Tripp Lite P131-000-A-DISP User manual

1
Quick Start Guide
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2018 Tripp Lite. All rights reserved.
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
HDMI to VGA Adapter
with Audio
Model: P131-000-A-DISP
Español 5 • Français 9 • Русский 13
18-11-094-933881.indb 1 11/20/2018 9:15:57 AM

2
Product Features
Package Includes
Installation
• Connect your HDMI-enabled device to a VGA display with audio
• Supports resolutions up to 1920 x 1200 @ 60 Hz
• Bus-powered HDMI connection (USB Micro-B port included on unit in
the event additional power is needed)
• HDCP 1.4 and HDMI 1.4b compliant
• Plug-and-Play—no software or drivers to install
• HDMI to VGA Adapter with Audio
• USB Micro-B to USB-A Cable (1 ft.)
• 3.5 mm Stereo Audio Cable (1 ft.)
• Owner’s Manual
Note: Make sure all devices you are connecting are powered off prior to installation.
1. Connect an HDMI cable between the HDMI port on the adapter unit
and an HDMI source.
2. Connect the VGA male end of the adapter unit to the VGA display.
3. Connect a 3.5 mm audio cable between the 3.5 mm port on the unit
and the audio jack on your monitor or speakers.
4. Turn on the power to the connected devices. If you are not receiving
a signal after powering up, connect a USB cable between the Micro-B
port on the unit and the USB-A port on a USB charger or the HDMI
source.
18-11-094-933881.indb 2 11/20/2018 9:15:57 AM

3
Specifications
Warranty and Product Registration
3-YEAR LIMITED WARRANTY
TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period
of three (3) years from the date of initial purchase. TRIPP LITE’s obligation under this warranty is
limited to repairing or replacing (at its sole option) any such defective products. To obtain service
under this warranty, you must obtain a Returned Material Authorization (RMA) number from
TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to
TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and
must be accompanied by a brief description of the problem encountered and proof of date and
place of purchase. This warranty does not apply to equipment, which has been damaged by
accident, negligence or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid
limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically,
TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of
use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or
otherwise.
Connectors
Audio/Video Input HD15 (Male)
Video Output HDMI (Female)
Audio Output 3.5 mm (Female)
USB (Power) USB Micro-B (Female)
Environmental
Operating Temperature 32 to 104 °F (0 to 40 °C)
Storage Temperature -4 to 140 °F (-20 to 60 °C)
Relative Humidity 10% to 90%, Non-Condensing
18-11-094-933881.indb 3 11/20/2018 9:15:57 AM

4
Warranty and Product Registration
PRODUCT REGISTRATION
Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You’ll be
automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the
user’s authority to operate this equipment.
Use of this equipment in life support applications where failure of this equipment can reasonably
be expected to cause the failure of the life support equipment or to significantly affect its safety or
effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without
notice.
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
18-11-094-933881.indb 4 11/20/2018 9:15:57 AM

5
Guía de Inicio Rápido
1111 W. 35th Street, Chicago, IL 60609 EE UU • www.tripplite.com/support
Copyright © 2018 Tripp Lite. Todos los derechos reservados.
Adaptador de HDMI a
VGA con Audio
Modelo: P131-000-A-DISP
English 1 • Français 9 • Русский 13
18-11-094-933881.indb 5 11/20/2018 9:15:57 AM

6
Características del Producto
El Paquete Incluye
Instalación
• Conecte su dispositivo HDMI a una pantalla VGA con audio
• Suporta resoluciones de hasta 1920 x 1200 @ 60 Hz
• Conexión HDMI alimentada por bus (puerto USB Micro-B incluido en la
unidad en caso de necesitar alimentación adicional)
• Compatible con HDCP 1.4 y HDMI 1.4b
• Conectar y Usar—No requiere instalar programas ni controladores.
• Adaptador de HDMI a VGA con Audio
• Cable USB Micro-B a USB-A 30.5 cm [1 pie]
• Cable de audio estéreo de 3.5 mm de 30.5 cm [1 pie]
• Manual del Propietario
Nota: Asegúrese de que todos los dispositivos que esté conectando estén apagados
antes de la instalación.
1. Conecte un cable HDMI entre el puerto HDMI en la unidad
adaptadora y una fuente HDMI.
2. Conecte el extremo VGA macho de la unidad adaptadora a la pantalla
VGA.
3. Conecte un cable de audio de 3.5 mm entre el puerto de 3.5 mm en
la unidad y el enchufe de audio en el monitor o las bocinas.
4. Encienda los dispositivos conectados. Si no recibe una señal después
del encendido, conecte un cable USB entre el puerto Micro-B de la
unidad y el puerto USB-A un cargador USB o la fuente HDMI.
18-11-094-933881.indb 6 11/20/2018 9:15:57 AM

7
Especificaciones
Conectores
Entrada de Audio y Video HD15 (macho)
Salida de Video HDMI (Hembra)
Salida de Audio 3.5 mm (Hembra)
USB (Alimentación) USB Micro-B (Hembra)
Ambiental
Temperatura de Operación 0 °C a 40 °C [32 °F a 104 °F]
Temperatura de Almacenamiento -20 °C a 60 °C [-4 °F a 140 °F]
Humedad Relativa De 10% a 90%, Sin Condensación
18-11-094-933881.indb 7 11/20/2018 9:15:57 AM

8
Garantía
GARANTÍA LIMITADA DE 3 AÑOS
TRIPP LITE garantiza durante un período de tres (3) años a partir de la fecha de compra inicial que
este producto no tiene defectos de materiales ni de mano de obra. La obligación TRIPP LITE
bajo esta garantía está limitada a la reparación o reemplazo (A su entera discreción) de cualquier
producto defectuoso. Para obtener servicio bajo esta garantía, debe obtener un número de
Autorización de Devolución de Mercancía (RMA) de TRIPP LITE o de un centro de servicio
autorizado de TRIPP LITE. Los productos deben ser regresados a TRIPP LITE o a un centro de
servicio autorizado de TRIPP LITE con los cargos de transporte prepagados y deben acompañarse
con una breve descripción del problema y un comprobante de la fecha y el lugar de compra. Esta
garantía no se aplica a equipos que hayan sido dañados por accidente, negligencia o mal uso, o
hayan sido alterados o modificados de alguna manera.
EXCEPTO COMO SE INDICA EN EL PRESENTE, TRIPP LITE NO HACE GARANTÍAS EXPRESAS O
IMPLÍCITAS, INCLUIDAS GARANTÍAS DE COMERCIABILIDAD Y ADECUACIÓN PARA UN PROPÓSITO
PARTICULAR.
Algunos estados no permiten la limitación o exclusión de garantías implícitas; por lo tanto, las
limitaciones o exclusiones antes mencionadas pueden no aplicarse al comprador.
EXCEPTO COMO SE INDICA ANTERIORMENTE, EN NINGÚN CASO TRIPP LITE SERÁ RESPONSABLE
POR DAÑOS DIRECTOS, INDIRECTOS, ESPECIALES, INCIDENTALES O CONSECUENTES QUE
SURJAN DEL USO DE ESTE PRODUCTO, INCLUSO SI SE ADVIERTE SOBRE LA POSIBILIDAD DE
TAL DAÑO. Específicamente, TRIPP LITE no es responsable por ningún costo, como pérdida de
utilidades o ingresos, pérdida de equipos, pérdida del uso de equipos, pérdida de software,
pérdida de datos, costos de sustituciones, reclamaciones de terceros o de cualquier otra forma.
1111 W. 35th Street, Chicago, IL 60609 EE UU • www.tripplite.com/support
18-11-094-933881.indb 8 11/20/2018 9:15:58 AM

9
Guide de démarrage
rapide
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Droits d'auteur © 2018 Tripp Lite. Tous droits réservés.
Adaptateur de HDMI
à VGA avec audio
Modèle : P131-000-A-DISP
English 1 • Español 5 • Русский 13
18-11-094-933881.indb 9 11/20/2018 9:15:58 AM

10
Caractéristiques du produit
L'emballage inclut
Installation
• Raccorder l’appareil compatible HDMI à un écran VGA avec audio
• Prend en charge des résolutions jusqu'à 1 920 x 1 200 @ 60 Hz
• Connexion HDMI alimentée par bus (port USB Micro-B inclus sur
l'appareil si de l'alimentation supplémentaire est nécessaire)
• Compatible HDCP 1.4 et HDMI 1.4b
• Prêt à l'emploi; aucun logiciel ou lecteur à installer
• Adaptateur de HDMI à VGA avec audio
• Câble USB Micro-B à USB-A (0,3 m (1 pi))
• Câble audio stéréo de 3,5 mm (0,3 m (1 pi))
• Manuel de l'utilisateur
Remarque : S'assurer que tous les appareils à être raccordés sont hors tension
avant l'installation.
1. Raccorder un câble HDMI entre le port HDMI sur l’adaptateur et une
source HDMI.
2. Raccorder l’extrémité mâle VGA de l’adaptateur à l’écran VGA.
3. Raccorder un câble audio de 3,5 mm entre le port de 3,5 mm sur
l'appareil et la prise audio sur le moniteur ou les haut-parleurs.
4. Mettre les appareils connectés sous tension. S'il n'y a aucun signal
après la mise sous tension, raccorder un câble USB entre le port
Micro-B sur l'appareil et le port USB-A sur un chargeur USB ou la
source HDMI.
