to the squeegee
pivot bracket. Make sure the knobs are
completely seated into the slots before securing
knobs.
3. Connect the vacuum hose to the squeegee
assembly. Loop the hose by using the hose clip
provided.
4. Check the squeegee blades for proper
adjustment.
MACHINE SET UP & INSTALLATION

SSS Ultron 18BA 7
OPERATOR MANUAL
FILLING THE SOLUTION TANK
The machine is equipped with a Solution ll-port
(see machine components, P5 item #21) at the
front of the Solution tank, you can ll the solution
tank by using a hose or a bucket.
Fill the solution tank to the "10-Gal" level on
the Solution tank sight gauge (see machine
components, P5 item #11). When using the bucket,
stop lling when the level reaches the bottom edge
of the ll-port.
NOTE: When lling the solution tank with a bucket,
make sure that the bucket is clean. Do not use the
same bucket for lling and draining the machine.
WARNING: Do not put any ammable
materials into solution tank. This can cause
an explosion or a re. Only use recommended
cleaning chemicals. Contact your Triple S
Dealer for recommendations on proper
chemicals.
WARNING: Do not operate machine un-
less you have read and understand this manu-
al.
1. Lower the Squeegee assembly to the oor by
lowering the Squeegee lift lever.
2. Lower the Scrub head to the oor by lifting
the Control handle bar, while the Rear parking
wheel will not touch the oor.
3. Turn on the Brush motor switch (see machine
components, P5 item #7), check the Battery
meter (see machine components, P5 item
#5), if the battery meter is in the red, DO NOT
continue to operate the machine and recharge
the batteries immediately.
4. Turn on the Vacuum motor switch (see machine
components, P5 item #6), and then the vacuum
motor will start work.
5. Pull the Control trigger (see machine
components, P5 item #17) backwards to start
scrubbing by moving the machine forward.
NOTE: The Brush motor will not work and
the solution will not ow until the control
trigger is pulled.
6. To stop scrubbing, release the Control trigger,
lift the Squeegee assembly and turn off the Vac-
uum motor switch, and then turn off the Brush
motor switch, lift the Scrub head.
WARNING: Fire or Explosion Hazard. Do
Not Pick Up Flammable Materials or Reactive
Metals.
1. Go slow on inclines and slippery surfaces. Do
not operate the machine on inclines that exceed
5% (3°).
2. Do not keep the machine in the same position
with pad / brush spinning, keep the machine
moving to prevent damage to oor nish.
3. If the squeegee assembly leaves streaks on the
oor, raise the squeegee off the oor and wipe
the blades down with a damp cloth. Pre-sweep
the area to prevent leaving streaks on the oor.
4. Pour a recommended defoamer into the
recovery tank if excessive foam appears.
WARNING: Do not allow foam to enter
the oat shut-off screen, vacuum motor dam-
age will result. Foam will not activate the oat
shut-off screen.
5. Occasionally check the Battery meter, the indi-
cator displays the level of the batteries. When
meter is in the red, stop scrubbing and recharge
the batteries.
6. When the solution tank runs empty, turn off
the Brush motor switch and lift the brush head.
Keep the squeegee down and continue to vacu-
um until all the dirty water is picked up.
NOTE: See TANK DRAINING section to learn
how to drain recovery and solution tanks.
MACHINE OPERATION
MACHINE OPERATION
Red Yellow 2 Yellow 1 Green 2 Green 1
All green lights on: 100% level.
Yellow lights on, green lights off : 50% level.
Red light on, other lights off: 20% level, the ma-
chine should be stopped and the batteries should
be recharged.
Red light ash: the batteries have already been
discharged deeply.

8SSS Ultron 18BA
OPERATOR MANUAL
1. Turn off the machine.
2. With the squeegee and scrub head in their "up"
position, transport machine to approved area for
draining tank(s).
DRAINING THE RECOVERY TANK
Any time scrubbing is completed, or when relling
solution tank, the recovery tank should be drained
and cleaned.
WARNING: If the recovery tank is not
drained when the solution tank has been re-
lled, foam or water may enter the oat shut-
off screen and cause damage to the vacuum
motor.
1. While holding the drain hose (see machine
components, P5 item #10) upward, remove the
cap and lower hose to drain.
2. Open the recovery tank cover and rinse out
the tank. Use a rag to remove any excess dirt.
Clean the oat shut-off screen and debris tray
located in the recovery tank .
DRAINING THE SOLUTION TANK
Any time scrubbing operation is completed, the
solution tank should be drained and cleaned.
1. Pull the solution clear tube (see machine
components, P5 item #11) off the hose tting,
this will allow the solution to ow freely into a
bucket or oor drain.
2. Remove the cover of the lter assembly to drain
the solution tank, check the lter screen and
clean up it if necessary.
3. Rinse the solution tank with clean water after
every use. This will help prevent chemical
buildup and clogging of the solution lines.
4. After rinsing out the tank, securely reconnect
the tank level hose to the hose tting, replace
the lter assembly cover and be sure the lter
screen and the "O" ring is in the correct position.
WARNING: Fire or Explosion Hazard.
Batteries Emit Hydrogen Gas. Keep Sparks and
Open Flame Away. Keep Battery Compartment
Propped Open When Charging.
1. Transport the machine to a well ventilated area.
2. Turn the machine off.
3. If charging wet, lead acid, batteries check the
uid level before charging.
4. Prop up the recovery tank onto the support
stand (see machine components, P5 item #18)
for ventilation.
5. Connect the charger's AC power supply cord to
a properly grounded receptacle.
6. The charger will automatically begin to charge,
you can watch the charging status on the
window (machine components, P5 item #9),
once the charging cycle begins, the indicator
lights will progress from red, yellow to green.
When the green indicator light comes on, the
charging cycle is done. Unplug the charger
cord.
NOTE: The machine will not operate when
charging.
BATTERY CHARGINGTANK DRAINING

SSS Ultron 18BA 9
OPERATOR MANUAL
WARNING: Before performing any main-
tenance on the machine, be sure that the power
is turned off, or the batteries are disconnected!
WARING: Repairs are to be completed by
a Triple S Dealer only. Any repairs completed
by unauthorized persons will void the warranty.
DAILY MAINTENANCE
1. Remove pad driver/ brush and clean with ap-
proved cleaner.
2. Drain recovery and solution tanks completely
and rinse out with clean water. Visually check
the recovery tank for debris and clean out as
necessary.
3. Raise the squeegee assembly off oor and wipe
it down with a damp towel. Be sure to store the
squeegee in the up position.
4. Remove the oat shut-off assembly and rinse it
out with clean water.
5. Clean machine with an approved cleaner and a
damp towel.
6. Recharge the batteries.
7. Check the condition of the squeegee blade
wiping edge, rotate blade if worn.
MONTHLY MAINTENANCE
1. Clean the battery tops to prevent corrosion.
2. Check for loose battery cable connections.
3. Inspect and clean the recovery tank cover seal.
Replace it if damaged.
4. Lubricate all grease points and pivot points with
silicon spray and approved grease.
5. Check the machine for loose nuts and bolts.
6. Check the machine for leaks.
MOTOR MAINTENANCE
1. Contact your Triple S Dealer for any motor
maintenance.
2. Motor should have the brushes checked every
250 hours. Brushes should be replaced when
they are worn to a length of 10 mm or less.
BATTERY MAINTENANCE
WARNING: Batteries emit hydrogen
gas and an explosion or re can result. Keep
sparks and re away from batteries at all times.
WARNING: Whenever servicing batteries,
be sure to wear protective gloves. Avoid con-
tact with battery acid at all times.
NOTE: For the best machine performance, keep
batteries properly charged at all times. Do not let
them sit in a discharged condition.
1. Always follow the battery charging directions as
outlined in the BATTERY CHARGING section of
this manual.
2. Keep battery tops and terminals free from corro-
sion. A strong solution of baking soda and water
is the best way to keep the batteries corrosion
free. DO NOT ALLOW THE BAKING SODA /
WATER SOLUTION TO ENTER THE BATTERY
CELLS.
3. Use a wire brush with the baking soda solution
to properly clean the battery posts and connec-
tions.
4. Check battery connections for wear and loose
terminals. Replace if necessary.
MACHINE STORAGE
1. Always store the machine indoors.
2. Always store the machine in a dry area.
3. Always store the machine in its upright position.
4. Always store the machine with the pad driver/
brush raised off the oor.
5. Always store the machine with the squeegee
assembly raised off the oor.
6. If storing in an area which may reach freezing
temperatures, be sure to drain all uids from the
machine prior to storage. Any damage caused
by freezing temperatures will not be covered by
the warranty.
7. Drain the recovery tank.
8. Drain the solution tank of all uid.
PREVENTATIVE MAINTENANCE

10 SSS Ultron 18BA
OPERATOR MANUAL
PROBLEM CAUSE SOLUTION
Machine will not
operate
Batteries need to be charged Charge batteries
Bad batteries Replace batteries
Loose battery cable Tighten loose cable
Brush motor will
not operate
Control handle trigger not pulled Pull control handle trigger
Tripped brush motor circuit breaker Reset brush circuit breaker button
Bad brush motor switch Replace brush motor switch
Bad brush motor solenoid Replace brush motor solenoid
Faulty brush motor or wiring Contact Triple S Dealer
Worn motor carbon brushes Contact Triple S Dealer
Vacuum motor
will not operate
Bad vacuum motor switch Replace vacuum motor switch
Bad vacuum motor relay Replace vacuum motor relay
Faulty vacuum motor or wiring Contact Triple S Dealer
Worn motor carbon brushes Contact Triple S Dealer
Little or no
solution ow
Ball valve is shut-off Turn on the ball valve
Clogged solution tank lter or solution
hose
Clean solution tank lter or ush out
solution hose
Clogged solution solenoid valve Remove valve and clean
Poor water pick
up
Recovery tank is full Drain recovery tank
Loose drain hose cap Tighten cap
Clogged oat shut-off screen located in
recovery tank Clean screen
Clogged squeegee assembly Clean squeegee assembly
Worn squeegee blades Replace or rotate squeegee blades
Incorrect squeegee blade deection Adjust squeegee blade height
Loose vacuum hose connections Secure hose connections
Clogged vacuum hose Remove clogged debris
Damaged vacuum hose Replace vacuum hose
Recovery tank lid not in place Properly position cover
Damaged recovery tank cover seal Replace seal
Faulty vacuum motor Contact Triple S Dealer
Low battery charge Recharge batteries
Short run time
Low battery charge Fully recharge batteries
Defective batteries Replace batteries
Batteries need maintenance See BATTERY MAINTENANCE
Faulty battery charger Repair or replace battery charger
BASIC TROUBLESHOOTING

SSS Ultron 18BA 11
OPERATOR MANUAL
TECHNICAL SPECIFICATIONS
Model Ultron 18BA
Voltage 24VDC
Recovery tank capacity 13 gal / 50 L
Solution tank capacity 10 gal / 40 L
Cleaning path width 18 in / 450 mm
Squeegee width 30 in / 762 mm
Drive system Brush Assisted
Pad/Brush pressure 55 lbs / 25 Kg
Brush motor 0.75 hp / 0.55 Kw
Brush speed 180 RPM
Vacuum motor 0.68 hp / 0.5 Kw
Water lift 45 in H2O
/ 1143 mm H2O
Batteries 2-12, 85AH @ 20 hr
Weight without batteries 145 lbs / 65 Kg
Weight with batteries 265 lbs / 120 Kg
Decibel rating at operator's ear, indoors 68dB(A)
Grade level, max 5% (3°)
Dimensions L × W × H 43.4 × 20.5 × 42.5 in
/ 1152 × 520 × 1080mm

12 SSS Ultron 18BA
PARTS LIST
RECOVERY TANK GROUP

SSS Ultron 18BA 13
PARTS LIST
RECOVERY TANK GROUP
DIA
NO.
PART
NUMBER DESCRIPTION NO. REQ'D
1 8050201-OR RECOVERY TANK 1
2 8131010 DRAIN HOSE 1
3 1962050 CLAMP 1
4 8111300 HINGE ASSEMBLY 2
5 1421612 FLAT WASHER M6×DIA12×1.6 12
6 1021616 HEX HEAD BOLT M6×16 10
7 8131020 CABLE 1
8 8132050 VACUUM MOTOR, 24VDC, 2-STAGE, KIT 1
9 1123608 LOCK NUT, M6 3
10 8011007 MUFFLER 1
11 8112006 STUD, M6×92 3
12 1121605 NUT, M6 3
13 8112005 GASKET, VACUUM MOTOR 1
14 8050112 LOGO, TRIPLE S 1
15 8111008 BRACKET 1
16 1421824 FLAT WASHER M8×DIA24×2.0 2
17 8111007 RECOVERY TANK SUPPORT 1
18 8115404 SLEEVE, P/M 1
19 1021830 HEX HEAD BOLT M8×30 1
20 8111015 FLOAT, SHUT-OFF 1
21 1321210 SCREW, SELF-TAPPING, ST4×10 6
22 2320220 ELBOW 1
23 1421409 FLAT WASHER M4×DIA9×0.8 4
24 2320217 RUBBER HINGE 1
25 2320218 GASKET 1
26 2320216 COVER, CLEAR 1

14 SSS Ultron 18BA
PARTS LIST
SOLUTION TANK GROUP

SSS Ultron 18BA 15
PARTS LIST
SOLUTION TANK GROUP
DIA
NO.
PART
NUMBER DESCRIPTION NO. REQ'D
1 8050101 SOLUTION TANK 1
2 8119100 FILTER ASSEMBLY 1
3 1421409 FLAT WASHER M4×DIA9×0.8 2
4 1221412 PAN HEAD SCREW M4×12 2
5 8016010 WHEEL SHAFT 1
6 1421824 FLAT WASHER M8×DIA24×2.0 3
7 1422821 LOCK WASHER, M8 5
8 1021820 HEX BOLT, M8×20 2
9 8115200 WHEEL, 8 INCH 2
10 1421828 FLAT WASHER M8×DIA28×2.0 3
11 1021816 HEX BOLT, M8×16 2
12 8115206 WHEEL CAP 2
13 1645324 COTTER PIN 1
14 8037015 PIN DIA12×70 1
15 8115004 SPRING 1
16 8037010 BRACKET, SQUEEGEE 1
17 8135001 PLASTIC WASHER, M8×DIA30×1.5 4
18 8115001 SQUEEGEE SUPPORT 1
19 1123115 LOCK NUT, M12 2
20 8114511 JOINT BEARING 1
21 1421618 FLAT WASHER M6×DIA18×1.6 8
22 1123608 LOCK NUT, M6 1
23 8115405 SLEEVEE, P/M 2
24 1421132 FLAT WASHER M12×DIA32×2.0 2
25 1021230 HEX BOLT, M12×30 2
26 1021616 HEX BOLT, M6×16 6
27 1422616 LOCK WASHER, M6 6
28 8037020 BRACKET, SQUEEGEE 1
29 8119007 ELBOW, G1/2 1
30 8119005 BALL VALVE, G1/2 1
31 1021830 HEX BOLT, M8×30 1
32 8013016 2 INCH CASTER 1
33 8034012 BRACKET, CASTER 1
34 1962025 CLAMP, 16-25MM 1

16 SSS Ultron 18BA
PARTS LIST
SOLUTION TANK GROUP
DIA
NO.
PART
NUMBER DESCRIPTION NO. REQ'D
35 8050105 CLEAR TUBING 1
36 8050130 CONNECTOR 1
37 8113009 NYLON, CLAMP 7
38 1421510 FLAT WASHER M5×DIA10×1 10
39 1221512 PAN HEAD SCREW M5×12 8
40 8013010 BATTERY, DISCOVER EV24A-A OR TROJAN 24TMX 2
41 8114751 JACKET, BATTERY TERMINAL, BLACK 4
42 8050476 BATTERY CONNECT CABLE, RED 1
43 8050475 BATTERY CONNECT CABLE, BLACK 3
44 1321310 SCREW, SELF-TAPPING, ST4.8×9.5 3
45 8050153 CHAIN 1
46 8050156 LID, SOLUTION TANK FILL PORT 1
47 8050150-BK LID, KIT 1
48 8050152 SEAL 1
49 6210107 FILTER 1
50 8013002 BRACKET 1

SSS Ultron 18BA 17
PARTS LIST
CONTROL CONSOLE GROUP

18 SSS Ultron 18BA
PARTS LIST
CONTROL CONSOLE GROUP
DIA
NO.
PART
NUMBER DESCRIPTION NO.
REQ'D
1 8050401 CONTROL CONSOLE HOUSING 1
2 8050420 PLATE, CONTROL PANEL 1
3 8050431 DECAL, CONTROL PANEL 1
4 1421510 FLAT WASHER M5×DIA10×1.0 16
5 1221512 PAN HEAD SCREW M5×12 9
6 8014063 BATTERY CAPACITY METER 1
7 8014006 ROCKER SWITCH 2
8 8014041 CLAMP 1
9 8014043 BUFFER 1
10 8114703 CIRCUIT BREAKER, 35A 1
11 2320403 CABLE GLAND 1
12 8014066 ON BOARD BATTERY CHARGER, KIT 1
13 1123406 LOCK NUT, M4 6
14 8112030 POWER CORD, BATTERY CHARGER 1
15 8134060 PLATE, BATTERY CHARGER 1
16 8134061 CLEAR COVER 1
17 1221306 PAN HEAD SCREW M3×6 2
18 1421409 FLAT WASHER M4×DIA9×0.8 6
19 1221412 PAN HEAD SCREW M4×12 6
20 1021630 HEX HEAD BOLT M6×30, SS 1
21 1421618 FLAT WASHER M6×DIA18×1.6 1
22 8050410 CABLE, SQUEEGEE LIFT 1
23 8014101 LIFTING ROPE SPACER 1
24 8034011 BAFFLE 1
25 1123608 LOCK NUT M6 1
26 8134501 BRACKET 1
27 1021512 HEX HEAD BOLT M5×12,SS 1
28 1421515 FLAT WASHER M5×DIA15×1.0 3
29 1421132 FLAT WASHER M12×DIA32×1.5 2
30 1121605 HEX NUT M6 1
31 8134081 SLEEVE 1
32 8134080 SQUEEGEE LIFTING HANDLE 1
33 8113104 BALL KNOB M8 1
34 1021840 HEX HEAD BOLT M8×40, SS 2

SSS Ultron 18BA 19
PARTS LIST
CONTROL CONSOLE GROUP
DIA
NO.
PART
NUMBER DESCRIPTION NO. REQ'D
35 1422821 LOCK WASHER M8 8
36 1421828 FLAT WASHER M8×DIA28×3 2
37 6210111 CLAMP, DRAIN HOSE 1
38 1221516 PH SCREW M5×16 7
39 8034013 WEIGHT 1
40 8114030 BRACKET, CONTROL CONSOLE 1
41 1421824 FLAT WASHER M8×DIA24×2 6
42 1021820 HEX BOLT M8×20 6
43 1221520 PH SCREW M5×20 2
44 1021320 SCREW M3×20 2
45 1434300 LOCK WASHER, TOOTH, M3 2
46 8114712 MICRO SWITCH 1
47 1123507 LOCK NUT M5 5
48 8014061 BRACKET, MICRO SWITCH 1
49 1123305 LOCK NUT M3 2
50 8014062 BRACKET, REAR PANEL 1
51 8114707 RELAY 1
52 8014035 SPRING 1
53 8014034 BRACKET, SPRING 1
54 8210421 RELAY 1
55 1534608 SET SCREW M6×8 4
56 8024022 TRIGGER 1
57 8014031 BUSHING, HEX 1
58 8014032 SPRING ROD 1
59 8014033 PLATE 1
60 1422411 LOCK WASHER, M4 2
61 8114101 SHAFT 1

20 SSS Ultron 18BA
PARTS LIST
SCRUB HEAD GROUP
